Plantronics M155 Bluetooth headset User Manual Manual
Plantronics Inc Bluetooth headset Manual
Manual
2 3 i
GET
STARTED
This version of the wordmark can only be
used at this size. It has a larger registration
mark than the other size wordmarks.
Please use one of the other sizes if you need
a larger version.
MARQUE™ M155
Bluetooth® Headset
DESIGNED IN SANTA CRUZ, CALIFORNIA
TIPS TO REMEMBER MYHEADSET™ APP
v
Listen to the voice (in English only)
Various status alerts include:
• Power on or off
• Remaining talk time
• Battery level
• Maximum volume reached
• Mute status
• Connected or lost connection (to phone)
Play tunes and take calls
Audio will automatically pause to allow you to answer or
ignore an incoming call. Once the call ends or is ignored,
the streaming audio resumes playback.
2-in-1 charging cable
Charge your headset and your smartphone at the same
time, using our custom cable.
© 2011 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark of Bluetooth SIG,
Inc. and any use by Plantronics is under license. All other trademarks are the property of their
respective owners. Patents US 5,712,453; D628188; Patents Pending.
(07-11) 85845-06 Rev A am85846-06 Printed in China
Download the MyHeadset App:
Our free MyHeadset app gives you tips, tricks and tools
for your Android 3.0 or iPhone. A quick download from
the Android marketplace or the Apple app store gets
you going.
• Sample your voice quality before a call
• Record a memo then email it
• Learn about A2DP audio streaming
• Check out product FAQs and user guide
Tel: 0800 410014
Tel: +44 (0)1793 842443*
Tel: +44 (0)1793 842443*
Tel: 80 88 46 10
Deutschland 0800 9323 400
Österreich 0800 242 500
Schweiz 0800 932 340
Tel: +44 (0)1793 842443*
Tel: 902 41 51 91
en
Tel: 80011336
Tel: +44 (0)1793 842443*
Tel: 0800 84 45 17
Tel: +44 (0)1793 842443*
Tel: +44 (0)1793 842443*
Tel: 0200 21 46 81
Tel: +44 (0)1793 842443*
Tel: 0800 117095
Tel: 0800 945770
Tel: 1800 551 896
Tel: +44 (0)1793 842443*
Tel: +44 (0)1793 842443*
Numero Verde: 800 950934
NL 0800 7526876
BE 0800 39202
LUX 800 24870
ar
cs
da
de
el
es
fi
fr
ga
he
hu
it
nl
no
pl
pt
ro
ru
sv
tr
*Support in English
plantronics.com
AE11
EEE Yönetmeliğine Uygundur
85846-06_M155_BlackBird_GSG.indd 1-1 13/07/2011 09:30
iviii
CONNECT TO YOUR PHONE
2
CONNECT TO YOUR PHONE
ii
NOTE See ‘For Your Safety’ booklet for important safety, charging, battery,
and regulatory information before you use this headset. This headset has an
embedded, non-replaceable battery.
Full user guide: plantronics.com/documentation.
Register your headset at plantronics.com/productregistration.
WARNING Always listen at moderate levels. See plantronics.com/
healthandsafety for more information on headsets and hearing.
POWER SWITCH
• On (slide to reveal green)
• Off (slide to conceal green)
MICRO USB CHARGING PORT
• Charge: 1 hour before first use
2 hours (for full charge)
VOLUME/MUTE BUTTON
• Volume presets (1 tap per level
change)
• Mute on/off (1-sec press during call)
INDICATOR LIGHT (LED)
• Low battery (3 red flashes at
powering on)
• Pairing mode (red/white flashes)
• Charging (solid red until charged)
CALL BUTTON
• Take a call (1 tap or say “Answer”)
• Reject a call (1-sec press or
say “Ignore”)
• Redial (2 taps)
• Initiate phone’s voice-dialing
(2-sec press)
• Reconnect lost connection (1 tap)
• Activate pairing mode after initial
set up (press until LED flashes
red/white)
TAKE A GOOD LOOK TAKE A GOOD LOOK FIND THE BEST FIT
C
A C
D
E
B
Congratulations! The product you have just purchased carries
the TCO Certified Headsets 2 certification. This means that
your headset is designed and manufactured according to
some of the strictest performance and environmental criteria
in the world.
Certified headsets are specifically designed for limiting the risk for hearing
impairment. The headsets have acoustic limit protection to protect the user
from sudden “sound-spikes” caused by interference on the telephone lines.
Other features of TCO certified headsets:
Ecology
•Designed for recycling, manufactured
under ISO 14001 certified
environmental management system.
Corporate Social Responsibility policy
promotes good labour relations and
working conditions. High efficiency
power supply and restrictions on:
– Chlorinated and brominated flame
retardants and polymers
– Halogenated and non-halogenated
substances
– Hazardous heavy metals such as cadmium,
mercury, hexavalent chromium and lead.
All TCO labelled products are verified and certified by TCO Development,
an independent third party labelling organisation. For more information visit
tcodevelopment.com and plantronics.com/tco
Ergonomics
•Volume control, individual
adjustment and adaptation,
replaceable parts, excellent
sound quality and durability.
Emissions
•Low SAR value. Low electrical
and magnetic fields.
TCO DEVELOPMENT
AB D
E
85846-06_M155_BlackBird_GSG.indd 3 13/07/2011 09:30
en
3
en
“Pairing” connects your headset to your phone. “Multipoint” lets you use this headset
with two phones.
READY
First time: Slide power switch to turn the headset on.
The LED flashes red/white to indicate pairing mode.
Pair new or 2nd phone: Turn on headset. Press Call button until LED flashes
red/white (pairing mode).
SET
Activate the Bluetooth feature on your phone, then use phone menus to
add/search/discover new Bluetooth devices.
iPhone: Settings > General > Bluetooth > On (starts the search for devices)
Android™: Settings > Wireless & networks > Bluetooth settings > Scan for devices
BlackBerry®: Settings/options > Bluetooth: On > Search for devices.
CONNECT
Select “PLT_M155” from the list of Bluetooth devices shown on your phone.
If phone asks for a passcode, enter four zeros (0000).
Headset LED will stop flashing red/white once successfully paired/connected.
Our free MyHeadset app gives you tips, tricks and tools for your Android 3.0 or
iPhone. Download it now from the Android marketplace or the Apple app store.
1
2
3
CONNECT TO YOUR PHONE
85846-06_M155_BlackBird_GSG.indd 3 13/07/2011 09:30
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
‧ This device may not cause harmful interference, and
‧ This device must accept any interference received, including interference that
may cause undesired operation.
‧
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the Federal Communications Commission (FCC)
rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
‧ Reorient or relocate the receiving antenna.
‧ Increase the separation between the equipment and receiver.
‧ Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
‧ Consult the dealer or an experienced radio/TV technician for help.
Note:
Any changes or modifications not expressly approved by the grantee of this device
could void the user's authority to operate the equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment, and must not be co-located or operating in conjunction with
any other antenna or transmitter.
Canada regulatory compliance
This device complies with Industry Canada licence-exempt RSS standard(s).
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of this device.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes: (1) il
ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à
accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de
compromettre le fonctionnement du dispositif.
