User Manual: Pump 12475 2 Taco 1600-205Rp Repair Parts
Open the PDF directly: View PDF
.
Page Count: 4
Form No. F304-001
E
E (Standard) 1600-868CRP Ceramic/Carbon/EPT (replaces
1600-846CRP, 1600-170RP and 1600-170ERP)
O O X O O
WATER SEAL KIT, ITEM #29 5⁄8" SHAFT
S (High Temp) 1600-868SRP Sealide-C/Sealide-C/Viton
(replaces 1600-846SRP and 1600-170HRP)
Replacement Parts List
121 thru 138 Pumps / 1600 Series Pumps
304-001
SUPERSEDES: October 1, 2011 EFFECTIVE: April 1, 2012
IMPORTANT: When ordering, always specify part number, part name, and complete model number of pump.
Nameplate located on front of casing. For OEM models, please consult OEM.
RP
ITEM #31 REPLACEMENT MOTOR ASSEMBLY *
HP 115/60/1 115/230/60/1 200-230/460/60/3 **
1⁄4
1⁄3
1⁄2
3⁄4
1
11⁄2
2
3
121-151RP
131-143RP
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
132-096RP
133-119RP
138-119RP
1636-013RP
1638-012RP
N/A
N/A
N/A
1661-022RP
1661-023RP
1661-024RP
1661-025RP
1661-026RP
1661-027RP
HP 200-230/460/60/3
Motor No. **
** Replaces below
230/460/60/3 200/60/3
1⁄4
1⁄3
1⁄2
3⁄4
1
11⁄2
2
3
1661-022RP
1661-023RP
1661-024RP
1661-025RP
1661-026RP
1661-027RP
132-097RP
133-134RP
138-142RP
1636-010RP
1638-010RP
1640-010RP
132-066RP
133-140RP
138-148RP
1636-019RP
1638-015RP
1640-013RP
** Replaces 200/60/3 and 230/460/60/3 models below
Note (1) When replacing item #8 body on 131, 132, 133, 138 and 1600C—1&—9, you must also order current style impeller.
Note (2) Body for the 1602 & 1604 are no longer available. Consult factory.
* When ordering other than standard, refer to nameplate, then consult factory.
132-033RP 132-033RP
1⁄2
All
4J
5J
3J All Inline Pumps 1⁄4 & 1⁄3 HP
(5⁄8" x 1⁄2")
COUPLER 4J (5⁄8" x 1⁄2")
(5⁄8" x 5⁄8")
(5⁄8" x 5⁄8")
1624—030RP Inline Pumps 1⁄2 HP, 48 frame motor
Inline Pumps 3⁄4 thru 2 HP, 56 frame motor
56
Pumps
Do it Once. Do it Right.®
TACO INC., 1160 Cranston Street, Cranston, RI 02920 Telephone: (401) 942-8000 Fax: 942-2360
TACO (Canada), Ltd., 8450 Lawson Road, Unit #3, Milton, Ontario L9T 0J8 Telephone: (905) 564-9422 Fax: (905) 564-9436
Visit our website at: www.taco-hvac.com
Printed in USA
Copyright 2012
TACO, Inc.
(1⁄2")
02RP
