Model Name: PF302
General Speaker Setup & Pairing:
‐ Select a BT 2.0 or above device (mobile phone or music player) for pairing.
‐ Turn on the Main Power Switch of PF302 at the back.
Remark: Make sure your PF302 has been fully charged.
‐ Activate your BT device to the searching mode (new device searching).
‐ Press and hold “Stand-by or Phone & Phone” key at the side of PF302 till the flashing of BLUE/RED
LED, PF302 will have 3mins (searchable time) for your BT device to pair with.
‐ <<Plastoform PF302>> will be displayed in your BT device. Please select it for pairing. “0000” is the
pairing code if necessary.
‐ PF302 will stop flashing & with a sound effect to specify it is paired with the BT device.
Remark: Pairing steps are for 1st time connection, simple steps could be done by either PF302 or your
BT device in future use.
‐ Double check with your BT device to see PF302 is connected.
Remark: PF302 will also stop flashing with another sound effect to specify pairing failure after the
3mins. Repeat from the activation of your BT device to try again the pairing with PF302.
Connection & Operation (Music) Instruction:
‐ Turn on the Main Power Switch of PF302 at the back.
‐ To Power up the unit: Press “Stand-by or Phone” key at the side of PF302 till BLUE LED is on
Remark: Make sure PF302 has been fully charged & the Main Power Switch is on
‐ Turn on your BT device and select the connection w/ <<Plastoform PF302>>
‐ Play & Pause Music: Press “Stand-by or Phone” key at the side
‐ To play Next song: Press “>>|” key at the side
‐ To play Previous song: Press “|<<” key at the side
‐ To Fast Forward: Press & hold “>>|” key at the side
‐ To Rewind: Press & hold “|<<” key at the side
‐ To adjust the Volume: Adjust the volume level either in PF302 or your BT device
‐ To Power down the unit: Press the Stand-by or Phone key at the side of PF302 till BLUE LED is off
Remark: If HFP/HSP is available in your BT mobile ONLY (No A2DP), such as iPhone 2G, PF302
could perform as a speaker phone.
Operation (Speaker Phone) Instruction:
‐ To Answer a call: Press Any Key at the side
‐ To Reject a call: Press & hold “Stand-by or Phone” key at the side
‐ To Hang-up a call: Press “Stand-by or Phone” key at the side
‐ To Switch the call in between PF302 & mobile: Press & hold “Stand-by or Phone” key at the side
‐ To Answer Call Waiting (3rd Party): Double Press “Stand-by or Phone” key at the side
‐ To Toggle in between 3rd Party/Original call: Double Press “Stand-by or Phone” key at the side
‐ To Redial Last Calling number: Double Press “Stand-by or Phone” key at the side
Remark: PF302 could perform as a speaker phone, ONLY HFP/HSP is available in your BT mobile,
Battery Recharge & Firmware Upgrade Instruction:
‐ PF302 could be recharged in any status by USB power (thru the provided USB cable from PC; or from
USB adaptor “Not included”)
‐ PF302 firmware upgrade is available thru USB cable from PC
LED indicator (on the Speaker):
‐ LED Off – Power OFF
‐ BLUE LED ON – Power ON
‐ Flashing of BLUE/RED LED – Pairing mode
‐ RED LED ON – Low Battery Level
‐ Flashing of RED LED – Almost No Power
‐ Flashing of BLUE LED – Battery is Recharging
Remark: No LED indication if Main Power Switch-off at the back
Specification:
‐ Total 6W output (3W / Channel)
‐ Full-range (35mm) driver / Channel + Passive Radiator
‐ Distortion <= 10 %
‐ S/N ratio:>75dB@1W
‐ Frequency Response: 200Hz – 15k Hz
‐ Li—polymer Batt: 1150mAh
‐ Playtime: 5hours in 80% Volume
‐ Recharging Time: 3hours
‐ (Optional) Power Adaptor: 5VDC @ 500mA
Compatibility (Bluetooth device)
‐ BT 2.0 or above device with A2DP/AVRCP/ HFP/ HSP
Trouble Shooting:
Sound not Clear or no sound ‐ Please check PF302 or BT device Volume
Level
Playing Music Not Transfer from BT device to
PF302
‐ Make sure your BT device has A2DP
‐ Check if both devices are connected
‐ Restart PF302 for auto-connecting with your
BT device
LED No Power ‐ Make sure PF302 Main Switch is ON
‐ Make sure PF302 is charged.
Sound is Too small / too much distortion ‐ Adjust the volume level of PF302 or BT
device
Phone call Not Answer by PF302 ‐ Make sure your mobile has HSP/HFP
‐ Check if both devices are connected
‐ Restart PF302 for auto-connecting with your
BT device
No Music Resume after hanging up a call ‐ Press play to resume music
No Music Control by PF302 ‐ Make sure your BT device has AVRCP
