Antenna Gain and Power table
Antennas Used for 2.4 GHz Testing
For P-MP operation, the transmit power must be reduced if the gain of the antenna exceeds 12 dBi.
The Transmit power must be set that +36 dBm EIPR is not exceeded.
Antenna Type
Gain
Manufacturer and
Model Number
Operation Allowed
Transmit
Power
Allowed
Omni-directional 12 dBi Terabeam A2412 Point to Multipoint 24 dBm
Flat Panel 18 dBi Terabeam FP18 Point to Point 24 dBm
Sector Antenna 17 dBi Terabeam LP17 Point to Multipoint 19 dBm
