BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
SECTION 7
RELIEF VALVES, FLOAT VALVES & ACCESS., AIR VOLUME
CONTROLS, FLOW CONTROLS
PRODUCT LINE PAGE
Relief Valves ...................................................................................... 1
No Lead Brass
Stainless Steel
PVC
Snifter Valves ..................................................................................... 2
Bleeder Orifices .................................................................................... 2
Float Valves ....................................................................................... 2
Plug Adapters ..................................................................................... 4
Float Rods ........................................................................................ 4
Floats ............................................................................................. 4
Stainless Steel
Copper
Plastic
Black Economy Plastic
Float Valve Parts .................................................................................. 5
Air Volume Controls ............................................................................... 6
Shallow Well
Deep Well
Brady Air Volume Controls ......................................................................... 7
Brady A.V.C. Installation Kit ....................................................................... 7
Flow Controls ..................................................................................... 8
Rev. 1.0 US
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
7-1
December 10/12
NO LEAD BRASS RELIEF VALVES (NON-ADJUSTABLE)
Pressure relief valves are recommended for all cold water system installations - to protect against damage to piping and pressure tanks.
Set at 75 PSI or 100 PSI, ( ±) 15% setting accuracy, field adjustments are not recommended.
These valves are not T & P valves that are required with water heaters.
Max. Operating Temp.
140◦F (60◦)
•Brass body •Stainless steel spring and retaining screw •Buna N sealing disc
PART NO. SIZE FACTORY QUANTITY LIST
BRASS IN OUT PRE-SET CTN CASE PRICE-A
RVNB05-075NL 1/2"MPT 1/2"FPT 75 PSI 10 100 10.30
RVNB07-075NL 3/4"MPT 1/2"FPT 75 PSI 10 100 10.81
RVNB05-100NL 1/2"MPT 1/2"FPT 100 PSI 10 100 10.30
RVNB07-100NL 3/4"MPT 1/2"FPT 100 PSI 10 100 10.81
#304 STAINLESS STEEL RELIEF VALVES (NON-ADJUSTABLE)
Boshart recommends - Using both Gray Stainless Steel PTFE Tape & Gray Magic Pipe Thread
Compound together for joining stainless steel threaded connections.
Pressure relief valves are recommended for all cold water system installations - to protect against damage to piping and pressure tanks.
Set at 75 PSI, ( ±) 15% setting accuracy, field adjustments are not recommended.
SIZE FACTORY QUANTITY LIST
PART NO. IN OUT PRE-SET CTN CASE PRICE-A
SSRVN05-075 1/2"MPT 1/2"FPT 75 PSI 10 100 15.63
SSRVN07-075 3/4"MPT 1/2"FPT 75 PSI 10 100 16.77
SSRVN05-100 1/2"MPT 1/2"FPT 100 PSI 10 100 15.63
SSRVN07-100 3/4"MPT 1/2"FPT 100 PSI 10 100 16.77
PVC RELIEF VALVES
Pressure relief valves are recommended for all cold water system installations - to protect against damage to piping and pressure tanks.
Set at 75 PSI, ( ±) 15% setting accuracy, field adjustments are not recommended.
•PVC material
•Designed for low maintenance
•Factory Preset to 75 PSI (Adjustable to 150 PSI)
•High quality Stainless Steel spring
FACTORY QUANTITY LIST
PART NO. SIZE PRE-SET CTN CASE PRICE-A
PVCRVN05-75150 1/2"75 PSI 20 240 5.28
NO LEAD HEAVY DUTY RELIEF VALVES
Pressure relief valves are recommended for all cold water system installations - to protect against damage to piping and pressure tanks.
Accuracy ±15% of factory preset PSI. Field adjustments are not recommended.
These valves are not T & P valves that are required with water heaters.
Max. Operating Temp. 140◦F (60◦)
•Heavy duty cast bronze body •Stainless steel spring •E.P.D.M. rubber sealing disc
SIZE FACTORY RANGE PSI QTY LIST
PART NO. IN OUT PRE-SET MIN. MAX. PRICE-A
RVHD05NL 1/2"MPT 1/2"FPT 75 PSI 10 150 1 54.44
RVHD07NL 3/4"MPT 3/4"FPT 75 PSI 10 100 1 66.52
RVHD10NL 1"MPT 3/4"FPT 75 PSI 50 100 1 116.72
RVHD12NL 1-1/4"MPT 1-1/4"FPT 65 PSI 50 100 1 197.94
RVHD15NL 1-1/2"FPT 1-1/2"FPT 65 PSI 60 100 1 508.50
RVHD20NL 2"FPT 2"FPT 65 PSI 60 100 4 519.43
NOTE: Valves will be sold at factory pre-set PSI only. While field adjustments are not recommended we have included the
approximate range information shown above which has been provided by the manufacturer(s). However, any changes made to
the pre-set pressure is entirely at the risk of the person(s) / company who make the adjustment. Any changes made
should be thoroughly tested for accuracy at time of installation. Neither the manufacturer or Boshart Industries Inc. will
assume any liability or responsibility caused as a result of adjusting the relief valve setting. If the pressure setting is
adjusted, it will void any warranty or return of the product. Relief valves must be installed so that they drain to a floor drain,
sump or other safe location with an air break. If an outlet pipe is used then it must be at least the same diameter as the relief
valve outlet. Cold water use only.
Rev. 1.0 US
7-2
May 16/14
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
NO LEAD SNIFTER (AIR / TANK) VALVES
WORKING WORKING OPENING QUANTITY LIST
PART NO. DESCRIPTION PRESSURE TEMP. (◦F) PRESSURE BAG CASE PRICE-A
SV-0-NCS 1/8"MPT Snifter Valve 15-150 PSI -10◦To +165◦3 PSI 10 100 3.74
Assembled with “Springless” valve core & vented cap *
SV-0NL 1/8"MPT Snifter Valve 15-150 PSI -10◦To +165◦3 PSI 50 1000 2.89
SV-0NL manufactured with light spring required for shallow well pump and bleeder systems
SV-0-SC-VC 1/8"MPT Snifter Valve 15-150 PSI -10◦To +165◦3 PSI 10 100 3.78
Assembled with light (soft core) spring & vented cap
SV-1-NCS 1/4"MPT Tank Valve 15-150 PSI -10◦To +165◦3 PSI 10 100 4.45
Assembled with “Springless” valve core & vented cap *
SV-1NL 1/4"MPT Tank Valve 0-200 PSI -40◦To +225◦60 PSI 50 800 3.28
General Purpose Peak of 300
SV-1-SC-VC 1/4"MPT Snifter Valve 15-150 PSI -10◦To +165◦3 PSI 10 100 4.49
Assembled with light (soft core) spring & vented cap
SV-CAP-M Chrome plated steel cap c/w rubber seal & valve core driver feature 10 100 1.00/cap
Valves must be ordered in
multiples of 10.
SV-CAP Black Flexible Plastic Cap - has no sealing unit 10 100 0.30/cap
*Vented Cap similar to SV-CAP-M but without rubber seal - allows air to vent through open orifice
BLEEDER ORIFICES
•BOB07NL - 3/4"MPT No Lead Brass •BOR10 - 1"MPT rubber
•Will not corrode or stick •Non-corrosive bleeder
•Rapid opening and closing valve for submersible pumps •Fast bleed through its large opening
•Complete closure prevents loss of pumping volume
QUANTITY LIST QUANTITY LIST
PART NO. CTN CASE PRICE-A PART NO. CTN CASE PRICE-A
BOB07NL 48 384 8.07 BOR10 50 600 2.20
NO LEAD BRASS BULKHEAD FLOAT VALVES - THREADED OUTLET
•Heavy duty body c/w Buna-N disc
•Rubber bulkhead gasket/brass nut
•Maximum operating temperature rating 180◦F (82◦C)
•Maximum operating pressure rating 125 PSI
DESCRIPTION ROD CONN. QUANTITY LIST
PART NO. INLET OUTLET TAPPED CTN CASE PRICE-A
28-BHFV-05NL 1/2"SMT x 3/8"FPT 1/2"MPT 1/4"- 20 SAE 10 100 25.27
28-BHFV-07NL 3/4"SMT x 1/2"FPT 3/4"MPT 1/4"- 20 SAE 10 80 28.42
SMT = Straight Male Thread
BRONZE FLOAT VALVE WITH “NO FREEZE” FLOW KIT
•Designed for livestock watering applications where freeze up conditions occur.
•Extra long heavy duty valve body which allows for a 1/8"FPT tapping on the inlet side right before the valve port.
•Easy connection allows for a controlled (adjustable) continuous trickle or low volume flow of water thru the valve
into the livestock watering tank preventing the pipes from freezing
QUANTITY LIST
PART NO. SIZE CTN CASE PRICE-A
28-BFV07T-KIT 3/4"MPT X 3/4"MPT BRONZE FLOAT 10 80 28.64
with NEEDLE VALVE + 45 ST. ELB
28-BFV10T-KIT 1"MPT x 1"MPT BRONZE FLOATS 10 40 41.95
with NEEDLE VALVE + 45 ST. ELB
Replacement Parts: These valves use the same plunger and linkage components as the standard float valves.
CAUTION: There are definite temperature limitations in which this system will operate successfully, the operating temperature
may vary widely due, the ambient temp., wind chill, incoming water temp. (distance water travels thru piping exposed to freezing
temperatures), the rate of continuous flow and the frequency and duration of operation of the float valves filling the watering tank
WARNING! Since there are too many variables Boshart Industries Inc. cannot provide installation recommendations. Boshart
Industries Inc. will not cover any damages to the product or assume any liability for issues which result from freeze up to these valves
or damages resulting from freeze up. It is the responsibility of the end user to adjust flow as required and to monitor the system
regularly to ensure it is functioning properly.
US Rev. 1.0
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
7-3
April 9/13
NO LEAD BRASS FLOAT VALVES - THREADED OUTLET
•Heavy duty body c/w Buna-N disc
•Maximum operating temperature rating 180◦F (82◦C)
•Maximum operating pressure rating 125 PSI
ROD CONN. QUANTITY SHIPPING LIST
PART NO. SIZE INLET OUTLET TAPPED CTN CASE WGT LBS PRICE-A
28-BFV-03NL 3/8"3/8"MPT 3/8"MPT 1/4"- 20 SAE 10 100 0.66 20.41
28-BFV-05NL 1/2"1/2"MPT 1/2"MPT 1/4"- 20 SAE 10 100 0.74 19.46
28-BFV-07NL 3/4"3/4"MPT 3/4"MPT 1/4"- 20 SAE 10 80 0.96 22.21
28-BFV-10NL 1"1"MPT 1"MPT 1/4"- 20 SAE 10 40 1.38 34.67
NO LEAD BRASS FLOAT VALVES - FAUCET OUTLET
•Heavy duty body c/w Buna-N disc
•Maximum operating temperature rating 180◦F (82◦C)
•Maximum operating pressure rating 125 PSI
ROD CONN. QUANTITY SHIPPING LIST
PART NO. SIZE INLET OUTLET TAPPED CTN CASE WGT LBS PRICE-A
28-BFV-12NL 1-1/4"1-1/4"FPT Faucet 3/8"- 16 SAE 1 20 3.10 89.72
28-BFV-15NL 1-1/2"1-1/2"FPT Faucet 3/8"- 16 SAE 1 20 3.24 85.87
28-BFV-20NL 2"2"FPT Faucet 3/8"- 16 SAE 1 20 3.44 95.64
NOTE: A 8"diameter float with a 12"rod is the minimum size recommended for use with 1 1/4"to 2"float valves.
PVC FLOAT VALVES
These heavy duty PVC Float Valves provide a low cost alternative for costly stainless steel or other metal float valves. They are
ideal for automatic tank filling applications. The most common use of a float valve is to control the filling of livestock water
tanks and water tower cooling tanks as well as many other automatic tank filling applications.
FEATURES:
•Heavy Duty PVC body will never corrode or rust.
•Corrosion resistant stainless steel bolt, wing nut and fulcrum pin.
•Replaceable seals are easily changed, and designed for long life.
Disc Seal: 1/2"thru 1"PVC Domed Cap Seal
1-1/4"thru 1-1/2"NBR Domed Cap Seal
Piston Seal: 1/2"& 3/4"NBR O-Ring Seal
1"thru 1-1/2"NBR Cup Seal
•Easy adjustable angle for liquid level control.
•Dual fulcrum pin holes allow for two positions to set the lever to accommodate different pressures and flow rates.
•Maximum operating pressure rating 100 psi.
ROD CONN. PORT QUANTITY LIST
PART NO. SIZE INLET OUTLET TAPPED SIZE CTN CASE PRICE-A
28-PFV-05 1/2"1/2"MPT 1/2"MPT 1/4"- SAE 0.50"1 192 7.38
28-PFV-07 3/4"3/4"MPT 3/4"MPT 1/4"- SAE 0.50"1 144 8.36
28-PFV-10 1"1"MPT 1"MPT 1/4"- SAE 0.75"1 120 14.27
28-PFV-12 1-1/4"1-1/4"MPT 1-1/4"MPT 3/8"- SAE 1.21"1 40 43.79
28-PFV-15 1-1/2"1-1/2"MPT 1-1/2"MPT 3/8"- SAE 1.21"1 40 39.19
A complete line of plastic, copper and stainless steel floats and brass and stainless steel float rods are available in a wide range
of sizes to accommodate all of your installation needs (sold separately).
Rev. 1.0 US
7-4
July 3/13
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
PLUG ADAPTERS
PART NO. DESCRIPTION LIST PRICE-A
28-BFVA-R434-0 1/4"- 20 SAE FEMALE X 3/8"MPT BRASS 11.88
Adapts 1/4"rod (3/8"thru 1"valves) to 3/8"MPT (8"floats)
28-BFVA-R434-11 3/8"- 16 SAE FEMALE X 3/8"MPT BRASS 12.07
Adapts 3/8"rod (1 1/4"thru 2"valves) to 3/8"MPT (8"floats)
28-BFVA-R435-5 3/8"- 16 SAE FEMALE X 1/4"- 20 SAE MALE 29.89
Adapts 3/8"rod (1 1/4"thru 2"valves) to 1/4"rod (6"& smaller floats)
FLOAT RODS
LIST
PART NO. PRICE-A THREAD SIZE LENGTH FITS VALVE
28-BFVRSS-045 2.29 1/4 - 20 SAE x 1/4 - 20 SAE 4.5"
Use to connect 3/8"thru 1"float
valves with float balls up to and
including 6"diameter
28-BFVRSS-06 7.54 1/4 - 20 SAE x 1/4 - 20 SAE 6"
28-BFVRSS-08 7.95 1/4 - 20 SAE x 1/4 - 20 SAE 8"
28-BFVRSS-10 8.43 1/4 - 20 SAE x 1/4 - 20 SAE 10"
28-BFVRSS-12 8.79 1/4 - 20 SAE x 1/4 - 20 SAE 12"
28-BFVRSS3814-10 9.76 3/8 - 16 SAE x 1/4 - 20 SAE 10"Use to connect 3/8"thru 1"float
valves with 8"or larger float balls.
Or 1 1/4"thru 2"float valves with
6"or smaller float balls.
28-BFVRSS3814-12 7.01 3/8 - 16 SAE x 1/4 - 20 SAE 12"
28-BFVRSS3814-14 7.40 3/8 - 16 SAE x 1/4 - 20 SAE 14"
28-BFVRSS3814-16 12.42 3/8 - 16 SAE x 1/4 - 20 SAE 16"
28-BFVRSS38-10 5.58 3/8 - 16 SAE x 3/8 - 16 SAE 10"
Use to connect 1 1/4"thru 2"
float valves with 8"diameter and
larger float balls.
28-BFVRSS38-12 6.60 3/8 - 16 SAE x 3/8 - 16 SAE 12"
28-BFVRSS38-14 7.18 3/8 - 16 SAE x 3/8 - 16 SAE 14"
28-BFVRSS38-16 8.00 3/8 - 16 SAE x 3/8 - 16 SAE 16"
Male SAE x Male SAE threads
STAINLESS STEEL FLOATS
•AISI 304 Stainless Steel
•Suitable for use in corrosive fluids where high pressure or extreme temperatures may exist
PART FLOAT BUOYANCY FEMALE SPUD WEIGHT LIST
NO. DIAMETER IN LBS CONNECTION LBS PRICE-A
28-BFVF-S3 3"0.21 1/4 - 20 SAE 0.19 48.45
28-BFVF-S4 4"0.65 1/4 - 20 SAE 0.44 80.55
28-BFVF-S5 5"1.55 1/4 - 20 SAE 0.81 92.74
28-BFVF-S6 6"2.15 1/4 - 20 SAE 1.19 157.46
28-BFVF-S8 8"6.50 3/8 - 16 SAE 1.81 244.06
COPPER FLOATS
•Two float halves soldered together using an inside lapping joint
•For open tank service only
PART FLOAT BUOYANCY FEMALE SPUD WEIGHT LIST
NO. DIAMETER IN LBS CONNECTION LBS PRICE-A
28-BFVF-C3 3"0.34 1/4 - 20 SAE 0.19 56.74
28-BFVF-C4 4"0.80 1/4 - 20 SAE 0.38 52.22
28-BFVF-C5 5"1.73 1/4 - 20 SAE 0.56 75.14
28-BFVF-C6 6"3.26 1/4 - 20 SAE 0.69 94.79
28-BFVF-C8 8"8.03 3/8"FPT 1.94 292.48
Note: It is not recommended to use less than an 8"diameter float with 1 1/4"to 2"valves. Due to a lack of buoyancy - 6"& smaller floats
can be used where inlet pressure is very low.
US Rev. 1.0
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
7-5
December 10/12
PLASTIC FLOATS
•Polypropylene •Corrosion resistant
•Lightweight •Up to 175◦F (79◦C)
•For open tank service only
PART FLOAT BUOYANCY FEMALE SPUD WEIGHT LIST
NO. DIAMETER LBS / CU.FT CONNECTION LBS PRICE-A
28-BFVF-P5 *5"1.2 1/4 - 20 SAE 0.18 6.64
28-BFVF-P6 *6"3.4 1/4 - 20 SAE 0.29 21.76
28-BFVF-P8 *8"8.4 1/4 - 20 SAE 1.00 31.47
*Float rod connection is not factory threaded, the smooth hole is designed for easy self-tapping by
threading the metal float rod into the blind hole.
BLACK ECONOMY PLASTIC FLOATS
•Polyethylene •Good abrasive resistance
4.5"Black Plastic Float
•Good impact resistance •Up to 150◦F (65◦C)
•Excellent corrosive resistance
FEMALE SPUD LIST
PART NO. DESCRIPTION CONNECTION PRICE-A
28-BFVF-PL4.5 *4.5"Black Plastic Float 1/4"- 20 SAE Female 1.26
28-BFVF-PL5 *5"Black Plastic Float 1/4"- 20 SAE Female 1.80
28-BFVF-PL6 *6"Black Plastic Float 1/4"- 20 SAE Female 3.66
28-BFVF-PL8 ♦8"Black Plastic Float 3/8"- 16 SAE Female 8.69
28-BFVF-PL10 ♦10"Black Plastic Float 3/8"- 16 SAE Female 9.41
NOTE: These units should not be used in applications that require them to be fully submersed.
For those applications, use Series 28-BFVF-P.
*Float rod connection is not factory threaded, the smooth hole is designed for easy self-tapping
by threading the metal float rod into the blind hole.
♦Floats have a threaded brass insert rod connection
FLOAT VALVE PARTS
LEVER ASSEMBLY PLUNGER ASSEMBLY REPL. SEAL KIT
PART NO. LIST PRICE-A PART NO. LIST PRICE-A PART NO. LIST PRICE-A
28-BFVP-LA0310 15.48 28-BFVP-PA0305 5.53 28-BFVP-SK0305 0.51
(For 3/8"- 1"Float Valve) (For 3/8"- 1/2"Float Valve) (For 3/8"- 1/2"Float Valve)
28-BFVP-PA07 8.55 28-BFVP-SK07 0.77
(For 3/4"Float Valve) (For 3/4"Float Valve)
28-BFVP-PA10 11.22 28-BFVP-SK10 0.61
(For 1"Float Valve) (For 1"Float Valve)
28-BFVP-LA1220 13.71 28-BFVP-PA1220 21.21 28-BFVP-SK1220 0.96
(For 1 1/4"- 2"Float Valve) (For 1 1/4"- 2"Float Valve) (For 1 1/4"- 2"Float Valve)
3/8"To 1"1 1/4"To 2"3/8"& 1/2"3/4"& 1"1 1/4"To 2"
PLASTIC JET PUMP AIR CONTROL
•Air volume control for jet systems that cures waterlogged tanks
AVC-P
•Positive action control - Simple in construction
•No flexing diaphragm or metal springs
•Will operate on as little as 5” of vacuum
•Molded from space age technology plastics - cannot corrode in moist environment
•Fits all size tanks up to and including 82 gallon - may be easily manifolded for larger size tanks
CASE LIST
PART NO. DESCRIPTION QTY PRICE-A
AVC-P Air Control 25 19.66
AVC-PK Air Control Installation Package 12.19
Contains:
•4 ft. Poly Tubing
•(2) 1/4"MIP x 1/4"Barb Brass Adapters
AVC-PKC Air Control Package 25.84
Contains:
•Air Control and Installation Package
Rev. 1.0 US
7-6
May 16/14
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
AIR VOLUME CONTROLS
SHALLOW WELL CONTROL
•Comes complete with 48” of 1/4” poly tubing and brass mini barb adapters
•Housing is tapped with a 1/4” FPT pressure gauge port
PART MANUFACTURER TANK WEIGHT QUANTITY LIST
NO. CONN. LBS CTN CASE PRICE-A
•Zinc die-cast housing with sealed plastic float mounted on solid brass rod
AVC-SW BOSHART INDUSTRIES 1-1/4"MPT 1.0 1 50 22.00
AVC-L AMETEK 1-1/4"MPT 1.0 1 50 57.55
AVC-SW AVC-L
NOTE: GAUGE IS SOLD SEPARATELY
DEEP WELL AIR RELEASE
•Housing is tapped with a 1/4” FPT pressure gauge port
PART MANUFACTURER TANK WEIGHT QUANTITY LIST
NO. CONN. LBS CTN CASE PRICE-A
•Durable plastic housing with sealed plastic float mounted on solid brass rod
AVC-DWP BOSHART INDUSTRIES 1-1/4"MPT 0.4 1 50 18.41
AVC-PENN-WJ PENN 1-1/4"MPT 0.4 1 50 31.97
AVC-DWP AVC-PENN-WJ
NOTE: GAUGE IS SOLD SEPARATELY
DEEP WELL WITH ADJUSTABLE MINIMUM AIR RELEASE
•Minimum pressure air release valve is factory set @ 25psi, Adjustable range is 0 - 40psi
•Housing is tapped with a 1/4” FPT pressure gauge port
PART MANUFACTURER TANK WEIGHT QUANTITY LIST
NO. CONN. LBS CTN CASE PRICE-A
•Zinc die-cast housing with sealed plastic float mounted on solid brass rod
AVC-DW-AR BOSHART INDUSTRIES 1-1/4"MPT 1.0 1 50 24.02
AVC-WJ AMETEK 1-1/4"MPT 1.0 1 50 54.29
•All plastic construction
AVC-AE10 *1-1/4"MPT 1.0 50 23.41
AVC-DW-AR AVC-WJ AVC-AE10*
NOTE: GAUGE IS SOLD SEPARATELY *NOT 3RD PARTY CERTIFIED TO NSF/ANSI 372
US Rev. 1.0
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
7-7
May 16/14
USAGE RECOMMENDATIONS
PRESSURE SYSTEM RANGE
TANK SIZE 20-40 PSI 30-50 PSI 40-60 PSI
Thru 42 Gallons AV30 / AVC45 / AV45 AV42 / AVC45 / AV45 AV42 / AVC45 / AV45
70 Gallons AV42 / AVC100 / AV100 AV80 / AVC100 / AV100 AV80 / AVC100 / AV100
80 Gallons AV100 / AVC100 AV100 / AVC100 AV100 / AVC100
120 Gallons AV80 / AVC100 AV120 AV120
AV100 / AVC100 AV100 / AVC100 AV100 / AVC100
220 Gallons AV120 AV120 AV120
NON-REPAIRABLE AIR VOLUME CONTROL
•Ensure proper water pressure •Prolong pump life by reducing cycling frequency
•Maximum working pressure not to exceed 100 PSI •Zinc-electroplated steel construction
TANK PUMP QUANTITY LIST
PART NO. CONNECTION CONNECTION CTN CASE PRICE-A
AVC45 1/4"NMPT 1/4"Male Compression Thread 1 20 8.95
AVC100 3/8"NMPT 1/4"Male Compression Thread 1 20 8.95
BRADY NON-REPAIRABLE AIR VOLUME CONTROLS
•Maximum working pressure not to exceed 100 PSI •Zinc-electroplated steel construction
•AV100 Incorporates a ball check valve so it can be universally used on tank sizes from 12 to 120 gallons and function
properly with a minimum amount of vacuum or in areas where high water tables may be a problem
•AV45 Brass spring and orifice
PART TANK PUMP CASE LIST
NO. CONNECTION CONNECTION QTY PRICE-A
AV45 1/4"MPT 1/4"Male Compression Thread 20 POR
AV45F 1/4"MPT 1/8"Female Pipe Thread 20 POR
AV100 3/8"MPT 1/4"Male Compression Thread 20 POR
AV100F 3/8"MPT 1/8"Female Pipe Thread 20 POR
BRADY REPAIRABLE AIR VOLUME CONTROLS
•Maximum working pressure not to exceed 100 PSI
AV30 AV42, 80 & 120 style
•Zinc-die cast construction
•Buna-N diaphragm
•Reduces cycling frequency
•Can be used on jet, centrifugal & rotary pumps
PART TANK PUMP CASE LIST
NO. CONNECTION CONNECTION QTY PRICE-A
AV30 1/4"MPT 7/16"- 24 THD 42 POR
AV42 1/4"FPT 1/4"FPT 20 POR
AV80 1/4"FPT 1/4"FPT 18 POR
AV120 1/4"FPT 1/4"FPT 14 POR
BRADY A.V.C. REPAIR KITS
Kit includes: diaphragm, springs, screws, nuts, ball and seal which are needed for a quick and simple repair job.
PART NO LIST PRICE-A PART NO LIST PRICE-A
AV-30-3A 26.85 AV-80-3A 36.85
AV-42-3A 29.16 AV-120-3A 48.97
BRADY A.V.C. INSTALLATION KIT
•KIT INCLUDES:
(2) Fitting No. 75-1/8 1/4"Barb x 1/8"MPT Plastic Fitting
(2) Fitting No. 75-1/4 1/4"Barb x 1/4"MPT 90 Elbow Plastic Fitting
(1) Fitting No. 78E 1/4"Barb x 7/16"Compression Elbow Plastic Fitting
(1) 4’ of Polyethylene Tubing 1/4"I.D. x 3/8"O.D.
•A fitting attaches to suction side of pump for air volume control use and to pressure side of pump for pressure switch use or
the second fitting attaches to pump side of AV-42, AV-80 and AV-120 air volume controls for air volume control use. For
pressure switch installation, it attaches to pressure switch and pressure side of pump.
PART NO. QTY LIST PRICE-A
AVC-UK1 50 21.70
Rev. 1.0 US
7-8
December 31/12
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
NO LEAD FLOW CONTROLS
APPLICATIONS:
•Save... Water, Energy & Money!
•Ideal for Potable Water Wells (regulating pumps on low yielding wells),
Water Purification, Water softener, Electronic faucet, Tank-less water heater
Geothermal equipment, Irrigation, Distributing machine and General industrial use.
FEATURES:
•NSF/ANSI 61 & NSF/ANSI 372 certified by CSA International
•Maintain a defined flow rate (tolerance is +/- 15%) regardless of pressure
variations of the supply line (usually 0 to 125 PSI).
•Precise flow control improves system performance and in the case of plumbing
systems, it provides comfort of use at low pressure as well as water and
energy saving at high pressure (125 PSI).
CONSTRUCTION RATING:
•Nickel Plated, No lead brass housing
•EPDM O-ring
•Clear water only
•Acetal (celcon R
) orifice
•Service Temp: 90◦F (32◦C)
•Max Pressure: 125 PSI (861 kPa) •Max Temp: 150◦F (65◦C)
•To order add Flow Rate to Part No. eg. FC-A0.13
PART NO. INLET/OUTLET LENGTH AVAILABLE FLOW RATES LIST PRICE-A
FC-A 3/8"FNPT 1.75"0.13, 0.19, 0.25, 0.35, 0.50, 0.75, 1.00, 1.30, 20.42
1.50, 1.75, 2.00, 2.50, 3.00, 4.00
FC-B 1/2"FNPT 1.94"0.25, 0.50, 0.75, 1.00, 1.30, 1.50, 1.75, 2.00, 23.74
2.50, 3.00, 3.50, 4.00, 4.50, 5.00, 6.00, 7.00
FC-C 3/4"FNPT 2.28"1.00, 1.30, 1.50, 1.75, 2.00, 2.50, 3.00, 3.50, 31.43
4.00, 4.50, 5.00, 6.00, 7.00, 8.00, 9.00,
10.00, 13.00, 15.00, 20.00, 25.00, 30.00
FC-X 1"FNPT 2.75"1.00, 1.50, 2.00, 2.50, 3.00, 3.50, 4.00, 4.50, 50.46
5.00, 6.00, 6.50, 7.00, 8.00, 9.00, 10.00,
12.00, 13.50, 15.00, 20.00, 25.00, 30.00
FC-Y 3/4"MNPT x FNPT 1.50"1.00, 1.50, 2.00, 2.50, 3.00, 3.50, 4.00, 5.00, 43.07
6.00, 7.00, 8.00, 9.00
FC-P 1-1/4"MNPT 3.00"3.00, 4.00, 5.00, 6.00, 6.50, 7.00, 8.00, 9.00, 96.50
10.00, 12.00, 13.00, 13.50, 15.00, 20.00, 25.00,
30.00
FC-T 1-1/2"MNPT 3.00"5.00, 6.00, 6.50, 7.00, 8.00, 9.00, 10.00, 12.00, 106.83
13.00, 13.50, 15.00, 20.00, 25.00, 30.00
FC-F 2"MNPT 3.00"10.00, 12.00, 13.00, 13.50, 15.00, 20.00, 25.00, 175.76
30.00
FC-H 2-1/2"MNPT 4.00"30.00, 35.00, 40.00, 45.00, 50.00, 55.00, 60.00, 396.33
65.00, 70.00, 75.00, 80.00, 85.00, 90.00
FC-K 3"MNPT 4.00"30.00, 35.00, 40.00, 45.00, 50.00, 55.00, 60.00, 413.56
65.00, 70.00, 75.00, 80.00, 85.00, 90.00, 95.00,
100.00, 105.00, 110.00, 115.00, 120.00
•Additional flow rates may be available. Please contact your Inside Sales Representative for availability.
•Also available in 316 SS
•Models A,B,C, and X are also available with a union connection
US Rev. 1.0
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
7-9
January 3/14
DOLE FLOW CONTROLS
•Self Cleaning
•Delivers a constant volume of water flow output over a wide pressure drop range
•Flexible orifice varies effective area inversely to the applied pressure
•At pressures below threshold point, flexible insert acts as a fixed orifice
•Above threshold point, insert begins to reduce orifice area maintaining desired flow output
•Flow rates maintained to within ±15% up to pressure drops of 125 psi
•Flow rate varies due to tolerances and water temperatures
•Used, where possible, in flow regulators with flow rates between 1 US GPM and 4 US GPM
•Nickel Plated Brass Housing
•To order add Flow Rate to Part No. eg. FCGA-.35NL
PART NO. CONNECTION HEX SIZE LENGTH AVAILABLE FLOW RATES LIST PRICE-A
FCGA- NL 3/8 X 3/8 FPT 7/8"1 3/4".125, .1875, .25, .35, .5, .75, 1 28.09
FCGB- NL 1/2 X 1/2 FPT 1"2"1, 1.5, 2, 2.5, 3, 3.5, 4, 5, 6 32.66
FCGC- NL 3/4 X 3/4 FPT 1-1/4"2-1/4"1, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 6, 7, 8,
9, 10, 11.5
43.21
FCGY- NL 3/4 M X 3/4 F 1-1/4"1-1/2"1, 1.5, 2, 2.5, 3, 3.5, 4, 5, 6, 7, 8, 9, 10 59.12
FCGX- NL 1 X 1 FPT 1-1/2"2-3/4"1, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5, 6, 7,
8, 9, 10, 12, 13.5, 15, 20, 25, 30
69.44
•Zinc Plated Steel Housing
•To order add Flow Rate to Part No. eg. FCGH-30NL
PART NO. CONNECTION HEX SIZE LENGTH AVAILABLE FLOW RATES LIST PRICE-A
FCGP- NL 1-1/4 X 1-1/4 MPT 1-5/8"3"2, 2.5, 3, 3.5, 4, 5, 7, 8, 9, 10, 12, 13.5,
15, 20, 25, 30
125.86
FCGT- NL 1-1/2 X 1-1/2 MPT 1-13/16"3"1, 1.5, 2, 2.5, 3, 3.5, 4, 5, 6, 7, 8, 9, 10,
12, 13.5, 15, 20, 25, 30
139.42
FCGF- NL 2 X 2 MPT 2-3/8"3"10, 11.5, 12, 13.5, 15, 20, 25, 30 237.71
FCGH- NL 2-1/2 X 2-1/2 MPT 2-7/8"4"30, 35, 40, 45, 50, 55, 60, 65, 70, 75,
80, 85, 90
526.80
FCGK- NL 3 X 3 MPT 3-1/2"4"30, 35, 40, 45, 50, 55, 60, 65, 70, 75,
80, 85, 90, 95, 100, 105, 110, 115, 120
547.71
Rev. 1.0 US
7-10
January 3/14
BOSHART INDUSTRIES
Telephone: 1-519-595-4444 - Toll Free: 1-800-561-3164
Fax: 1-519-595-4380 - www.boshart.com
US Rev. 1.0

Navigation menu
