Important: All Approval and safety information is outlined in the ‘EP10 Handheld-computer User Manual’ – part number
8000227. This manual is available on our website www.psion.com through the community website
http://community.psion.com/home/default.aspx.
Important: The EP10 with the RFID option must not be held closer than 20 cm from the rest of the body. This product
must not be used in a holster or on a belt-clip.
The RFID Module HF-KR1-2S
PART NUMBER: 8000277 REV: A.0
SHEET 2 OF 5
Important: The EP 10 with the RFID option must not be held closer than 20 cm from the rest of the body. This product
must not be used in a holster or on a belt-clip.
¾ Reading area:
This area depends on the TAG type, TAG packaging, Tag position and environment (metallic or not).
¾ Software installation:
o Copy and install the two latest CAB file named ““Psion EP10 HF.CAB” and “RFID Driver_EP
10_EP10_HF_KRX_2S.CAB”
Reading Area
Tag
PART NUMBER: 8000277 REV: A.0
SHEET 3 OF 5
o After installation, select “Psion EP10 HF” in Program File folder, the connection panel opens:
o To read the ID of a TAG, press the Read button. Put the TAG in front of the antenna.
Select TAG type
ID tag
PART NUMBER: 8000277 REV: A.0
SHEET 4 OF 5
EP 10 RFID MODULE HF-KRX-2S
RFID Regulatory Information
IMPORTANT NOTE FOR NORTH AMERICA:
The RFID must not be used whilst the host EP 10 is being powered by the ac/dc adaptor.
FCC Information to Users:
Radiation Exposure Compliance
This product complies with the FCC RF exposure limits for an uncontrolled environment. For continued compliance, the
product must not be held closer than 20 cm from the rest of the body. This product must not be used in a holster or on a belt-clip.
Federal Communication Commission Interference Statement.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
Emissions Information for Canada:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is Subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
PART NUMBER: 8000277 REV: A.0
SHEET 5 OF 5
