Item # 851117, A2X-1965 Plenum Rated Pump

A2X-1965 Plenum Rated Pump

 UL 2043 Plenum Rated

 Dual Voltage Commercial Grade Condensate Pump

 Heavy Duty Cast Aluminum Reservoir

 Dual Voltage Thermally Protected Motor

 Stainless Steel Motor Shaft

 Replaces KESCO 1965

PLENUM RATED*

*Hartell’s Model A2-X-1965 DV has been tested to, and yielded results that fell within the acceptance criteria of UL

Standard 2043, Third Edition, “Fire Test for Heat and Visible Smoke Release for Discrete Products and Their Accessories

Installed in Air-Handling Spaces.”

SPECIFICATIONS

Model

A2-X-1965

Voltage

115 V

230 V

Inlet (ID)

1 3/8 inches

Outlet Size

3/8 inches

Outlet Connection Type

FNPT

Motor Power at 3000 rpm

1/10 hp

Motor Speed

3000 rpm

Cord and Plug

No cord &plug, wire leads only ft

Auxiliary Switch

Yes

20' Tubing

No

Unit Dimensions (W x D x H)

6" x 9" x 10"

2/17/2014 | Page 1 of 2

Width

6 inches

Depth

9 inches

Height

10 inches

Flow Rate at Lift of 6'

185 gal/h

Flow Rate at Lift of 12'

139 gal/h

Flow Rate at Lift of 18'

79 gal/h

Flow Rate at Lift of 20'

51 gal/h

Weight

14 lb

Reservoir

1 gal

Shut off

22 ft

Head Size

22 ft

Max. Temperature

150 ºF

Mast. Ctn.

4 pcs.
