Primax Electronics KKBBT41811 iPad Keyboard Capsule User Manual RF iCAP12 10 1198 QSG V2 EN eps
Primax Electronics Ltd iPad Keyboard Capsule RF iCAP12 10 1198 QSG V2 EN eps
User Manual
Keyboard
Installing the batteries
1 Remove the battery cover on the bottom of the iCapsule
by pressing the release buttons and sliding o the cover.
2 Install the two AA batteries. Make sure that the + and -
ends of the batteries match the markings on the battery
compartment.
3 Replace the battery cover.
RF-iCAP12 I iCapsule
Quick Setup Guide
# Component Description
1 LED indicator Green - Lights for three seconds when keyboard is turned on
Green (ashing) - Pairing
Green - Caps lock on
Red (ashing) - Low battery indicator
2 Battery compartment Install batteries here
Package contents
• Keyboard (1)
• AA batteries (2)
• Quick Setup Guide
Features
• 85-key design
• 16 special keys designed for iPad
• Compact design for mobility and saving space
• Low power consumption
• Dual-color status LED indicator
iCapsule open iCapsule back
Setting up your iCapsule
Landscape mode
1 Align and place the iPad onto the panel while 2 Release the latch to lock the iPad in place.
pressing up the latch.
Portrait mode
• Align and place the iPad onto the gap.
# Description
1 Home button
2 Search button
3 Select all button
4 Select left button
5 Select right button
6 Copy button
7 Cut button
8 Paste button
# Description
9 Previous track button
10 Play/Pause button
11 Next track button
12 Mute button
13 Volume down button
14 Volume up button
15 Virtual keyboard button
16 Connect button
RF-iCAP12_10-1198_QSG_V2_EN.eps 1 11/12/2010 9:52:55 AMRF-iCAP12_10-1198_QSG_V2_EN.eps 1 11/12/2010 9:52:55 AM
V2
FINAL
FOR PRINT
Pairing with an iPad
To pair and connect with an iPad for the rst time:
1 On the iCapsule, press and hold the Connect button ( ) for ve seconds.
2 On the iPad, tap Settings > General > Bluetooth to turn on Bluetooth. The iPad searches for
devices.
3 Tap iCapsule Bluetooth Keyboard.
4 When prompted, enter the passkey shown on the iPad using the iCapsule keyboard, then press
Enter.
After the iCapsule is paired with the iPad, you don’t need to pair again.
Note: After a period of no activity, the keyboard enters sleep mode. To wake up the keyboard from
sleep, tap a few keys and the Bluetooth icon appears in the upper right corner of the iPad.
Using the special keys
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning
Changes or modications not expressly approved by the party responsible for compliance with the
FCC Rules could void the user’s authority to operate this equipment.
IC RSS210
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
One-year limited warranty
Visit www.rocketshproducts.com for details.
Contact Rocketsh:
For customer service, please call 1-800-620-2790.
www.rocketshproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richeld, MN 55423-3645 USA
© 2010 BBY Solutions, Inc., All Rights Reserved. ROCKETFISH is a trademark of BBY Solutions, Inc. All
other products and brand names are trademarks of their respective owners.
Best Buy Imports, S. de R.L. de C.V. Av. Santa Fe 485, Segundo Piso, Colonia Cruz Manca, Programa
Parcial de Desarrollo Santa Fe, Delegación Cuajimalpa, Distrito Federal, México 05349
© 2010 Best Buy UK Distributions Limited. All rights reserved. Distributed by Best Buy Europe
Distributions Limited. 1 Portal Way, London W3 6RS
ENGLISH 10-1198
Button Description
Home Return to the home screen
Search Search keywords on the iPad or the Internet
Virtual keyboard Activate or deactivate the on-screen keyboard
Select all, Select left, or Select right Select text
Copy or Cut Copy text
Paste Paste text
Play/Pause Play or pause the music
Next track or Previous track Listen to the next or previous song
Volume up or Volume down Adjust the volume
Mute Mute the volume
