Mini Bluetooth Headset
The Mini Bluetooth Headset is a Bluetooth device developed with the latest Bluetooth
technology, which can connect to other Bluetooth devices such as mobile phone,
desktop or notebook computer, PDA (with audio gateway profile supported) wirelessly.
Getting Started
Charging Battery
The Headset comes with a rechargeable battery included. The battery is
not fully charged when it is new. Plug the charging cable or adapter. The
red indicator on the headset will turn on as headset is charging.
When the battery is full, the red indicator will turn off.
B
Bl
lu
ue
et
to
oo
ot
th
h
V
V3
3.
.0
0
M
Mo
on
no
o
H
He
ea
ad
ds
se
et
t
B
BT
T-
-0
07
7H
HS
S
2/5
Turning the Headset On or Off
To turn the Headset on
Press and hold the SW1 button for 3 seconds, then the blue indicator
of the Headset flashes. The Headset is now turned on.
To turn the Headset off
Press and hold the SW1 button for 3 seconds, then the Red indicator
will flash, and then the Headset will turn off.
Pairing the Headset
You are required to pair the Headset with your mobile phone before
using the Headset.
Step 1 : The Headset must be powered off before initiating the
paring. Hold and keep pressing the SW1 button for 6 seconds until the
blue and the red indicators are flashing alternatively. The headset is
now ready for pairing.
Step 2 : Initiate pairing process on your Bluetooth mobile phone to pair
with the Headset. After search, you can find the device name “VH-2163”
Step 3 : When asked the Passkey by the mobile phone, enter 1234 and
confirm it.
When pairing is successful, the red indicator will turn off and the blue
indicator will flash.
Making Call
Using voice dialing
Press the SW1, waiting for a beep, and say the name of the person you
want to call.
Using the phone keys to make call
Dial the number on the mobile phone as you normally do. Once the call
has been set up, the sound will be transmitted to your Headset
automatically.
B
Bl
lu
ue
et
to
oo
ot
th
h
V
V3
3.
.0
0
M
Mo
on
no
o
H
He
ea
ad
ds
se
et
t
B
BT
T-
-0
07
7H
HS
S
3/5
Answering Calls and Ending Call
When the Headset is powered on, and there is an incoming call, you will
hear a ring tone. When the Headset rings, press the SW1 button to
answer.
Adjust the Headset volume by press the SW2 to increase the volume or
SW3 to decrease the volume.
End calls by pressing SW1 or don’t press any button.
Mute Press both SW2 and SW3 keys in the same time to enable Mute function,
To press both SW2 and SW3 in the same time again to disable Mute
function.
Transfer Audio
If you want to transfer the audio from headset to phone, press SW1 and
SW3 together.
Reject Call
When the headset ring and you do not want to answer this call. To press
SW2 and SW3 together to reject this call.
Multipoint
1. To do pair procedure to pair with mobile phone#1 and connect it
2. To do pair procedure again to pair with mobile phone#2 and connect
it.
3. Re-power on headset, the headset should connect to both mobile
phone.(If headset did not connect to mobile phone, please operate
Bluetooth setting of mobile phone to establish connection)
4. Now, you can use headset to pick up call for each mobile phone and
be able to switch by SW1 short press between each other. By pressing
both SW2 and SW3 to end the call.
Note : A2DP multipoint is only support on mobile phone.
B
Bl
lu
ue
et
to
oo
ot
th
h
V
V3
3.
.0
0
M
Mo
on
no
o
H
He
ea
ad
ds
se
et
t
B
BT
T-
-0
07
7H
HS
S
4/5
Low Battery
When the red indicator starts to flash, it indicates that the Headset is running low on
battery.
Charge the Headset until the red indicator turns off.
B
Bl
lu
ue
et
to
oo
ot
th
h
V
V3
3.
.0
0
M
Mo
on
no
o
H
He
ea
ad
ds
se
et
t
B
BT
T-
-0
07
7H
HS
S
5/5
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part responsible
for compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference that may cause
undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
