Features/Benefits:

Complete range of shallow and deepwell jetpumps.

I.E.C. motors for better efficiency, longer life, and quieter operation.

Corrosion resistant composite components;impeller, ejector and diffuser.

Rugged Cast Iron (models JPF and JDF) for durability and strength.

Stainless Steel construction (model JPS) for superior corrosion protection.

Built in Thermal Overload for motor protection.

Clean out port (JPF models only) for easy ejector service.

Available From:

Technical information listed as a range only and subject

to change without notice. Consult a Grundfos product

submittal data sheet for exact specifications.

Technical Data: Series JPF/JDF Series JPS

Electrical Supply 1x115V or 1x230V 1x115V or 1x230V

Fluid Temperature 95°F JPF (104°F JDF) 95°F

Maximum Working Pressure 87 PSI 87 PSI

Maximum Lift 25 feet JPF, (70 feet JDF) 25 feet

HP Range 1/2, 3/4 & 1 (1/2 & 3/4 JDF) Hp 1/2 & 1 Hp

Suction 1 & 11/4 (JPF5 & JDF) NPT 1 NPT

Discharge 1 NPT 1 NPT

Motor I.E.C. I.E.C.

Materials:

Motor Stool Cast Iron E-Coated Aluminum

Shaft Seal Carbon/Ceramic/NBR Carbon/Ceramic/NBR

O-Rings & Gaskets NBR NBR

Pump Housing (Cap) Cast Iron Stainless Steel

Impeller Noryl® Technopolymer A

Tubing Polyethylene Polyethylene

Ejector/Guide Vane Noryl® Technopolymer A

Construction/Operation:
