User Manual: Pump 13627 3 Armstrong S & H Series Repair Parts

Open the PDF directly: View PDF .
Page Count: 114 [warning: Documents this large are best viewed by clicking the View PDF Link!]

Replacement Parts

Circulator Parts Catalog

File no: 6010.201

Date: September 17, 2013

Supersedes: 6010.201

Date: February 05, 2013

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ORDERING INSTRUCTIONS

Part Number identification for ordering purposes may be determined by obtaining the item number of the required part from the Assembly Drawi

on page 1, then referring to the Service Parts Tables on pages 3 to 25 under the Model Number of the Circulator and class of construction as

provided on the pump nameplate. Always specify the Circulator Model Number and Serial Number with your order. For service kits see page 26

CONSTRUCTION CODE

STD. - Denotes "Universal" or "Standard" construction.

IBBF or BF - denotes "Bronze"-Fitted" construction.

AB - denotes "All Bronze" construction.

AI - denotes "All Iron" construction.

When no construction code is provided on pump nameplate, the Circulator is classed as "Standard Construction". Choose service parts from

the lists with this heading.

SERIAL NUMBER CODE

All Armstrong Standard and High Duty Circulators bear a four-diget combination serial and date code denoting year and month of manufacture.

For example, a Circulator manufactured in June of 2001 would bear the serial date code of 0106 on the nameplate. Series 1050 Circulators may

bear the four digit serial date code if their custom feature is impeller diameter and/or special motor. However, if special materials of construction,

special seals, etc. are used, a straight numerical serial number appears on the pump nameplate and must be specified when ordering. Such

parts must be ordered from factory unless actual part number has been established and carried in a service dealer's stock.

TREATED SYSTEM WATER

Additives for sealing system leaks, and some water treatments, improperly applied, are injurious to pump seals. New hydronic systems should be

thoroughly washed, fully drained and refilled with clean water before running pump. System must be kept clean of foreign materials such as

welding slag, etc.

Stop-leak compounds or cleaning chemicals must be thoroughly flushed out after using.

Circulator and/or Service Parts Wrranty will be void if chemicals are improperly used or if stop-leak compound is left in system.

ARMSTRONG

CIRCULATOR

SERVICE PARTS

Circulator Parts List 1 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

31/6

1/2 5

S46 1/3

S57 3/4

S35 1/6 3 1/4 4

S25 1/12 2

41/4

Service Parts For Armstrong Circulators

TYPICAL ASSEMBLY DETAILS

H.P.MODEL SIZE SIZEH.P.

1/6

H52

H54 5

1/2 51/3 5

H41 1/6

EXPLODED VIEW APPLIES TO CIRCULATORS LISTED ABOVE

1/4 TO 3/4 5

EXPLODED VIEW APPLIES TO CIRCULATORS LISTED ABOVE

3/4

MODEL H.P. SIZE MODEL H.P. SIZE

S69 1 6 H63 1/2 6

3/4 6

H64 3/4 6 H65 3/4 6

1 1/2 6

H65 1

H67 1 6 H68

6 H66

1060 1/2 TO 1 1/2 6 1060 3D 1 TO 3 6

MODEL

S34

S45

S55

H32

H51

H53

1050

Circulator Parts List 2 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

STANDARD CIRCULATORS

CATALOG MODEL NO. S25 S25 S25 S25 S35 S45 S46 S55 S57

FLANGE SIZE NPT (INCHES) 3/4 1 1 1/4 1 1/2 2 3 3 3 3

PARTS LIST PAGE NUMBER 14-18 24-28 29-33 34-38 39-43

FORMER MODEL NUMBER #75 #100 #125 #150 2 3LD 3HD PD35 PD37

HIGH DUTY CIRCULATORS

CATALOG MODEL NO. H32 H32 H32 H41 H51 H52 H53 H54

FLANGE SIZE NPT (INCHES) 1 1 1/4 1 1/2 1 1 1 1/4 1 1/2 2

PARTS LIST PAGE NUMBER 19-23 44-48 49-53 54-58 59-63

FORMER MODEL NUMBER 1HV 1 1/4HV 1 1/2HV 1 PR 60-1 60-2 60-3 60-4

SERIES 1050 CUSTOM BUILT CIRCULATORS

CATALOG MODEL NO. 1B 1 1/4B 1 1/2B 2B

FLANGE SIZE NPT (INCHES) 1 1 1/4 1 1/2 2

PARTS LIST PAGE NUMBER 64-68 69-73 74-78 79-83

FORMER MODEL NUMBER 1AA 1 1/4AA 1 1/2AA 2AA

STANDARD CIRCULATORS

CATALOG MODEL NO. S69

FLANGE SIZE NPT (INCHES) 3

PARTS LIST PAGE NUMBER 84-86

FORMER MODEL NUMBER PD39

HIGH DUTY CIRCULATORS

CATALOG MODEL NO. H63 H64 H65 H66 H67 H68

FLANGE SIZE NPT (INCHES) 1 1/2 1 1/2 1 1/2 2 2 2

PARTS LIST PAGE NUMBER 87-89 90-92 93-95 96-98 99-101 102-104

FORMER MODEL NUMBER 60-5 60-6 60-7 60-8 60-9 60-10

SERIES 1060 CUSTOM BUILT CIRCULATORS

CATALOG MODEL NO. 1 1/2D 2D 3D 3D 3D 3D

FLANGE SIZE NPT (INCHES) 1 1/2 2 3 3 3 3

PARTS LIST PAGE NUMBER 105-107 108-110

FORMER MODEL NUMBER 1 1/2A 2A S615 S610 S620 S630

S34

Service Parts For Armstrong Circulators

MODEL DESIGNATIONS AND PARTS PAGE INDEX

SIZE 2 3 5

OBSOLETE

USE

H32

1 1/2"

PARTS

LIST

5SIZE 3

SIZE 5

4-8

9-13

111-113

SIZE

Circulator Parts List 3 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

28 BODY GASKET

12 BRACKET HOUSING

(2)

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 116077-071

3 FLANGE - 3/4" NPT - CAST IRON 116013-011

3 FLANGE - 1" NPT - CAST IRON 116012-011

3 FLANGE - 1 1/4" NPT - CAST IRON 116011-011

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 1/2 911123-112

4 FLANGE GASKET 816653-000

11 FLANGE NUTS - 7/16-14 JAM 911123-112

2 IMPELLER 812961-111

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 913171-100

26 IMPELLER WASHER 927311-100

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/12HP/115V

805316-010

10 MOTOR CAPSCREWS - 1/4-20X5/8 911117-105

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805482-011

9 PUMP BODY CAPSCREWS- 3/8-16X7/8 911121-107

29 SEAL BEARING ASSEMBLY

(1)

810119-001

16 SHAFT AND BEARING MODULE

(3)

816999-071

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 812961-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module, Impeller Key,

"Armite" Seal Assembly, Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 5/8 Ounces of Oil.

816958-111

DESCRIPTION ARMSTRONGPART NUMBER

104442-000

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S25 - SIZE 2 - Serial No. 6205 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

Circulator Parts List 4 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 104442-000

12 BRACKET HOUSING

(2)

816958-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 116077-071

3 FLANGE - 3/4" NPT - BRONZE 116013-041

3 FLANGE - 1" NPT - BRONZE 116012-041

3 FLANGE - 1 1/4" NPT - BRONZE 116011-041

3 FLANGE - 1 1/2" NPT - BRONZE 116009-041

5 FLANGE BOLTS - 7/16-14X1 1/2 911123-112

4 FLANGE GASKET 816653-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER 812961-111

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927411-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/12HP/115V

805316-010

10 MOTOR CAPSCREWS - 1/4-20X5/8 911117-105

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805482-041

9 PUMP BODY CAPSCREWS- 3/8-16X7/8 911121-107

29 SEAL BEARING ASSEMBLY

(1)

810119-001

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 812961-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S25 - SIZE 2 - Serial No. 6205 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 5 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

28 BODY GASKET 104442-000

12 BRACKET HOUSING

(2)

816958-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 116077-071

3 FLANGE - 3/4" NPT - CAST IRON 116013-011

3 FLANGE - 1" NPT - CAST IRON 116012-011

3 FLANGE - 1 1/4" NPT - CAST IRON 116011-011

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 1/2 911123-112

4 FLANGE GASKET 816653-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER (Steel)

(4)

812961-011

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927411-700

15 MECHANICALSEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/12HP/115V

805316-010

10 MOTOR CAPSCREWS - 1/4-20X5/8 911117-105

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805482-011

9 PUMP BODY CAPSCREWS- 3/8-16X7/8 911121-107

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-001

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 812961-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 812961-111 Impeller on the Universal SBA must be removed and replaced with a 812961-011 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S25 - SIZE 2 - Serial No. 6205 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 6 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 104442-000

12 BRACKET HOUSING

(2)

816958-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 116077-071

3 FLANGE - 3/4" NPT - CAST IRON 116013-011

3 FLANGE - 1" NPT - CAST IRON 116012-011

3 FLANGE - 1 1/4" NPT - CAST IRON 116011-011

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 1/2 911123-112

4 FLANGE GASKET 816653-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER (Brass)

(4)

812961-041

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927411-700

15 MECHANICAL SEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/12HP/115V

805316-010

10 MOTOR CAPSCREWS - 1/4-20X5/8 911117-105

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805482-011

9 PUMP BODY CAPSCREWS- 3/8-16X7/8 911121-107

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-001

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 812961-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 812961-111 Impeller on the Universal SBA must be removed and replaced with a 812961-041 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S25 - SIZE 2 - Serial No. 6205 & Later

Circulator Parts List 7 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 104442-000

12 BRACKET HOUSING

(2)

816958-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 116077-071

3 FLANGE - 3/4" NPT - BRONZE 116013-041

3 FLANGE - 1" NPT - BRONZE 116012-041

3 FLANGE - 1 1/4" NPT - BRONZE 116011-041

3 FLANGE - 1 1/2" NPT - BRONZE 116009-041

5 FLANGE BOLTS - 7/16-14X1 1/2 911123-112

4 FLANGE GASKET 816653-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER (Brass)

(4)

812961-041

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927411-700

15 MECHANICAL SEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/12HP/115V

805316-010

10 MOTOR CAPSCREWS - 1/4-20X5/8 911117-105

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805482-041

9 PUMP BODY CAPSCREWS- 3/8-16X7/8 911121-107

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-001

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 812961-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 812961-111 Impeller on the Universal SBA must be removed and replaced with a 812961-041 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S25 - SIZE 2 - Serial No. 6205 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 8 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 1" NPT - CAST IRON 106073-011

3 FLANGE - 1 1/4" NPT - CAST IRON 104300-011

3 FLANGE - 1 1/2" NPT - CAST IRON 104301-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105176-000

4 FLANGE GASKET

(Prior to 1990)

104034-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER 816322-111

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816402-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

810119-003

29 SEAL BEARING ASSEMBLY

(4)

816549-091

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816322-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module, Impeller Key,

"Armite" Seal Assembly, Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H32 - SIZE 3 - Serial No. 6509 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

Circulator Parts List 9 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 1" NPT - BRONZE 106073-041

3 FLANGE - 1 1/4" NPT - BRONZE 104300-041

3 FLANGE - 1 1/2" NPT - BRONZE 104301-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105176-000

4 FLANGE GASKET

(Prior to 1990)

104034-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER 816322-111

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816402-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

810119-003

29 SEAL BEARING ASSEMBLY

(4)

816549-091

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816322-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module, Impeller Key,

"Armite" Seal Assembly, Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

BAR CODE

MODEL NUMBER H32 - SIZE 3 - Serial No. 6509 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 10 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 1" NPT - CAST IRON 106073-011

3 FLANGE - 1 1/4" NPT - CAST IRON 104300-011

3 FLANGE - 1 1/2" NPT - CAST IRON 104301-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105176-000

4 FLANGE GASKET

(Prior to 1990)

104034-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER (Steel)

(4)

816322-011

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODUL

961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816402-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-003

29 SEAL BEARING ASSEMBLY

(5) & (6)

816549-091

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816402-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 816322-111 Impeller on the Universal SBA must be removed and replaced with a 816322-011 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H32 - SIZE 3 - Serial No. 6509 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 11 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 1" NPT - CAST IRON 106073-011

3 FLANGE - 1 1/4" NPT - CAST IRON 104300-011

3 FLANGE - 1 1/2" NPT - CAST IRON 104301-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105176-000

4 FLANGE GASKET

(Prior to 1990)

104034-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2 IMPELLER (Brass)

(4)

816322-041

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODUL

961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816402-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-003

29 SEAL BEARING ASSEMBLY

(5) & (6)

816549-091

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816402-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 816322-111 Impeller on the Universal SBA must be removed and replaced with a 816322-011 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

BAR CODE

MODEL NUMBER H32 - SIZE 3 - Serial No. 6509 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 12 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKE

106049-000

12 BRACKET HOUSING

(2)

816961-111

8COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLAT

109522-071

3 FLANGE - 1" NPT - BRONZ

106073-041

3 FLANGE - 1 1/4" NPT - BRONZE 104300-041

3 FLANGE - 1 1/2" NPT - BRONZE 104301-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911123-114

4FLANGE GASKET

(1990 & Later)

105176-000

4FLANGE GASKET

(Prior to 1990)

104034-000

11 FLANGE NUTS - 7/16-14 JAM 913523-100

2IMPELLER

(

Steel

)

(4)

816322-041

23 IMPELLER KEY

(

WOODRUFF #2

)

974507-100

27 IMPELLER NU

106076-000

26 IMPELLER WASHE

927311-700

15 MECHANICAL SEAL ASSY.

(

Viton

)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODUL

961131-036

18 O RING - REAR BEARIN

961131-024

19 O RING - SHAF

961131-013

24 OIL SEA

116975-000

21 OIL WICK

(

BRIDGE

)

116949-000

20 OIL WICK

(

ROUND

)

116948-000

1 PUMP BOD

816402-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-003

29 SEAL BEARING ASSEMBLY

(5) & (6)

816549-091

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816402-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 816322-111 Impeller on the Universal SBA must be removed and replaced with a 816322-041 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket

Bod

Gasket

106076-000 Im

eller Nut

927411-000

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H32 - SIZE 3 - Serial No. 6509 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 13 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 2" NPT - CAST IRON 105210-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105209-002

4 FLANGE GASKET

(Prior to 1990)

105209-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816322-111

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816327-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

810119-003

29 SEAL BEARING ASSEMBLY

(4)

816549-091

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816322-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module, Impeller Key,

"Armite" Seal Assembly, Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

BAR CODE

MODEL NUMBER S35 - SIZE 3 - Serial No. 6509 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 14 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 2" NPT - BRONZE 105210-041

5 FLANGE BOLTS - 1/2-13X2 1/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105209-002

4 FLANGE GASKET

(Prior to 1990)

105209-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816322-111

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY

(4)

816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816327-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

810119-003

29 SEAL BEARING ASSEMBLY

(4)

816549-091

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816322-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module, Impeller Key,

"Armite" Seal Assembly, Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

BAR CODE

MODEL NUMBER S35 - SIZE 3 - Serial No. 6509 & Later

ALL BRONZE CONSTRUCTION

CIRCULATOR PARTS

DESCRIPTION ARMSTRONG

Circulator Parts List 15 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 2" NPT - CAST IRON 105210-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105209-002

4 FLANGE GASKET

(Prior to 1990)

105209-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER (Steel)

(4)

816322-011

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816327-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-003

29 SEAL BEARING ASSEMBLY

(5) & (6)

816549-091

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816322-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module, Impeller Key,

"Armite" Seal Assembly, Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816322-111 Impeller on the Universal SBA must be removed and replaced with a 816322-011 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S35 - SIZE 3 - Serial No. 6509 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 16 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 2" NPT - CAST IRON 105210-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105209-002

4 FLANGE GASKET

(Prior to 1990)

105209-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER (Brass)

(4)

816322-041

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816327-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-003

29 SEAL BEARING ASSEMBLY

(5) & (6)

816549-091

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816402-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 816322-111 Impeller on the Universal SBA must be removed and replaced with a 816322-041 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S35 - SIZE 3 - Serial No. 6509 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 17 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 2" NPT - BRONZE 105210-041

5 FLANGE BOLTS - 1/2-13X2 1/4 911123-114

4 FLANGE GASKET

(1990 & Later)

105209-002

4 FLANGE GASKET

(Prior to 1990)

105209-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER (Steel)

(4)

816322-041

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(5)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816327-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (5)

810119-003

29 SEAL BEARING ASSEMBLY

(5) & (6)

816549-091

16 SHAFT AND BEARING MODULE

(3) & (5)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 816402-111 Impeller,

Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module Impeller Key,

"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Ceramic Seal Seat, Buna "L" (retainer) Cup, 5/8 ounces of oil.

(4) The 816322-111 Impeller on the Universal SBA must be removed and replaced with a 816322-041 Impeller

(5) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(

)

Seal Bearin

Assembl

includes Bearin

Bracket, Bod

Gasket, 106076-000 Impeller Nut, 927411-000,

Module, Impeller Key, "Armite" Seal Assy., Ceramic Seal Seat, Buna "L" (retainer) Cup & 5/8oz. of Oil

BAR CODE

MODEL NUMBER S35 - SIZE 3 - Serial No. 6509 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 18 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 116290-071

3 FLANGE - 1" NPT - CAST IRON 116012-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911123-114

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 913125-100

2 IMPELLER 116301-325

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 811240-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

816027-002

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H41 - SIZE 4 - Serial No. 5710 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 19 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 116290-071

3 FLANGE - 1" NPT - BRONZE 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911123-114

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 913125-100

2 IMPELLER 116301-325

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 811240-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

816027-002

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER H41 - SIZE 4 - Serial No. 5710 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 20 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 1" NPT - CAST IRON 116012-011

5 FLANGE BOLTS - 7/16-14x1 1/4 911123-114

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 913125-100

2 IMPELLER (Steel) 816301-025

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816327-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

810119-003

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER H41 - SIZE 4 - Serial No. 5710 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 21 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE - 1" NPT - CAST IRON 116012-011

5 FLANGE BOLTS - 7/16-14x1 1/4 911123-114

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 913125-100

2 IMPELLER (Brass) 816301-055

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816327-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

810119-003

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER H41 - SIZE 4 - Serial No. 5710 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 22 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106049-000

12 BRACKET HOUSING

(2)

816961-111

8 COUPLER ASSEMBLY

(4 - Spring)

806026-001

22 FACEPLATE 109522-071

3 FLANGE -1" NPT - BRONZE 116012-041

5 FLANGE BOLTS - 7/16-14x1 1/4 911123-114

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 913125-100

2 IMPELLER (Brass) 816301-055

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V

817025-001

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 811240-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

810119-003

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER H41 - SIZE 4 - Serial No. 5710 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 23 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 2 1/2" NPT - CAST IRON 105189-011

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-328

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

817025-007

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

816027-002

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

CIRCULATOR PARTS

MODEL NUMBER S45 - SIZE 4 - Serial No. 5405 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION

BAR CODE

ARMSTRONG

Circulator Parts List 24 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 2 1/2" NPT - BRONZE 105189-041

3 FLANGE - 3" NPT - BRONZE 105188-041

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-328

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

817025-007

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

816027-002

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

CIRCULATOR PARTS

MODEL NUMBER S45 - SIZE 4 - Serial No. 5405 & Later

BAR CODE

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 25 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 2 1/2" NPT - CAST IRON 105189-011

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-028

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

817025-007

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

816027-002

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER S45 - SIZE 4 - Serial No. 5405 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 26 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 2 1/2" NPT - CAST IRON 105189-011

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-058

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

817025-007

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

816027-002

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER S45 - SIZE 4 - Serial No. 5405 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 27 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 2 1/2" NPT - BRONZE 105189-041

3 FLANGE - 3" NPT - BRONZE 105188-041

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-058

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

817025-007

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

816027-002

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER S45 - SIZE 4 - Serial No. 5405 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 28 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-325

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

817025-013

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

816027-002

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

CIRCULATOR PARTS

MODEL NUMBER S46 - SIZE 4 - Serial No. 5405 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

BAR CODE

Circulator Parts List 29 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 3" NPT - BRONZE 105188-041

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-325

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

817025-013

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1)

816027-002

16 SHAFT AND BEARING MODULE

(3)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

BAR CODE

MODEL NUMBER S46 - SIZE 4 - Serial No. 5405 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 30 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-025

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

817025-013

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

816027-002

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S46 - SIZE 4 - Serial No. 5405 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 31 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-055

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

817025-013

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-011

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

816027-002

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

BAR CODE

MODEL NUMBER S46 - SIZE 4 - Serial No. 5405 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 32 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106050-000

12 BRACKET HOUSING

(2)

816963-111

8 COUPLER ASSEMBLY

(4 - Spring)

806168-001

22 FACEPLATE 116290-071

3 FLANGE - 2 1/2" NPT - BRONZE 105189-041

3 FLANGE - 3" NPT - BRONZE 105188-041

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816305-055

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton)

(4)

816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

817025-013

10 MOTOR CAPSCREWS - 5/16-18x1 911118-108

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 805484-041

9 PUMP BODY CAPSCREWS - 7/16-14x1 911123-108

29 SEAL BEARING ASSEMBLY

(1) & (4)

816027-002

16 SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Buna "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S46 - SIZE 4 - Serial No. 5405 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 33 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-321

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V

811757-001

RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

BAR CODE

MODEL NUMBER S55 - SIZE 5 - Serial No. 6104 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 34 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - BRONZE 105188-041

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-321

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V

811757-001

RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S55 - SIZE 5 - Serial No. 6104 & Later

ALL BRONZE CONSTRUCTION

Circulator Parts List 35 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-021

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V

811757-001

RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat, Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S55 - SIZE 5 - Serial No. 6104 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 36 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-051

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V

811757-001

RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

CIRCULATOR PARTS

MODEL NUMBER S55 - SIZE 5 - Serial No. 6104 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

BAR CODE

Circulator Parts List 37 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-051

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V

811757-001

RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S55 - SIZE 5 - Serial No. 6104 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 38 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V

811757-002

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S57 - SIZE 5 - Serial No. 6104 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

Circulator Parts List 39 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - BRONZE 105188-041

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V

811757-002

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

BAR CODE

MODEL NUMBER S57 - SIZE 5 - Serial No. 6104 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 40 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET

106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-017

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V

811757-002

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER S57 - SIZE 5 - Serial No. 6104 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 41 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET

106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V

811757-002

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

BAR CODE

MODEL NUMBER S57 - SIZE 5 - Serial No. 6104 & Later

CIRCULATOR PARTS

Circulator Parts List 42 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 3" NPT - CAST IRON 105188-011

5 FLANGE BOLTS - 1/2-13x2 1/2 911125-120

4 FLANGE GASKET 105201-000

11 FLANGE NUTS - 1/2-13 913125-100

2 IMPELLER 816304-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V

811757-002

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 804133-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

MODEL NUMBER S57 - SIZE 5 - Serial No. 6104 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 43 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-319

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

816141-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (4)

830781-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER H51 - SIZE 5 - Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 44 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - BRONZE 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-319

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

816141-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (4)

830781-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H51 - SIZE 5 - Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

Circulator Parts List 45 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (STEEL) 816302-019

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

816141-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5)

830781-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

ARMSTRONG

CIRCULATOR PARTS

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION

MODEL NUMBER H51 - SIZE 5 - Serial No. 6208 & Later

Circulator Parts List 46 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-049

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

816141-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5)

830781-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H51 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 47 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-049

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

816141-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5)

830781-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER H51 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 48 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116011-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (4)

830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

CIRCULATOR PARTS

MODEL NUMBER H52 - SIZE 5 - Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

BAR CODE

Circulator Parts List 49 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - BRONZE 116011-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (4)

830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H52 - SIZE 5 - Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 50 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (STEEL) 816302-017

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5)

830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H52 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 51 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116011-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5)

830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

CIRCULATOR PARTS

MODEL NUMBER H52 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION

BAR CODE

ARMSTRONG

Circulator Parts List 52 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116011-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816302-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5)

830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H52 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 53 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816303-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RIGID MOUNT. MOT. ASSY. - 1PH/1/2HP/115/230V

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H53 - SIZE 5 - Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 54 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - BRONZE 116009-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816303-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RIGID MOUNT. MOT. ASSY. - 1PH/1/2HP/115/230V

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H53 - SIZE 5 - Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 55 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (STEEL) 816303-017

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RIGID MOUNT. MOT. ASSY. - 1PH/1/2HP/115/230V

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

( 1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H53 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 56 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816303-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RIGID MOUNT. MOT. ASSY. - 1PH/1/2HP/115/230V

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

SHAFT AND BEARING MODULE

(3) & (4)

816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H53 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 57 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - BRONZE 116009-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816303-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RIGID MOUNT. MOT. ASSY. - 1PH/1/2HP/115/230V

831009-062

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5)

831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5)

811757-004

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H53 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 58 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - CAST IRON 106074-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816304-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V(4)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H54 - SIZE 5 - Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

Circulator Parts List 59 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - BRONZE 106074-041

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816304-317

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V(4)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

MODEL NUMBER H54 - SIZE 5 - Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 60 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - CAST IRON 106074-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816304-017

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-023

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (5)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (5)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H54 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 61 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - BRONZE 106074-041

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816304-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-023

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (5)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (5)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

MODEL NUMBER H54 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 62 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

COUPLER ASSEMBLY (Flexible) 1/2X5/8

806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - BRONZE 106074-041

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER 816304-047

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V

831010-062

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (5)

831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (5)

811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H54 - SIZE 5 - Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 63 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER - 5 1/4" DIA. (See note 4) 816302-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816302-321

2 IMPELLER - 4 3/8" DIA. (See note 4) 816302-324

2 IMPELLER - 4" DIA. (See note 4) 816302-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

MODEL NUMBER 1050 1B - SIZE 5 Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 64 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - BRONZE 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER - 5 1/4" DIA. (See note 4) 816302-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816302-321

2 IMPELLER - 4 3/8" DIA. (See note 4) 816302-324

2 IMPELLER - 4" DIA. (See note 4) 816302-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 1B - SIZE 5 Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

Circulator Parts List 65 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

BODY GASKE

106158-000

BRACKET HOUSING (2

)

816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

COUPLER INSER

875000-800

FACEPLAT

174003-071

FLANGE - 1" NPT - CAST IRON 116012-011

FLANGE BOLTS - 7/16-14X1 3/4 911125-120

FLANGE GASKET 105176-000

FLANGE NUTS - 7/16-14 JAM 913125-100

IMPELLER (Steel) - 5 1/4" DIA. (See note 5) 816302-017

IMPELLER (Steel) - 4 3/4" DIA. (See note 5) 816302-021

IMPELLER (Steel) - 4 3/8" DIA. (See note 5) 816302-02

IMPELLER (Steel) - 4" DIA. (See note 5) 816302-027

IMPELLER KEY (WOODRUFF #2) 974507-100

IMPELLER NU

106076-000

IMPELLER WASHE

927311-700

MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6)

830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6)

830590-083

MOTOR CAPSCREWS - 3/8-16X3/

911121-106

O RING - MODULE 961131-036

O RING - REAR BEARING 961131-02

O RING - SHAFT 961131-013

OIL SEAL 116975-000

OIL WICK (BRIDGE) 116949-000

OIL WICK (ROUND) 116948-000

PUMP BOD

816337-011

PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

BAR CODE

MODEL NUMBER 1050 1B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 66 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKE

106158-000

12 BRACKET HOUSING (2

)

816966-111

COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2

807436-000

COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8

806137-000

0 COUPLER INSER

875000-800

22 FACEPLAT

174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816302-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816302-051

2 IMPELLER (Brass) - 4 3/8" DIA. (See note 5) 816302-05

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816302-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NU

106076-000

26 IMPELLER WASHE

927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V

816141-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6)

830781-083

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V

816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6)

830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/

911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-02

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BOD

816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 1B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 67 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1" NPT - CAST IRON 116012-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816302-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816302-051

2 IMPELLER (Brass) - 4 3/8" DIA. (See note 5) 816302-054

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816302-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

BAR CODE

MODEL NUMBER 1050 1B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 68 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/4" NPT - CAST IRON 116011-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER - 5 1/4" DIA. (See note 4) 816302-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816302-321

2 IMPELLER - 4 3/8" DIA. (See note 4) 816302-324

2 IMPELLER - 4" DIA. (See note 4) 816302-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 11/4B - SIZE 5 Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 69 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/4" NPT - BRONZE 116011-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER - 5 1/4" DIA. (See note 4) 816302-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816302-321

2 IMPELLER - 4 3/8" DIA. (See note 4) 816302-324

2 IMPELLER - 4" DIA. (See note 4) 816302-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER 1050 11/4B - SIZE 5 Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 70 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/4" NPT - CAST IRON 116011-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Steel) - 5 1/4" DIA. (See note 5) 816302-017

2 IMPELLER (Steel) - 4 3/4" DIA. (See note 5) 816302-021

2 IMPELLER (Steel) - 4 3/8" DIA. (See note 5) 816302-024

2 IMPELLER (Steel) - 4" DIA. (See note 5) 816302-027

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER 1050 11/4B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 71 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/4" NPT - CAST IRON 116011-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816302-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816302-051

2 IMPELLER (Brass) - 4 3/8" DIA. (See note 5) 816302-054

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816302-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER 1050 11/4B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 72 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/4" NPT - BRONZE 116011-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 105176-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816302-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816302-051

2 IMPELLER (Brass) - 4 3/8" DIA. (See note 5) 816302-054

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816302-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER 1050 11/4B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 73 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER - 5 1/4" DIA. (See note 4) 816303-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816303-321

2 IMPELLER - 4 3/8" DIA. (See note 4) 816303-324

2 IMPELLER - 4" DIA. (See note 4) 816303-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (5) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (5) 811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 11/2B - SIZE 5 Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

Circulator Parts List 74 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - BRONZE 116009-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER - 5 1/4" DIA. (See note 4) 816303-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816303-321

2 IMPELLER - 4 3/8" DIA. (See note 4) 816303-324

2 IMPELLER - 4" DIA. (See note 4) 816303-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (5) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (5) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (5) 811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, contact the factory.

BAR CODE

MODEL NUMBER 1050 11/2B - SIZE 5 Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 75 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Steel) - 5 1/4" DIA. (See note 5) 816303-017

2 IMPELLER (Steel) - 4 3/4" DIA. (See note 5) 816303-021

2 IMPELLER (Steel) - 4 3/8" DIA. (See note 5) 816303-024

2 IMPELLER (Steel) - 4" DIA. (See note 5) 816303-027

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V 65) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (6) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (6) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (6) 811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(

)

Seal Bearin

Assembl

includes Bearin

Bracket

Bod

Gasket

Standard 106076-000 Im

eller Nut

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 11/2B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 76 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - CAST IRON 116009-011

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816303-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816303-051

2 IMPELLER (Brass) - 4 3/8" DIA. (See note 5) 816303-054

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816303-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (6) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (6) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (6) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (6) 811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816337-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

BAR CODE

MODEL NUMBER 1050 11/2B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 77 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 1 1/2" NPT - BRONZE 116009-041

5 FLANGE BOLTS - 7/16-14X1 3/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 7/16-14 JAM 913125-100

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816303-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816303-051

2 IMPELLER (Brass) - 4 3/8" DIA. (See note 5) 816303-054

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816303-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V 816141-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V (6) 830781-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (6) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (6) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (6) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (6) 811757-006

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 11/2B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 78 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - CAST IRON 106074-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 1/2-13 913125-118

2 IMPELLER - 5 1/4" DIA. (See note 4) 816304-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816304-321

2 IMPELLER - 4" DIA. (See note 4) 816304-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115/230V 816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (5) 830590-083

RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (5) 831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (5) 831011-083

RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (5) 831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (5) 811757-006

RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (5) 816676-062

RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (5) 816676-069

RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (5) 811757-009

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, please contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 2B - SIZE 5 Serial No. 6208 & Later

STANDARD AND BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 79 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - BRONZE 106074-041

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 1/2-13 913125-118

2 IMPELLER - 5 1/4" DIA. (See note 4) 816304-317

2 IMPELLER - 4 3/4" DIA. (See note 4) 816304-321

2 IMPELLER - 4" DIA. (See note 4) 816304-327

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSEMBLY 816706-021

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115/230V 816141-002

RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (6) 831011-083

RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (6) 831011-083

RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (6) 831012-083

RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (6) 811757-006

RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (6) 816676-062

RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (6) 816676-069

RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (6) 811757-009

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) 816032-000

16 SHAFT AND BEARING MODULE (3) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the

factory.

(5) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER 1050 2B - SIZE 5 Serial No. 6208 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION ARMSTRONG

Circulator Parts List 80 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - CAST IRON 106074-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 1/2-13 913125-118

2 IMPELLER (Steel) - 5 1/4" DIA. (See note 5) 816304-017

2 IMPELLER (Steel) - 4 3/4" DIA. (See note 5) 816304-021

2 IMPELLER (Steel) - 4" DIA. (See note 5) 816304-027

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115/230V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (6) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (6) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (6) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (6) 811757-006

7 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

7 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (6) 816676-062

7 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (6) 816676-069

7 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (6) 811757-009

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

BAR CODE

MODEL NUMBER 1050 2B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. STANDARD CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 81 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - CAST IRON 106074-011

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 1/2-13 913125-118

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816304-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816304-051

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816304-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115/230V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (6) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (6) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (6) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (6) 811757-006

7 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

7 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (6) 816676-062

7 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (6) 816676-069

7 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (6) 811757-009

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-011

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

DESCRIPTION ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 2B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. BRONZE FITTED CONSTRUCTION ( 225 - 275 DEG. F )

Circulator Parts List 82 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM PART NUMBER

NO.

28 BODY GASKET 106158-000

12 BRACKET HOUSING (2) 816966-111

8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2 807436-000

8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8 806137-000

0 COUPLER INSERT 875000-800

22 FACEPLATE 174003-071

3 FLANGE - 2" NPT - BRONZE 106074-041

5 FLANGE BOLTS - 1/2-13X2 1/4 911125-120

4 FLANGE GASKET 116117-000

11 FLANGE NUTS - 1/2-13 913125-118

2 IMPELLER (Brass) - 5 1/4" DIA. (See note 5) 816304-047

2 IMPELLER (Brass) - 4 3/4" DIA. (See note 5) 816304-051

2 IMPELLER (Brass) - 4" DIA. (See note 5) 816304-057

23 IMPELLER KEY (WOODRUFF #2) 974507-100

27 IMPELLER NUT 106076-000

26 IMPELLER WASHER 927311-700

15 MECHANICAL SEAL ASSY. (Viton) (4) 816706-023

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115/230V 816141-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V (6) 830590-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (6) 831011-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (6) 831011-083

7 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (6) 831012-083

7 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (6) 811757-006

7 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

7 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (6) 816676-062

7 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (6) 816676-069

7 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (6) 811757-009

10 MOTOR CAPSCREWS - 3/8-16X3/4 911121-106

17 O RING - MODULE 961131-036

18 O RING - REAR BEARING 961131-024

19 O RING - SHAFT 961131-013

24 OIL SEAL 116975-000

21 OIL WICK (BRIDGE) 116949-000

20 OIL WICK (ROUND) 116948-000

1 PUMP BODY 816338-041

9 PUMP BODY CAPS. - 5/16-1/8x3/4 911123-108

29 SEAL BEARING ASSEMBLY (1) & (4) 816032-000

16 SHAFT AND BEARING MODULE (3) & (4) 816999-041

NOTES:

(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,

Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(2) Includes Face Plate and Buna "N" Oil Seal

(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,

rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,

Sintered Silicone Carbide Seal Seat,Viton "L" (retainer) Cup, and 1/2 Ounces of Oil.

(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and

replaced with a 816706-023 Viton High Temperature Mechanical Seal.

(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if

possible the diameter of the impeller being replaced.

(6) For TEFC or Explosion Proof Motors, contact the factory.

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER 1050 2B - SIZE 5 Serial No. 6208 & Later

HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )

DESCRIPTION ARMSTRONG

Circulator Parts List 83 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE - 3" NPT - (Cast Iron)

32 FLANGE BOLTS - 5/8-11X2 1/2

30 FLANGE GASKET

- FLANGE NUTS - 5/8-11

25 IMPELLER (Brass) 5 7/8"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V (4)

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4)

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4)

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4)

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER S69 - SIZE 6 Serial No. 6505 & Later

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION ARMSTRONGPART NUMBER

911117-105

911121-107

106592-000

BAR CODE

816366-041

816342-011

874112-000

816339-011

816861-011

816346-011

911119-106

816665-000

116114-000

875000-801

974515-100

106074-011

911129-120

927412-700

105201-000

816308-042

913129-100

974508-100

116406-000

816354-041

816707-001

116904-001

116369-000

116361-000

816707-003

911121-107

811757-007

911121-106

816676-062

116400-000

816565-000

816676-069

811757-009

816354-071

116368-000

Circulator Parts List 84 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE - 3" NPT - (Bronze)

32 FLANGE BOLTS - 5/8-11X2 1/2

30 FLANGE GASKET

- FLANGE NUTS - 5/8-11

25 IMPELLER (Brass) 5 7/8"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V (4)

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4)

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4)

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4)

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

811757-009

911121-107

116368-000

816354-041

811757-007

911121-106

816676-062

816676-069

116361-000

816707-003

116400-000

816565-000

927412-700

816707-001

116904-001

116369-000

913129-100

816308-042

974508-100

116406-000

911119-106

106074-041

911129-120

105201-000

974515-100

816346-041

816339-041

911121-107

106592-000

816665-000

816354-071

CIRCULATOR PARTS

MODEL NUMBER S69 - SIZE 6 Serial No. 6505 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

116114-000

BAR CODE

816366-041

816861-041

816342-011

874112-000

911117-105

875000-801

Circulator Parts List 85 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE - 3" NPT - (Cast Iron)

32 FLANGE BOLTS - 5/8-11X2 1/2

30 FLANGE GASKET

- FLANGE NUTS - 5/8-11

25 IMPELLER (Steel) 5 7/8"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230V (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816565-000

911121-106

911121-107

116368-000

816354-071

116904-001

116369-000

116361-000

116400-000

974508-100

913173-100

927412-700

816707-002

911129-120

105201-000

913129-100

816308-012

974515-100

816346-041

911119-106

106074-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816339-011

911121-107

BAR CODE

816366-071

816861-071

816342-011

CIRCULATOR PARTS

MODEL NUMBER S69 - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

816707-004

Circulator Parts List 86 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 5 3/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230V (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-041

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911123-116

104034-000

913129-100

874058-051

974515-100

816346-011

911119-106

104301-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816397-011

911121-107

BAR CODE

816366-041

816861-011

816342-011

CIRCULATOR PARTS

MODEL NUMBER H63 - SIZE 6 Serial No. 6505 & Later

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

Circulator Parts List 87 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Bronze)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 5 3/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230V (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-041

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911123-116

104034-000

913129-100

874058-051

974515-100

816346-041

911119-106

104301-041

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816397-041

911121-107

BAR CODE

816366-041

816861-041

816342-011

MODEL NUMBER H63 - SIZE 6 Serial No. 6505 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 88 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Steel) 5 3/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230V (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

116368-000

911121-107

116400-000

816565-000

911121-106

816354-071

816707-004

116904-001

116369-000

116361-000

974508-100

913173-100

927412-700

816707-002

911123-116

104034-000

913129-100

874058-021

974515-100

816346-011

911119-106

104301-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816397-011

911121-107

BAR CODE

816366-071

816861-071

816342-011

MODEL NUMBER H63 - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 89 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 6 1/2"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 811757-006

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER H64 - SIZE 6 Serial No. 6505 & Later

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-011

816342-011

874112-000

911117-105

816397-011

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-011

911119-106

104301-011

911123-116

104034-000

913129-100

874058-045

974508-100

116406-000

927412-700

816707-001

816707-003

116904-001

116369-000

116361-000

116400-000

816565-000

911121-106

911121-107

816354-041

816354-071

116368-000

Circulator Parts List 90 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Bronze)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 6 1/2"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 811757-006

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER H64 - SIZE 6 Serial No. 6505 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-041

816342-011

874112-000

911117-105

816397-041

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-041

911119-106

104301-041

911123-116

104034-000

913129-100

874058-045

974508-100

116406-000

927412-700

816707-001

816707-003

116904-001

116369-000

116361-000

116400-000

816565-000

911121-106

911121-107

816354-041

816354-071

116368-000

Circulator Parts List 91 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Steel) 6 1/2"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 811757-006

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER H64 - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-071

816861-071

816342-011

874112-000

911117-105

816397-011

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-011

911119-106

104301-011

911123-116

104034-000

913129-100

874058-015

974508-100

913173-100

927412-700

816707-002

816707-004

116904-001

116369-000

116361-000

116400-000

816565-000

911121-106

911121-107

816354-071

116368-000

Circulator Parts List 92 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 7"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (6) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (6) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (6) 811757-009

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

MODEL NUMBER H65 - SIZE 6 Serial No. 6505 & Later

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-011

816342-011

874112-000

911117-105

816397-011

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-011

911119-106

104301-011

911123-116

104034-000

913129-100

874058-041

974508-100

116406-000

927412-700

816707-001

816707-003

116904-001

116369-000

116361-000

116400-000

816565-000

911121-106

911121-107

816354-041

816354-071

116368-000

CIRCULATOR PARTS

Circulator Parts List 93 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Bronze)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 7"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (6) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (6) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (6) 811757-009

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER H65 - SIZE 6 Serial No. 6505 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-041

816342-011

874112-000

911117-105

816397-041

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-041

911119-106

104301-041

911123-116

104034-000

913129-100

874058-041

974508-100

116406-000

927412-700

816707-001

816707-003

116904-001

116369-000

116361-000

116400-000

816565-000

911121-106

911121-107

816354-041

816354-071

116368-000

Circulator Parts List 94 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Steel) 7"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (6) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (6) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (6) 811757-009

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER H65 - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-071

816861-071

816342-011

874112-000

911117-105

816397-011

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-011

911119-106

104301-011

911123-116

104034-000

913129-100

874058-011

116361-000

974508-100

913173-100

927412-700

816707-002

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-004

116904-001

116369-000

Circulator Parts List 95 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 5 5/8"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 811757-006

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER

BAR CODE

816565-000

911121-106

116368-000

816354-041

816354-071

116400-000

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911125-100

116117-000

913125-100

816393-052

974515-100

816346-011

911119-106

106074-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-011

911121-107

816366-041

816861-011

816342-011

ARMSTRONG

CIRCULATOR PARTS

MODEL NUMBER H66 - SIZE 6 Serial No. 6505 & Later

Circulator Parts List 96 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Bronze)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 5 5/8"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 811757-006

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816393-052

974508-100

116406-000

927412-700

ALL BRONZE CONSTRUCTION

911121-107

816354-041

816354-071

116368-000

911121-106

816707-001

816707-003

116904-001

116369-000

816565-000

116361-000

116400-000

106074-041

911125-100

116117-000

913125-100

875000-801

974515-100

816346-041

911119-106

911121-107

106592-000

816665-000

116114-000

816342-011

874112-000

911117-105

816174-041

ARMSTRONG

816366-041

816861-041

MODEL NUMBER H66 - SIZE 6 Serial No. 6505 & Later

DESCRIPTION PART NUMBER

BAR CODE

CIRCULATOR PARTS

Circulator Parts List 97 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Steel) 5 5/8"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 811757-006

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

116368-000

816393-052

974508-100

913173-100

927412-700

106074-011

911125-100

911121-107

816354-071

911121-106

816707-002

816707-004

116904-001

116369-000

816565-000

116361-000

116400-000

116117-000

913125-100

875000-801

974515-100

816346-011

911119-106

911121-107

106592-000

816665-000

116114-000

816342-011

874112-000

911117-105

816174-011

ARMSTRONG

816366-071

816861-071

CIRCULATOR PARTS

MODEL NUMBER H66 - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER

BAR CODE

Circulator Parts List 98 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 6 1/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-071

116368-000

816565-000

911121-106

911121-107

816354-041

116904-001

116369-000

116361-000

116400-000

116406-000

927412-700

816707-001

816707-003

116117-000

913125-100

816393-047

974508-100

816346-011

911119-106

106074-011

911125-100

816665-000

116114-000

875000-801

974515-100

911117-105

816174-011

911121-107

106592-000

816366-041

816861-011

816342-011

874112-000

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

CIRCULATOR PARTS

MODEL NUMBER H67 - SIZE 6 Serial No. 6505 & Later

STANDARD BRONZE FITTED CONSTRUCTION

Circulator Parts List 99 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Bronze)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 6 1/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-041

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911125-100

116117-000

913125-100

816393-047

974515-100

816346-041

911119-106

106074-041

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-041

911121-107

BAR CODE

816366-041

816861-041

816342-011

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

MODEL NUMBER H67 - SIZE 6 Serial No. 6505 & Later

Circulator Parts List 100 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Steel) 6 1/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-004

116904-001

116369-000

116361-000

974508-100

913173-100

927412-700

816707-002

911125-100

116117-000

913125-100

816393-017

974515-100

816346-011

911119-106

106074-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-011

911121-107

BAR CODE

816366-071

816861-071

816342-011

MODEL NUMBER H67 - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 101 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 6 3/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1 1/2HP/115/230V 811757-028

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-041

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911125-100

116117-000

913125-100

816393-043

974515-100

816346-011

911119-106

106074-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-011

911121-107

BAR CODE

816366-041

816861-011

816342-011

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

MODEL NUMBER H68 - SIZE 6 Serial No. 6505 & Later

Circulator Parts List 102 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Bronze)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 6 3/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1 1/2HP/115/230V 811757-028

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-041

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911125-100

116117-000

913125-100

816393-043

974515-100

816346-041

911119-106

106074-041

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-041

911121-107

BAR CODE

816366-041

816861-041

816342-011

MODEL NUMBER H68 - SIZE 6 Serial No. 6505 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 103 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Steel) 6 3/4"

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1 1/2HP/115/230V 811757-028

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-011

816354-071

116400-000

816565-000

911121-106

911121-107

116368-000

816707-004

116904-001

116369-000

116361-000

974508-100

913173-100

927412-700

816707-002

911125-100

116117-000

913125-100

816393-013

974515-100

816346-011

911119-106

106074-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-011

911121-107

BAR CODE

816366-071

816861-071

816342-011

MODEL NUMBER H68 - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 104 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 7" Dia.

25 IMPELLER (Brass) 6 1/2" Dia.

25 IMPELLER (Brass) 6" Dia.

25 IMPELLER (Brass) 5 1/2" Dia.

25 IMPELLER (Brass) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115V/230 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230 (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 816678-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER 1060 1 1/2D - SIZE 6 Serial No. 6505 & Late

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-011

816342-011

874112-000

911117-105

816397-011

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-011

911119-106

104301-011

911123-116

104034-000

913129-100

874058-041

974508-100

116406-000

927412-700

816707-001

816707-003

116904-001

116369-000

116361-000

116400-000

816565-000

911121-106

911121-107

816354-041

816354-071

116368-000

874058-045

874058-049

874058-053

874058-057

Circulator Parts List 105 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Bronze)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Brass) 7" Dia.

25 IMPELLER (Brass) 6 1/2" Dia.

25 IMPELLER (Brass) 6" Dia.

25 IMPELLER (Brass) 5 1/2" Dia.

25 IMPELLER (Brass) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115V/230 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230 (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 816678-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER 1060 1 1/2D - SIZE 6 Serial No. 6505 & Late

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-041

816342-011

874112-000

911117-105

816397-041

874058-041

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

116400-000

816565-000

116368-000

816354-071

911121-106

911121-107

816354-041

874058-045

874058-049

874058-053

874058-057

816707-003

116904-001

816346-041

911119-106

104301-041

927412-700

816707-001

911123-116

104034-000

913129-100

116369-000

116361-000

974508-100

116406-000

Circulator Parts List 106 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -1 1/2" NPT - (Cast Iron)

32 FLANGE BOLTS - 7/16-14X2

30 FLANGE GASKET

- FLANGE NUTS - 7/16-14

25 IMPELLER (Cast Iron) 7" Dia.

25 IMPELLER (Cast Iron) 6 1/2" Dia.

25 IMPELLER (Cast Iron) 6" Dia.

25 IMPELLER (Cast Iron) 5 1/2" Dia.

25 IMPELLER (Cast Iron) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115V/230 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230 (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 816678-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER 1060 1 1/2D - SIZE 6 Serial No. 6505 & Late

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-071

816861-071

816342-011

874112-000

911117-105

816397-011

911121-107

106592-000

816665-000

116114-000

875000-801

974515-100

816346-011

911119-106

104301-011

911123-116

104034-000

913129-100

874058-011

974508-100

913173-100

927412-700

816707-002

816707-004

116904-001

116369-000

116361-000

116400-000

816565-000

911121-107

911121-106

816354-071

116368-000

874058-015

874058-019

874058-023

874058-027

Circulator Parts List 107 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 7" Dia.

25 IMPELLER (Brass) 6 1/2" Dia.

25 IMPELLER (Brass) 6" Dia.

25 IMPELLER (Brass) 5 1/2" Dia.

25 IMPELLER (Brass) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115V/230 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230 (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 816678-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/208/230/460V (4) 816681-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/575V (4) 816686-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816354-041

816354-071

116368-000

816393-053

816393-057

116400-000

816565-000

911121-106

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911125-100

116117-000

913125-100

816393-041

816393-045

816393-049

974515-100

816346-011

911119-106

106074-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-011

911121-107

BAR CODE

816366-041

816861-011

816342-011

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

MODEL NUMBER 1060 2D - SIZE 6 Serial No. 6505 & Later

Circulator Parts List 108 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Bronze)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Brass) 7" Dia.

25 IMPELLER (Brass) 6 1/2" Dia.

25 IMPELLER (Brass) 6" Dia.

25 IMPELLER (Brass) 5 1/2" Dia.

25 IMPELLER (Brass) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115V/230 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230 (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 816678-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/208/230/460V (4) 816681-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/575V (4) 816686-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

911121-107

874112-000

911117-105

816174-041

CIRCULATOR PARTS

816393-045

816393-049

816393-053

816393-057

816354-041

816354-071

116368-000

116400-000

816565-000

911121-106

911121-107

816707-003

116904-001

116369-000

116361-000

974508-100

116406-000

927412-700

816707-001

911125-100

116117-000

913125-100

816393-041

911119-106

106074-041

106592-000

816665-000

116114-000

875000-801

816346-041

974515-100

BAR CODE

816366-041

816861-041

816342-011

MODEL NUMBER 1060 2D - SIZE 6 Serial No. 6505 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

Circulator Parts List 109 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -2" NPT - (Cast Iron)

32 FLANGE BOLTS - 1/2-13X2 1/4"

30 FLANGE GASKET

- FLANGE NUTS - 1/2-13

25 IMPELLER (Steel) 7" Dia.

25 IMPELLER (Steel) 6 1/2" Dia.

25 IMPELLER (Steel) 6" Dia.

25 IMPELLER (Steel) 5 1/2" Dia.

25 IMPELLER (Steel) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V 811757-001

1 RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V 811757-002

1 RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115V/230 811757-007

17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)

1 RIGID MOUNT. MOT. ASSY. - 1PH /1/2HP/115/230 (4) 831009-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/3/4HP/115/230V (4) 831010-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V (4) 831011-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V (4) 831012-083

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V (4) 811757-004

1 RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V (4) 816678-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/208/230/460V (4) 816681-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/575V (4) 816686-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

816707-004

116904-001

116369-000

116361-000

911125-100

116117-000

816354-071

116368-000

911121-106

911121-107

974508-100

913173-100

927412-700

816707-002

116400-000

816565-000

913125-100

816393-011

816393-023

816393-027

816393-015

816393-019

974515-100

816346-011

911119-106

106074-011

106592-000

816665-000

116114-000

875000-801

874112-000

911117-105

816174-011

911121-107

BAR CODE

816366-071

816861-071

816342-011

MODEL NUMBER 1060 2D - SIZE 6 Serial No. 6505 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

CIRCULATOR PARTS

Circulator Parts List 110 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -3" NPT - (Cast Iron)

32 FLANGE BOLTS - 5/8-11X2 1/2"

30 FLANGE GASKET

- FLANGE NUTS - 5/8-11

25 IMPELLER (Brass) 7" Dia.

25 IMPELLER (Brass) 6 1/2" Dia.

25 IMPELLER (Brass) 6" Dia.

25 IMPELLER (Brass) 5 1/2" Dia.

25 IMPELLER (Brass) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/208/230/460V (4) 816681-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/575V (4) 816686-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/3HP/208/230/460V (4) 816711-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/3HP/575V (4) 816687-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER 1060 3D - SIZE 6 Serial No. 6910 & Later

STANDARD BRONZE FITTED CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-011

816342-011

874112-000

911117-105

816646-041

911121-107

106592-000

840482-013

116114-000

875000-898

974515-100

816346-011

911119-106

933615-010

911125-100

425605-106

913125-100

816647-041

816647-045

816647-049

816647-053

816647-057

974508-100

116406-000

927412-700

816707-001

116400-000

816565-000

911121-107

816707-003

116904-001

116369-000

116361-000

816354-041

816354-071

116368-000

Circulator Parts List 111 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Bronze)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -3" NPT - (Bronze)

32 FLANGE BOLTS - 5/8-11X2 1/2"

30 FLANGE GASKET

- FLANGE NUTS - 5/8-11

25 IMPELLER (Brass) 7" Dia.

25 IMPELLER (Brass) 6 1/2" Dia.

25 IMPELLER (Brass) 6" Dia.

25 IMPELLER (Brass) 5 1/2" Dia.

25 IMPELLER (Brass) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Bronze)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Brass Buna)

24 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/208/230/460V (4) 816681-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/575V (4) 816686-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/3HP/208/230/460V (4) 816711-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/3HP/575V (4) 816687-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY

6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER 1060 3D - SIZE 6 Serial No. 6910 & Later

ALL BRONZE CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-041

816861-041

816342-011

874112-000

911117-105

816646-011

911121-107

106592-000

840482-013

116114-000

875000-898

974515-100

816346-041

911119-106

106466-041

911125-100

425605-106

913125-100

816647-041

816647-045

816647-049

816647-053

816647-057

974508-100

116406-000

927412-700

816707-001

116400-000

816565-000

911121-107

816707-003

116904-001

116369-000

116361-000

816354-041

816354-071

116368-000

Circulator Parts List 112 of 113

FILE NO.: 6010.201

DATE: September 17,2013

SUPERSEDES: 6010.201

DATE: February 05,2013

ITEM

NO.

35 BEARING ASSEMBLY (1)

35 BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)

10 BEARING BRACKET

4 BEARING CAP ASSEMBLY (3)

3 BEARING CAP CAPSCREWS 1/4-20X5/8

29 BODY

21 BODY CAPS. - 3/8-16X7/8

28 BODY GASKET

2 COUPLER ASSEMBLY (Flexible) 5/8X5/8

15 COUPLER GUARD

0 COUPLER INSERT

7 COUPLER KEY (Woodruff #9)

20 COVERPLATE (Cast Iron)

18 COVERPLATE CAPSCREWS 5/16-18X3/4

31 FLANGE -3" NPT - (Cast Iron)

32 FLANGE BOLTS - 5/8-11X2 1/2"

30 FLANGE GASKET

- FLANGE NUTS - 5/8-11

25 IMPELLER (Steel) 7" Dia.

25 IMPELLER (Steel) 6 1/2" Dia.

25 IMPELLER (Steel) 6" Dia.

25 IMPELLER (Steel) 5 1/2" Dia.

25 IMPELLER (Steel) 5" Dia.

8 IMPELLER KEY (WOODRUFF #3)

27 IMPELLER NUT 7/16-20NF (Steel)

26 IMPELLER WASHER

24 MECH. SEAL ASSY. (Steel Buna)

24 MECH. SEAL ASSY. (Steel Viton High Temp. 225F-275F)

14 OIL LEVEL WINDOW

9 OIL SLINGER

12 OIL WELL COVER ASSEMBLY

11 OIL WELL COVER GASKET

- OIL WICKS (3/8X1/2)

1 RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4) 816676-062

1 RIGID MOUNT. MOT. ASSY. - 1PH/1 1/2HP/115/230V (4) 816678-062

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4) 816676-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/208/230/460V (4) 816678-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/208/230/460V (4) 816681-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4) 811757-009

1 RIGID MOUNT. MOT. ASSY. - 3PH/1 1/2HP/575V (4) 816685-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/2HP/575V (4) 816686-068

1 RIGID MOUNT. MOT. ASSY. - 3PH/3HP/208/230/460V (4) 816711-069

1 RIGID MOUNT. MOT. ASSY. - 3PH/3HP/575V (4) 816687-068

17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)

6 SHAFT & SLEEVE ASSEMBLY (S/S Sleeve)

19 WATER SLINGER

NOTES:

(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.

(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.

(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.

(4) For TEFC or Explosion Proof Motors, contact the factory.

CIRCULATOR PARTS

MODEL NUMBER 1060 3D - SIZE 6 Serial No. 6910 & Later

ALL IRON CONSTRUCTION

DESCRIPTION PART NUMBER ARMSTRONG

BAR CODE

816366-071

816861-071

816342-011

874112-000

911117-105

816646-011

911121-107

106592-000

840482-013

116114-000

875000-898

974515-100

816346-011

911119-106

933615-010

911125-100

425605-106

913125-100

816647-011

927412-700

816707-002

816647-015

816647-019

816647-023

816647-027

116368-000

116400-000

816565-000

911121-107

816354-071

816707-004

116904-001

116369-000

116361-000

974508-100

913173-100

Circulator Parts List 113 of 113

13627 3 Armstrong S & H Series Repair Parts 6010.201 .202 Circulator User Manual

547689 3 Armstrong S & H Series Repair Parts 547689_3_Armstrong S & H Series Repair Parts

547697 3 Armstrong S & H Series Repair Parts 547697_3_Armstrong S & H Series Repair Parts

548420 3 Armstrong S & H Series Repair Parts 548420_3_Armstrong S & H Series Repair Parts

547699 3 Armstrong S & H Series Repair Parts 547699_3_Armstrong S & H Series Repair Parts

547868 1 Armstrong S & H Series Repair Parts 547868_1_Armstrong S & H Series Repair Parts

Navigation menu

Versions of this User Manual:

Views

Navigation
