Primax Electronics Ltd BLUETOOTH LASER MOUSE VGP BMS77 eng ver
Manual
Bluetooth
®
Laser Mouse
VGP-BMS77
User’s Manual
X-XXX-XXX-XX(1) © 2008 Sony Corporation Printed in Japan
Thank you for purchasing it.
If it doesn't defend notes for safety, an electric product
might become a fire and an accident resulting in injury or
death.。
Please often read this manual and use the product safely. Please keep it in
the place in which it is always seen after it reads.
For Safety
The Sony product is designed safely considering it enough. However, an
electric product might become an accident resulting in injury or death by a fire
and the electric shock, etc. if all wrong of those who use it are done and is
dangerous. Please guard the following to prevent the accident
Safety Project Notice
Please read the notice “for this safety” well.
Do not use, when it breaks
Please request repair at the VAIO customer link repair window directly.
Abnormality occurs
z When the smoke comes
out
z Abnormal sound
z the water and the foreign
material enter inside
z When the product is
dropped and/or the cabinet
being broken
→
① Power of the mouse is turned off
② Repair is requested at the VAIO customer
link repair window
T
he AC adaptor is not brandished.
It is likely to hit the person and the glass, etc. and to injure.
The power supply code is not damaged.
When the power supply code is damaged, it might cause a fire and
the electric shock.
z When setting it up, don’t places between the product, the
wall, and the rack, etc.
z The power supply code is not processed, and damaged.
z The heavy one is not put, and pulled.
z Doesn't bring close to the heat apparatus.
z When the power supply code is pulled out, pulling it out with
the plug without fail.
D
ust that attach to the plug of the AC adaptor has to be regularly
removed. It becomes insulation shortage because of moisture etc.
when dust is collected in the plug, and it causes a fire.
I
f the plug of the AC adaptor is not inserted in the outlet even of the
root up to the root firmly, it causes a fire and the electric shock.
It causes a fire and the electric shock not used excluding the AC adaptor
of the attachment.
When wiring accessories in the connection cable will make current
exceeds ratings flows and it possibly causes a fire.
When having begun to thunder, it causes the electric shock by
lightning that doesn't touch the AC adaptor. Please pull out the AC
adaptor from the outlet beforehand for a fire, the electric shock,
and the product protection when the thunder is forecast.
If the following precaution is not observed, might it
injure and a peripheral article is disadvantaged.
In a packed train in crowded places such as the use of the
machine
At the place where it has the possibility the person who the heart
pacemaker is installed being, there is a possibility of producing
effect on operation of the pacemaker with radio wave near.
22 cm or more separating from the installation region of the
heart pacemaker
There is a possibility of producing effect on operation of the
pacemaker with the radio wave which you use
Inside the medical institution of the hospital and the like,
at the vicinity of the medical application electrical
machinery and apparatus the knitting machine is not
used
Waves to affect the electro-medical equipment to malfunction
and cause accidents that may be.
On board the aircraft taking off and landing when not in use
Waves to affect the cause of accidents and malfunctions that may
be. The aircraft in the available information, available to airlines to
use terms such as please.
This equipment is being used by other radio equipment, such
as failure to occur, do not use the machine
Waves to affect the cause of accidents and malfunctions that may
be.
These are not observed and to the injured and
damage to goods around them.
Do not use a computer other than specified
It might cause the breakdown not used for computers other than
specification.
Stable place
The product might drop when putting it on the shaking stand put on
a steady place and the inclination, etc. and it cause the injury.
There is a possibility of hurting eyes by the originated laser light.
Pleas avoid to see the mouse back side directly where the lens is
set n directly (The laser light is not seen in eyes.)
The connector is neatly connected
z Please do not put the metal piece in the connector. The pin
and the pin might be short-circuited, and it cause a fire and the
breakdown..
z Please insert straight and connect the connector. The pin and
the pin might be short-circuited when diagonally inserting it,
and it causes a fire and the breakdown.
The AC adaptor is not touched by a wet hand.
The AC adaptor might be pulled out, be opened with a wet
hand, and then, it causes the electric shock.
It doesn't touch this machine and the AC adaptor under
energizing for a long time.
When the skin remains touching for a long time, it might cause
the low temperature burn.
The heat not used with this machine and the AC adaptor covered
with the cloth oneself, and the case might be transformed, and it
cause a fire.
When moving, the AC adaptor has to pull out.
The connected equipment floats from the outlet when moving
while connected the plug of the AC adaptor, causes the electric
shock, and it causes the breakdown and the injury. Moreover,
please do not drop this machine
When not using it for a long time, the plug of the AC adaptor has to
pull out.
Please pull out the plug of the AC adaptor from the outlet for
safety when you do not use it for a long time.
The power cord/code is not wound around the AC adapter
It might cause the disconnection if wrap the power supply code
around the AC adaptor
Unless the below-mentioned note is protected, it
becomes cause of breakdown
Do not use in such as moisture and dust, oily smoke, steam places.
Use will cause trouble in these places.
It does not allow to disassembled and remodel.
The cause of breakdown. As for inspection and repair inside
please ask the VAIO customer link repair window.
The water and the foreign material are not poured inside.
When the water and the foreign material enter, it becomes cause of
breakdown. IF the water and the foreign material enter, please
consult the VAIO customer link repair window.
Attention on safety of battery
It causes severely injure by the liquid leakage and generation of heat, the
explosion, and the ignition and the accidental ingestion and lose one's sight
when the battery usage is mistaken, so guard the following.
z Don't charge it excluding the specified charge method.
z Don't put it in the fire. The short is not allowed.
Don't heat it with the microwave oven and the oven. It might be short
when carrying, and keeping it with the metals.
z Don't charge and leave it under and near the fire and hot weather.
z When the liquid that leaks from a built-in battery catches one's eye,
please consult the doctor at once after washing in clear water.
z Don't strike the built-in batter.
Please do not give strong shock, do not put the heavy stuff, and turn
the heat by dropping. It causes the breakdown.
z The safety in the following cases is not warrantable.
－Not use it in the specified model
－Resolved and remodeled
Dismantle a built-in battery
－Please follow to the regulations and the local self-governing body.
－Please do not throw into the general rubbish away.
Please take it to the recycling cooperative store.
About the electric wave trouble self-imposed restraint
This device is class B info tech equipment based on the standard of electric
wave trouble self-imposed restraint conference (VCCI). The reception trouble
might be caused when this device is adjacent to the radio and the television
receiver and it is used though this device has aimed to use it by home
environments.
Please do it correct handling according to the manual.
About the attestation based on Radio Law
This product has received the attestation as wireless of small electric power
data communication based on Radio Law equipment. Therefore, when this
product is used, it is not necessary to license the wireless station.
However, when the following matters are done, it is likely to be punished by
the law.
• Resolution/remodel this product.
• Peel off the proof label pasted to the bottom of this product.
Moreover, this product is only for the domestic country. It is not possible to use
it in foreign countries because of Radio Law in each country.
About the frequency
This machine is 2.4 GHz bandwidth used. Other wireless applications might
use the same wavelength. Please use it noting the following matter to prevent
the electric wave interference with other wireless applications.
Directions of this machine
This frequency band are operated not only by other homogeneous wireless
stations besides the equipment for industry, the science, and the medical
treatment such as microwave ovens and production lines of the factory that
require the premises wireless station and the license for the movable body
identification, but also in a specific small electric power wireless station and
the amateur radio station (Hereafter, it is abbreviated, "Other wireless
stations"), that do not require the premises wireless station and the license.
1. Please confirm "Other wireless stations" has not been operated in the
vicinity before this machine is used.
2. Please promptly change the use place of this machine when the electric
wave interference is generated between this machine and "Other wireless
stations" by any chance or stop the operation of the equipment (the electric
wave is stopped).
3. Please inquire of the VAIO customer link when trouble and an uncertain
point occurs.
This wireless applications use 2.4GHz bandwidth.
The FH-SS modulation method is adopted as a modulation
method, and the distance is 20m.
About the laser safety standard
The goods concerning the laser standard (JIS C 6802) class agreement. The
following acceptable label is displayed in the mouse bottom.
About the leakage current self-imposed restraint, this device suits personal
computer standard (PC-11-1988) of corporation Japan Electronics and
Information Technology Industries Association (old JEIDA).
Collection and the recycling of a rechargeable battery
The lithium-ion battery can be recycled. Please paste the insulating tape such
as scotch tapes to the metal part and have the lithium-ion battery and
proposal unnecessary rechargeable battery in recycling cooperation shop.
Inquiries concerning the collection, the recycling of a rechargeable
battery, and the recycling cooperation shop:
JBRC
Homepage：
http://www.jbrc.net/hp/contents/index.html
Please detach a built-in battery according to the procedure on the
back when you annul this machine.
It is dangerous to use it excluding a built-in battery of this machine.
Please do not detach built-in battery, except when you annul this machine.
Battery drain
The battery using time might become short when leaving it for a long time to
discharge besides the battery relief the current naturally little by little even
when not using. We will encourage charging it again before it uses it.
The Battery capacity degradation and exchange of the battery
As for the battery, efficiency keeps decreasing little by little frequency of
charge, period of use, attendant upon retention period. 。For this reason,
which has not been fully charged battery life is shorter or longer life may be.
Battery life is short and has been the case, we specify a new battery in
exchange.
In regard to the exchange of the battery, please inquire to VAIO customer link.
At that time, it is not necessary to remove the built-in battery.
z is a trademark of Sony Corporation.
z Microsoft, Windows, and Windows Vista are registered trademarks of
Microsoft Corporation in the United States and/or other countries.
Forward button
Backward button
Wheel button
Right button
Left button
Power Switch
Connect Button
Status Lamp
Lens
z The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.,
andany use of such marks by Sony Corporation is under license. Other
trademarks and Trade names are those of their respective owners.
z All other names of systems, products, and services are trademarks of
their respective owners. In this manual, the ™ or ® marks are not
specified.
z In this manual, Microsoft® Windows® XP Home Edition and Microsoft®
Windows® XP Professional are referred to as Windows XP.
z In this manual, Windows Vista® Home Basic, Windows Vista® Home
Premium, Windows Vista® Business and Windows Vista® Ultimate are
referred to as Windows Vista.
*Attention
This machine might not work correctly by the version of the personal computer
and the software used.
Please confirm the system requirements beforehand on the homepage of the
VAIO customer link.
Please confirm information on the Bluetooth correspondence of biotechnology
on the homepage of the VAIO customer link.
MOUSE
Charging
* Attention *
「Main specification」 (inside)
When the range of the operating temperature described in the「 main
specification」(back) is exceeded, it is not possible to charge.
1 Connect cradle DC IN 5.2 V connector to AC adapter ①、AC And
connect AC adapter to power code②、and inserts it in the power
supply.③.
2 Put mouse on the cradle
The status lamp lights to the umber color when the charge starts.
When the status lamp is turned off, the charge is completed.
Charge time
z When the amount of the remainder of a built-in battery is enough,
lamp turns off after amber LED lights 3~4 sec. In the meantime
battery is not charging for protection.
z When mouse's status lamp has flashed amber color, it means
that remainder of built-in battery not enough. Please charge.
While connecting mouse
Use personal computer installed the Bluetooth software to connect the mouse.
Please see "Bluetooth equipment connection guide" of the attached paper
about the method of the connection.
HINT
As for the Bluetooth software there are times when operation differs
depending upon the personal computer of errand. Concerning the how to
use, the electronic manual which belongs to the personal computer itself
of errand please view together
Connection is cut off
Please turn the power switch of the mouse to OFF
The operation distance of the mouse
Operational distance usually has designated the mouse as within largest
approximately 10m from the personal computer. But, there are times when
carry-over factor of radio wave becomes extremely short depending upon use
environment, does not operate normally.
When the mouse does not operate normally, please make sure to use with the
below-mentioned environment
z You use at the place where just it is far from the other radio equipment
be made
z The mouse is used at the close place with the personal computer
z The mouse pad is used
while using mouse
When the mouse is moved, moving the pointer on the screen in the same
direction.
It explains here about mouse's basic use method.
*Attention*
z It is likely not to operate correctly on mouse pad including transparent
material according to characteristic of the laser sensor. In that case,
please avoid on such a material or use mouse pad for a laser sensor.
z As for fluor plastics PTFE (polytetrafluoro-ethylene) that the mouse uses
as foot pad is more slip compared to the desk and mouse pad because of
low friction material of its feature.
Speed of the pointer is adjustable
With the below-mentioned procedure, speed of the pointer can be adjusted
Windows XP：
1. [Start] it clicks the button, [the control panel], [the printer and the other
hardware], [the mouse], [pointer option] clicks in order of the button.
2. With item of speed regulation, necessary adjustment is done
Windows Vista：
1. [Start] it clicks the button, [the control panel], [the mouse], [pointer option]
clicks in order of the tub
2. With item of speed regulation, necessary adjustment is done.
*Attention*
z Indication of the picture speed regulation are times when it differs
depending upon the type of personal computer which has been used.
z When adjusting the speed of the pointer, the home page of VAIO
customer link (http://vcl.vaio.sony.co.jp/) please verify
Basic Function
Turn power switch ON on the back side of mouse.
1.Wheel button
The scroll operation can be done easily by clicking the scroll bar of the window
when the wheel button is used. Moreover, the auto scroll function can be used
by pushing the wheel button.
2.Left button
Use to open document and picture file made. When the mouse is used, this
button is chiefly used.
3.Left button
Use to copy document and picture file made and check those details. Short cut
menu is displayed to do various operations and the settings at once
4.Forward button
5.Backward button
The page displayed in Internet Explorer can be moved to ahead and the
following page.
Resolution switch
1. A left button and a right button are pushed at the same time while
pushing the CONNECT button on the back of the mouse.
The status lamp alternately blinks to green and orange, and it becomes a
resolution switch mode.
2. The following buttons are pushed according to the resolution.
800 dpi: left button.
1200 dpi: wheel button
1600 dpi: middle button
Attention in use
Use and the inventory location
Please do not use in the place where direct sunshine strikes and do not
keep it where a lot of moistures exists and where the temperature is high
and temperature is various.
Operation
z Please put and use it on the horizontal place.
z Please avoid a rapid temperature change. It might be dewy internal.
Bluetooth communications
z The 2.4 GHz band used by Bluetooth and wireless LAN devices is also
used by various other devices. Bluetooth devices incorporate technology
that minimizes interference from other devices using the same
wavelength. However, communication speed and achievable distances
may be reduced. Interference from other devices can also stop
communications altogether.
z The data transfer rate will vary depending on distance and obstacles
between devices, device configuration, radio interference, operating
system, software application, and so on. In some cases, communication
may be interrupted.
z Communication range will vary according to whether walls or other
obstacles are located between devices, the material used in walls, the
presence of radio frequency interference and other environmental
conditions, and the type of software being used.
z If wireless LAN and Bluetooth functionality are used at the same time on
the same personal computer, communication speed may be reduced due
to electromagnetic interference, and other unwanted effects may occur.
z
Remove Battery
Remove the cover on the back of the mouse
Remove cellophane and take out battery
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
After-sales service
Check first when you have trouble
Please see again examine this manual
Please contact the VAIO customer link when the condition
is still bad.
Please see the written guarantee about the VAIO customer link.
Repair during guaranteed term
Based on the content of the description of the written guarantee. However, It
might be assumed repair fee even though in the guaranteed term.
Please see the written guarantee in detail.
Repair after guaranteed term passes
The function can be maintained by the repair with charge
Repair
The repair of the Bluetooth laser mouse take place in our company.
Our designated vendor will receive and deliver the mouse from/to the
customer house. Please contact the VAIO customer link in detail.
About the repair parts for the repair
In terms of environmental protection, Sony might use the reproduction parts or
substitutes. Moreover, please acknowledge beforehand that Sony by occasion
will collect exchanged parts as an ownership thing.
The possession periods of parts
After discontinuance of manufacturing, our company has had the performance
parts (parts necessary to maintain the function of the product) for the repair of
the Bluetooth laser mouse for six years. We will make it to the period of being
able to repair this part possession period.
Please inform as follows when you consult.
z Model Name：VGP-BMS77
z Serial Number： Inside Battery Box
z State of breakdown：as detail as you can
z Purchase Date：
Main Feature
■ Mouse
Communication
method
Bluetooth Ver.2.0+EDR
Reading method Laser sensor
Resolution 800/1200/1600 account
Frequency 2.4 GHz（Bluetooth）
Power voltage DC 3.7 V （built-in battery）
Battery life About 1 month (full charged）
Communication
distance
Max. 10 m
Dimension 56.4（W） x 34.1（H） x 121.7（D） mm
Weight 110 g（battery imbedded）
■ Cradle
Dimension 62.2（W） X 56.5（H） X 75.8 (D） mm
Weight 45 g
■ Others
System Windows XP or Windows Vista
AC adapter Input ：AC100 - 240 V 50/60 Hz
（imbedded AC100 V [power cord）
Output ：DC 19.5 V
Working
temperature
5℃～35℃
Working moisture 20％～80％
Storage
temperature
–20℃～60℃）
Storage moisture 10％～90％
Attachments cradle（1）
AC adapter（1）
Power cord（1）
Li-On battery （1）
User manual （1）
Warranty card（1）
Troubleshooting
Before you consult VAIO customer link, already 1 times please try checking.
When even then condition is bad, please consult VAIO customer link.
Condition Action
The mouse does
not turn on when I
set the power
switch to ON.
Other mouse buttons are being pressed
while the power switch is set to ON.
→ If the power switch is set to ON while other mouse
buttons are being pressed, the mouse will not turn on.
Be sure not to press any other buttons when setting
the power switch to ON.
Nothing happens
when I press a
mouse button.
The software is not compatible.
→Use a supported
software. .
The mouse batteries are exhausted
→Replace the batteries. For details, see
“Inserting Batteries into the Mouse”.
The mouse and the personal computer are
not communicating
→Perform the steps in “Enabling
Communication between the Mouse and Your
Personal Computer” to ensure that proper
communication is possible.
→Turn off the mouse, wait a few seconds,
turn on the mouse, and then reestablish
communication.
→In some operating environments, the
usable distance may be notably shorter,
preventing normal operation. In such case,
use the mouse farther away from other
electronic devices such as other computers
and displays. →If the mouse is
too far from your personal computer,
communication is not possible. Bring the
mouse and your personal computer closer
together
The mouse is being used on an unsuitable
surface.
→ Due to the characteristics of the laser
sensor, the mouse may not work properly on
transparent surfaces or on a mouse pad that
has a clear surface. Avoid sing on such
materials, or use a Commercially-available
mouse pad that is compatible with a laser
sensor mouse.
The CONNECT button is pressed while
operating the mouse
→When the CONNECT button is pressed
while operating the mouse, the mouse goes
into a standby state for about 1 minute and
cannot be operated during this time. If you
press the CONNECT button, reset the power
switch of the mouse once to ON before
beginning operation.
The mouse may have difficulty
communicating in an environment with 2.4
GHz wireless LAN or other Bluetooth
communication.
→It is best to use the mouse in a location with
low interference from wireless devices.
Pressing the
CONNECT button
does not establish
a connection.
→ Check whether batteries are inserted in the
mouse. For details, see “Inserting Batteries into
the Mouse”.
→ If the power switch on the mouse is set to OFF,
communication with the personal computer is
not possible. Check the power switch setting
on the bottom of the mouse.
→ If the power does not come on when the power
switch is set to ON, the batteries may be
exhausted. Under normal operating conditions,
a set of alkaline batteries lasts about three
months. Replace the batteries. For details, see
“Inserting Batteries into the Mouse”.
→ Communication between the mouse and your
personal computer may not have been properly
established. If the CONNECT button on the
mouse is not pressed within 30 seconds after
the Bluetooth device search begins, mouse
communication is canceled. In such a case,
perform the procedure again to enable
communication. For details, see “Enabling
Communication between the Mouse and Your
Personal Computer.
→If the mouse and personal computer are too far
apart, communication is not possible. The
maximum communication distance between
the mouse and personal computer is about 32
ft. (10m). If used on a metal table or if
obstacles lie between the mouse and personal
computer, the usable distance may be less.
→ Make sure that the Bluetooth function on your
computer is activated. For details, refer to the
manuals provided with your personal
computer.
The scrolling
features do not
work.
The operating system is not compatible.
→ Use a supported operating system.
The program you are using is not
compatible with the scrolling features.
→ The scrolling features only work with programs
that use a scroll function
→ Some programs do not support the scrolling
features.
The pointer does
not move when I
→ Processing performed by Windows or other
software may temporarily disable the
move the mouse. mouse. Wait a few moments for the
processing to finish before using the
mouse.
→ You may find some useful solutions in your
personal computer’s operating instructions.
Refer to the manuals provided with your
personal computer.
The mouse batteries are exhausted.
→ If the power does not come on when the
power switch is set to ON, replace the batteries.
For details, see “Inserting Batteries into the
Mouse”.
The mouse is not set to ON.
→ Set the power switch on the bottom of the
mouse to ON.
The mouse and your personal computer
are not communicating.
→ Perform the steps in “Enabling Communication
between the Mouse and Your Personal Computer” to
ensure that proper communication is possible.
→ In some operating environments, the usable
distance may be notably shorter, preventing normal
operation. In such case, use the mouse farther away
from other electronic devices such as other
computers and displays.
→ If the mouse is too far from your personal
computer, communication is not possible. Bring
the mouse and your personal computer closer
together.
The mouse is being used on an unsuitable
surface.
→ Due to the characteristics of the laser sensor,
the mouse may not work properly on transparent
surfaces or on a mouse pad that has a clear
surface. Avoid using on such materials, or use a
commercially-available mouse pad that is
compatible with a laser sensor mouse.
The mouse pointer
does not move
smoothly across
the screen.
→Due to the characteristics of the laser sensor,
the mouse may not work properly on
transparent surfaces or on a mouse pad that
has a clear surface. Avoid using on such
materials, or use a commercially-available
mouse pad that is compatible with a laser
sensor mouse.
Exiting
power-saving
mode with the
mouse is not
possible.
→ Press any key or the power button on the
keyboard.
The mouse does
not move smoothly
after returning from
the power saving
mode.
→Deactivate the Bluetooth connection, wait a few
seconds, and then reestablish connection.
The mouse is not
found when the
Bluetooth device
search is
performed.
z The mouse is unable to be detected.
→ Press the CONNECT button located on
the bottom of the mouse, and then try the
search again.
z The power switch on the mouse is set to OFF.
→ Check the power switch setting on the
bottom of the mouse.
z The Bluetooth function on your computer is
not activated.
z Make sure that the Bluetooth function is
activated.
→For details, refer to the manuals provided
with your personal computer.
I am asked to input
a key at the time of
authentication.
Input “0000” as the key.
To prevent fire or shock hazard, do not expose the unit to rain or
moisture.
WARNING
Owner’s Record
The model number and the serial number are located inside the battery
compartment of the mouse. Record the serial number in the space provided
below. Refer to this number whenever you call your Sony dealer regarding this
product.
Model No. VGP-BMS77
Serial No. ____________________
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
For questions regarding your product or for the Sony Service Center nearest you,
call 1-888-476-6972 in the United States or 1-800-961-7669 in Canada.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
IC Statement
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may
cause undesired operation of the device.
For customers in the U.S.A. and Canada
This equipment complies with FCC/IC radiation exposure limits set forth for
uncontrolled equipment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency
(RF) Exposure rules. This equipment has very low levels of RF energy that it
deemed to comply without maximum permissive exposure evaluation (MPE).
But it is desirable that it should be installed and operated with at least 20cm
and more between the radiator and person’s body (excluding extremities:
hands, wrists, feet and ankles). Caution - The use of optical instruments with
this product will increase eye hazard.
Located on bottom side
For customers in other countries and regions
The equipment is classified as a CLASS 1 LASER PRODUCT and complies
with the Laser Products Safety Standard IEC/EN 60825-1. You can find the
following sticker on the bottom of this equipment.
VGP-BMS77(J)_X-XXX-XXX-XX(1)
