User Manual
Kiwi BT Laser Mouse
User’s Guide
Model No :MOBTE7UL
Rating: 3V DC 40mA
Made in China
Introduction
Package Contents
· AAA Battery x 2 pc
· User’s Guide x 1
System Requirements
· Pentium processor or equivalent
· At least one USB port (USB 2.0 or 1.1)
· Operating System: Windows® XP with Service Pack 1 or higher, Windows® Vista, Windows® 7
Feature
Kiwi BT is Bluetooth Laser Mouse in middle size with magnetic battery cover, is equipped with Laser-based
Soc Sensor 7630 from Avago that’s empowered by Bluetooth 2.1 Technology and a changeable
1000DPI/1500DPI, and using OFM A320 sensor for 4-way scrolling controls.
It also provides a low battery indicator on top of the mouse to warning user for battery change.
Function Introduction
1. Left Button
2. Right Button
3. Touch-Sensitive Scrolling
4. Windows 7 Task Switching
5. Gesture button
6. Power and DPI LED.
7. Bluetooth pairing button and LED Indication
8. Power On/Off
Pairing introduction
The Bluetooth connection indication and LED indication is defined as below:
A dual-color, blue and white, LED is used to indicate the status of power and Bluetooth connection, present
DPI, including the power on and off state, low-power alert, Bluetooth pairing, Bluetooth reconnecting.
The power detection is defined as three levels:
A: Power is sufficient: voltage level is higher than 2.2 volt; LED will be on in the color upon present DPI
setting, and then be off in 2 seconds.
B: power is low: voltage level is lower than 2.2 volt, but higher than 2.05 volt; LED will be on in the color
upon present DPI setting, and then be blinking once every one second, lasting for 1 minute.
C: Power is off: voltage level is lower than 2.05 volt; mouse power is cut off and LED is not turned on
The Bluetooth connection indication is defined as below:
In pairing mode: blue LED starts blinking once every one second, lasting for 2 minutes. AS long as KIWI BT is
successfully paired with the computer, blue LED will be turned off.
KIWI checks the battery status and enables the LED indication:
A: battery status change in active mode
B: mouse is waked up from sleeping mode or standby mode
C: power is manually turned on and off by the sliding switch
Regulatory Compliance
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
The product comply with the US/Canada portable RF exposure limit set forth for an uncontrolled
environment and are safe for intended operation as described in this manual. The further RF exposure
reduction can be achieved if the product can be kept as far as possible from the user body or reduce output
power if it doesn't affect the transmission/receiving quality.
IC Statement
Operation is subject to the following two conditions: 1) this device may not cause interference and 2) this
device must accept any interference, including interference that may cause undesired operation of the
device.
Eye safety
This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.
50, dated June 24, 2007.
