Proxim Wireless PROXMB82 802.11a/b/g/n MPCI Module User Manual PROXMB82 UserManual v2
Proxim Wireless Corporation 802.11a/b/g/n MPCI Module PROXMB82 UserManual v2
Contents
User Manual
1561 Buckeye Drive Milpitas, CA 95035 P 408.383.7600 F 408.383.7680 www.proxim.com
PROXMB82 nimiPCI Module
User’s Guide
Revision January 2010
1561 Buckeye Drive Milpitas, CA 95035 P 408.383.7600 F 408.383.7680 www.proxim.com
NOTICE:
The information in this document has been carefully reviewed and is believed to be
accurate. Nonetheless, this document is subject to change without notice, and Proxim
Wireless Corporation (Proxim) assumes no responsibility for any inaccuracies that may
be contained in this document and makes no commitment to update or to keep current the
contained information, or to notify a person or organization of any updates. Proxim
reserves the right to attempt to supply the best product possible. Proxim dos not represent
the products described herein are free from patent infringement or from any other third
party right.
Subject to change without notice.
PROXIM MAKES NO WARRANTIES OF ANY KIND WITH REGARD TO THE
CONTENT OF THIS DOCUMENT, IN NO EVENT SHALL PROXIM BE LIABLE
FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL SPECULATORY OR
CONCEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSIBILITY OF SUCH DAMAGES. IN PARTICULAR PROXIM SHALL NOT
HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA
TRANSMITTED OR OTHERVWISE USED WITH THE PRODUCT, INCLUDING
THE COST OF REPARING, REPLACING, INTERGATING, INSTALLING OR
RECOVERING SUCH HARDWARE, SOFTWARE OR DATA.
This document use information provided by Atheros Communications Inc. (Atheros),
Atheros radio and chipsets user manuals, technical specifications, and Atheros regulatory
manual.
1561 Buckeye Drive Milpitas, CA 95035 P 408.383.7600 F 408.383.7680 www.proxim.com
INTRODUCTION
The Proxim PROXMB82 miniPCI module implements an IEEE 802.11a/b/g/n wireless
LAN (WLAN) with DFS Master function. MIMO operation is implemented using three
transmit and three receive chains per the 802.11n standard.
The device will be marketed under brand name: PROXMB and model: PROXMB82.
This module may be installed in PC and host processor systems using approved external
antennas. The module may be configured for 2.4 GHz or 5 GHz operation USING THE
Web Server function provided by Atheros Communications Inc. Please, refer to Atheros’
driver User Manual instructions for details.
1561 Buckeye Drive Milpitas, CA 95035 P 408.383.7600 F 408.383.7680 www.proxim.com
CONFIGURATION
This section provide procedures for connecting and configuring the AP. Configuration
can be performed either from a web browser accessing the build-in web server, or by
entering commands using the command line interface (CLI). For detailed information on
using the server refer to “AP Web Server and for using CLI, refer to detailed operational
guide provided by Atheros for the chipset.
AP Initial Configuration
Configure the AP for its Service Set Identifier (SSID) unique to the application. This
configuration can be done either through a web browser with access to the build-in AP
web server, or by commands using the command line interface (CLI).
WEB Browser
3. Select the Access Point Web Server hotlink.
4. A dialog box appears requesting login authorization. When prompted, enter the
following information to log in:
Login: Admin (case-sensitive)
Password: 5up
5. Click OK to complete the login process. The 5 GHz Statistics window will appear.
6. Select the Configuration hotlink from the navigation menu. The system
Configuration window will appear.
7. Enter the SSID (name or address) for the AP in the SSID field. The SSID must be 1-
32 characters in length.
1561 Buckeye Drive Milpitas, CA 95035 P 408.383.7600 F 408.383.7680 www.proxim.com
To configure a single SSID to have more then one AP in a single SSID, specify a
unique System Name for each AP within that single SSID. Note that range of
available channels will be automatically determined by factory settings.
Note that the radio channel is specified using the IEEE 802.11 a standard. For
example, channel 48 is the equivalent of 5.240 GHz. The channel number is derived
as:
Channel Number =
8. Click Update to commit the changes.
9. After all configuration changes are complete, reboot the AP to enable them. To
reboot AP, click on the REBOOT AP button that appears.
For detailed information on using the server refer to “AP Web Server” and for using CLI
refer to “AP Command-Line Interface” provided in Appendixes A and B of Atheros
MPCI Module User’s Guide.
Channel Frequency (in MHz) – 5000 MHz
5MHz
1561 Buckeye Drive Milpitas, CA 95035 P 408.383.7600 F 408.383.7680 www.proxim.com
FCC Requirements for Operation in the United States
This device is restricted to indoor use only due to its operation in 5150 to 5250 MHz and
5470 to 5725 MHz frequency ranges in accordance with latest FCC regulations.
Host systems using Porxim Firmware with this 802.11 a/b/g/n 3x3 MIMO nimiPCI
module to be sold in the United States do not have country code settings and are factory
configured to only operate on the channels allowed by the FCC. Master devices with a
US SKU that contain the 802.11 a/b/g/n Radio module are limited to the following
operating channels:
1 -11 (2412 to 2462 MHz) in the 2.4 GHz band
36 – 64 (5180 to 5320 MHz) in the 5150 to 5350 MHz band
100 – 116 (5500 to 5580 MHz) and 132 – 140 (5660 to 5700 MHz) in the 5470 to
5725 MHz band
149 – 165 (5745 to 5825 MHz) in the 5725 to 5825 MHz band
High power radars may use the 5250 to 5350 MHz and 5470 to 5725 MHz frequency
ranges in your area. Such radar stations can cause interference and damage to this device.
This radio module implements a radar detection function which may cause interruption of
normal operation when radar signal is detected.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
RF Exposure
To ensure compliance with FCC RF exposure requirements, the antennas used for this
device must be installed to provide a separation distance of at least 20 cm from all
persons.
