XP SERIES

Commercial/Residential

Portable Generators

XP6500E

Model 5930-1 UPC: 696471059304

(EPA/49-State/CSA-Canada)

Model 5934-0 UPC: 696471059342

(EPA/CARB-California)

Features

49-State/CSA Control Panel

®

XP6500E

• The Generac OHVI® engine incorporates full pressure lubrication with

automotive style spin on oil filter for longer life engine.

• TruePower™ Technology provides clean, smooth operation of sensitive

electronics, tools, and appliances.

• Idle Control reduces noise and conserves fuel for extended run-times.

• Full panel GFCI protection meets OSHA safety requirements.

• 120/240V selector switch provides full 120V power.

• Integrated lifting eye provides easy transport and security on the jobsite.

• Hour meter with maintenance resets tracks ussage and monitors

maintenance cycles.

• Large-capacity steel fuel tank with incorporated fuel gauge provides

durability and extended run times.

• Low-oil pressure shutdown automatically safeguards engine from damage.

• Covered outlets provides added protection from the environment and rugged

working conditions.

• Full-wrap, heavy-duty, 1 1/4" steel tube cradle for added durability and

strength.

• All-terrain, never flat wheels and fold-down locking handle for reliable

portability and compact storage.

• Single touch electric start provides hassle-free start-up, battery included.

On-control panel plug-in battery charger jack keeps battery charged.

• User-friendly design has conveniently placed engine controls for simple

operation and east start-up.

• First oil and maintenance kit included.

AC Rated Output Running Watts 6500

AC Maximum Output Starting Watts 8125

(2) 120V 20A 5-20R Duplex Outlets

(1) 120V 30A L5-30R Twist Lock Outlet

(1) 120/240V 30A L14-30R Twist Lock Outlet

Full Panel GFCI Module

(2) 20A Push-to-reset Circuit Breakers

(1) 30A Push-to-reset

Circuit Breaker

(1) 30A 2P Circuit Breaker

120/240 Volt Selector

Hour Meter

Fuel Shut Off

Choke

Off/On/Start Switch

12VDC Battery Charger Input

Idle Control

Model 5930-1 5934-0

Length in (mm) 34.5 (880)

Width in (mm) 29 (736)

Height in (mm) 27.25 (691)

Extended Length in (mm) 48.5 (1230)

Carton Length in (mm) 37.25 (948)

Carton Width in (mm) 22.75 (578)

Carton Height in (mm) 25.5 (646)

Unit Weight lbs (kg) 228 (103.5) 235 (106.5)

Shipping Weight lbs (kg) 261 (118.5) 267 (121)

Product Series XP6500E

Model (Configuration) 5930-1

(EPA/49-State/CSA-Canada)

5934-0 (EPA/CARB-California)

AC Rated Output Running Watts 6500

AC Maximum Output Starting Watts 8125

Rated AC Voltage 120/240 VAC

Rated AC Frequency 60 Hz

Rated 120/240 VAC Amperage 54.2/27.0

Max 120/240 VAC Amperage 67.7/33.9

Engine Displacement 407cc

Engine Type OHVI

Engine RPM 3600

Recommended Oil 10W-30 / SAE 30

Lubrication Method Oil Pump

Choke Location On Control Panel

Fuel Shut Off On Control Panel

Starting Method Electric/Recoil Pull Start

Battery Yes

Battery Type 12VDC 10Ah

Battery Wall Charger Adapter Included

Low Oil Shutdown Low Pressure

Neutral Bonded to Ground Yes

Start Switch Type Off/On/Start

Switch Location On Control Panel

Single Lifting Eye Included

Fuel Gauge Built-in Tank

Fuel Tank Capacity Gal (Ltrs) 9 (34)

Run Time at 50% (Hours) 11

Handle Style Folding Interlocked

Wheel Type 10" Solid Wheels

Maintenance Kit Included

Warranty- Residential 3 Year

Warranty- Commercial 3 Year

Dimensions and Weights

2 of 2

XP6500E

GeneracPowerSystems,Inc.•P.O.Box8,Waukesha,WI53187•generac.com

©2012 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0196500SBY-A / Printed in U.S.A. 10/22/12

XP6500E

®

Specifications

Extended Length

Length

Width

Height
