118 3 Phcc Pro Series Vs Float Switch Brochure Catalog 10 2015 Email User Manual

544584 4 Phcc Pro Series Vs Float Switch Brochure 544584_4_PHCC Pro Series VS Float Switch Brochure

544596 4 Phcc Pro Series Vs Float Switch Brochure 544596_4_PHCC Pro Series VS Float Switch Brochure

544600 4 Phcc Pro Series Vs Float Switch Brochure 544600_4_PHCC Pro Series VS Float Switch Brochure

544604 4 Phcc Pro Series Vs Float Switch Brochure 544604_4_PHCC Pro Series VS Float Switch Brochure

544719 4 Phcc Pro Series Vs Float Switch Brochure 544719_4_PHCC Pro Series VS Float Switch Brochure

User Manual: Pump 118 3 Phcc Pro Series Vs Float Switch Brochure

Open the PDF directly: View PDF PDF.
Page Count: 1

VSC2
VSC2
VSC1.5
VSC1.5
VS
VS
Controller Comparison
Controller Comparison
System is operating light (flashes)
Universal controller mounting tabs
Activates pump weekly to exercise and
extend pump life
Adjustable run time from 5-45 seconds
after the water falls
Float switch can be unplugged from
controller for east installation
Includes remote terminals for connecting
to a home security system, remote dialer
or other device
Includes: Switch, manual and stainless steel hose clamp
Piggy-back plug
10' float switch cord
DFC1 DFC1.5
VSC1.5
DFC2
VSC2
Standard Enhanced Deluxe
Available with low voltage Vertical Switch
Available with Dual Float Switch
9V battery is low or slide switch is off
Sounds an alarm and alerts when:
AC power has failed
Pump or float problem is detected
2' power cord
4' power cord
Vertical Float Switch
Vertical Float Switch
Switches and Controllers
12
Features
• Can be used in clear water and sewage applications
• Mechanical float on rod
• Two versions of the vertical switch:
Piggy-back plug (120 VAC) version - no controller
Low voltage version included with VSC1.5 and
VSC2 Enhanced and Deluxe controllers
• The internal switching mechanism has sealed gold
contacts for reliable high cycle operation
(VSC1.5 and VSC2)
• Float switch can be unplugged from
t
he controller
for easy installation
(VSC1.5 and VSC2)
• Mounts to discharge pipe with included stainless
steel hose clamp
• Activation level is adjustable
Vertical Switch
Enhanced Controller
with Vertical Switch
Deluxe Controller
with Vertical Switch
