Proxim Wireless NGP1058 802.11 ac PCIe Module User Manual NGP1058 user manu 20150527
Proxim Wireless Corporation 802.11 ac PCIe Module NGP1058 user manu 20150527
User manual
802.11acPCIeModule
Model Number: NGP1058
Warning Statement
FCC NOTICE
This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This device generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
device does cause harmful interference to radio or television reception, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Connect the computer to an outlet on a circuit different from that to which
the receiver is connected.
• Increase the separation between the computer and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the grantee
of this device could void the user's authority to operate the equipment.
FCC Compliance Statement: This device complies with Part 15 of the
FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that
may cause undesired operation.
RF Exposure warning
The equipment complies with FCC RF exposure limits set forth for an
uncontrolled environment.
This device and its antenna(s) must not be co-located with any other transmitters
except in accordance with FCC multi-transmitter product procedures.
Refering to the multi-transmitter policy, multiple-transmitter(s) and module(s)
can be operated simultaneously without C2P.
This device is going to be operated in 5.725~5.85GHz frequency range.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is responsible
for the compliance to all the rules that apply to the product into which this
certified RF module is integrated.
Additional testing and certification may be necessary when multiple modules
are used.
390cm minimum distance has to be able to be maintained between the antenna
and the users for the host this module is integrated into. Under such
configuration, the FCC radiation exposure limits set forth for an
population/uncontrolled environment can be satisfied.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep
at least 390cm separation with the antenna while this end product is installed and
operated. The end user has to be informed that the FCC radio-frequency
exposure guidelines for an uncontrolled environment can be satisfied. The end
user has to also be informed that any changes or modifications not expressly
approved by the manufacturer could void the user's authority to operate this
equipment. If the size of the end product is smaller than 8x10cm, then additional
FCC part 15.19 statement is required to be available in the users manual: This
device complies with Part 15 of FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following "
Contains TX FCC ID: HZB-NGP1058 ". If the size of the end product is larger
than 8x10cm, then the following FCC part 15.19 statement has to also be
available on the label: This device complies with Part 15 of FCC rules. Operation
is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Overview the Product
Introduction
The high-performance Wireless Radio Module is designed for enterprise and
public access applications. Embedded with the Atheros chipset, it boasts
network robustness, stability and wider network coverage. Based on 802.11n
(Draft 2.0), the access point supports high-speed data transmission of up to
800Mbps.
The access point host with this device is capable of operating in different
modes, which makes it suitable for a wide variety of wirelessapplications,
including long-distance deployments.
Designed with dual polarization high gain antenna it offers a compact,
rugged design for outdoor installation and excellent performance..
To protect your security and privacy, the access point with this device is
armed with many enhanced and latest wireless security features such as
IEEE 802.11i standards, MAC Address Filtering, IEEE 802.1x Authentication
and 64/128-bit WEP (Wired Equivalent Privacy) to ensure privacy for the
heterogeneous mix of users within the same wireless network.
Features
• Qualcomm-Atheros QCA9882,Peregrine Series
• Maximum 27dBm output power (per chain), 30dBm (aggregate)
• IEEE 802.11ac complaint & backward compatible with 802.11a/n
• 2X2 MIMO Technology & up to 867Mbps
• MiniPCI Express 1.1 interface
• Supports Spatial Multiplexing, Cyclic-Delay Diversity (CDD), low-density parity
check (LDPC), Maximal Ratio Combining (MRC), Space Time Block Code (STBC)
• Supports IEEE 802.11d, e, h, I, k, RO, v time stamp, and w standards
• Supports Dynamic Frequency Selection (DFS)
• Cards are individually calibrated for Quality Assurance
• Supported by either CompexWRT with Atheros Reference Wireless Driver OR
OpenWRT with ath10k Wireless Driver on WPJ344
Install in the Host
This device will be build-in into Proxim’s Host Tsunami ®, and it should be
professional installation.
The host system must be labelled with: Contains FCC ID: HZB-NGP1058;
Please refer to the user guide for the host on our web site :
http://www.proxim.com/
