Item # 801218, KT3X-1UL
List Price $82.51
KT3X-1UL
The HARTELL KT3 series condensate pumps have been manufactured to meet the demand for high quality, high
performance, condensate removal pumps. High torque motors, reliable switch assemblies, and full-flow check valves
transform a solid design into an outstanding pump with a three year warranty.
The KT3, the newest member of the KT series condensate pump family, is the first to offer a three year warranty. The KT3
uses a double splash protected motor with five times more starting torque than a standard motor. This provides the power
needed to start the pump even after seasonal shut downs. An innovative cam-action switch/float assembly allows a "drink"
nearly twice the standard volume without increasing outside dimensions. This large drink means the KT3 cycles less
often. A new, integral, full-flow check valve virtually eliminated blocked pump discharge.
The KT3 has the following features :
• Thermally protected 115 or 230 VAC 3000 rpm motor with stainless steel shaft.
• Suitable for gas condensing furnace application.
• Capped inlet : 1" and 1-3/8"
• Outlet: Barbed for 3/8" ID tubing.
• Factory installed full-flow check valve.
Tested by UL to US and Canadian safety standards.
SPECIFICATIONS
Model KT3X-1UL
Voltage 115 V
Current 1.7 A
Motor Speed 3000 rpm
Check Valve Integral
Flow Rate at Lift of 6' 155 gal/h
Flow Rate at Lift of 12' 120 gal/h
Flow Rate at Lift of 18' 50 gal/h
Cord and Plug 6 ft
Auxiliary Switch Yes
Capped Inlet
1 inches
1 3/8 inches
Barbed Outlet 3/8 inches
Shut off 18.5 ft
20' Tubing No
2/17/2014 | Page 1 of
2
Unit Dimensions (W x D x H) 1 9.25" x 5.50" x 8.5"
Width 9.25 inches
Depth 5.50 inches
Height 8.5 inches
Weight 6 lb
Head Size 18.5 ft
Reservoir 3 quart
Max. Temperature 110 ºF
Mast. Ctn. 6 pcs.
1 Width at mounting is 11.25 inches
