User Guide

Keyboard
First time use
When you unpack your iCapsule II, the internal battery is only
partially charged. You should charge it fully before using it.
Charge the battery
Connect your iCapsule II to a computer or the power adapter
using the USB cable (provided) to charge the internal battery.
Note: USB cable charging voltage is 4.4v ~ 6.0v. It is recommended
to use iPad 2 chargers or regular computers.
Rocketsh iPad 2 Keyboard Capsule
RF-iCAP14 I Quick Setup Guide
# Component
1 Earphone jack
2 Battery LED
3 Bluetooth
connection LED
4 30-pin connect slot
5 Micro USB port
Package contents
Keyboard Ear phone jack spare cover
USB cable Quick Setup Guide
Features
82-key design, 20 hot keys for iPad 2
Easily switch between two Bluetooth devices
Compact design for mobility and space saving
Working range up to 33 ft. (10 m)
Low power consumption
Bluetooth version 2.0
iCapsule II parts
Setting up iCapsule II
1 Insert a nger into the gap, then lift to open
the top panel.
2a For the Typing mode, align and 2b For the Stand mode, align the panel
place the panel on the gap. with the front edge of the keyboard.
3 Place the bottom edge of the iPad
into the bottom of the frame, push
up on the latch, then move the top
edge of the iPad into the frame.
4 Release the latch to lock the iPad 2
in place.
# Description
1 Home button
2 Search button
3 Photo Slide Show button
4 Virtual Keyboard button
5 Select All button
6 Select Left button
7 Select Right button
8 Copy button
9 Cut button
10 Paste button
# Description
11 Previous track button
12 Play/Pause button
13 Next track button
14 Mute button
15 Volume down button
16 Volume up button
17 Lock button
18 Bluetooth-Fn button (Works with 19 and 20 only)
18+19 Switch Bluetooth device button
18+20 Pairing button
Caps Lock Enter
Shift
Ctrl
Option
Alt
ASDFGHJ KL :
;
"
'
ZXCVBNM<
,
>
.
?
/
QWE R T Y U I O P }
]
{
[
|
\
~
`
!
1
@
2
#
3
$
4
%
5
^
6
&
7
*
8
(
9
)
0
_
-
+
=
Select
All
Select
Left
Select
Right
Tab
Backspace
Shift
Command Command
-Fn 1
2
A
A
B
B
Description
Remove the rubber piece to connect the earphone to the iPad 2 earphone jack.
Orange OFF: Battery full
Orange ON: Battery charging
Orange BLINKING: Battery low
Green / Blue ON (2 seconds): Power on (green and blue stand for dierent
paired devices)
Green and Blue BLINKING: Searching for devices (pairing)
Slide out the rubber piece to connect the 30 pin connector.
Connects to the computer or the power adapter to charge the iCapsule battery.
RF-iCAP14_11-0498_QSG_V1_EN.eps 1 6/8/2011 1:53:05 PMRF-iCAP14_11-0498_QSG_V1_EN.eps 1 6/8/2011 1:53:05 PM
V1
FINAL
FOR PRINT
Pairing with an iPad 2
When you open your iCapsule II for the rst time, it automatically enters discoverable mode for
pairing. If the devices are not paired, press the Bluetooth-Fn + Pairing button to pair, then do
the following:
1 On your iPad 2, turn on Bluetooth by going to Settings > General > Bluetooth.
iPad 2 searches for devices.
2 Select the iPad 2 Keyboard Capsule.
3 When prompted, enter the passkey shown on your iPad 2, then press Enter.
Once paired, you do not have to pair with the iPad 2 again.
Note: Your iCapsule II can also pair and be used with other Bluetooth devices, such as an iPhone4 or
a notebook PC. You can press Bluetooth-FN + Pairing button again to pair with another device.
This allows you to type on your iPad, iPhone, Notebook PC, or any other bluetooth-enabled device.
Simply toggle between the two devices by pressing the Bluetooth-FN + Switch Bluetooth
device. To set up these additional devices press the Bluetooth-FN + Pairing button.
Using the special keys
Legal notices
FCC caution
You are cautioned that changes or modications not expressly approved by the part responsible for
compliance could void the user's authority to operate the equipment.
FCC statement:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
IC RSS-102 statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the
radiator and your body.
Cet équipement est conforme à l'exposition aux rayonnements IC limites établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm
de distance entre le radiateur et votre corps.
IC RSS-Gen and RSS-210 statement:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
ENGLISH 11-0498
Button
Home
Search
Photo slide show
Virtual keyboard
Select all, Select left, or Select right
Copy or Cut
Paste
Play/Pause
Next track or Previous track
Volume up or Volume down
Mute
Lock
Bluetooth-Fn + Switch
Bluetooth-Fn + Pairing
Description
Press to return to the home screen
Press to search keywords on your iPad 2 or the Internet
Press to play a photo slide show
Press to activate or deactivate the on-screen keyboard
Press to select text
Press to copy text
Press to paste text
Press to play or pause music playback
Press to listen to the next or the previous song
Press to adjust the volume
Press to mute the volume
Press to switch screen on or o
Press to switch the Bluetooth device connection
Press to search and pair other devices
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélec-
trique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
One-year limited warranty
Visit www.rocketshproducts.com for details.
Contact Rocketsh:
For customer service, please call 1-800-620-2790.
www.rocketshproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richeld, MN 55423-3645 USA
© 2011 BBY Solutions, Inc., All Rights Reserved. ROCKETFISH is a trademark of BBY Solutions, Inc.
All other products and brand names are trademarks of their respective owners.
Best Buy Imports, S. de R.L. de C.V. Av. Santa Fe 485, Segundo Piso, Colonia Cruz Manca, Programa
Parcial de Desarrollo Santa Fe, Delegación Cuajimalpa, Distrito Federal, México 05349
© 2011 Best Buy UK Distributions Limited. All rights reserved. Distributed by Best Buy Europe
Distributions Limited. 1 Portal Way, London W3 6RS
