User Manual
802.11 a/b/g/n Mini-PCI module
MB82HP
RF Module User’s Guide
NOTICE:
The information in this document has been carefully
reviewed and is believed to be accurate. Nonetheless, this document is subject to change without
notice, and Proxim Wireless Corporation (Proxim) assumes no responsibility for any inaccuracies
that may be contained in this document and makes no commitment to update or to keep current
the contained information, or to notify a person or organization of any updates. Proxim reserves
the right to attempt to supply the best product possible. Proxim dos not represent the products
described herein are free from patent infringement or from any other third party right.
Subject to change without notice.
PROXIM MAKES NO WARRANTIES OF ANY KIND WITH REGARD TO THE CONTENT OF
THIS DOCUMENT, IN NO EVENT SHALL PROXIM BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL SPECULATORY OR CONCEQUENTIAL DAMAGES ARISING
FROM THE USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF
ADVISED OF THE POSIBILITY OF SUCH DAMAGES. IN PARTICULAR PROXIM SHALL
NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA TRANSMITTED OR
OTHERVWISE USED WITH THE PRODUCT, INCLUDING THE COST OF REPARING,
REPLACING, INTERGATING, INSTALLING OR RECOVERING SUCH HARDWARE,
SOFTWARE OR DATA.
This document use information provided by Atheros Communications Inc. (Atheros), Atheros
radio and chipsets user manuals, technical specifications, and Atheros regulatory manual.
INTRODUCTION
The Proxim MB82HP miniPCI module implements an IEEE
802.11a/b/g/n wireless LAN (WLAN) with Master function. MIMO operation is implemented
using three transmit and three receive chains per the 802.11n standard.
The device will be marketed under brand name: Proxim and model: MB82HP.
This module may be installed in PC and host processor systems using approved external
antennas. The module may be configured for 5GHz and 4.9GHz operation USING THE Web
Server function provided by Atheros Communications Inc. Please, refer to Atheros’ driver User
Manual instructions for details.
※ The 2.4GHz radio frequency band will be turn off by firmware on this module.
CONFIGURATION
This section provide procedures for connecting and
configuring the AP. Configuration can be performed either from a web browser accessing the
build-in web server, or by entering commands using the command line interface (CLI). For
detailed information on using the server refer to “AP Web Server and for using CLI, refer to
detailed operational guide provided by Atheros for the chipset.
AP Initial Configuration
Configure the AP for its Service Set Identifier (SSID) unique to the application. This
configuration can be done either through a web browser with access to the build-in AP web
server, or by commands using the command line interface (CLI).
WEB Browser
3. Select the Access Point Web Server hotlink.
4. A dialog box appears requesting login authorization. When prompted, enter the following
information to log in:
Login: Admin (case-sensitive) Password: 5up
5. Click OK to complete the login process. The 5GHz Statistics window will appear.
6. Select the Configuration hotlink from the navigation menu. The system Configuration window
will appear.
7. Enter the SSID (name or address) for the AP in the SSID field. The SSID must be 132
characters in length.
To configure a single SSID to have more then one AP in a
single SSID, specify a unique System Name for each AP
within that single SSID. Note that range of available channels will be automatically determined
by factory settings.
Note that the radio channel is specified using the IEEE 802.11a standard. For example, channel
48 is the equivalent of 5.240 GHz. The channel number is derived as:
Channel Frequency (in MHz) – 5000MHz Channel Number =
5MHz
1 Click Update to commit the changes.
2 After all configuration changes are complete, reboot the AP to enable them. To reboot AP,
click on the REBOOT AP button that appears.
For detailed information on using the server refer to “AP Web Server” and for using CLI refer to
“AP Command-Line Interface” provided in Appendixes A and B of Atheros MPCI Module User’s
Guide.
FCC Requirements for Operation in the
United States
This device is restricted to indoor use only due to its operation in 5150 to 5250 MHz frequency
ranges in accordance with latest FCC regulations.
Host systems using Porxim Firmware with this 802.11a/b/g/n 3x3 MIMO nimiPCI module to be
sold in the United States do not have country code settings and are factory configured to only
operate on the channels allowed by the FCC. Master devices with a US SKU that contain the
802.11a/b/g/n Radio module are limited to the following operating channels:
? 36 – 64 (5180 to 5320 MHz) in the 5150 to 5250 MHz band
? 149 – 165 (5745 to 5825 MHz) in the 5725 to 5825 MHz band
? 4940 to 4990MHz band.
FCC Statement:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one of the following
measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This device and its antenna(s) must not be co-located or operation in conjunction with any other
antenna or transmitter.
This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor
environment only.
FCC NOTICE: To comply with FCC part 15 rules in the United States, the system must
be professionally installed to ensure compliance with the Part 15 certification. It is the
responsibility of the operator and professional installer to ensure that only certified systems are
deployed in the United States. The use of the system in any other combination (such as
co-located antennas transmitting the same information) is expressly forbidden.
The module (Model number: MB82HP) is Limited Module Approval and only limited to install to
the AP (Proxim / MP 8200).
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 50cm
between the radiator & your body.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC
compliance requirement of the end product, which integrates this module.
50cm minimum distance has to be able to be maintained between the antenna and the users for
the host this module is integrated into. Under such configuration, the FCC radiation exposure
limits set forth for an population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the user’s manual of the end product, the end user has to be informed to keep at least 50cm
separation with the antenna while this end product is installed and operated. The end user has to
be informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment
can be satisfied. The end user has to also be informed that any changes or modifications not
expressly approved by the manufacturer could void the user's authority to operate this
equipment.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX FCC ID:
HZB-MB83HP5 ". The FCC part 15.19 statement below has to also be available on the label:
This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept
any interference received, including interference that may cause undesired operation.
IC Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
This device and its antenna(s) must not be co-located or operation in conjunction with any other
antenna or transmitter.
Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une
autre antenne ou transmetteur.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec
une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut
choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne
dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.
This radio transmitter (identify the device by certification number, or model number if Category II)
has been approved by Industry Canada to operate with the antenna types listed below with the
maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for
that type, are strictly prohibited for use with this device.
Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son numéro de modèle
s'il fait partie du matériel de catégorie I) a été approuvé par Industrie Canada pour fonctionner avec les
types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour
chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au
gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
The device could automatically discontinue transmission in case of absence of information to
transmit, or operational failure. Note that this is not intended to prohibit transmission of control or
signaling information or the use of repetitive codes where required by the technology.
Le dispositif pourrait automatiquement cesser d'émettre en cas d'absence d'informations à transmettre, ou
une défaillance opérationnelle. Notez que ce n'est pas l'intention d'interdire la transmission des
informations de contrôle ou de signalisation ou l'utilisation de codes répétitifs lorsque requis par la
technologie.
This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor
environment only.
The module (Model number: MB82HP) is Limited Module Approval and only limited to install to
the AP (Proxim / MP 8200).
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 50cm
between the radiator & your body.
Declaración de exposición a la radiación de Canada: Este equipo cumple con los límites de exposición a
la radiación de la IC establecidos para un ambiente no controlado. Este equipo se debe instalar y operar
con una distancia mínima de 50 cm entre el radiador y su cuerpo.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is still responsible for the IC
compliance requirement of the end product, which integrates this module.
50cm minimum distance has to be able to be maintained between the antenna and the users for
the host this module is integrated into. Under such configuration, the IC RSS-102 radiation
exposure limits set forth for an population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 50cm
separation with the antenna while this end product is installed and operated. The end user has to
be informed that the IC radio-frequency exposure guidelines for an uncontrolled environment can
be satisfied. The end user has to also be informed that any changes or modifications not
expressly approved by the manufacturer could void the user's authority to operate this equipment.
IC statement is required to be available in the users manual: This Class B digital apparatus
complies with Canadian ICES-003. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX IC:
1856A-MB83HP5 ".
Antenna information:
Ant.BrandModelNameAntenna
TypeChain Attenuator
(dBi)ConnectorAntenna
Gain
Cable
loss
TestAnt
Gain(dBi)
1MARSMA‐WA55‐30Panel1/2/3 20N‐Type,Female3028
2MARSMA‐WB55‐20Sector1/2/3 10N‐Type,Female2028
3SmartAntUSI05‐220170Dipole1/2/3 - RPSMAPlug514
4MARSMA‐WO55‐10NHOmmi1/2/3 ‐
N‐Type,Female/
N‐Type,Male
(optional)
1028
5CommScope PX3F‐52‐N7ADish1/3 20NFemale34212
6MARSMA‐WA56‐DP25N Panel1/3 20N‐Type,Female23.521.5
7MARSMA‐WD56‐DP16Sector1/3 10N‐Type,Female1624
