IPT ENGINE DRIVEN TRASH PUMPS
IPT Portable High Volume, Self-priming
Centrifugal Trash pumps come standard
with a cast iron impeller to resist abrasion
and one tool serviceability for easy
cleanout. All pumps feature aluminum
housing, cast iron wearparts, built-in
check valve, suction strainer and heavy
duty steel roll frame. Heavy duty cast iron
flanges with male NPT threads that rotates
in 90° increments. Easy access fill plug on
discharge port.
09
080706
05
0403
02
0
1
0
0
0
2
0
4
0
6
0
8
0
01
0
2
1
0
41
044004
0
6302308204
2
002061021
0
8
0
40
sei
r
e
S
X
5
S
2
=
A
sei
r
e
S
X
5
S3 =
B
0
5
0
1
51
0
2
52
0
3
5
3
0
4
]
*
.tf[
]m[
]
m
pg .S.
U
[
Total Head
m[ 3]
h/
B
A
yticap
a
C
0.1
y
ti
va
r
g ci
f
i
ceps reta
W
-
diu
qi
L
13
.2
y
b e
divi
d
,isp o
t
t
r
e
vn
o
C
)
*(
Performance of Engine Driven Self-Priming Trash Pumps
2˝ & 3˝ Engine
Driven Self-Priming
Trash Pumps
•Cast Aluminum with Cast Iron
Wearparts
•Silicon Carbide/Viton®Mechanical Seal
•EPDM/EPR O-Rings Standard with
Optional Viton®
•2˝ or 3˝ Removable Male NPT Suction
and Discharge Ports
•Discharge Rotates in 90° Increments
•Engine Options: Honda, B & S
Vanguard Gasoline or Hatz Diesel
Engines
•Easy Clean Out with One Tool
Serviceability
•Maximum Solids Handling up to 1-1/4˝
•Maximum Flow up to 290 GPM
•Maximum Head up to 125 Ft.
•Self-Priming to 26 Ft.
•Wheel Kit Optional
®
A Gorman-Rupp Company
Manufacturer of AMT & IPT Pumps
400 Spring Street • Royersford, PA 19468 USA
www.amtpump.com • 888-amt-pump (268-7867)
The Gorman-Rupp Company reserves the right to discontinue any model or change specifications at any time without incurring any obligation.
©2012 American Machine and Tool Company. All rights reserved.
ENG-14
Engine Driven Self-Priming Trash Pumps
0613
2" Trash Pumps
3" Trash Pumps
Model DIS* SUC* L** WH
2S5X Series 2 2 24.0 [60.9] 19.5 [49.5] 19.9 [50.5]
3S5X Series 3 3 24.0 [60.9] 19.5 [49.5] 19.9 [50.5]
3
Model* Seal Type &
Elastomer/Faces Mounting
2S5X 40
3S5X 45
Model A
Gas - 2S5X/3S5X 7.4 [18.7]
Diesel - 2S5X/3S5X 7.9 [20.0]
5/8" Threaded Pump Kit - Cast Aluminum
Ship Wt.
(Lbs.)
Viton® / SIC-SIC Handle
Handle
Viton® / SIC-SIC
(*) Standard NPT (Male) Pipe Thread.
(**) This dimension may vary due to engine manufacturer’s specifications.
NOTE: Dimensions are in inches (centimeters) and have a tolerance of ± 1/8". *Does not include roll cage or engine, unassembled
Standard Features
• Cast Iron Impeller
• One Tool Serviceability Tool Included with
Engine Driven Models
• Silicon Carbide Mechanical Seal with Graphite
Impregnated Seat and Viton®Elastomers
• Heavy Duty Steel Roll Frame and Strainer
Included
• Built-in EPDM/EPR Check Valve
• Removable/Replaceable Cast Iron
Suction/Discharge Ports
• Discharge Port Rotates in 90° Increments
• Choice of Honda, B & S Vanguard Gasoline or
Hatz Diesel Engine
• Vibration Dampening Feet
• Maximum Temperature 180° F
• Optional Viton®O-ring / Check Valve
Available
• Pedestal Version Available
• Optional Wheel Kit Available
• QSP – Quick Ship Pumps for Many Models
Viton® / SIC-SIC
Viton® / SIC-SIC
Viton® / SIC-SIC
3S5XAR B1.30.87/3.3100
3S5XHR B2.50.82/3.1100
3S5XZR B2.70.79/3.0120
M
Maximum Solids Handling Capacity:
1¼" Diameter
Construction: Cast Aluminum with Cast Iron Components
(♦) HP Class represents market category and is not intended to define actual horsepower.
▲ Oil Alert Included
M
Model Curve
5 HP
5 HP
5 HP
HP Class♦Port Driver Seal
Run Time
(Hours)
Tank Size
(Gal/Ltr.)
Ship Wt.
(Lbs.)
3" NPT
3" NPT
3" NPT
B & S Vanguard▲
Honda GX160▲
Hatz Diesel 1B20
2S5XAR AViton® / SIC-SIC
Viton® / SIC-SIC
Viton® / SIC-SIC
1.3 0.87/3.3 90
2S5XHR A2.00.82/3.190
2S5XZR A2.70.79/3.0115
M
Maximum Solids Handling Capacity: 1" DiameterConstruction: Cast Aluminum with Cast Iron Components
(♦) HP Class represents market category and is not intended to define actual horsepower.
Model Curve
5 HP
5 HP
5 HP
HP Class♦Port Driver Seal
Run Time
(Hours)
Tank Size
(Gal/Ltr.)
Ship Wt.
(Lbs.)
2" NPT
2" NPT
2" NPT
B & S Vanguard▲
Honda GX160▲
Hatz Diesel 1B20
