Item # 801035, KT-15-1UL

List Price $72.07

KT-15-1UL

The HARTELL KT-15 series condensate pumps are manufactured to meet the demand for high quality, standard

performance, condensate removal pumps. These pumps are warranted for one year and provide reliable operation in the

vast majority of HVAC applications.

The standard of condense pumps. The KT-15 will provide years of trouble free service. With 15' maximum lift, nearly all

installations can be managed with this pump. A high impact, corrosion resistant, ABS plastic reservoir combined with a

stainless steel motor shaft makes this pump ideal for gas condensing furnace application.

The KT-15 has the following features :

• with stainless steel shaft.

• Suitable for gas condensing furnace application.

• Full-flow check valve included.

• 1 year warranty.

NOTE: Picture shows pump models with an "X" in the model # which includes 2 yellow wires for safety auxiliary switch.

SPECIFICATIONS

Model KT-15-1UL

Current 1.3 A

Voltage 115 V

Motor Speed 3000 rpm

Check Valve Integral

Head Size 15 ft

Flow Rate at Lift of 6' 118 gal/h

Flow Rate at Lift of 12' 68 gal/h

Auxiliary Switch No

Capped Inlet

1 inches

1 3/8 inches

Barbed Outlet 3/8 inches

Cord and Plug 6 ft

Shut off 15 ft

20' Tubing No

2/17/2014 | Page 1 of

2

Unit Dimensions (W x D x H) 9.25" x 5.50" x 8.25"

Width 9.25 inches

Depth 5.50 inches

Height 8.25 inches

Weight 6 lb

Reservoir 3 quart

Max. Temperature 110 ºF

Mast. Ctn. 6 pcs.
