Features
Small size and premium ID design which is suitable for PDA and handled device.
Low power consumption, extend battery life of Host system
2400-2483.5 MHz single SKU for world wide market
Support 802.11d for universal regulation
Easy for use on mobile and handheld devices with CF type I interface
Two ceramic antennas support antenna diversity to extend the range performance and maintain robust
wireless link under multi path fading
environments.
Support Wi-Fi and Radio regulatory
compliance
Wi-Fi is a trademark of the Wireless Ethernet Compatibility Alliance. This product is certified
by Wi-Fi Alliance.
Introduction
Compact Flash Card
USI Mobility Device's
Wireless Solution
WLAN
The USI 802.11 Type I Compact flash Wireless network adapter card which refers as "CF-B-AG-01" is a full
function 802.11b 11Mbps wireless network adapter, which provides CF+ host interface with type 1 mechanical
design. CF-B-AG-01 provides the wireless network connectivity anywhere, anytime for PDA or handheld
devices.
CF-B-AG-01 is a standard product which is approved as one of USI WLAN NIC product lines. That supports
user friendly interface software and plug and play features to enable user for management and access to the
network.
The small size design, low power consumption and excellent Radio performance make it the best solution for
OEM customers who require CF type 802.11b WLAN NIC adapter, such as, access point, wireless router, PDA,
mini-Printer, wireless camera, Tablet PC etc.
For the Hardware features, Agere "Beagle" chipset solution is adopted. In additional to the classic radio
performance of Agere solution, two ceramic antennas provide diversity switch, which support robust and
smooth data connection under multi-path (office) environments. New features such as WOL (Wake on LAN)
and 802.11d are supported for new application and requirement.
In addition to WEP, WPA and TKIP are supported to provide your network security. For the software and driver
development, USI provides standard drivers base on listed OS and processors for OEM.
www.usi.com.tw
www.usi.com.tw
WLAN Compact Flash Card Family
Specification
IEEE 802.11b/g (2.4-GHz)
11b- 11, 5.5, 2, 1 Mbps
11b- DSSS, CCK
WEP64/128-bit
WPA (SSN) Support Availability
Host System Interface
Operting Volatge
Dimensions (mm)
Operating Temperature
802.11d Support
Wake-On-Lan (WOL)
Power Saving Mode
Microsoft Windows
Linux , Vx Works
Certification
CF-B-AG-02
802.11b
Agere Hermes-II
Yes
Yes
Yes
WEP 64.128 bit
WPA/TKIP SSN
-83 @ 11 Mbps
-86 @ 5.5 Mbps
-89 @ 2 Mbps
-92 @ 1 Mbps
15 (Typical)
TX : 265
RX :165
Sleep : 2- 15 mA
CompactFlash Type-I
5/3.3 Volt
56.56x42.8x5.57
0-70 Celsius
Yes
Yes
Yes
Win98/ME/2000/XP
WinCE 3.0/NET
Pocket PC 2002 ,2003
FCC , Telec, ...Cetificated
PDA, Tablet PC,
Mobile Device, AccessPoint,
Router, Printer .. Etc.
Available Now
N/A
2 (U.FL) RF Connector
CF-B-AG-01
802.11b
Agere Hermes-II
Yes
Yes
Yes
WEP 64.128 bit
WPA/TKIP SSN
-83 @ 11 Mbps
-86 @ 5.5 Mbps
-89 @ 2 Mbps
-92 @ 1 Mbps
15 (Typical)
TX : 265
RX : 165
Sleep : 2- 15 mA
CompactFlash Type-I
5/3.3 Volt
56.56x42.8x5.57
0-70 Celsius
Yes
Yes
Yes
Win98/ME/2000/XP
WinCE 3.0/ NET
Pocket PC 2002 ,2003
FCC , Telec, ...Cetificated
PDA, Tablet PC,
Mobile Device, Notebook
Available Now
Power / link activity
2, Ceramic with Diversity
Supported
Model Name
Wireless Network
Standard
Chipset Solution
Specification
Security
Receive Sensitivity(dBm)
RF Output Power (dBm)
Power Consumption
(mA)
Physical and
Environmental
Specifications
Features
Operating System
Support
Regulatory Approval
Application
Availability Status
LED Indicator Classic Blue
Antenna
RF Connector
Specification CF Card CF Module
WLAN Compact Flash Card
Internet:
E-mail:
Headquarters:
Asia:
America:
Name:
Location:
Tel:
Fax:
E-mail:
http://www.usi.com.tw
usi@ms.usi.com.tw
141, Lane 351, Taiping Road, Sec. 1, Tsaotuen, Taiwan,
(Tsaotuen)+886-49-2350-876, 2325-876 (Nankang)+86-49-2261-876
China: (Shenzhen)+86-755-2693-1560 (Shanghai)+86-21-5896-6996
Japan: (Yokohama)+81-45-3483-885
USA: (CA)+1-408-776-1966 (NC)+919-771-2788 ext.101
(TX)+512-835-2500 ext. 30
Contact Window
BR-CF-01-20030711
