Polaroid Tda 03211C Users Manual User's 20070411

32” HD Widescreen LCD TV/DVD Combo

TDA-03211C

This TV incorporates High-Deﬁ nition Multimedia Interface (HDMITM) technology.

HDMI, the HDMI logo and High-Deﬁ nition Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC.

Manufactured under license from Dolby Laboratories.

“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

“Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation, Waltham, MA, USA.

Changes are periodically made to this document. Changes, technical inaccuracies, and

typographic errors will be corrected in subsequent editions.

For service, support and warranty information, visit www.polaroid.com.

This product contains electrical or electronic materials. The presence of these materials may,

if not disposed of properly, have potential adverse effects on the environment and human

health. Presence of this label on the product means it should not be disposed of as unsorted

waste and must be collected separately. As a consumer, you are responsible for ensuring that

this product is disposed of properly. To ﬁ nd out how to properly dispose of this product, please

go to www.polaroid.com and click on “Company“ or call the customer service number for your

country listed in the instruction manual.

ENGLISHENGLISH

1

FCC

Federal Communications

Commission Statement

This equipment has been tested and found to comply with the limits of a class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

1. Reorient/Relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit which is different from what the receiver is

connected to.

4. Consult the dealer or an experienced radio/TV technician for help.

Changes or modi cations not expressly approved by the manufacturer

responsible for compliance could void the user authority to operate the

equipment.

2

Warnings and Precautions

To reduce the risk of ﬁ re or electric shock, do not expose this equipment to rain or moisture.

This symbol is intended to alert the user to avoid the risk of electric shock.

This equipment must not be disassembled by anyone except qualiﬁ ed service personnel.

This symbol is intended to alert the user to the presence of important operating and

maintenance instructions in the literature accompanying the appliance.

▪ TO REDUCE THE RISK OF ELECTRIC SHOCK,

▪ DO NOT REMOVE COVER (OR BACK).

▪ NO USER-SERVICEABLE PARTS INSIDE.

▪ REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Use of controls, adjustments or performance of procedures other than those speciﬁ ed herein

may result in hazardous radiation exposure.

CAUTION

Important Safety Instructions

To prevent any injuries, the following safety precautions should be observed in the installation, use,

servicing and maintenance of this equipment.

Before operating this equipment, please read this manual completely, and keep it nearby for future

reference.

WARNING

▪ Do not place the equipment on any uneven or unstable carts, stands, tables, shelves etc.

The equipment may fall, causing serious injury to children or adults and serious damage to

the equipment itself.

▪ Use only a cart or stand recommended by the manufacturer. This equipment and

recommended cart or stand should be handled with care. Quick stops, excessive force, and

uneven surfaces may cause the equipment and cart/stand to overturn.

▪ Do not disable the 3-wire grounding type plug. The grounding pin on the 3-prong plug is an

important feature. Removing the grounding pin will increase the risk of damaging the

equipment.

▪ If you can not ﬁ t the plug into the electrical outlet, contact an electrician to install a grounding

outlet.

▪ Always operate this equipment from the type of power source indicated on the rear of the

serial/model plate.

▪ Never overload wall outlets and extensions.

This symbol indicates caution points.

This symbol indicates actions that should not be done.

This symbol indicates actions that must be performed.

ENGLISHENGLISH

3

Warnings and Precautions

▪ Use and handle the power cord with care. Do not place any heavy objects on the AC

power cord.

▪ Do not pull the AC power cord. Do not handle the AC power cord with a wet hand.

▪ Do not touch the power cord and antenna cable during lightning.

▪ Remove the plug from the wall outlet, if the equipment will not be used for a long period

of time.

▪ Do not place, use or handle this equipment near water.

▪ Never expose the equipment to liquid, rain, or moisture.

Seek for service if any of the above is spilled into the equipment.

▪ Do not expose the equipment to extreme temperature or to direct sunlight, as the

equipment may heat up and suffer damage.

▪ Do not install the equipment near any heat sources such as radiators, heat registers,

stoves, or any other apparatus that might produce heat.

▪ Do not attempt to service the equipment yourself.

▪ Opening and removing the covers may expose you to dangerous voltage or other

hazards and may void your warranty. Refer service to qualiﬁ ed personnel.

▪ Do not place or drop any other objects on top.

▪ Do not insert anything into the ventilation holes of your equipment.

Inserting any metal or ﬂ ammable objects may result to ﬁ re or electric shock.

▪ Protect the power cord from being walked on or pinchrd particularly at plugs ,convenience

receptacles, and the point where they exit from the apparatus.

▪ Do not place the equipment on uneven or unstable carts, stands, tables, shelves etc. The

equipment may fall, causing serious injury to children or adults and serious damage to

the equipment itself.

Always place the equipment on the ﬂ oor or on a surface that is sturdy, level, stable and

strong enough to support the weight of the equipment.

▪ Do not block any ventilating openings. Leave an open space around the equipment.

Never place the equipment :

on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a

bookcase, built-in cabinet, or any other similar places that may cause poor ventilation.

▪ Unplug this apparatus during lightning storms or when unused for long periods of time.

▪ Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normally, or has been dropped.

▪ Always remove the power cord from the outlet before cleaning the equipment.

▪ Never use liquid or aerosol cleaners on the equipment.

Clean only with a soft dry cloth.

▪ Only use attachments/accessories specified by the manufacturer.

4

Warnings and Precautions

Outdoor Antenna Safety Instructions

Antenna lead-in wire

Antenna discharge unit

(NEC section 810-20)

Grounding conductors

(NEC section 810-20)

Ground clamps

Power service grounding

(NEC Art250 part H)

Ground clamps

Electric service

equipment

NEC : National Electrical code

If an outdoor antenna is connected, follow the precautions below:

EXAMPLE OF OUTDOOR ANTENNA GROUNDING

Section 810 of National Electrical Code (NEC) provides information with respect to proper grounding of the

mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding

conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for

the grounding electrode.

▪ An outdoor antenna should not be located in any area where it could come in contact with

overhead power lines, or any other electric light or power circuits.

▪ When installing an outdoor antenna system, extreme caution should be taken to prevent

contact with power lines. Direct contact with power lines may be fatal and should be avoided

at all costs.

ENGLISHENGLISH

5

TABLE OF CONTENTS

Federal Communications Commission Statement .......................... 1

Warnings and Precautions

Important Safety Instructions ....................................................................................... 2

Antenna Safety Instructions ......................................................................................... 4

Chapter 1 Introducing the LCD TV

Key Features ............................................................................................................... 6

Package Contents ....................................................................................................... 7

Setting Your LCD TV .................................................................................................... 8

Your LCD TV ...............................................................................................................11

Your Remote Control ................................................................................................. 14

Chapter 2 Installing the LCD TV

Connecting a TV Cable or an Antenna ...................................................................... 18

Connecting a VCR ..................................................................................................... 23

Connecting a Video Camera or Game Console ........................................................ 24

Connecting a DVD Player .......................................................................................... 26

Connecting a Digital TV Cable Box or Digital Satellite Receiver ............................... 27

Connecting an AV Equipment with HDMI Connector ................................................. 28

Connecting an AV Equipment with DVI Connector .................................................... 29

Connecting a PC........................................................................................................ 30

Connecting an Audio Receiver or a Dolby Digital 5.1 Sound System........................ 31

Chapter 3 USING THE FEATURES

Using The Built-in DVD ...............................................................................................................................32

Using The USB Storage and SD Card Reader ............................................................................. 34

Wide Screen Viewing ...................................................................................................................................37

Using the Program Guide .......................................................................................................................... 38

Operating the Menu .....................................................................................................................................39

Customizing the VIDEO Settings ........................................................................................................... 41

Customizing the AUDIO Settings ........................................................................................................... 43

Customizing the TV Settings .................................................................................................................... 45

Customizing the SETUP Settings .........................................................................................................47

Using the Program Block Settings ........................................................................................................50

Speciﬁ cations ........................................................................................................ 55

Programming your Remote Control ......................................................... 56

6

Chapter 1 Introducing the LCD TV

Various Audio/Video terminals for external equipment connection

▪ 2 sets of composite A/V input terminals

▪ 1 set of S-VIDEO terminals

▪ 2 sets of component Video input terminals

▪ 1 VGA/ Audio input terminals

▪ 2 HDMI/Audio input terminals

▪ 1 set of Audio(L/R) output terminals

▪ 2 SPDIF output terminals (Optical x 1 /Coaxial x 1)

▪ 1 Headphone terminal

Built-In Slot-type DVD Player

▪ Supports DVD/SVCD/VCD/CD compatibility.

Built-in SD Card Reader

▪ Allows access to digital content stored on a SD card.

Built-In USB Connector

The built-in TV tuner to receive HD ATSC

▪ This function allows the reception of HD broadcasting without the addition of a set top

box.

High De nition Multimedia Interface (HDMI)

▪ High Deﬁ nition Multimedia Interface (HDMI) is a small, user-friendly interconnect that

can carry up to 5 Gbps of combined video and audio in a single cable. This system

eliminates the cost, complexity and confusion of multiple cables used to connect

current A/V systems.

HDTV Component Video Inputs

▪ Offers the best video quality for DVD (1080i, 720p) and digital set-top-box (1080i,

720p) connections.

3D Digital Noise Reduction

▪ This function can digitally reduce image noise to provide better picture quality.

Film-Mode Detection (3:2 Reverse Pull Down)

▪ This function can automatically detect content derived from ﬁ lm and adjust the

interlacer’s frame matching to provide a more natural-looking, clearer image of the

moving picture.

Chapter 1

Introducing the LCD TV

Key Features

ENGLISH

7

Chapter 1 Introducing the LCD TV

Make sure all of the above contents are included in the package. If you are missing

any items, please contact the Polaroid customer service department.

 LCD TV

Make sure all of the following contents are included.

 Power Cord

These items are all you need to set up and operate the LCD TV in its basic conﬁ guration.

Package Contents

 VIDEO Cable Remote Control/

AAA Batteries x 2

 User’s Manual

 Bottom Stand /

Screw Driver and Screws (4)

 Component Cable

 Quick Start Guide

 AUDIO Cable  Warranty Card

SET UP

TV

MUTE

GUIDE PIP

OK

MENU

INFO

12

ABC

3

DEF

4

GHI

5

JKL

6

MNO

9

WXYZ

8

TUV

7

PQRS

INPUT

.

0ENTER

CC EXIT

LIVE TV

DVR

ASPECT LAST

SLEEP

VOL CH PAGE

CAB/

SAT

AUXDVD

DVD MENU

 Stand Assembly Guide

8

Chapter 1 Introducing the LCD TV

Setting Up Your LCD TV

How to install the TV Stand

Attach the Stand the TV with the bottom foam packaging material still

attached.

Read all instructions before continuing with the stand installation.

a b

Stand Shipping box

Protective bag

Table

c. Remove protective bag from LCD unit, but DO NOT remove the bottom foam packaging

material from the TV.

d. Locate the place on the back of the TV to attach the stand. Secure the stand to the LCD

with all six screws.

c

d

Packaging material

Stand

Unit

Table

Unit

Table

Stand

Screws

a. Lift foam packaging material from the top of the LCD out of the box.

b. Lift LCD out of the box, with the bottom foam packaging material still attached, and place

onto a stable surface.

ENGLISH

9

Chapter 1 Introducing the LCD TV

If you prefer to mount your new Polaroid TV on a wall instead of attaching it to the stand, please

reference the instructions included in the wall mounting kit (sold separately).

 Remove the screws of the table stand and detach the table stand from the TV.

Soft cloth

 Align the holes on the wall mounting hook units with the corresponding holes on the rear

of the TV and fasten four screws.

Soft cloth

Table stand

How to remove the TV Stand

Soft cloth

Wall mounting hook

unit (supplied with the

wall mount kit)

 To prevent damaging the surface of the LCD TV, place the TV on a soft cloth.

Verify your TV’s model and be sure to use the wall mounting kit speciﬁ ed

for your TV model only. Contact your technician for assistance when

installing the wall mounting kit.

4 screws (supplied

with the wall mount

kit)

10

Chapter 1 Introducing the LCD TV

Do not use caustic cleaners (porcelain, stainless steel, toilet, or oven cleaner

etc.) on the remote, as it may su er damage.

 Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT. terminal

(refer to page18-22).

 Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.

 Insert the 2 batteries supplied in remote control.

 Connect other an external AV device (refer to page23-31).

Step1 Slide the back cover up to open the

battery compartment of the remote

control.

Step2 Insert two AAA size batteries.

Make sure to match the (+) and

( - ) ends of the batteries with

the (+) and ( - ) ends indicated

in the battery compartment.

Slide the cover back into place.

How to setup the TV

ENGLISH

11

Chapter 1 Introducing the LCD TV

Your LCD TV

LED

The LED light indicates when the LCD TV is

activated.

IR

Infrared

Receiver

MENU

Press once to display the OSD (on screen display),

press again to turn the OSD off.

VOLUME+-

Adjusts the volume up and down. Selects the main-

menu item and change values for items when in the

OSD mode.

Turns the LCD TV on and into standby mode.

CHANNEL▲▼

Scans up and down through channels. Selects sub-

menu item when in the OSD mode.

INPUT

Chooses from different input signal sources.

Front/Right Side View and Controls

Right Side View and Controls

SLOT-TYPE DVD PLAYER

Any of the following disc types can

be played on the DVD player: DVD/VCD/CD/CD-

R/CD-RW/JPEG/KODAK PICTURE CD/WMA/

DVD+R/RW/DVD-R/RW/MPEG-4

.

USB

Allows access to digital content stored on

a USB storage : MP4/JPEG

/

STOP/EJECT

BUILT-IN SD CARD READER

Allows access to digital content stored on a

SD card : JPEG/MPEG1/MPEG2/MPEG4

/

PLAY/PAUSE

L

R

VIDEO1 IN

VIDEO

HEADPHONE

Connects to the external headphone

for private listening.

VIDEO1 IN

Connects to the composite Video and

Audio output jacks on external video

equipment.

12

Chapter 1 Introducing the LCD TV

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

VGA IN

Connects the PC, or other AV equipment with VGA and

AUDIO(L/R) output jacks.

YPbPr1 IN/YPbPr2 IN

Connects to the DVD player, Digital Set-Top-Box, or other AV

equipment with component(YPbPr) video and audio output jacks.

VIDEO2 IN

Connects to the composite VIDEO and AUDIO(L/R) output jacks on external video equipment.

HDMI1 IN/HDMI2 IN

Connects the all digital AV equipment with HDMI connector.HDMI supports enhanced,

high-deﬁ nition video and two-channel digital audio. The AUDIO(L/R) of HDMI IN is for

DVI connection.

AC IN

Connects to the AC power cord.

S-VIDEO IN

Connects to the S-VIDEO and AUDIO(L/R) output jacks on external

video equipment.

AUDIO OUT-STEREO

Connects to the AUDIO(L/R) input jacks on AV equipment.

AUDIO OUT-DIGITAL-OPTICAL/COAXIAL

Connects to the DIGITAL AUDIO jack on the digital/standard 5.1

audio system.

HDTV/TV AIR/CABLE

Connects RF input from VHF/UHF antenna or cable

to receive high/standard deﬁ nition television.

ENGLISH

13

Chapter 1 Introducing the LCD TV

Rear View and Jacks

SET UP

TV

MUTE

GUIDE PIP

OK

MENU

INFO

12

ABC

3

DEF

4

GHI

5

JKL

6

MNO

9

WXYZ

8

TUV

7

PQRS

INPUT

.

0ENTER

CC EXIT

LIVE TV

DVR

ASPECT LAST

SLEEP

VOL CH PAGE

CAB/

SAT

AUXDVD

DVD MENU

14

Chapter 1 Introducing the LCD TV

Your Remote Control

Turns the LCD TV on and off

SET UP Remote control universal code setup.

For more information on setting up your

remote control, please see the

“Programming Your Remote Control”

section (refer to page 56)

TV Controls the LCD TV/Built-in DVD/USB /

SD card reader.

CAB/SAT Controls Cable Converter or Satellite

Receiver

DVD Controls DVD player or Video player

AUX Controls Audio Ampliﬁ er

SLEEP Cycles through the LCD TV sleep time:

OFF/10/20/30/40/50/60/90/120 mins

 ► Other device function keys

   

VOL+- Increases and decreases volume

CH▲▼ Change channel up and down

ASPECT Cycles through Wide mode settings:

NORMAL/FULL/WIDE/ZOOM

MUTE Pressing once mutes audio. Pressing

again restores audio

LAST Returns to previously selected channel

GUIDE In TV mode, pressing GUIDE displays

the Program Guide on the screen

This package includes a Polaroid remote that enables control of up to four devices.

To select a device, simply select one of the following device mode controls: TV, CBL/SAT, DVD/VCR,

or AUDIO.

1

2

3

2

4

5

6

7

8

9

10

11

2

5

6

8

1

4

7

3

10

11

9

Input Source

TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR)

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

DVD

USB

CARD READER

VIDEO6 (HDMI1)

VIDEO7 (HDMI2)

COMPUTER(VGA)

ENGLISH

15

Chapter 2 Installing the LCD TV

E ective range:

The remote can control the LCD TV from up to 5m away, if pointed directly at the receiver.

PIP Other device function key

MENU Displays the OSD menu on the

screen.

◄ ►▲▼,OK Cycles through OSD options and selects

individual menu items. OK conﬁ rms option

settings

OK In TV mode, pressing OK to display a

channel list

INFO Displays information on the LCD TV

screen such as input source, channel,

program title.

CC Cycles through the Closed Caption:

 Analog Closed Caption:OFF/CC1/

CC2/CC3/CC4/Text1/Text2/Text3/

Test4

 Digital Closed Caption:

Allow to set the digital closed caption

EXIT Exits the OSD menu

0-9/ENTER Pressing a number selects a channel.

Following selection, pressing ENTER

activates the channel, or channel

activates automatically in 3 seconds

INPUT Pressing INPUT to display a source

list, use ▲▼ to select the video

equipment connected to the video

inputs of your LCD TV:

12

13

14

15

16

18

SET UP

TV

MUTE

GUIDE PIP

OK

MENU

INFO

12

ABC

3

DEF

4

GHI

5

JKL

6

MNO

9

WXYZ

8

TUV

7

PQRS

INPUT

.

0ENTER

CC EXIT

LIVE TV

DVR

ASPECT LAST

SLEEP

VOL CH PAGE

CAB/

SAT

AUXDVD

DVD MENU

12

13

14

15

16

17

18

19

17

▪ In TV mode, use with 0-9 and ENTER

buttons to select a digital channels.

SET UP

TV

MUTE

GUIDE PIP

OK

MENU

INFO

12

ABC

3

DEF

4

GHI

5

JKL

6

MNO

9

WXYZ

8

TUV

7

PQRS

INPUT

.

0ENTER

CC EXIT

LIVE TV

DVR

ASPECT LAST

SLEEP

VOL CH PAGE

CAB/

SAT

AUXDVD

DVD MENU

16

Chapter 2 Installing the LCD TV

DVD MENU Press to display the menu of a DVD

disc.

While playing, press to jump to the

previous/next chapter or track.

Pressing this button during playback

advances/reviews playback; speed

increases with each pressing:

2x/4x/8x/16x/32x

Normal playback.

While playing, press this button to stop

playing.

While playing, press this button once to

pause playing, press once again to

resume playing.

VOL+- Increases and decreases volume.

ASPECT Cycles through Wide mode settings:

NORMAL/FULL/WIDE/ZOOM

MUTE Pressing once mutes audio. Pressing

again restores audio.

GUIDE Displays the

Built-in DVD Setup Menu

on the screen.

◄ ►▲▼,OK Cycles through Built-in DVD OSD

options and selects individual menu

items. OK conﬁ rms option settings

INFO Displays current information on screen

during playback.

EXIT Press this button to eject the disc.

1

2

3

4

5

6

7

8

9

10

11

3

5

8

1

4

2

13

10

9

Controlling The Built-in DVD

Press the TV button once to activate the built-in DVD control keys, the following functions are preset to

operate the built-in DVD:

12

6

7

12

11

13

SET UP

TV

MUTE

GUIDE PIP

OK

MENU

INFO

12

ABC

3

DEF

4

GHI

5

JKL

6

MNO

9

WXYZ

8

TUV

7

PQRS

INPUT

.

0ENTER

CC EXIT

LIVE TV

DVR

ASPECT LAST

SLEEP

VOL CH PAGE

CAB/

SAT

AUXDVD

DVD MENU

ENGLISH

17

Chapter 2 Installing the LCD TV

DVD MENU Press to display FILE MENU.

Press to go to the next or previous

image.

Normal playback.

Press to display the thumbnail album.

While Slide show, press this button

once to pause playing, press once

again to resume playing.

VOL+- Increases and decreases volume.

ASPECT Cycles through Wide mode settings:

NORMAL/FULL/WIDE/ZOOM

MUTE Pressing once mutes audio. Pressing

again restores audio.

◄ ►▲▼,OK In FILE MENU and thumbnail album,

Press to move the highlight bar to a ﬁ le,

then press OK to conﬁ rm the selected

ﬁ le.

►▼ While image displaying, press to rotate

an image 90 degrees in a clockwise or

counterclockwise.

1

2

3

4

5

6

7

8

9

4

7

1

3

2

8

Controlling The USB Storage and SD Card Reader

Press the TV button once to activate the built-in USB and SD Card Reader control keys, the following

functions are preset to operate the USB Storage and SD Card: For more information on setting up your

USB storagnd adn card reader, please see the “Using the USB Storage and SD Card Reader” section.

5

6

9

18

Chapter 2 Installing the LCD TV

Chapter 2

Installing the LCD TV

Refer to the owner’s manual of any external equipment to be connected.

When connecting any external equipment, do not connect any AC power cords to wall outlets

until all other connections are completed.

Antenna Connection

The antenna requirements for good color TV reception are more important than those for a black &

white TV reception. For this reason, a good quality outdoor antenna is strongly recommended.

The following is a brief explanation of the type of connection that is provided with the various antenna

systems.

75-ohm coaxial cable (round)

F-type connector

300-ohm twin-lead cable ( at)

■ A 75-ohm system is generally a round cable (not included) with F-

type connector that can easily be attached to a terminal without

tools.

■ A 300-ohm system is a  at twin-lead cable (not included) that can

be attached to a 75-ohm terminal through a 300-75-ohm adapter

(not included).

Connecting a TV Cable or an Antenna

ENGLISH

19

Chapter 2 Installing the LCD TV

OUT IN

300-ohm twin-

lead cable

300-ohm twin-

lead cable

75-ohm

coaxial cable

UHF

Antenna

VHF

Antenna

Combiner

(not included)

A. Combination VHF/UHF antenna

300-ohm twin-

lead cable

75-ohm

coaxial cable

VHF/UHF

Antenna

VHF/UHF

Antenna

300/75-ohm adapter

(not included)

B. Separate VHF and/or UHF antennas

Use one of the following two diagrams when connecting an outdoor antenna.

A: Shows how to use a VHF/UHF combination outdoor antenna.

B: Shows how to use a separate VHF and/or UHF outdoor antenna.

20

Chapter 2 Installing the LCD TV

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the

National Electrical Code (NEC) that provides guidelines for proper grounding and, in particular,

speciﬁ es that the cable ground shall be connected to the grounding system of the building

accurately, or as close to the point of cable entry as possible. Use of this TV for other than

private viewing of programs broadcasted on UHF, VHF or transmitted by cable companies for

the use of the general public may require authorization from the broadcast/cable company, and/

or program owner.

A

IN

B

OUT

Cable TV Line

2 set signal

splitter

(not included)

RF switch

(not included)

Cable TV converter/

descrambler

(not included)

Cable TV (CATV) Connection

■ The RF switch (not included) is required to provide two inputs (A and B). Setting

the RF switch to position A allows viewing of all unscrambled channels by using

the TV channel keys.

■ Setting the RF switch to position B allows viewing of all scrambled channels via

the converter/descrambler by using the converter channel keys.

■ A 75-ohm coaxial cable connector is built into the set for easy hookup.

When connecting the 75-ohm coaxial cable to the set, connect the 75-

ohm cable into the ANT. terminal.

■ Some cable TV companies o er premium pay channels. Since the

signals of these premium pay channels are scrambled, a cable TV

converter/descrambler is generally provided to the subscriber by the

cable TV company.

This converter/descrambler is necessary for normal viewing of scrambled channels.

(Set your TV to channel 3 or 4, typically one of these channels is used. If this is unknown,

consult your cable TV company.)

For more speciﬁ c instructions on installing cable TV, consult your cable TV company.

One possible method of connecting the converter/descrambler provided by your cable TV

company is shown in the diagram below.

VHF/UHF IN

ENGLISH

21

Chapter 2 Installing the LCD TV

 Use a supplied antenna cable to connect the TV signal to the LCD TV’s TV CABLE terminal.

 Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.

HDTV/TV

AIR/CABLE

VHF/UHF IN

HDTV/TV

AIR/CABLE

VHF/UHF IN

BE SURE TO UNPLUG AC POWER CORD BEFORE REMOVING THE FUSE.

This TV is equipped with a safety fuse. In the event of an electrical storm or power outage

the safety fuse is designed to protect your TV. If your TV has no power, check the fuse by

prying the cover off, following the illustration below.

If the fuse is blown, visit your local hardware store and ask for a 4A 250V - 5x20mm Time

Lag Fuse (Slow Blow) to replace the fuse.

4A 250V

5x20mm

Fuse

Back of TV

Firm Plastic Prying Tool

(Using a metal tool may cause shock)

 Press the button on the remote to turn on the LCD TV.

Always disconnect the LCD TV from the main voltage when the LCD TV will not

be used for a long period of time. The POWER button on the front panel is only

used for switching the LCD TV into standby, it does not disconnect the device

from the main voltage. To completely disconnect the main voltage, please

remove the power plug from the socket.

22

Chapter 2 Installing the LCD TV

 Press the OK button to display the received channel list, then press ▲▼ to select a

channel. Or, use the ▪ (INPUT button) with 0-9 buttons to select digital channel( for

example 9.1)

The digital main channel might include many subchannels (for example 9-1, 9-

2..) that are showing program at the same time.

The Channel Scanning will create a list of receivable channels for the current

input (antenna or cable). You will be required to run Channel Scanning for each

RF input to create a list of available channels from both inputs.

 Press the INPUT button on the remote to display the Input List. Use the ▲▼ buttons to

select TV and press the OK button.

 Press the MENU button on the remote control to display the Main menu, and use the ◄►

buttons to select the TV.

 Press the ▼ button to select Channel Scan, and press the OK button.

The Channel Scan automatically creates a list of receivable channels. Press the MENU

button at any time to interrupt the memorization process.(the list cannot be created if

interrupted)

Channel List

5-2 RF5-2

9-1 KQED-HD

9-2 KOED-SD

8 CCT

12

13

15

TV Select Exit

Channel Scan

Tuner Mode Cable

Channel Skip

Time Zone Eastern Time

Main

 TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR)

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

DVD

USB

CARD READER

VIDEO6 (HDMI1)

VIDEO7 (HDMI2)

COMPUTER(VGA)

 METHOD A:

Use a composite cable to connect the VCR’s composite video/audio jacks to the LCD TV’s

VIDEO2 IN jacks.

METHOD B:

Use an audio cable to connect the VCR’s audio output jacks to the LCD TV’s audio

inputs. Use a S-Video cable to connect the VCR’s s-video output jack to the LCD TV’s

S-VIDEO IN input jack.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 To watch a videotape, press the INPUT button on the remote to select

VIDEO2( METHOD A), or VIDEO3 (METHOD B).

Connecting a VCR

A B

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

Rear of TV

AUDIO Cable

S-VIDEO Cable

AV Cable

ENGLISH

23

Chapter 2 Installing the LCD TV

L

R

VIDEO1 IN

VIDEO

Right Side

24

Chapter 2 Installing the LCD TV

A

B

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

Rear of TV

or AUDIO Cable

S-VIDEO Cable

AV Cable

Connecting a Video Camera or Game console

GAME CONSOLE

 METHOD A:

Use a composite cable to connect the video camera’s or game console’s composite

video/audio jacks to the LCD TV’s VIDEO2 IN jacks or VIDEO1 IN jacks.

METHOD B:

Use an audio cable to connect the video camera’s or game console’s audio output

jacks to the LCD TV’s audio inputs. Use an S-Video cable to connect the video

camera’s or game console’s s-video output jack to the LCD TV’s S-VIDEO IN input

jack.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 To watch a video vis camera or game console, press the INPUT button on the remote

to select VIDEO2/VIDEO1( METHOD A), or VIDEO3 (METHOD B).

Not all cameras have the ability to connect to a TV. Please check your video camera

user guide for compatibility.

ENGLISH

25

Chapter 2 Installing the LCD TV

C

Rear of TV

AB

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

or

 METHOD A:

Use a composite cable to connect the DVD player’s composite video/audio jacks to the

LCD TV’s VIDEO2 IN jacks.

METHOD B:

Use an audio cable to connect the DVD player’s audio output jacks to the LCD TV’s

audio inputs. Use an S-Video cable to connect the DVD player’s s-video output jack

to the LCD TV’s S-VIDEO IN input jack.

METHOD C:

Use a component cable to connect the DVD player’s component output jacks to the LCD

TV’s YPbPr1 IN or YPbPr2 IN input jacks.

Use an audio cable to connect the DVD player’s component audio jacks to the LCD TV’s

audio input jacks.

DVD PLAYER

PrPb

Connecting a DVD Player

The component video jacks on your DVD player are sometimes labeled

YPbPr, or YCbCr. For an explanation of component video, see your DVD

player’s user guide.

AUDIO Cable

S-VIDEO Cable

AV Cable

COMPONENT/AUDIO Cable

26

Chapter 2 Installing the LCD TV

For best picture quality, if your equipment has component video output, use

a component cable instead of a composite video or S-video cable.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 To watch a DVD, press the INPUT button on the remote to select

VIDEO2( METHOD A), or VIDEO3 ( METHOD B), or VIDEO4/VIDEO5 (METHOD C).

ENGLISH

27

Chapter 2 Installing the LCD TV

 Use a component cable to connect the satellite receiver’s/TV Cable Box’s component

(YPbPr1) output jacks to the LCD TV’s component input jacks.

Use an audio cable to connect the satellite receiver’s/TV Cable Box’s component audio

jacks to the LCD TV’s audio input jacks.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 To watch programs via satellite receiver or TV Cable Box, press the INPUT button on

the remote to select VIDEO4/VIDEO5.

Rear of TV

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

PrPb

Connecting a Digital TV Cable Box or Digital Satellite Receiver

COMPONENT/AUDIO Cable

28

Chapter 2 Installing the LCD TV

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

Rear of TV

 Use a HDMI cable to connect the AV equipment’s HDMI output jack to the LCD TV’s HDMI IN

jacks.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 Press the INPUT button on the remote to select VIDEO6 or VIDEO7.

Connecting an AV Equipment with HDMI Connector

The HDMI connector provides both video and audio signals, it’s not

necessary to connect the audio cable.

HDMI Cable

AV EQUIPMENT

ENGLISH

29

Chapter 2 Installing the LCD TV

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

Rear of TV

 Use a HDMI-to-DVI cable to connect the AV equipment’s DVI output jack to the LCD TV’s

HDMI IN jacks.

Use an audio cable to connect the AV equipment’s audio output jacks to LCD TV’s HDMI

AUDIO jacks.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 Press the INPUT button on the remote to select VIDEO6 or VIDEO7.

Connecting an AV Equipment with DVI Connector

If the LCD TV is connected to AV equipment’s DVI connector, you will need

an HDMI-to-DVI cable or an HDMI adapter(not suplied) and an audio cable.

AV EQUIPMENT

HDMI-to-DVI Cable

AUDIO Cable

DVI IN

AUD IO

LR

30

Chapter 3 Using the LCD TV

 Use a D-SUB cable to connect the PC’s D-SUB output jack to the LCD TV’s VGA input

jack. Use an audio cable to connect the PC’s audio output jacks to LCD TV’s.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 Press the Input button on the remote to select COMPUTER.

HDMI2 INHDMI1 IN

AUDIO

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDIO

Rear of TV

Connecting a PC

VGA Cable

AUDIO Cable

PC

ENGLISH

31

Chapter 3 Using the LCD TV

HDMI2 INHDMI1 IN

AUDI O

LR LR LR

LR

L

RLR

LR

AUDIO

VGA IN

VIDEO2 IN

VIDEO AUDIO

S-VIDEO IN

S-VIDEO AUDIO

YPbPr1 IN

AUDIO OUT

STEREO DIGITAL

OPTICAL

COAXIAL

HDTV/TV

AIR/CABLE

VHF/UHF IN

YPbPr AUDIO

YPbPr2 IN

YPbPr

AUDI O

Audio Receiver Audio Am

p

lifier

A

B

 Connecting to Audio Receiver:

Use an audio cable to connect the audio receiver’s audio LINE IN jacks to LCD TV’s

AUDIO OUT jacks.

 Connecting to Digital 5.1 Sound System:

METHOD A:

Use a optical cable to connect the audio ampliﬁ er’s OPTICAL IN jacks to LCD TV’s

OPTICAL OUT jacks.

METHOD B:

Use a coaxial cable to connect the audio ampliﬁ er’s COAXIAL IN jacks to LCD TV’s

COAXIAL OUT jacks.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

Connecting an Audio Receiver or a Dolby Digital 5.1 Sound System

AUDIO Cable

For better sound quality, you may want to use a Home Theater/Stereo System.

NOTE: If you have a Home Theater/Stereo System that you would like to use with your new TV, we

recommend that you do NOT use your TV’s audio output for this connection. For the best sound

quality, our product testing has shown that you should connect your Home Theater/Stereo System

directly to your A/V device. I.E. You should connect your Home Theater/Stereo System to your DVD

player, Cable/Satellite box or other AV equipment. Although not recommended, if you prefer to use

the TV audio output to make this connection to your Home Stereo System, please follow the

instructions below.

32

Chapter 3 Using the LCD TV

 Turn your LCD TV on.

 Insert a disc (DVD, VCD, SVCD, or audio CD).

NOTE: The printed side of the disk should face the front of the TV.

Using The Built-in DVD

 Press the Input button on the remote, use ▲▼ to select DVD and press

the OK button.

Chapter 3

USING THE FEATURES

Input Source

TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR)

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

 DVD

USB

CARD READER

VIDEO6 (HDMI1)

VIDEO7 (HDMI2)

COMPUTER(VGA)

Insert

Push

 TO INSERT A DISC

Any of the following disc types can be

played on the DVD player: DVD-Video/DVD

R/RW/SVCD/VCD/CD/CD-R/CD-RW.

 TO REMOVE A DISC

When removing the disc, do not

attempt to pull it from its slot. Please

push the EJECT button as

illustrated below.

ENGLISH

33

Chapter 3 Using the LCD TV

 Press GUIDE button on the remote control to display the Built-in DVD Setup Menu:

 USING THE BUILT-IN DVD SETUP MENU

1. Use the ▲▼◄► on the remote control to to move the light bar to the option you want,

press the OK button.

2. During playback, the following operations are available:

 EJECT Stops playback.

 PLAY Starts playback.

 Get slow motion effect during playback

 F.FWD/NEXT Jumps to the previous/next chapter or track.



REW./PREV. Gets different playback forward/backward speeds.

 PAUSE While playing, pause playback temporarily

 AUDIO Press to select the Audio effect and Language.

 SUBTITLE Changes DVD subtitle language. When this icon is

highlighted you must press the OK button to change the

language selections.

 CAMERA ANGLE Press to select the desired camera angle disc.

 The Built-in DVD player can playback JPEG format pictures and audio ﬁ les on a

personally recorded CD-R/RW disc. After loading all ﬁ les, the File Menu will show the

contents of the disc:

00:00

001/015

01 P107001

02 P107002

03 P107003

04 P107004

05 WOFSON

06 HDCP

07 EDIT

 Press ▲▼ to select an image and press the button to play the ﬁ le.

 Press ▲▼ to select the folder and then press ► to enter the folder. Press the ENTER

button to active and press ▲▼ to select a ﬁ le. Press ◄ to back the File Menu.

 While an image is displayed, press the DVD MENU button to display the File Menu.

Using The USB Storage and SD Card Reader

Input Source

TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR)

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

DVD

 USB

CARD READER

VIDEO6 (HDMI1)

VIDEO7 (HDMI2)

COMPUTER(VGA)

Insert Insert

Input Source

TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR)

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

DVD

USB

 CARD READER

VIDEO6 (HDMI1)

VIDEO7 (HDMI2)

COMPUTER(VGA)

34

Chapter 3 Using the LCD TV

 Turn your LCD TV on.

 Insert a USB device/SD card that contains JPG/JPEG/MPG/WMA/DAT ﬁ les.

 Press the Input button on the remote, use ▲▼ to select a input source and

press the OK button.

 TO INSERT A USB STORAGE

Allows the insertion of a USB storage.

You can view digital images or music in

a USB storage on your TV.

 TO INSERT A SD CARD Reader

Allows the insertion of a SD card. You

can view digital images or music.

Be sure to insert the USB storage or SD card in the correct direction. If the USB storage or

SD card is forced in the wrong way, it may cause damage.

 TO INSERT A USB STORAGE  TO INSERT A SD CARD Reader

ENGLISH

35

Chapter 3 Using the LCD TV

 After loading all ﬁ les, the File Menu will show the contents of the USB device:

00:00

001/015

01 P107001

02 P107002

03 P107003

04 P107004

05 WOFSON

06 HDCP

07 EDIT

Do not switch the Input Source between USB and CARD READER while the data is being

read. It may cause data loading failure.

 Press ▲▼ to select an image and press the button to play the ﬁ le.

 Press ▲▼ to select the folder and then press ► to enter the folder. Press the ENTER

button to active and press ▲▼ to select a ﬁ le. Press ◄ to back the File Menu.

 While an image is displayed, press the DVD MENU button to display the File Menu.

  RUNNGING A SLIDE SHOW

1. Press ▲▼ on the remote control to move the light bar to the ﬁ le you want to play,

and press the OK button to play the ﬁ le.

2. While an image is displayed full size, you can pause the slide show by pressing

.

3. Press on the remote control to go to the next or previous image.

 USING THE THUMBNAIL ALBUM

1. Press button on the remote control to display the thumbnail album.

Slide Show ◄Prev Next►

2. Press on the remote control to go to the next or previous image.

.

36

Chapter 3 Using the LCD TV

2. Press ▲▼◄ on the remote control to move the light bar to the image you

want to play, and press the OK button to play the ﬁ le.

3.  Slide Show: Press ▲▼◄ to highlisht Slide Show and press the OK

button, to display all the images recorded on the SD card/USB storage.

 Prev/Next: Press ▲▼◄ to highlisht Prev/Next and press the OK button,

to go to the previous or next page of the thumbnail album.

 ROTATING PICTURES

1. Press ◄► on the remote control to to rotate the picture clockwise or

counterclockwise in 90-degree increments.

Slide Show ◄Prev Next►

ENGLISH

37

Chapter 3 Using the LCD TV

 WIDE

Stretches the image vertically and

horizontally to ﬁ ll the screen at 1:1.85

aspect ratio

Wide Screen function allows viewing of 4:3/16:9 images in wide screen mode, cycling through

the following wide screen settings. Press the ASPECT button repeatedly to select the screen

format you want.

 NORMAL

Displays at 4:3 aspect ratio

 ZOOM

Stretches the image vertically and

horizontally to ﬁ ll the screen at 1:2.35

aspect ratio

Wide Screen Viewing

 FULL

Stretches the image vertically and

horizontally to keeps the image size

consistent in the center of the screen and

stretches the sides

NORMAL is not available when you are watching 720p or 1080i source.

38

Chapter 3 Using the LCD TV

Using the Program Guide

 With the LCD TV connected to a television programming source, press the INPUT button

on the remote control and use the ▲▼ buttons to select TV and press the OK button.

 Press the GUIDE button on the remote control, the Program Guide will appear on the

screen:

The Program Guide feature brings all sorts of information to your screen, such as program title,

program duration, time remaining, rating information, closed caption, availability, etc.

 Press the ◄► button to select the channel.

 Press the ▲▼ button to select the program from a list, the Program Guide provides

introduction about the current program being shown on each channel.

The Program information in the guide is provided by the broadcasters. It may sometimes

include only the channel number, without a program title or description.

 Press the GUIDE button again on the remote control to exit the Program Guide

3-1 7-2 KQED-SD 7-2

Monday 15 January 2007 2:36:26 PM

Today 7:00 PM EYEWITHNESS NEWS 4PM cc

Today 7:30 PM ABC WORLD NEWS cc

Today 9:30 PM ABC’S MONDAY NIGHT FOOTBALL cc

Tomorrow 12:30 AM SPORTSZONE cc

3-1 7-2 KQED-SD 7-2

5:00 PM - 5:30 PM Mon, 20 Jan.

EYEWITHNESS NEWS

Monday 15 January 2007 2:36:26 PM

TV-PG

Today 7:00 PM EYEWITHNESS NEWS 4PM cc

Today 7:30 PM ABC WORLD NEWS cc

Today 9:30 PM ABC’S MONDAY NIGHT FOOTBALL cc

Tomorrow 12:30 AM SPORTSZONE cc

ENGLISH

39

Chapter 3 Using the LCD TV

 Press the button to turn the LCD TV on.

 Press the MENU button on the remote control, the on-screen menu will appear on the

screen. Use the ◄► buttons to select your main menu option.

VIDEO MENU:

AUDIO MENU:

Operating the Menu

▪ If the signal source is VIDEO/S-VIDEO/YPbPr/

HDMI/VGA, the AUDIO MENU appears as:

▪ If the signal source is TV, the AUDIO MENU

appears as:

▪ If the signal source is TV, the VIDEO MENU

appears as:

Allows you to make adjustments to your picture settings.

Allows you to customize the audio options and effects.

▪ If the signal source is Video/S-Video/YPbPr/VGA/

HDMI, the VIDEO MENU appears as:

Audio Select Exit

Bass 50

Treble 50

Balance 0

Sound E ect Surround

Speaker On

Bass 50

Treble 50

Balance 0

Sound E ect Surround

MTS Stereo

SPDIF Type Dolby Digital

Audio Language English

Speaker On

Audio Select Exit

Video Select Exit

Picture Mode User

Contrast 50

Brightness 54

Saturation 54

Hue 0

Sharpness 5

Color Temperature

Noise Reduction Medium

Video Select Exit

Picture Mode User

Contrast 50

Brightness 54

Color Temperature

Noise Reduction Medium

VGA

40

Chapter 3 Using the LCD TV

 Use the ▲▼ buttons to highlight the option of the sub-menu, and press the OK

button. While in adjustment mode, and use the ◄► buttons to change the value of

the item.

 Press the EXIT button to exit the menu.

SETUP MENU:

Allows you to set up a variety of features: Language, Closed Caption, factory reset, Parental Control, sleep

timer.

TV MENU:

Allows you to edit and label channels.

▪ If the signal source is TV, the SETUP MENU

appears as:

▪ If the signal source is HDMI/VGA/Video/S-Video/

YPbPr, the SETUP MENU appears as:

TV Select Exit

Channel Scan

Tuner Mode Cable

Channel Skip

Time Zone Eastern Time

Setup Select Exit

OSD Language English

Time Setup

Closed Caption

Parental

Gamma Middle

Reset Default

Setup Select Exit

OSD Language English

Time Setup

Parental

Gamma Middle

Reset Default

ENGLISH

41

Chapter 3 Using the LCD TV

 Press the button to turn the LCD TV on.

 Press the MENU button on the remote control to display the Main menu, and use the ◄►

buttons to select the VIDEO.

 Use the ▲▼buttons to highlight an individual VIDEO option, use the ◄► buttons to

change the setting, and press the MENU to exit the menu

Customizing the VIDEO Settings

 The VIDEO menu includes the following options:

Picture Mode Cycles among display types: Vivid/Hi-Bright/Cinema/Sport/User

Contrast Controls the difference between the brightest and darkest regions of

the picture

Brightness Controls the overall brightness of the picture

Saturation Controls the color intensity

Hue Controls the difference between the green and red regions of the


Sharpness Increase this setting to see crisp edges in the picture; decrease it for

soft edges

▪ If the signal source is TV, the VIDEO MENU

appears as:

▪ If the signal source is VGA/Video/S-Video/YPbPr/

HDMI, the VIDEO MENU appears as:

Video Select Exit

Picture Mode User

Contrast 50

Brightness 54

Saturation 54

Hue 0

Sharpness 5

Color Temperature

Noise Reduction Medium

Video Select Exit

Picture Mode User

Contrast 50

Brightness 54

Color Temperature

Noise Reduction Medium

VGA

42

Chapter 3 Using the LCD TV

Color temperature Adjusts color components independently to achieve a warm or cool

effect: Cool/Middle/Warm/User

▪ Warm: Increases red tint

▪ Nature : Increases natural tint

▪ Cool : Increases blue tint

▪ User : Allows the user to adjust red, green and blue color

component levels independently.

Noise Reduction Select to reduce the noise level of connected equipment: Off/Low/

Medium/Strong.

VGA Press the OK button to enter the VGA Setting:

▪ Auto Adjust Press the OK button to automatically adjust

the display settings to optimize performance

based on the VGA mode

▪ H. Position Adjusts the position of the picture left and right

in the window

▪ V. Position Adjusts the position of the picture up and down

in the window

▪ Clock Controls the width of the picture based on the

VGA mode

▪ Phase Controls the signal phase, which can improve

focus clarity and image stability based on the

VGA mode

Color Temperature Select Exit

Color Temperature User

R Gain 120

G Gain 120

B Gain 120

VGA Select Exit

Auto Adjust

H.Position 72

V. Position 31

Clock 127

Phase 31

ENGLISH

43

Chapter 3 Using the LCD TV

 Press the button to turn the LCD TV on.

 Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the AUDIO.

 Use the ▲▼buttons to highlight an individual AUDIO option, use the ◄► buttons to

change the setting, and press the MENU to exit the menu

 The AUDIO menu includes the following options:

Bass Controls the relative intensity of lower-pitched sounds

Treble Controls the relative intensity of higher pitched sounds

Balance Adjusts the relative volume of the speakers in a multiple speaker

system

Sound E ect Allows selection of an audio-enhancement technique from among the

following options: Surround/Live/Dance/Techno/Classic/Soft/Rock/

POP/Off

MTS Allows you to listen to high-ﬁ delity stereo sound while watching TV

▪ Stereo:

Use separate audio tracks for left and right speakers, if available

▪ SAP:

You can enjoy a second audio program from the speakers while

watching a scene in the original program

▪ Mono:

Allows mono output (useful when stereo is noisy or inconsistent)

Customizing the AUDIO Settings

▪ If the signal source is VIDEO/S-VIDEO/YPbPr/

HDMI/VGA, the AUDIO MENU appears as:

▪ If the signal source is TV, the AUDIO MENU

appears as:

Audio Select Exit

Bass 50

Treble 50

Balance 0

Sound E ect Surround

Speaker On

Bass 50

Treble 50

Balance 0

Sound E ect Surround

MTS Stereo

SPDIF Type Dolby Digital

Audio Language English

Speaker On

Audio Select Exit

44

Chapter 3 Using the LCD TV

SPDIF Type Allows to selection of the digital sound format: PCM/OFF/Dolby

Digital

▪ PCM:

The external audio system is connected to the AUDIO OUT (L/R)

of the LCD TV

▪ Dolby Digital:

The external audio system is connected to the AUDIO OUT

DIGITAL (OPTICAL or COAXIAL) ot the LCD TV

▪ OFF:

Select OFF to turn off the external audio system

Audio Language Allows to select the audio language:English/Spanish/French.

Speaker Allows to select to turn on or off the TV speakers.

ENGLISH

45

Chapter 3 Using the LCD TV

 Press the button to turn the LCD TV on.

 Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the TV.

 Use the ▲▼buttons to highlight an individual TV option, use the ◄► buttons

changes the setting, and press the MENU exits the menu.

 The TV menu includes the following options:

Channel Scan Press the OK button, the Channel Scanning automatically

creates a list of receivable channels.

Tuner Mode Allows selection between CATV cable and antenna signal sources:

▪ AIR

Choose this setting if you are receiving TV channels with an antenna

(over the air)

▪ Cable

Choose this setting if you are receiving TV channels with a CATV

(cable TV)

Channel Skip Allows addition/removal of channels on the channel list.

 Press the OK button to display the Channel Skip menu:

Customizing the TV Settings

TV Select Exit

Channel Scan

Tuner Mode Cable

Channel Skip

Time Zone Eastern Time

Channel Skip Select Exit

2 ABC Analog

3 DISC Analog

4 Analog

5 Analog

6 Analog

7 Analog

8 Analog

9 Analog

10 Analog

46

Chapter 3 Using the LCD TV

 Press the ▼ button to select the desired channel, andpress the

OK button repeatedly to select show () or hide()

Time Zone Allows selection of regional TV systems of USA: Eastern Time/

Indiana/Central time/Mountain Time/Arizona/Paciﬁ c Time/Alaska/

Hawaii

ENGLISH

47

Chapter 3 Using the LCD TV

 Press the button to turn the LCD TV on.

 Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the SETUP.

 Use the ▲▼buttons to highlight an individual SETUP option, use the ◄► buttons to

change the setting, and press the MENU to exit the menu.

Customizing the SETUP Settings

 The SETUP menu includes the following options:

OSD Language Selects to display all on-screen menus in your language of choice:

English/French/Spanish

Closed Caption Allows to select from analog or digital closed caption modes and

press the OK button. The Closed Captain list appears:

 Analog Closed Caption:

Press the ◄► buttons to select the basic analog closed caption

options: OFF/CC1/CC2/CC3/CC4

▪ CC1 /CC2 /CC3 /CC4:

Display a printed version of the dialog and sound effects of the

program being viewed

▪ If the signal source is TV, the SETUP MENU

appears as:

▪ If the signal source is HDMI/VGA/Video/S-Video/

YPbPr, the SETUP MENU appears as:

Setup Select Exit

OSD Language English

Time Setup

Closed Caption

Parental

Gamma Middle

Reset Default

Setup Select Exit

OSD Language English

Time Setup

Parental

Gamma Middle

Reset Default

Closed Caption Select Exit

Analog Cloaed Caption O

Digital Cloaed Caption O

Digital Caption Style

48

Chapter 3 Using the LCD TV

▪ T1/T2:

Display station information presented using either half or the

whole screen

▪ T3/T4:

Extended Data Services. For example: Network name, program

name, program length, etc.

 Digital Closed Caption:

Press the◄►buttons to select the digital closed caption option.

Note: The setting here will be applied to each DTV channel

 Caption Style:

Press OK button to customize the settings for digital closed

caption option:

Parental The Parental Control can be set up to the TV to block Channel,

Video Source and to change password.

 Use the ▼ button to select the Parental, and press the OK to

display the Parental menu

 Use the Program Block function, must enter a four-digit

password. The factory password is 0000

 The Parental list appears:

 Program Block Allows to setup the TV and MPAA Rating

Lock options (refer to “Using the Program

Block Setting”).

Closed Caption Style Select Exit

Caption Style Custom

Font Size Large

Font Color White

Font Opacity Solid

Background Color Black

Background Opacity Solid

Window Color Black

Window Opacity Translucent

Parental Block Select Exit

U.S.TV Ratings

U.S. Movie Ratings

Canadian English Ratings

Canadian French Ratings

Block MPAA Unrated NO

Block TV Unrated NO

ENGLISH

49

Chapter 3 Using the LCD TV

 Channel Block Allows to block digital channels.

 Input Block Selects to block a Input source signal

 Change Password Selects to change your password

Gamma Allows adjustment of the display’s gamma correction, which

ﬁ netunes both brightness and red/green/blue ratios: On/Off/Middle/

Bright/Dark

Reset Default Press the OK button to restore factory settings

Input Block Set OK Select Exit

Channel Block Set OK Select Exit

2 ABC Analog

3 DISC Analog

4 Analog

5 Analog

6 Analog

7 Analog

8 Analog

9 Analog

10 Analog

1 TV(CABLE/AIR)

2 VIDEO1 (AV)

3 VIDEO2 (S-VIDEO)

4 VIDEO3 (YPbPr1)

5 VIDEO4 (YPbPr2)

6 DVD

7 USB

8 CARD READER

6 VIDEO5 (HDMI1)

7 VIDEO6 (HDMI2)

8 COMPUTER(VGA)

50

Chapter 3 Using the LCD TV

 Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the SETUP.

 Use the ▼ buttons to highlight Parental, and press the OK button.

Using the Program Block Settings

 Use the Parental function, must enter a four-digit password. The factory password is

0000.

 Use the ▼ button to select the Program Block, and press the OK to display the

Program Block menu.

Parental Select Exit

Setup Select Exit

OSD Language English

Closed Caption

Parental

Gamma Middle

Reset Default

Password ****

Parental Select Exit

Program Block

Channel Block

Input Block

Change Password

Program Block Select Exit

U.S.TV Ratings

U.S. Movie Ratings

Canadian English Ratings

Canadian French Ratings

Block MPAA Unrated NO

Block TV Unrated NO

ENGLISH

51

Chapter 3 Using the LCD TV

 The Parental block menu includes the following options:

U.S. TV Ratings Selects to activate the TV Rating programs.

U.S. Movie Ratings Selects to activate the MPAA Rating programs

Canadian English Ratings Selects to activate the English Rating programs of Canada.

Canadian French Ratings Selects to activate the French Rating programs of Canada

Block MPAA Unrated ▪ YES:

Block all movies that are broadcast without a MPAA rating.

▪ NO:

Allows all movies that are broadcast without a MPAA rating

Block TV None Rating ▪ YES:

Block all movies that are broadcast without a TV rating.

▪ NO:

Allows all movies that are broadcast without a TV rating.

52

Chapter 3 Using the LCD TV

CONTENT-BASED

FV D L S V

AGE-BASED

TV-Y

TV-Y7 

TV-G

TV-PG 

TV-14 

TV-MA 

 : To block programs by both content and age.

The U.S.TV Rating has 2 rating methods: Content-Based Rating and Age-Based Rating.

The U.S.TV Rating includes the following options:

Use the ◄►▲▼ buttons to select the rating you want and press the OK button repeatedly to

select BLOCK or UNBLOCK .

AGE-BASED

RATING DESCRIPTION

TV-Y All children

TV-Y7 Directed to children age 7 and older

TV-G General Audience

TV-PG Parental Guidance suggested

TV-14 Parents strongly cautioned

TV-MA Mature Audience only

CONTENT-BASED

RATING DESCRIPTION

FV Fantasy violence

D Suggestive dialogue

L Strong language

S Sexual situations

V Violence

ALL All contents are blocked

U.S. TV Ratings

U.S. TV Ratings Set OK Select Exit

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

A D L S V FV

Allowed Rating Blocked Rating

Note:

When a channel is blocked the user can

unblock the channel by entering the password.

Press the OK button and enter the password

to watch that channel. Once the channel is

changed and you return to it, they must re-

enter the password.

ENGLISH

53

Chapter 3 Using the LCD TV

The Canadian Englsh Ratings includes the following options:

RATING DESCRIPTION

G All children

C8+ Children 8 years and older

G General programming

PG Parental guidance

14+ Viewers 14 and older

18+ Adult programming

Canadian English Ratings

Use the ◄►▲▼ buttons to select the rating you want and press the OK button repeatedly to

select BLOCK or UNBLOCK .

The Canadian French Ratings includes the following options:

RATING DESCRIPTION

G General programming

8 ans+ Not recommended for ages under 8

13 ans+ Not recommended for ages under 13

16 ans+ Not recommended for ages under 16

18 ans+ Programming restricted to adults.

Canadian French Ratings

Use the ◄►▲▼ buttons to select the rating you want and press the OK button repeatedly to

select BLOCK or UNBLOCK .

Canadian English Ratings Set OK Select Exit

G

C8+

G

PG

14+

18+

Allowed Rating Blocked Rating

Canadian French Ratings Set OK Select Exit

G

8 ans+

13 ans+

16 ans+

18 ans+

Allowed Rating Blocked Rating

54

Speci cations

The U.S. Movie Ratings is used for original movies rated by the Motion Picture Association of

America(MPAA) as broadcasted on cable TV and not edited for television.

The U.S. Movie Ratings includes the following options:

RATING DESCRIPTION

G General Audiences. Movie is appropriate for all ages

PG Parental Guidance Suggested. May contain material not suited for younger

viewers

PG-13 Contains content that may not be appropriate for viewers under the age of

13

R Restricted. Contains adult content, no one under 17 admitted without

parent

NC-17 No one 17 and under admitted

X No one 17 and under admitted

U.S. Movie Ratings

Use the ◄►▲▼ buttons to select the rating you want and press the OK button repeatedly to

select BLOCK or UNBLOCK .

Canadian English Ratings Select Exit

G

PG

PG-13

R

NC-17

X

Allowed Rating Blocked Rating

ENGLISHENGLISHENGLISH

55

Speci cations

SPECIFICATIONS

MODEL TDA-03211C

LCD Panel Panel Size 32” TFT LCD

Brightness 500 cm2

Contrast Ratio 1200:1

Max. Resolution 1366x768

Input Connector VIDEO/AUDIO(L/R) 2

S-VIDEO/AUDIO(L/R) 1

YPbPr/AUDIO(L/R) 2

VGA/AUDIO(L/R) 1

HDMI/AUDIO(L/R) 2

AUDIO OUT(L/R) 1

OPTICAL/COAXIAL 1

HEADPHONE 1

Built-in DVD 1

USB Connector 1

SD Card Reader 1

Power Source AC100~240V, 50/60HZ, 4.0A

Power Consumption 180 W, standby < 1 W

Dimension 31.7 w x 25.0 h x 8.4 d inch

WEIGHT 39.5 LB

20070411

56

Programming Your Remote Control

PROGRAMMING YOUR REMOTE CONTROL

Your remote lets you control four devices with one easy-to-use, compact unit. After installing

batteries, you can program the remote to control your Universal TV, VCR or DVD, Cable or Satellite

Receivers, Ampliﬁ er or Tuner, and Auxiliary devices. To do so, follow the instructions in

“Programming a Device”. For best results, please read and follow all the remaining instructions.

Keep this guide for future reference.

A Quick Look at Programming a Device

To control VCR or DVD, Cable or Satellite Receivers, Ampliﬁ er or Tuner, and Auxiliary devices,

follow these steps. Before proceeding, ﬁ nd the codes for the devices you want to program in

“Manufacturer’s Codes” on the right side of this page and write them down or highlight them.

 Turn on the device (for example, DVD player) and, if needed, load media (for

example, a DVD).

 Press a device key (VCR/DVD, CBL/ SAT, or AUX).

 Press and hold SET UP until the red LED blinks twice; then release.

 Enter the ﬁ rst ﬁ ve-digit code for your device. The LED blinks once as each digit is

entered. If the code is correct, the LED blinks twice.

To program a DVD Player, TV/DVD Combo, TV/VCR/DVD Combo, portable DVD

player, or mobile DVD player, use the DVD key.

If the LED does not blink twice, repeat steps 2 to 4 and try entering the

code again.

 Aim the remote at the device and press . The device should turn off. If it does not,

repeat steps 3–5, trying each code for your brand until you ﬁ nd one that works. If

you cannot ﬁ nd a code that works, see “Searching for Your Code”.

 Repeat steps 1–5 for the other devices you want to control. For future reference,

write down each working device code below:

AUX Code:

CBL Code:

CD Code:

DVD Code:

SAT Code:

TNR Code:

VCR Code:

 Press set to save and exit.

ENGLISHENGLISHENGLISH

57

Programming Your Remote Control

For example, to ﬁ nd out which code is assigned to your TV:

Searching for your Code

If your device does not respond to the remote after trying all codes listed for your brand, or if

your brand is not listed, try searching for your code:

 Press a device key once.

 Press and hold SET UP until the red LED blinks twice; then release.

 Enter 9-9-1, then the device group number (0= Cable, 1= TV, 2= VCR, 3= Audio).

The LED blinks twice.

 Aim the remote at the device and press . The remote sends IR codes from its

library to the selected device, starting with the most popular code ﬁ rst. If the device

responds, go to step 7.

 If the device does not respond, press CH▲. The remote will try the next code.

Continue until the device responds. Press CH▼ to try the previous code.

 To search for other device codes, repeat steps 1 to 5.

 Press SET UP to save and exit.

 Press TV once.

 Press and hold SET UP until the red LED blinks twice; then release.

 Enter 9-9-0. The LED blinks twice.

 To view the code for the ﬁ rst digit, press 1. Count the LED blinks (for example, three

blinks = 3), and write down the number in the appropriate code listing in step 8

under “Programming a Device”.

If a code digit is 0, the LED does not blink.

 Repeat step 4 for the four remaining digits, using 2 for the second digit, 3 for the

third digit, 4 for the fourth digit, and 5 for the ﬁ fth digit.

Changing Volume Lock

The remote comes preset to allow independent volume control of each selected device (Global Volume

Unlock). However, you may change the Volume Lock setting to Global Volume Lock so that one

device’s volume will control volume in all other modes. After that, you can perform Individual Volume

Unlock on a selected device to set its volume control for independent operation or Global Volume

Unlock to remove all volume locking.

Checking the Codes

If you have set up the remote using the procedure in “Searching for Your Code”, you may need to ﬁ nd

out which four-digit code is operating your equipment.

58

Programming Your Remote Control

 Press and hold SET UP until the red LED blinks twice; then release.

 Enter 9-9-3 and then press the mode key for the device you want to control volume (for

example,TV). The LED blinks twice. Now when you press VOL+, VOL-, or Mute, the selected

device (for example, TV) will control the volume regardless of the current mode.

Changing Volume Lock

The remote comes preset to allow independent volume control of each selected device (Global

Volume Unlock). However, you may change the Volume Lock setting to Global Volume Lock so that

one device’s volume will control volume in all other modes. After that, you can perform Individual

Volume Unlock on a selected device to set its volume control for independent operation or Global

Volume Unlock to remove all volume locking.

Unlocking All Volume Control (Restoring Global Unlock)

 Press and hold SET UP until the red LED blinks twice; then release.

 Enter 9-9-3 and then press VOL+. The LED blinks four times.

Volume is now independently controlled for all programmed devices.

Unlocking a Single Device’s Volume Control

 Press a device key (TV, VCR/DVD, CBL/ SAT, or AUX).

 Press and hold SET UP until the red LED blinks twice; then release.

 Enter 9-9-3 and then press VOL-. The LED blinks four times. Volume is now

independently controlled for the selected devices.

Locking Volume Control to One Mode (Global Volume Lock)

Troubleshooting

PROBLEM

LED does not blink when you press a key.

LED blinks when you press a key, but

device does not respond.

LED blinks one long blink.

Remote does not control devices or

commands are not working properly.

CH▲, CH▼, and LAST do not work for your

RCA TV.

No volume on a device.

Channels do not change properly.

SOLUTION

 Replace battery with new AAA size battery.

 Make sure the remote is aimed at your device and is not more

than 15 feet away

 An entry error has occurred (for example, wrong key). Try entry

sequence again.

 Try all listed codes for the device. Make sure the device operates with

an infrared remote control.

 Due to RCA design from 1983 to 1987, only the original remote

control will operate these functions.

 See “Changing Volume Lock”.

 If the original remote control required you to press Enter to

change channels, press Enter on this remote after entering the

channel number.

ENGLISHENGLISHENGLISH

59

Programming Your Remote Control

A-Mark 0008, 0144

ABC 0237, 0003, 0008

Accuphase 0003

Acorn 0237

Action 0237

Active 0237

Americast 0899

Archer 0237

BCC 0276

Bell South 0899

British Telecom 0003

Century 0008

Digeo 1187

Director 0476

Fosgate 0276

GE 0144

General Instrument 0476, 0810, 0276, 0003

Gibraltar 0003

GoldStar 0144

Hamlin 0009

Hitachi 0003, 0008, 0009

Insight 0476, 0810

Jerrold 0476, 0810, 0276, 0003

Memorex 0000

Mitsubishi 0003

Motorola 0476, 1376, 0810, 0276, 1187

Manufacturer Code

Adcom 0577, 1100

Aiwa 0406

Arcam 0269

Bose 0674

Carver 0892, 0269

Cinema Sound 0160

Curtis Mathes 0300

Denon 0160

Durabrand 1561

Elan 0647

GE 0078

Grundig 0269

Harman/Kardon 0892

JVC 331

Left Coast 0892

Lenoxx 1561

Linn 0269

Luxman 0165

Magnavox 0269

Marantz 0892, 0269, 0321

McIntosh 0251

Micromega 0269

Audio Ampliﬁ ers

Manufacturer’s setup codessetup codes

Modulaire 0395

NEC 0264

Naim 0269

Nakamichi 0321

Optimus 0013, 0300, 0823, 0395

Panasonic 0308, 0521

Pass Labs 0269

Philips 0892, 0269

Pionee 0013, 0300, 0823

Polk Audio 0892, 0269

RCA 0013, 0300, 0823

RadioShack 0395

Realistic 0013, 0395, 0220

Revox 0269

Sansui 0321

Shure 0264

Sony 0815, 0220, 0689

Soundesign 0078

Technics 0308, 0521

Victor 0331

Wards 0013, 0078

Yamaha 0354, 0133

Manufacturer Code

Cable Converters

Nova Vision 0008

Novaplex 0008

Pace 0877, 1877, 0237, 0008

Panasonic 0000, 0008, 0144, 0107

Paragon 0000, 0008, 0525

Penneys 0000

Philips 1305, 0317

Pioneer 0877, 1877, 0144, 0533

Pulsar 0000

Quasar 0000

Regal 0276, 0279

Runco 0000

Samsung 0003, 0144

Scientiﬁ c Atlanta 0877, 1877,0477,

0237, 0003, 0000, 0008

Son 1006

Sprucer 0144

Starcom 0003

Supercable 0276

Time Warner cable 1877

Torx 0003

Toshiba 0000

US Electronics 0276, 0003, 0008

United Cable 0276, 0003

Videoway 0000

Zenith 0000, 0008, 0525, 0899

Manufacturer Code Manufacturer Code

Manufacturer CodeManufacturer Code

60

Programming Your Remote Control

ADC 0531

AMC 1077

AMW 1563, 1615

Aiwa 1243, 1405,1388, 1641,

0189, 0121, 0405, 0158

Akai 1255, 1512, 0244, 0346

Alco 1390

Amphion Media Works 1563, 1615

Anam 1609, 1074

Apex 1257

Apex Digital 1774, 1257, 1430

Arcam 1189, 1120

Audiotronic 1189

Audiovox 1390, 1627

B & K 0820, 0840, 0701, 0702

BK 0702

Bose 1229, 0639, 1253

Brix 1602

Cairn 0189

Cambridge Soundworks 1370

Capetronic 0531, 0195

Carver 1189, 0189, 0121, 1289,

0042, 0360, 0008

Casio 0195

Clarinette 0195

Classic 1352

Coby 1389

Compaq 1136

Criterion 1420

Curtis Mathes 0014, 0080, 0039

Daewoo 1250

Dell 1383

Delphi 1414

Denon 1142, 1360, 1306, 0121,

0004

Emerson 0531, 0195, 0424

Fisher 1801, 0801, 0042, 0360,

0219, 0008

Garrard 0463, 0424

Gateway 1517, 1567

Go Video 1352, 1532

Grundig 0189

Harman/Kardon 0110, 1304, 1306, 0891,

0189, 1289

Hewlett Packard 1181

Hitachi 1273, 1801

Initial 1426

Inkel 0491

Integra 0842, 0135, 1320, 1298

JBL 0110, 1306

JVC 1058, 1374, 1495, 1811,

0074

KLH 1428, 1390, 1412

Kawasaki 1390

Audio Amp/Tuners

Kenwood 1313, 1570,1569, 0186,

0042, 0239, 0027, 0077

Koss 1497, 1366, 0424

LG 1293

LXI 0181

Lasonic 1798

Lenoxx 1437

Lexicon 1076

Linn 0189

Liquid Video 1497

Lloyd’s 0195

Lloyds 0195

MCS 0039, 0346

Magnavox 1189, 1269, 0531,1266,

0189, 1514, 0195,

0391,1120

Marantz 1189, 1269, 0891, 0189,

1289, 1120, 0039

McIntosh 289

Micromega 1189, 0189

Mitsubishi 1393

Modulaire 0195

Myryad 1189

NAD 0320

Nakamichi 1313, 0097, 1555, 0347

New Castle 0502

Nikko 0322

Nikkodo 0322

Norcent 1389

Nova 1389

Onkyo 0842, 0135, 1320, 1298,

1531

Optimus 1023, 0531, 0014,1074,

0670, 0121, 0186, 0080,

0195, 0738, 0801, 0042,

0181, 0502, 0219, 0158,

0074, 0163, 0177

Oritron 1497, 1366

Outlaw Audio 0391

Panasonic 1308, 1518, 1548,1288,

1316, 1763, 1764, 1633,

0309, 0367, 0039

Penney 0195

Penneys 0195, 0039

Philips 1189, 1269, 0891,1266,

0189, 0391, 1120

Pioneer 1023, 1384, 0531, 0014,

0150, 0630, 0080, 0801,

0244, 0346

Polaroid 1508

Polk Audio 0189, 1289, 1414

Proscan 1254, 0054

Quasar 0039

RCA 1023, 1609, 1254, 0531,

1511, 1390, 1074, 0080,

Manufacturer Code Manufacturer Code

ENGLISHENGLISHENGLISH

61

Programming Your Remote Control

RadioShack 1609, 0181

Realistic 1609, 0121, 0186, 0195,

0042, 0181, 0158, 0163,

0177

Regent 1437

Revox 0189

Rio 1869, 1383

Rio Audio 1383

Saba 1519

Samsung 1295, 1500

Sansui 1189, 0189, 0346

Sanyo 1801, 1469, 1251, 0801,

0360, 0219

Scott 0322, 0163

Sears 0195, 0424

Sharp 0186, 1286

Sharper Image 1556

Sherwood 1077, 1653, 0491, 0502,

1423

Shinsonic 1426

Siemens 0424

Sirius 1811, 1602, 1627

Sonic Blue 1869, 1532, 1383

Manufacturer Code Manufacturer Code

Altec Lansing 1485

Cambridge Soundworks 1530

Creative 0872

D-Link 1522

Imerge 1491

Integra 1789

Jerrold 0520

Miscellaneous Audio

Marantz 1491

Motorola 1464

Netgear 1785

Omniﬁ 1605

Onkyo 1789

SSI 1522

Yamaha 1809, 1810

Sony 1058, 1441, 1258, 1759,

1758, 1622, 1858, 1658,

1558, 1406, 0405, 0474,

1349, 1442, 0158

Soundesign 0670

Stereophonics 1023

Sunﬁ re 1313

Teac 1267, 1390,1074, 1528,

0463, 0163

Technics 1308, 1518,1633, 0309,

0039

Thorens 1189

Toshiba 0842, 0135, 0080

Venturer 1390

Victor 0074

Waitec 1352

Wards 0014, 0189,0080, 0042,

0054, 0158

XM 1406, 1414

Yamaha 1023, 0176,1176, 1375,

1331, 1276, 0186

Yorx 0195

Zenith 1293, 0857, 0346

Audio Amp/Tuners

AlphaStar 0772

Bell ExpressVu 0775

Chaparral 0216

DirecTV 0566, 0639, 1639, 1640,

0247, 0749, 1749, 1142,

1442, 0724, 0819, 1856,

1108,1609, 0392, 1392,

1076, 0099

Dish Network 0775

Dish Network System 0775, 1775, 1005, 1505

Dishpro 0775, 1775, 1005, 1505

Echostar 0775, 1775, 1005, 1505

Expressvu 0775, 1775

Satellite Receivers

GE 0566, 0392

GOI 0775, 1775

General Instrument 0869

Goodmans 1246

HTS 0775, 1775

Hitachi 1250, 0749, 0819

Houston tracker 0775

Hughes 0749, 1749, 1142, 1442

Hughes Network Systems 0749,1749, 1142, 1442

Innova 0099

JVC 0775, 1775

Jerrold 0869

LG 1226

Manufacturer Code Manufacturer Code

62

Programming Your Remote Control

Magnavox 0724, 0722

McIntosh 0869

Memorex 0724

Mitsubishi 0749

Motorola 0869, 0856

NEC 1270

Netsat 0099

Next Level 0869

Optimus 0724

Panasonic 0701, 0247

Paysat 0724

Philips 0749, 1749, 1142, 1442,

0775, 0724, 0722, 0819,

1076, 0099

Pioneer 1142, 1442

Primestar 0869

Proscan 0566, 0392

RCA 0566, 1142, 1442, 0775,

0143, 0855, 0392, 1392

RadioShack 0566, 0775, 0869

SKY 0856, 0099

Samsung 1142, 1442, 1276, 1108,

1609

Sanyo 1219

Sony 0639, 1639, 1640

Star Choice 0869

Star Trak 0772, 0869

Thomson 0566, 0392

Tivo 1142, 1442

Toshiba 0749, 1749, 0790, 1285,

0819

UltimateTV 1640, 1392

Uniden 0724, 0722

Voom 0869

Zenith 0856, 1856

TVs

A-Mark 0047, 0054

AOC 0180, 0030

Accuscan 0047

Action 0030

Admiral 0463, 0180, 0047,0054,

0017, 0051, 0093

Advent 0761, 0783, 0815,0817,

0842

Adventuri 0000

Agna 0150

Aiko 0092

Akai 0060, 0702,0672, 0030,

0145, 0812

Albatron 0700, 0843

Alﬁ de 0672

Alleron 0030

Ambassador 0150

America Action 0180

American High 0000, 0060

Amstrad 0171

Amtron 0000, 0180

Anam 0180

Apex 0156, 0748, 0765

Apex Digital 0156, 0748, 0765,0879,

0767

Audinac 0180

Audiovox 0451, 0180, 0092, 0623

Aumark 0060

Aventura 0171

Baysonic 0180

Beaumark 0017, 0030, 0178

Belcor 0030

Bell & Howell 0054, 0154, 0093

Bell and Howell 0054, 0154, 0093

BenQ 1756, 1032

Bradford 0180

Brockwood 0030, 0178

Broksonic 0236, 0463, 0180

CXC 0180

Candle 0030

Capehart 0017, 0030, 0178, 0092

Capetronic 0030

Carnivale 0030

Carver 0054

Celebrity 0000

Celera 0765

Changhong 0156,0765, 0783, 0767

Cineral 0451, 0092

Citek 0047

Citizen 0054, 0000, 0451, 0463,

0180,0060, 0030, 0092,

0171

Clarion 0180

Classic 0030, 0092

Colortyme 0047, 0054, 0017, 0060,

0030, 0178

Commercial Solutions 0047, 1447

Conic 0178

Contec 0180

Craig 0180, 0171

Crosley 0054, 0000, 0180, 0030,

0171

Crown 0093, 0180, 0672

Crown Mustang 0672

Manufacturer Code Manufacturer Code

ENGLISHENGLISHENGLISH

63

Programming Your Remote Control

Curtis Mathes 0047, 0054, 0154, 0000,

0051, 0451, 0093, 0180,

0060, 0702, 0030, 0178,

0145, 0166, 1147, 1347

Daewoo 0451, 1661, 0672, 0178,

0092, 0623, 1755,1756,

0661

Dayton 0092

Daytron 0030, 0178, 0092

Dell 1454

Denon 0511, 0145

Dumont 0017, 0180, 0178

Durabrand 0463, 0180, 0178, 0171,

1034, 1463

Dwin 0093

ESA 0171, 0812

Eaton 0060

Electroband 0000

Electrograph 1755

Electrohome 0154, 0000, 0150,0030,

0178

Emerald 0178

Emerson 0047, 0154, 0451, 0236,

0463, 0180, 0150, 0178,

0171, 0623

Envision 0030

Fisher 0054, 0154, 0000

Fortress 0093

Funai 0000, 0180, 0171

Futuretech 0180

GE 0047, 0000, 0051,0451,

0060, 0030, 0178, 1147,

1347, 1447

Gateway 1755, 1756

Gemini 0047

Gibraltar 0017, 0000, 0030

Gibralter 0017, 0030Go

A-Mark 0047, 0054

AOC 0180, 0030

Accuscan 0047

Action 0030

Admiral 0463, 0180, 0047, 0054,

0017, 0051, 0093

Advent 0761, 0783, 0815, 0817,

0842

Adventuri 0000

Agna 0150

Aiko 0092

Akai 0060, 0702, 0672, 0030,

0145, 0812

Albatron 0700, 0843

Alﬁ de 0672

Alleron 0030

Ambassador 0150

America Action 0180

American High 0000, 0060

Amstrad 0171

Amtron 0000, 0180

Anam 0180

Apex 0156, 0748, 0765

Apex Digital 0156, 0748, 0765, 0879,

0767

Audinac 0180

Audiovox 0451, 0180, 0092, 0623

Aumark 0060

Aventura 0171

Baysonic 0180

Beaumark 0017, 0030, 0178

Belcor 0030

Bell & Howell 0054, 0154, 0093

Bell and Howell 0054, 0154, 0093

BenQ 1756, 1032

Bradford 0180

Brockwood 0030, 0178

Broksonic 0236, 0463, 0180

CXC 0180

Candle 0030

Capehart 0017, 0030, 0178, 0092

Capetronic 0030

Carnivale 0030

Carver 0054

Celebrity 0000

Celera 0765

Changhong 0156, 0765, 0783, 0767

Cineral 0451, 0092

Citek 0047

Citizen 0054, 0000, 0451, 0463,

0180,0060, 0030, 0092,

0171

Clarion 0180

Classic 0030, 0092

Colortyme 0047, 0054, 0017, 0060,

0030, 0178

Commercial Solutions 0047, 1447

Conic 0178

Contec 0180

Craig 0180, 0171

Crosley 0054, 0000, 0180, 0030,

0171

Crown 0093, 0180, 0672

Crown Mustang 0672

Curtis Mathes 0047, 0054, 0154, 0000,

0051, 0451, 0093, 0180,

0060,0702, 0030, 0178,

0145, 0166, 1147, 1347

Daewoo 0451, 1661, 0672, 0178,

0092, 0623, 1755, 1756,

0661

Dayton 0092

Daytron 0030, 0178, 0092

Manufacturer Code Manufacturer Code

64

Programming Your Remote Control

Dell 1454

Denon 0511, 0145

Dumont 0017, 0180, 0178

Durabrand 0463, 0180, 0178, 0171,

1034, 1463

Dwin 0093

ESA 0171, 0812

Eaton 0060

Electroband 0000

Electrograph 1755

Electrohome 0154, 0000, 0150, 0030,

0178

Emerald 0178

Emerson 0047, 0154, 0451,0236,

0463, 0180, 0150, 0178,

0171, 0623

Envision 0030

Fisher 0054, 0154, 0000

Fortress 0093

Funai 0000, 0180, 0171

Futuretech 0180

GE 0047, 0000, 0051, 0451,

0060, 0030, 0178,

1147,1347, 1447

Gateway 1755, 1756

Gemini 0047

Gibraltar 0017, 0000, 0030

Gibralter 0017, 0030Go

Video 0060

GoldStar 0047, 0054, 0030, 0178

Goodmans 0360

Gradiente 0053

Logik 0236, 0180

MGA 0150, 0030, 0178

MGN Technology 0178

MTC 0180, 0060, 0030, 0092

Magnasonic 0054,0000, 0156, 0093,

0030, 0092

Magnavox 0047, 1454, 0054,0154,

0000, 0051, 0250, 0180,

0060, 0030, 0092, 0171,

0706, 1254, 1755

Majestic 0017

Marantz 1454, 0054, 0030

Matsushita 0051, 0250, 0650

Maxcent 1755, 1756

Maxent 1755

Megapower 0700

Megatron 0047, 0178, 0145

Memorex 0154, 0463,0180, 0150,

0060, 0030, 0178

Micro Genius 0150

Midland 0047, 0017, 0051

Mitsubishi 0154, 0093, 0150, 1250,

0030, 0178, 0836

Monivision 0700, 0843

Motorola 0054, 0051, 0093, 0150

Multitech 0180

NAD 0156, 0178, 0166, 1156,

0866

NEC 0047, 0030, 0178, 1704

NTC 0092

NetTV 1755

Nikko 0047, 0017, 0154, 0156,

0030, 0178, 0092, 1347

Nikkodo 0030, 0178, 0092

Nishi 0030

Norcent 0748

Nyon 0000

Onwa 0180

Optimus 0154, 0250, 0093,0180,

0150, 0030, 0178, 0166,

0650, 0679

Optonica 0093

Orion 0017, 0236, 0463, 0180,

0178, 1463

PCE 0156, 0060

Pace 0092

Panasonic 0047, 0054, 0154, 0000,

0156, 0051, 0250, 0093,

0236, 0150, 0060, 0053,

0030, 0178, 0145,1347,

0650

Panda 0706

Paxonic 0060, 0030

Penney 0047, 0156, 0051, 0060,

0030, 0178, 1347

Penneys 0047, 0000, 0156, 0051,

0250, 0060, 0030, 0178

Petters 1523

Philco 0054, 0463, 0030, 0145

Philips 1454, 0054, 0017, 0000,

0030, 0171, 1254, 0690

Pilot 0051, 0060, 0030, 0178

Pioneer 0166, 0866, 0679

Polaroid 0765, 0865, 1523

Portland 0451, 0092

Precision 0236, 0180

Prima 0761, 0783, 0815, 0817

Princeton 0700

Prism 0051, 0250

Proscan 0047, 0030, 1347, 1447

Proton 0178

Pulsar 0017, 0092

Pulser 0178, 0092

Quartz 0150, 0178

Quasar 0051, 0250, 0650

Manufacturer Code Manufacturer Code

ENGLISHENGLISHENGLISH

65

Programming Your Remote Control

RCA 0090, 1547, 0047, 0054,

0000, 0051, 0093, 0178,

1047, 1147, 1247, 1347,

1447, 0679

Rabbit 0047

RadioShack 0047, 0154, 0180, 0150,

0030, 0178

Realistic 0047, 0154, 0180, 0150,

0030, 0178

Runco 0017, 0060, 0030

SR2000 0154, 0171

SSS 0180

SV2000 0054

SVA 0748, 0865

Sampo 0047, 0030, 1755, 1756

Samsung 0047, 0054, 0017, 0154,

0060, 0702, 0030, 0178,

1060, 0812

Sanky 0060, 0030

Sansui 0463, 0060, 0030

Sanyo 0088, 0047, 0054, 0154,

0000, 0463, 0171, 1755

Saville 0060

Scotch 0178

Scott 0236, 0180, 0030, 0178

Sears 0047, 0054, 0017, 0154,

0000, 0156, 0051, 0093,

0060, 0053, 0030, 0178,

0171, 0166

Sharp 0054, 0093, 0180

Sheng Chia 0093

Shivaki 0178

Siemens 0145

Signature 0054

Signature 2000 0047,0093,0030

Simpson 0030, 0178

Singer 0060, 0092

Solar Drape 0000

Sony 1100, 0017, 0154, 0000,

0150, 0053

Soundesign 0180, 178

Spectravision 0156, 0178

Squareview 0171

Starlite 0236, 0180

Studio Experience 0843

Supreme 0000

Sylvania 0047, 0054, 0154,0000,

0051, 0030, 0178, 0092,

0171

Symphonic 0000, 0180, 0178, 0171

TMK 0236, 0180, 0178

TNCi 0017

TVS 0463

Tandy 0093

Tatung 0000, 0051, 1756

Teac 0154, 0706

Technics 0047, 0054, 0017, 0051,

0250,1347, 0650

Technovox 0030

Techwood 0051, 0250, 0060

Teknika 0054, 0463, 0180, 0150,

0060, 0178, 0092

Telecolor 0017

Telefunken 0702

Thomas 0047, 0178

Thomson 0047, 1447

Tocom 0156

Toshiba 0154, 0156, 0150,1265,

0060, 0145, 0166, 1145,

1156, 1256, 1356, 1656,

1704, 0650

Totevision 0051

Toyomenka 0178

Truetone 0051, 0250

Ultra 0092

Universal 0047

V 1755, 1756

Vector Research 0030

Victor 1100, 0053

Vidikron 0054

Vidtech 0178

Viewsonic 1755

Viking 0060

Visio 1755, 1756

Vizio 1756

Wards 0047,0054,0017, 0154,

0000, 0156, 0051, 0093,

0236,0180, 0060, 0030,

0178, 0166, 1147, 1347,

1156, 0866

Waycon 0156

Welton 0178

Westinghouse 0451

White Westinghouse 0451, 0236, 0463, 0623

World 0451, 0236, 0463, 0180

XR1000 0154, 0180, 0171

Yamaha 0030

Yorx 0030

Zenith 0047, 0017, 0000, 0093,

0463, 0030, 0178, 0145,

0092, 0171, 1145, 0812

Manufacturer Code Manufacturer Code

66

Programming Your Remote Control

VCRs

A-Mark 0000, 0037, 0240

ABS 1972

Admiral 0209, 0060, 0048, 0039,

0047, 0104

Adventura 0000, 0037, 0240

Adyson 0072

Aiwa 0124, 0000, 0037

Akai 0175, 0041

Alba 0209, 0072

Alienware 1972

Allegro 0039

American High 0035, 0081

Amstrad 0000

Asha 0240

Astra 0035, 0240

Audiovox 0037

Avis 0000, 0072

Beaumark 0240

Bell & Howell 0000, 0035, 0048, 0039,

0104

Bell and Howell 0000, 0035, 0048, 0039,

0104

Broksonic 1479, 0184, 0121, 0209

CCE 0072

Calix 0037

Candle 0037

Canon 0035

Carrera 0240

Carver 0035, 0081

Citizen 1278, 0000, 0035, 0037,

0240, 0209

Classic 0037

Colortyme 0035, 0060, 0045

Colt 0000, 0072

Craig 0037, 0047, 0240, 0072

Criterion 0000, 0072

Crosley 0000, 0035, 0081

Crown 0072

Curtis Mathes 1035, 0000, 0035, 0060,

0162, 0240, 0041

CyberPower 1972

Cybernex 0240

Daewoo 1278, 0037, 0045

Daytron 0037

Dell 1972

Denon 0081, 0042

Derwant 0041

DirecTV 0739

Dual 003, 0000

Dynatech 0000, 0240

Electrohome 0000, 0060, 0037, 0240,

0043, 0209

Electrophonic 0037

Emerald 0184, 0121

Emerex 0032

Emerson 1479, 1278, 0000, 0037,

0184, 0240, 0121, 0043,

0209

Fisher 0000, 0039, 0047, 0104

Fuji 0035, 0033

Fujitsu 0000

Funai 0000, 0037, 0072

GE 1035, 1060, 0807, 0000,

0035, 0060, 0048, 0240

Garrard 0000

Gateway 1972

Gemini 0060

Genexxa 0000, 0037

Go Video 0614, 0240

GoldStar 1237, 0000, 0035, 0037,

0039

Granada 0081, 0042

Grundig 0081

HI-Q 0000, 0035, 0047

HP 1972

Harley Davidson 0000

Harman/Kardon 0081

Harvard 0072

Harwood 0072

Hewlett Packard 1972

Hitachi 0089, 0000, 0035, 0037,

0045, 0042, 0041

Howard Computers 1972

Hughes Network Systems 0739, 0042

Humax 0739

Hush 1972

Hytek 0000, 0047, 0072I

TT Nokia 0240, 0041

JVC 0067, 0041

Janeil 0240

Jensen 0067, 0041

KEC 0037

KLH 0072

KTV 0000

Kenwood 0067, 0041

Kodak 0035, 0037

LG 0037, 0240

LXI 0000, 0037, 0042, 0067

Linksys 1972

Lloyd’s 0000

Lloyds 0000, 0240, 0072

Loewe 0081

Logik 0000, 0240, 0072

M Electronic 0240

MEI 0035

MGA 0060, 0240, 0043

Manufacturer Code Manufacturer Code

ENGLISHENGLISHENGLISH

67

Programming Your Remote Control

MGN Technology 0240

MTC 0000, 0240, 0072

MTX 0000

Magnasonic 1278, 0000, 0037, 0240,

0072

Granada 0081, 0042

Grundig 0081

HI-Q 0000, 0035, 0047

HP 1972

Harley Davidson 0000

Harman/Kardon 0081

Harvard 0072

Harwood 0072

Hewlett Packard 1972

Hitachi 0089, 0000, 0035, 0037,

0045, 0042, 0041

Howard Computers 1972

Hughes Network Systems 0739, 0042

Humax 0739

Hush 1972

Hytek 0000, 0047, 0072

IKEC 0037

KLH 0072

KTV 0000

Kenwood 0067, 0041

Kodak 0035, 0037

LG 0037, 0240

LXI 0000, 0037, 0042, 0067

Linksys 1972

Lloyd’s 0000

Lloyds 0000, 0240, 0072

Loewe 0081

Logik 0000, 0240, 0072

M Electronic 0240

MEI 0035

MGA 0060, 0240, 0043

MGN Technology 0240

MTC 0000, 0240, 0072

MTX 0000

Magnasonic 1278, 0000, 0037, 0240,

0072

Magnavox 1781, 0000, 0618, 0035,

0037, 0048, 0039, 081,

0240

Magnin 0035, 008,0240

Marant1 Marta 0037

Matsui 0037, 0209

Matsushita 0035, 0081, 0162

Media Center PC 1972

Memorex 1237, 0000, 0035, 0037,

0048, 0039, 0047, 0162,

0240, 0104, 0209, 0072

Metz 0037

Microsoft 1972

Midland 0240

Mind 1972

Minolta 0042

Mitsubishi 0807, 0000, 0060, 0048,

0047, 0042, 0067, 0043,

0041

Motorola 0035, 0048

Movie Walker 0072

Multitech 0000, 0039, 0072

NAD 0240, 0104

NAP 0035, 0037, 0039, 0033,

0042

NEC 0067, 0104, 0041

Newtech 0072

Nikko 0037

Nikkodo 0037

Nishi 0240

Niveus Media 1972

Noblex 0240

Northgate 1972

Olympus 0035, 0162, 0104

Onkyo 0222

Optimus 0000, 0035, 0037,1062,

0048, 0047, 0162, 0240,

Orion 1479, 0000, 0184, 0240,

0104, 0121, 0209

Panama 0035

Panasonic 0225, 1035, 0000, 0614,

0616, 0035, 1062, 0162

Penney 1237, 1035, 0035, 0037,

0042, 0240

Penneys 0000, 0035, 0037, 0047,

0081, 0162, 0042, 0067,

0240

Pentax 0042

Philco 0000, 0035, 0081, 0209

Philips 0000, 0616, 0618, 0739,

0035, 0048, 0081, 0162,

0045, 0209

Pilot 0037

Pioneer 0081, 0162, 0042, 0067

Polk Audio 0081

Proﬁ tronic 0240

Proscan 1060, 0060

Protec 0000, 0072

Protech 0072

Pulsar 0039, 0240

Pulser 0240

Quartz 0035, 0047

Quasar 1035, 0035, 0162

RCA 1035, 1060, 0807, 0000,

0880, 0035, 0060, 0048,

0045, 0042, 0240

Manufacturer Code Manufacturer Code

68

Programming Your Remote Control

RadioShack 0000, 0035, 0037, 0048,

0047, 0162, 0240, 0104

Radix 0037

Randex 0037

Realistic 0000, 0035, 0037, 0048,

0047, 0162, 0240, 0104,

0121

ReplayTV 0614, 0616

Ricavision 1972

Runco 0039

STS 0042

SV2000 0000, 0072

SVA 0000

TT Nokia 0240, 0041

JVC 0067, 0041

Janeil 0240

Jensen 0067, 0041

Samsung 0000,1014, 0739, 0060,

0045, 0240

Samtron 0240

Sanky 0048, 0039

Sansui 1479, 0000,0067, 0240,

0209, 0041, 0072

Sanyo 0159, 0000, 0047, 0240,

0104

Scott 0184, 0045, 0121, 0043

Sears 1237, 0000, 0035, 0060,

0037, 0048, 0039, 0047,

0033, 0162, 0045, 0042,

0067, 0104, 0043, 0209,

0041, 0072

Sharp 0807, 0000,0048, 0047,

0032

Shintom 0000,0039, 0240, 0072

Shogun 0240

Siemens 0037, 0104

Signature 0035

Signature 2000 0000, 0035,

0060, 0037, 0048

Singer 0037, 0240, 0072

Sonic Blue 0614, 0616

Sony 1232, 0000, 0636,1972,

0035, 0047, 0032, 0033,

0067

Soundmaster 0000

Stack 9 1972

Sylvania 1781, 0000, 0035, 0081,

0043

Symphonic 0000, 0240

Systemax 1972

TMK 0000, 0240

TNIX 0037

Tagar Systems 1972

Tandy 0000, 0104

Tatung 0000, 0048, 0081, 0067,

0041

Teac 0000, 0067, 0041

Technics 0000, 0035, 0060, 0037,

0039, 0162

Teknika 0000, 0035, 0037

Telecorder 0240

Telefunken 0041

Thomas 0000

Thomson 0060, 0041

Tivo 0618, 0636, 0739, 1503

Tocom 0240

Toshiba 0845, 1145, 0000,1503,

1008, 1972, 0045, 0240,

0043, 0209, 0041

Totevision 0037, 0240

Touch 1972

Trix 0037

Ultra 0045

Unitech 0240

Vector 0045

Vector Research 0184

Vextra 0072

Victor 0067, 0041

Video Concepts 0045

Videomagic 0037

Videosonic 0000, 0240, 0072

Viewsonic 1972

Villain 0000

Voodoo 1972

Wards 0000, 0035, 0060, 0037,

0048, 0039, 0047, 0081,

0033, 0045, 0042, 0240,

0043, 0041, 0072

White Westinghouse 000, 0209, 0072

World 0209

XR-1000 0000, 0035, 0072

XR1000 0000, 0035, 0240, 0072

Yamaha 0041

ZT Group 1972

Zenith 1479, 0000, 0037, 0039,

0033, 0209, 0041

Manufacturer Code Manufacturer Code

ENGLISHENGLISHENGLISH

69

Programming Your Remote Control

Firstline 0651

Fisher 0670

Funai 0675, 1268, 1334

GE 0522, 0717, 0815

GPX 0699

Gateway 1158, 1073

General Electric 0717

Go Video 0573,1075, 1044,0744,

0717, 0869, 0741,0783,

1158, 1099, 1304,1730,

0833, 0715

Go Vision 1071

GoldStar 0801, 0869, 0741

Goodmans 0790

Gradiente 0490, 0651

Greenhill 0717

Grundig 0539, 0705

Harman/Kardon 0582, 0702

Hitachi 0573, 0664, 1247

Hiteker 0672

IRT 0783

Initial 0717

Integra 0571, 0627

JBL 0702

JMB 0695

JVC 0623, 1164, 0558, 0867

Jensen 1016

KLH 1020, 0790, 0717, 1149

KLH Digital 0717

Kawasaki 0790

Kenwood 0490, 0534

Kloss 0533

Koss 1061, 0651

LG 0801, 0591, 0869, 0741

Lasonic 0798, 0627

Lecson 1533

Lenoxx 1127

Lite-On 1058, 1158

LiteOn 1058, 1158, 1416, 1440

Loewe 0511, 0741

Logix 0783

Magnasonic 0675, 0651

Magnavox 0503, 0539,0675, 0646,

0821

Marantz 0503, 0539, 0675

McIntosh 1533

Medion 0651

Memorex 0695, 1270, 0831

Microsoft 0522

Minato 0752

Mintek 0717, 0839

Mitsubishi 0521, 1521

NAD 0591, 0741

3D LAB 0503, 0539

Advent 1016

Aiwa 0641

Akai 0899, 0770, 0705

Alba 0672, 0717

Alco 0790

Allegro 0869

Apex 0533, 0672, 1056,1061,

0830, 0794, 0796,0797,

1100, 1020, 0717, 0755

Apex Digital 0672, 1056, 1061, 0830,

0794, 0796, 0797, 1100,

1004, 1020, 0717, 0755

Aspire Digital 1168

Audiovox 0790, 0717, 1071, 1121,

1122

Axion 1071

Blaupunkt 0717

Blue Parade 0571

Blue Sky 0695, 0699

Brandt 0651

Broksonic 0695, 0868

California Audio Labs 0490

Celestial 1020

Centrex 0672, 1004

CineVision 0869, 0876, 0833

Cinea 0831

Citizen 1003, 1277

Clairtone 0571

Coby 0778, 1107

Craig 0831

Creative 0503, 0539

Curtis Mathes 1087

CyberHome 0816, 1023,1117,1024,

1129, 0874

Cytron 0705

DVD2000 0521

Daewoo 0869, 1172,0784,0770,

1169, 0705, 0833

Dansai 0770

Decca 0770

Denon 0490, 0634

Denver 0778

DiViDo 0705

Digitrex 0672

Disney 0675, 1270

Dual 0675

Durabrand 1127

Electrohome 1003

Emerson 0675, 0821, 1268,0591

Enterprise 0591

Entivo 0503, 0539

Enzer 0770

DVD Players

Manufacturer Code Manufacturer Code

70

Programming Your Remote Control

NEC 0785, 0869

Naiko 0770

Nesa 0717

NexxTech 1402

Norcent 1003, 1107

Onkyo 0792, 0503, 0627

Optimus 0571

Orion 0695

Oritron 0651

Palsonic 0672

Panasonic 0503, 0490, 1762,0703,

1362, 1462, 1490, 0571

Philips 0503, 0539, 0675,1267,

0646, 0854, 1354, 1260

Phonotrend 0699

PianoDisc 1024

Pioneer 0571, 0525, 0631

Polaroid 1061, 1020

Polk Audio 0539

Portland 0770

Prima 1016

ProVision 0778

Proceed 0672

Proscan 0522

Prosonic 0699

Qwestar 0651

RCA 0522, 0571,0822, 1132,

1022, 0790, 0717

RadioShack 0571

Radionette 0741

Realistic 0571

Reoc 0752

Revoy 0699

Rio 0869

Rotel 0623

Rowa 1004, 0823

SVA 0717

Saba 0651

Sampo 0752

Samsung 0490, 0573,0820, 1075,

0899, 1044, 0744

Sansui 0695

Sanyo 0695, 0675, 0670, 1334,

0873

Schneider 0783

Schwaiger 0752

Sensory Science 1158

Sharp 0675, 1256, 0752, 0630

Sharper Image 1117

Sherwood 0770, 1043

Shinsonic 0533, 0839

Slim Art 0784

Sonic Blue 0573, 0869 ,0783, 1099,

0715

Sony 0533, 1033, 1431, 0864,

1533

Sova 1122

Superscan 0821

Sylvania 0675, 0821, 1268, 0630

Symphonic 0675, 0821, 1268, 1334

Tatung 0770

Teac 0809, 0571, 0790, 0717

Technics 0490, 0703

Technika 0770

Tevion 0651

Theta Digital 0571

Thomson 0511, 0522

Toshiba 0503, 0695, 1045, 1154,

0573, 0539

US Logic 0839

USLogic 0839

Unimax 0770

Universum 0591

Urban Concepts 0503, 0539

Venturer 0790

Wesder 0699

Xbox 0522

Yamaha 0490, 0539, 0545

Zenith 0503, 0591, 0869, 0741

Zeus 0784

iLo 1348

CARE

• Keep the remote dry. If it gets wet, wipe it dry immediately.

• Use and store the unit only in normal temperature environments.

• Handle the remote gently and carefully. Don’t drop it.

• Wipe the remote with a damp cloth to keep it looking like new.

20070411

Polaroid Tda 03211C Users Manual User's 20070411

TDA-03211C tda03211c_ug_en

TDA-03211C to the manual d1f0b481-d4f5-4951-a007-3c1688c7ebcf

Navigation menu

Versions of this User Manual:

Views

Navigation
