X160 Series
Features
This series of submersible pumps is designed for use in residential or
commercial dewatering and effluent applications in Class I, Division 1, Group C
and D locations. Each pump is FM/CSA approved and features innovative motor
and electrical enclosures that are designed to reduce the risk of vapor ignition
both inside and outside the pump. Should vapors inside the electrical
enclosures become ignited, the enclosures are engineered to contain the event
and prevent escalation. Each pump is constructed of hardware that will allow it
to operate safely and efficiently in extreme conditions. As with every Zoeller
pump, each one is 100% factory tested to ensure quality and reliability for years
of trouble-free performance!
Automatic models are available with an optional seal failure panel (P/N 10-
1031).
Nonautomatic units require a Zoeller control panel with intrinsically safe relays
and a moisture indicator.
Surface temperature code T5 (1 Ph) or T6 (3 Ph).
Includes a stainless steel lifting bracket for easy installation and removal.
All models are hermetically sealed to be watertight, dust-tight, and completely
submersible.
Reserve Powered Design: For unusual conditions, a reserve safety factor is
engineered into the design of every pump. Automatic units Patent No. 8,535,014
Specifications
Motor Characteristics
Motor 1/2 - 1 HP
Voltage 115 - 575 V
Phase 1 or 3 Ph
Hertz 60 Hz
RPM 3450 RPM
Type Permanent split capacitor or 3 phase
Insulation Class B
Amps 2.4 - 15.5 Amps
Pump Characteristics
Operation Automatic or nonautomatic
Auto On/ Off Points 19-1/2" / 9-3/4" (49.5 cm / 24.8 cm)
Discharge Size 1-1/2" NPT (optional 2" or 3" flange available)
Solids Handling 3/4" (19 mm) spherical solids
Cord Length 20' (6 m) standard
Cord Type UL listed, 5-wire (1 Ph) or 8-wire (3 Ph) SOOW
cord
Max Head 86.5' (26 m)
Max Flow Rate 100 GPM (379 LPM)
Max Operating Temp 104 °F (40 °C)
Cooling Oil filled
Motor Protection Auto reset thermal overload (1 Ph) or thermal
sensor (3 Ph)
Materials Characteristics
Cap Cast iron
Motor Housing Cast iron
Pump Housing Cast iron
Base Cast iron
Upper Bearing Ball bearing
Lower Bearing Ball bearing
Mechanical Seals Carbon and ceramic with stainless steel parts
Impeller Type Non-clogging vortex
Impeller Bronze
Hardware Stainless steel or brass
Motor Shaft 416 stainless steel
FM1745_Ea
Updated 0816
Model
Model Number Seal Mode Volts Phase Amps HP Hz Lbs Kg
MX161 Single Auto 115 1 15.5 1/2 60 123 55
NX161 Single Non 115 1 15.5 1/2 60 114 51
DX161 Single Auto 230 1 7.5 1/2 60 123 55
EX161 Single Non 230 1 7.5 1/2 60 114 51
HX161 Single Auto 200 1 8.8 1/2 60 123 55
IX161 Single Non 200 1 8.8 1/2 60 117 53
JX161 Single Non 200 3 6.4 1/2 60 117 53
FX161 Single Non 230 3 5.2 1/2 60 117 53
GX161 Single Non 460 3 2.9 1/2 60 117 53
BAX161 Single Non 575 3 2.4 1/2 60 117 53
MX163 Single Auto 115 1 15.0 1/2 60 123 55
NX163 Single Non 115 1 15.0 1/2 60 114 51
DX163 Single Auto 230 1 7.5 1/2 60 123 55
EX163 Single Non 230 1 7.5 1/2 60 117 53
HX163 Single Auto 200 1 8.5 1/2 60 123 55
IX163 Single Non 200 1 8.5 1/2 60 117 53
JX163 Single Non 200 3 6.0 1/2 60 117 53
FX163 Single Non 230 3 4.8 1/2 60 117 53
GX163 Single Non 460 3 2.9 1/2 60 117 53
BAX163 Single Non 575 3 2.4 1/2 60 117 53
DX165 Single Auto 230 1 10.2 1 60 124 56
EX165 Single Non 230 1 10.2 1 60 114 51
HX165 Single Auto 200 1 12.6 1 60 124 56
IX165 Single Non 200 1 12.6 1 60 117 53
JX165 Single Non 200 3 7.5 1 60 117 53
FX165 Single Non 230 3 7.4 1 60 117 53
GX165 Single Non 460 3 3.7 1 60 117 53
BAX165 Single Non 575 3 3.0 1 60 117 53
Additional cord lengths are available in 25' (8 m), 35' (11 m) and 50' (15 m).
