Bell & Gossett SUBMITTAL
B-131.2E
JOB: REPRESENTATIVE:
UNIT TAG: ORDER NO. DATE:
ENGINEER: SUBMITTED BY: DATE:
CONTRACTOR: APPROVED BY: DATE:
Series 60
Maintenance Free In-Line Mounted Pump
SPECIFICATIONS
FLOW HEAD
HP RPM
VOLTS
CYCLE PHASE
ENCLOSURE
APPROX. WEIGHT
SPECIALS
MATERIALS OF CONSTRUCTION
BRONZE FITTED ALL BRONZE
FEATURES
MAINTENANCE FREE PUMP
INTERNALLY SELF-FLUSHING MECHANICAL
SEAL
XLII© LUBRICATION SYSTEM
THREE YEAR WARRANTY
FACTORY TEST
MAXIMUM WORKING PRESSURE
175 psi (12 bar) W.P.
TYPE OF SEAL
BUNA/CARBON-CERAMIC (STANDARD)
(-20 °F TO 225 °F)
TYPE OF SEAL
EPT/TUNGSTEN-CARBIDE
(-20 °F TO 250 °F)
TYPE OF SEAL
VITON/CARBON-CERAMIC
(0 °F TO 225 °F)
© COPYRIGHT 2003 ITT INDUSTRIES, INC.
Series 60 1-1/2x1-1/2x7 Centrifugal Pump Submittal B-131.2E
SUCTION AND DISCHARGE SIZE
INCHES NPT
PUMP DIMENSIONS IN INCHES (MM)
F G K L M N P R S T
1-1/2 9-3/8
(238)
3-1/4
(83)
4-5/8
(117)
1
(25)
3-7/8
(98)
9-1/2
(241)
3/4
(19)
6-1/2
(165)
7
(178)
13-1/2
(343)
MAXIMUM WORKING PRESSURE 175PSI (12 BAR)
ALL MOTORS 1750 RPM
DIMENSIONS − Inches (mm)
MOTOR HP MOTOR DIMENSIONS - INCHES (MM)
HP PHASE A B C D E H
3/4 110-1/8
(257)
2-1/4
(57)
7-7/8
(200)
4-3/8
(111)
11
(279)
23-5/8
(600)
3/4 37-7/8
(200) −7-7/8
(200)
4-3/8
(111)
11
(279)
23-5/8
(600)
1 1 10-1/8
(257)
2-1/4
(57)
7-7/8
(200)
4-3/4
(121)
11
(279)
23-5/8
(600)
1 3 7-7/8
(200) −7-7/8
(200)
4-3/4
(121)
11
(279)
23-5/8
(600)
1-1/2 18-3/4
(222)
2-1/4
(57)
6-1/2
(165)
3-1/4
(83)
10-3/4
(273)
21-5/8
(549)
1-1/2 36-1/2
(165) −6-1/2
(165)
3-1/4
(83)
10-3/4
(273)
21-5/8
(549)
2 3 6-1/2
(165) −6-1/2
(165)
3-1/4
(83)
10-3/4
(273)
21-3/8
(543)
Dimensions are subject to change. Not to be used for construction purposes unless certified.
Includes Companion Flan
g
es.
Bell & Gossett
8200 N. Austin Avenue, Morton Grove, IL 60053
Phone (847)966-3700
Facsimile (847)966-9052
www.bellgossett.com
