Power Beauty PBB-2835S LED Floating Duck with speaker User Manual
Power Beauty (Dongguan) Industrial Co., Ltd LED Floating Duck with speaker
User Manual
LED FLOATING DUCK WITH SPEAKER
MODELO #: PBB-2835S
Instruction Manual
PLEASE READ THIS GUIDE COMPLETELY BEFORE USING THIS PRODUCT.
SAVE THIS GUIDE FOR FUTURE REFERENCE.REFERENCIA FUTURA.
Warning
How the LED Floating Duck with Speaker Works
The LED floating duck with speaker functions using bluetooth technology to
wirelessly connect to a compatible device such as mobile phones, MP3 players,
PCs, notebooks or tablet PCs, and other enabled devices. If your output device
you intend to connect to the LED floating duck with speaker is not bluetooth
compatible, there are options such as a bluetooth adaptor.
Please refer to the device’s operation manual for options and availabilities.
Since audio is transferred by bluetooth technology, performance and sound
quality will be dependent on distance from the speaker.
This is not a toy, keep it out of the reach of children.
Keep this product away from chemicals, or high heat.
Regarding the adaptor:
Use the adaptor only to charge the battery of the LED floating duck with
speaker.
The adaptor should not be used outdoors, or exposed to rain, humidity, liquids
or heat.
Keep the adaptor and charging base out of the reach of children.
Disconnect the adaptor from power when not in use.
Never attempt to open the adaptor, the charging base or the
LED floating duck with speaker.
Keep the remote control away from water, liquids and heat.
Parts List
SPEAKERLIGHTING
(A)
LED FLOATING
DUCK WITH
SPEAKER
Qty: 1
(B)
Charging base
Qty: 1
(C)
Adaptad
Qty: 1
(D)
Remote Control
Qty: 1
SPEAKERLIGHTING
Features
Specification
Charging
Need Assistance? Call us at 1-888-301-0332 from 8am to 5pm CST Monday – Friday
Bluetooth connection to your music.
Choice of 7 LED colors.
Colors flash to rhythm of the music.
Waterproof and floats on water.
Pairs two speakers option available
Wireless Rechargeable lithium battery (wireless charging base included).
Can be used in garden, pool, party...
Adaptor: input 100-240 AC, Output 7.5 V-0.6 A.
12PCS RGB LED+6PCS White LED.
Rechargeable Lithium battery 3.7V 2200mAh.
Charging time: 6 to 8 hours.
Working time: 4 to 6 hours after full charge.
Password: 0000(may be necessary for some mobile phones).
Bluetooth range: 30’(10 m), will be reduced as battery power decreases or
when obstacles are in between bluetooth device and LED floating duck with
speaker.
IR Remote control range:9.84 feet (3 m).
Pairing speaker range:19.68 feet(6 m).
Place the charging base on a dry and level surface.
Use a clean and dry cloth to clean the surface of the charging base and the
bottom of the LED floating duck with speaker.
Insert the adaptor in the socket under the charging base (ILL.1).
Connect the adaptor to the electrical outlet.
Indicator light on charging base will light up in green when connected properly.
Place the LED floating duck with speaker on the base. It will begin to charge
and the indicator light will turn red.
Pair Max.2pcs LED Floating duck with Speakers if need
Operation
Need Assistance? Call us at 1-888-301-0332 from 8am to 5pm CST Monday – Friday
ILL. 3
ILL. 1
SPEAKERLIGHTING
The indicator light will turn green when the battery is fully charged.
After charging, disconnect the adaptor from the outlet and remove the LED
floating duck with speaker from the charging base.
Press the ON/OFF button to turn on or off the LED floating duck with
speaker (ILL.2).
Turn on 2 products:
Press the ON/OFF button to turn on the LED floating duck with speaker
Activate the bluetooth output on your device and allow your output device to
search for the bluetooth name “Speakerlighting”. It is connected to the main
speaker automatically when you hear a voice. Once connected, the Bluetooth
indicator light of the main speaker will stay in blue. The Bluetooth indicator light
will turn off automatically when you play music.
Pair Max.2 products
Press and hold the ON/OFF button from either of the 2 devices to pair. They will
be paired successfully when you hear a voice. The Bluetooth indicator light on
one device will flash rapidly and will become the main unit, the other device will
still flash slowly in blue and will become the secondary unit
on/off
ILL. 2
Need Assistance? Call us at 1-888-301-0332 from 8am to 5pm CST Monday – Friday
Connecting the Single LED Floating duck with Speaker via Bluetooth
Operation of the remote control
Note: Before using the remote control, first remove the plastic sheet from the
battery cover.
Turn the LED floating duck with speaker on as indicated in the "Operation"
section above.
Disconnected the pairing
Press and hold the on/off button on the bottom of either of the devices. The
Bluetooth indicator light will start to quickly flash in blue and you will hear a
beep. Once you hear it, the main speaker and the secondary speaker will be
disconnected.
NOTE:
If your Bluetooth device is more than 30 ft away from the main speaker, they will
disconnect. If you move the main speaker within 30 ft, then they can be paired
automatically and resume playing music.
If you move the secondary speaker more than 30 feet(10 m) away from Blue-
tooth device and within 19FT of the main speaker, the secondary can still play
music. If you move secondary more than 19 ft away from the main unit, it can
not play music. they can pair automatically and play music again when you
move it back within 19 FT.
Press the button on the bottom of the LED floating duck with speaker to power
on. Activate the bluetooth output on your device, allow your output device to
search the bluetooth name” Speakerlighting”, it’s connected successfully when
you hear a voice.You can now open your music to enjoy via the LED floating
duck with speaker.
Remark:If the sound becomes soft or quiet, maybe the water gets in the speaker,
please simply empty the speaker out and the sound returns to normal.
Light
On/Off button: press this button to turn the light on or off.
Turns on/off flashing light to sync with music.
Brightness and speed button：
Change brightness in the single color mode.
Adjust speed in smooth mode. Smooth mode cycles
through the colors.
When the light is on, use this button to cycle through
and select one of the six colors available.
When the light is On, use this button to increase the
warmth of the white (7 grades).
When the light is On, use this button to choose from
one of the seven colors.
When the light is On, use this button to choose from
one of the seven colors.
Use this button to cycle through the colors automatically.
Speaker
Press the button to turn on or off Bluetooth;
When the bluetooth is On and music is playing,
press this button to select the previous piece of music.
When the bluetooth is On and music is playing,
press this button to select the following piece of music.
When the bluetooth is On and music is playing,
press this button to pause or play the music.
When the bluetooth is On and music is playing,
press this button to increase or decrease the volume.
Need Assistance? Call us at 1-888-301-0332 from 8am to 5pm CST Monday – Friday
Need Assistance? Call us at 1-888-301-0332 from 8am to 5pm CST Monday – Friday
Battery replacement (for remote control)
1 30 minutes Red
2 60 minutes Green
3 90 Blue
4 120 Yellow
5 150 cyan
6 180 Violet
Once the light is on, press on the button to activate the
timer according to the following.
Note: Power off the LED floating duck with speaker to cancel the timer.
NUMBER OF TIME
TO PRESS ON
THE BUTTON
TIMER LIGHT COLOR
If remote control fails to activate the light, replace the battery.
- Press the tab on side of battery cover and slide it off
- Change the battery paying attention to the polarity shown on the cover
Warning!
- Make sure that battery is inserted correctly to avoid a short-circuit.
Maintenance of the LED Floating Duck with Speaker
Always turn it off after use.
Clean with a dry cloth.
Store the unit out of the reach of children.
Need Assistance? Call us at 1-888-301-0332 from 8am to 5pm CST Monday – Friday
Troubleshooting
SolutionProblem
The LED floating duck with speaker was connected
to another bluetooth device, please restart again
The device is too far away. The maximum distance
between LED floating duck with speaker and output
device should not exceed approximately 30 ft. (10 meters).
Path between output device and speaker might be
blocked. Sound interferences can be caused by
obstacles such as walls and other objects.
The bluetooth enabled device is not properly
functioning. Consult the device’s instruction manual.
There is no power. Check the adaptor and the
D/C port connection.
The volume is too low. Adjust using the volume
button on the remote.
The output device is not functioning properly.
Refer to the device’s instruction manual.
Bluetooth enabled
device will not connect
to the LED floating
duck with speaker
Output device is
connected, the light is
on but no sound is
being produced.
The small plastic sheet of the remote control was
not removed, please remove it to activate the remote.
The battery of the remote control is dead, please
remove it and replace with a new one. Note the
polarity of the battery on the cover and direction
when installing the new battery in the remote control.
Remote control
is not functioning
The Bluetooth device connected one of any of 2
devices before pairing, please turn off the Bluetooth
on your device and then pair again
The water gets in the speaker, please simply empty the
speaker out and the sound returns to normal
Pairing failed
sound becomes
soft or quiet
Need Assistance? Call us at 1-888-301-0332 from 8am to 5pm CST Monday – Friday
FCC statement
Please note that changes or modifications of this product is not expressly
approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation
