Users Manual
IKÔN RFID MODULE HF-AM1-IKON
EXPANSION MODULE INSTRUCTIONS
Important: All Approval and safety information is outlined in the ‘IKÔN Rugged PDA User Manual’ – part
number 8100147A.
Important: The IKON with the RFID option must not be held closer than 20 cm from the rest of the
body. This product must not be used in a holster or on a belt-clip.
Easily installable expansion modules for the IKON allow you to customise this hand-held to meet your
specific mobile computing requirements. This chapter outlines how to install the RFID Module HF-AM1-
IKÔN.
• Remove the batteries. If your unit is using AC power, disconnect it.
• Stick the FCC / IC Label (FCC ID: GM3HFA1IKON, IC ID: 2739D-HFAM1IKON) underneath the battery.
IKON PDA
Label area
• The RFID Module HF-AM1-IKON is connected by the Docking port
Docking port
May 14, 2009
DPD A00472 A00 Sheet 1 of 3
IKÔN Snap-On RFID Device
• Slide the RFID Snap-on under the IKON.
For detailed instructions, pleased refer to IKON Rugged PDA User Manual and to the RFID MODULE HF-
AM1-IKÔN User manual.
Important: The IKON PDA with the RFID option must not be held closer than 20 cm from the rest
of the body. This product must not be used in a holster or on a belt-clip.
READING AREA:
This area depends on the TAG type, TAG packaging, TAG position and environment (metallic or not).
Reading Area
TAG
May 14, 2009
DPD A00472 A00 Sheet 2 of 3
IKÔN RFID MODULE HF-AM1-IKON
RFID Regulatory Information
IMPORTANT NOTE FOR NORTH AMERICA:
The RFID must not be used whilst the host IKON PDA is being powered by the ac/dc adaptor.
FCC Information to Users:
This product and it antennas must not be co-located or operated in conjunction with any other antenna or
transmitter.
Radiation Exposure Compliance
This product complies with the FCC RF exposure limits for an uncontrolled environment. For continued
compliance, the product must not be held closer than 20 cm from the rest of the body. This product must
not be used in a holster or on a belt-clip.
Federal Communication Commission Interference Statement.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
Emissions Information for Canada:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
