User manual
NUMBER SLIDE
Mini Keyboard with Retractable Number Pad
The Number Slide’s retractable number pad
slides out when you need it and away when
you’re finished. This feature delivers important
ergonomic advantages over conventional
keyboards.
Number Slide reduces the distance you need to
reach to operate your mouse, which allows you
to adopt a more comfortable posture.
The mouse can be positioned in front of the left
or right shoulder (depending on your dominant
hand), which facilitates a better posture in the arm
and shoulder when using your mouse.
Being so compact, Number Slide frees up more
space at your workstation so you can bring work
closer to your midline but does not compromise
on functionality.
ERGONOMICS
x
WIRED VERSION
1. Insert USB cable into a spare USB port on your computer
2. There are two auxiliary USB ports on the rear of the keyboard for use with peripherals
Warning lights
a. Number lock (Number Lock key found on slide out number pad)
b. Caps lock
c. Scroll lock
BLUETOOTH VERSION With built in rechargeable Li-ion battery
To pair with a Windows® PC
1. Turn on Bluetooth via the Control Panel on your PC and search for devices
2. On the keyboard rear edge, slide the keyboard ON/OFF switch to the ON position
3. Press the ‘CONNECT’ button on the rear edge. The power light should ash until pairing is
complete
4. On your PC control panel, select Posturite KB Number Slide
5. To un-pair at any time, simply delete from the list of Bluetooth items
USB ports
(Wired version)
Power Connect (Bluetooth pairing)
(a)
Tab - pull gently
to slide out
number pad
(b)
(c)
To pair with an Apple® Mac
Please note on Mac the number keys are permanently active, so Number Lock will not operate.
1. Select ‘Bluetooth’ from the System Preferences menu on your Mac
2. On the keyboard rear edge, slide the keyboard ON/OFF switch to the ON position
3. Press the ‘CONNECT’ button on the rear edge of the keyboard. The power light should ash
until pairing is complete
4. On your Mac’s Bluetooth window nd ‘Posturite KB Number Slide’ and click ‘Pair’
5. To un-pair at any time, simply delete from the list of Bluetooth items
To pair with an Apple® iPad or iPhone
1. Make sure Bluetooth is turned on on your iOS device and keyboard is on
2. Press the ‘CONNECT’ button on the rear edge. The power light should ash until pairing is
complete
3. In the Bluetooth section on the iPad, select the ‘Posturite KB Number Slide’
4. You’ll be asked to type a pairing code on the keyboard - if it’s entered successfully, your
keyboard will be paired with the iOS device
5. Note that when you are using the Bluetooth keyboard, the normal iOS keyboard does not
appear - turn off to return to using the onscreen keyboard
Warning lights
a. Number lock (Number Lock key found on slide out number pad)
b. Caps lock
c. Power light - Charge Number Slide when light ashes or remains on
Charging
When voltage is low, the battery light will ash. This means that your keyboard needs charging.
1. Insert the USB end into a USB port directly into your computer (do not use a multi-port hub)
and the micro USB end into the back of your Bluetooth Number Slide Keyboard
2. While charging the red LED light will remain on
3. When charged the red LED light turn off (Approx 2 hours)
Sleep function
After 5 minutes of inactivity the battery will enter a power-saving sleep mode. Press any key to
wake up the keyboard.
For up to date support please visit www.posturite.co.uk/numberslide
Specifications
Bluetooth Li-ion rechargeable battery.
Bluetooth version: 3.0
Operating distance: 10m
System model: GFSSK 2.4G
Working voltage: 3-5V
Working current: 1.5mA
Battery: 300mA/h
Charging voltage: 4.2V
Charging current: 180mA
Charging time: Approx. 2 hours
™
™
© 2015 Posturite Ltd. All Rights Reserved. Posturite, the
logo design, are registered trademarks of Posturite Ltd.
Posturite Ltd, The Mill, Berwick, East Sussex BN26 6SZ, UK
+44 (0)845 345 0010 www.posturite.co.uk
GFSK 2.4G
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
IC STATEMENT
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil
ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
