![](/img.php?id=1459614&img=bg1.png)
GET TALKING
IN MINUTES
M20™ and M50™
![](/img.php?id=1459614&img=bg2.png)
TAKE A GOOD LOOK
Your headset may look
slightly different than the
illustration, but will still
work as described.
MICRO USB CHARGING PORT
• Use with the AC wall charger:
1 hour before first use
2 hours (100% charge)
• Do not use headset while charging
VOLUME BUTTONS
• Volume presets (1 tap per level change)
LED
• Charging (solid red)
• Low battery (3 red flashes at powering on)
• Pairing mode (repeating red/blue flashes)
CALL BUTTON
• Take a call or end it (1 tap)
• Redial (2 taps)
• Initiate phone’s voice-dialing
(2-second press until tone is heard)
• Reconnect lost Bluetooth connection
(1 tap if the headset doesn’t automatically
reconnect)
• Activate pairing mode after initial set up
(press until red/blue LED flashes)
• Activate multipoint (2-second press
while switching on power)
POWER SWITCH
• On (slide to reveal black)
• Off (slide to reveal red)
![](/img.php?id=1459614&img=bg3.png)
CONNECT TO YOUR PHONE
“Pairing” is the set-up process of
introducing your headset to your
phone. Before using your headset
for the first time, you must pair it
with your Bluetooth-enabled phone.
"Multipoint" lets you pair this
headset with two phones so you
can answer a call from either phone.
You must activate multipoint before
pairing second phone.
PLT_M50
1. READY
Activate the Bluetooth feature on
your phone, then get phone to add
/ search / discover new Bluetooth
devices.
Phones Have Different Menus to
Select From:
iPhone: Settings > General >
Bluetooth > On (starts the search
for devices)
BlackBerry® smartphone:
Settings/options > Bluetooth: On >
Search for devices
VIDEO TUTORIAL FOR USA:
www.plantronics.com/pairing
2. SET
First Time, Right Out of the Box:
Turn on the headset. The LED
flashes red/blue to indicate
pairing mode.
Activate Multipoint (for 2nd
phone):
While pressing Call button, turn on
the headset and continue pressing
Call button until LED flashes blue
twice. Repeat to turn off
multipoint.
Pair New or Second Phone:
Turn on headset. Press Call
button until the LED flashes
red/blue.
3. CONNECT
Select “PLT_M20” or "PLT_M50"
from the list of Bluetooth devices
shown on your phone.
If phone asks for a passcode, enter
four zeros (0000). You may see
**** on screen.
Some phones also ask to confirm
headset connection after pairing.
Headset LED will stop flashing
red/blue once successfully
paired/connected.
You can now make a call using your
phone’s keypad or voice-dialing
feature.
![](/img.php?id=1459614&img=bg4.png)
FIT EITHER EAR
1
2
1
2
Right Ear Left Ear
![](/img.php?id=1459614&img=bg5.png)
TIPS
Stay Near Your Phone
Bluetooth has a working “range” of up to 33
feet between the phone and headset before
audio degrades and the connection is lost.
Know How to Reconnect
Your headset tries to reconnect a lost
connection. If it can’t, then tap the Call button
once or manually reconnect via the phone’s
Bluetooth device menu.
Listen to the Voice
This headset automatically announces various
status alerts, including:
• Power on/off
• Battery high, medium, low or recharge
• Pairing in process, successful or incomplete
• Connected or lost connection [to phone]
Listen to Music and More (M50 series only)
If your phone also has the Bluetooth "A2DP"
stereo music feature, then your music,
podcasts, favorite internet radio and other
streaming audio can be heard through this
headset.
Use Multipoint One Call at a Time
Once you have activated multipoint and paired
your two phones, it's easy to answer calls from
either phone.
When already on a call, you will hear a
ringtone notification of the incoming call from
the second paired phone.
To answer a second call from the other phone,
you must end the current call (tap Call button)
so new call automatically answers.
If you choose not to answer the second call, it
will go to voicemail.
![](/img.php?id=1459614&img=bg6.png)
3.0
![](/img.php?id=1459614&img=bg7.png)
NEED MORE HELP?
Don’t return to the store - call our friendly customer support
team at 1-866-363-2583 (USA) or visit plantronics.com/support
for local numbers outside the US.
© 2011 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark of
Bluetooth SIG, Inc. and any use by Plantronics is under license. All other trademarks
are the property of their respective owners.
U.S. Patents Pending. 85844-01 EN-US
Z109
N10687
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating instructions
for satisfying RF exposure compliance. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Notice: Any changes or modification not expressly approved by the party responsible
could void the user's authority to operate the device.
Industry Canada (IC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the
part responsible for compliance could void the user’s authority to operate the
equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the IC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
* Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may
cause undesired operation of the device.
IC RF Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter.
