Primax Electronics TRFEX7 Bluetooth Headset User Manual RF EX7 10 0723 QSG V1 EN Draft6

Primax Electronics Ltd Bluetooth Headset RF EX7 10 0723 QSG V1 EN Draft6

User Manual

1 Rocketsh RF-EX7 Bluetooth headset
1 charger
1 USB charging cable
1 Quick Setup Guide (what you’re looking at)
4 round earbuds
3 tted earbuds
(medium size is pre-attached)
1 ear loop
1 Lift the charging port cover, then
connect the charger.
When, the indicator changes from red to
green, and you can disconnect the
charger.(See no.11 and no. 36)
Use one of the tted earbuds for the most
convenient and comfortable t, or alternatively use
a round earbud in combination with the ear loop.
To use a rounded earbud:
1 Remove the tted
earbud that's already
attached, then press
the round earbud
onto the headset.
2 Attach the ear loop
for a secure t.
3 Activate Bluetooth on your phone,
then set your phone to search for nearby
Bluetooth devices. For help with this step,
see your cell phones user guide.
4 When your phone detects the RF-EX7,
select it on the list, then enter “0000”
(zeros) for the PIN. The headset beeps and
the indicator turns green.
To turn o the headset, press and hold the
power button for about two seconds.
2 Press and hold the power button for 3
seconds to turn on your headset. It will
automatically enter pairing mode when
you turn it on for the rst time. When in
pairing mode, the LED light will blink
Green.(on conrmation)
1 Power & Pair 2 Get the perfect t
What’s in the box:
LED light
Ear bud
Charging port
with cover On/O
(reverse side)
Volume
touch pad
Send/end button
Bottom view
To use a tted earbud:
1 Attach the appropriate size
of tted earbud onto the
headset. The medium tted
earbud is already attached.
2 Insert the headset vertically in
your ear (shown in step 2)
3 Rotate the headset up towards
your mouth. The exible
portion of the ear bud should
t securely towards the back
of your outer ear.
You may need to guide it to a
comfortable position with
your nger.
Ear loop
Round earbuds
Fitted earbuds
Charger
Headset
LED light
What is PureSpeech®?
PureSpeech is a state-of-the-art noise cancelation and signal processing technology
created by SRS Labs and CSR. Your EX7 headset incorporates PureSpeech so that you
can hear your calls in amazing clarity, but also so you can be heard clearly by your
callers. PureSpeech is always activated on the EX7 so you will "Hear and Be Heard Like
Never Before."
v1
R7
3 To Call
To dial a number, make sure that your
headset is turned on, then dial the number
from your phone. Your headset will activate
as soon as the number is dialed.
To voice dial a number (not supported on
all phones), press send/end. A tone plays,
which is your signal to speak the command
or number.
Know the facts
Recharge time: About two hours
Talk time: Up to eight hours
Standby time: Up to 300 hours
Phone pairing: Up to eight phones at the same time
LEDs
To... Do this...
End a call Press send/end.
Answer a call Press send/end.
Redial a number Double-press send/end.
Reject a call
Double-press send/end.
Switch a call
between the
headset and
the phone.
Mute a call Double-press send/end.
10-0723
4 Maintaining
Press and hold the
power button and
send/end for about
two seconds.
To... Do this...
Increase
the volume
Decrease
the volume
Swipe upward (toward the ear)
on the touch pad.You will hear a
dierent "beep" for each level
change in volume.
Swipe downward (away from
the ear) on the outside of the
headset.
To...
Enable or disable the indicator
Check the battery level (method 1)
Check the battery level (method 2)
Erase paired device information
Multipoint pairing (pairing the
headset to multiple phones)
Reset
Disconnect from the phone (un-pair)
Do this...
Press the power button and send/end together.
Turn the headset on, then press and release the power button.
Green = Between 1/2 and full charge
Green then red = Between 1 hour talk time remaining
and 1/2 charge
Red = Less than 1 hour talk time remaining.
Turn the headset on. If the indicator ashes red and green,
or if it beeps every 300 seconds, the battery level is low.
Turn the headset o, then press and hold the power button
and send/end together for about two seconds.
Pair each phone with the headset. When you are in a call with one phone
but the other phone rings, press send/end to switch to the second call.
Connect the charger to reset the headset, then user can power on
headset after remove the charger.
Turn the headset o, then use the phone’s Bluetooth menu to
disconnect it. For help with this step, see your cell phones user guide.
Green Power On
Green (fast ashing) Pairing State
Red (ashing) Low Battery RF-EX7
EX7
WITH PURE SPEECH®
Hear and be heard like never before
© 2010 Best Buy Enterprise Services, Inc. Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN USA 55423-3645 RFEX7 QUICK SETUP GUIDE
FCC Part 15
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
FCC ID: EMJTRFEX7
“You are cautioned that changes or modications not
expressly approved by the part responsible for
compliance could void the
user’s authority to operate the equipment”.
Canada IC-RSS210 statement
IC: 4251A-HRFEX7
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of
the device.
