Planet Toys Worldwide Limited 49 MHz Remote Control - TX Users Manual
users manual
MOTOR WORKS MINI RADIO CONTROL VEHICLE
START UP
1. Press the release button and REMOVE the clear DOME cover.
2. CAREFULLY LIFT OFF the PLASTIC blister SECURING THE CHARGING
UNIT and ANTENNA, AND REMOVE BOTH. CAREFULLY unscrew AND
REMOVE the vehicle from the PLASTIC blister. And the antenna is a "UNIQUE
COUPLING" and the antenna connection a unique connection.
3.Secure / THREAD the antenna IN THE ANTENNA HOLE LOCATED ON THE
CONTROLLER
4.Unscrew and REMOVE the battery COVERS on both the controller and THE charging
unit. INSERT 3 “AAA” batteries (not included) into each charger unit and 3 “AA”
batteries (not included) into controller of the battery compartments. Then REPLACE
the battery COVERS and tighten the screws.
CHARGING THE VEHICLE
1.Place the vehicle on TOP OF the charging unit HOLDER, GENTLY BUT FIRMLY
PUSH THE VEHICLE INTO POSITION ON THE HOLDER.
2.Press the charging button and the charging LED indicator will turn on INDICATING
THE VHICLE IS CHARGING. The LED indicator will turn off when the vehicle is
fully charged (approx. 45 seconds).
PLEASE NOTE: a). If the batteries inside the controller are low, the LED
light will become dim or NOT LIGHT UP AT ALL, AND YOU WILL
NOT BE ABLE TO CHARGE THE VEHICLE. PLEASE REPLACE
THE BATTERIES.
b). Make sure the BATTERIES HAVE BEEN INSERTED
CORRECTLY (+ OR - ) then preparing TO CHARGE THE VEHICLE.
c). Rechargeable batteries may getting hot and dangerous if being continuously
recharged.
OPERATING THE VEHICLE:
1).Fully extend the CONTROLLER ANTENNA.
2).Press the forward and reverse buttons to make the vehicle move FORWARDS AND
BACKWARDS. FOR LEFT AND RIGHT TURNING, press the left and right buttons
respectively. PLEASE NOTE, the vehicle will turn only when it is moving forwards or
backwards. ALSO NOTE, the operation light will turn on when the vehicle is in use.
3).Adjust the fine tune STEERING LEVER located under the vehicle to keep it moving
straight.
PLEASE NOTE: a)When operating the controller, please do not touch the antenna. As
control distance and the speed will both be EFFECTED (AFFECTED???).
b).If YOU NOTICE A REDUCTION IN SPEED AND CONTROL, PLEASE
BEGIN RE-CHARGING PER THE INSTRUCTIONS ABOVE.
{Rosie, this is also recommended to add the following Warning on the manual.}
WARNING: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate ratio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is needed
• Consult the dealer or an experienced radio/TV technician for help
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR
TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO
THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S
AUTHORITY TO OPERATE THE EQUIPMENT.
