COMPONENTS FOR FULLY ASSEMBLED
WASTEWATER PACKAGES
Ribbed 23" x 30" Basin
Roll Top 18" x 30" Polyethylene Basin
PS Series Pumps
WW05 Series Vortex Pumps
GWP2_ with WW05 PumpGWP1_ with PS Pump
GWP
PLUMBER'S WASTEWATER PACKAGE SYSTEMS
TECHNICAL BROCHURE
BGWP1&2
PAGE 2
Wastewater
Goulds Water Technology
GWP1_ with PS Pump
A9-2PH
A9-2P
GWP1 ––– COMPONENTS Replacement Part Number
• Ribbed polyethylene basin 23" x 30" A7RP2330
(uses 18" diameter cover)
• Structural foam 18" diameter cover assembly A8SF18
(includes bolts, seal tape, cord grommet and
(1) 3" and (2) 2" grommets)
• Swing style check valve (2 choices)
• 2" Compression type A9-2P
• 2" Full ow rubber sleeve style A9-2PH
• Sch 40 PVC discharge pipe 2"D x 30"L ADP2030
• Ribbed basin 23" torque stop insert ATS23
• Vent and discharge grommets
*(to purchase separately from cover assembly)
• 2" (pipe) x 4" (cover hole) grommet *A8-24U
• 3" (pipe) x 4" (cover hole) grommet *A8-3U
PAGE 3
Wastewater
Goulds Water Technology
GWP2_ with WW05 Pump
A9-2PH
A9-2P
GWP2 ––– COMPONENTS Replacement Part Number
• Roll Top Polyethylene Basin 18" x 30" A7PE1830
• Structural foam 18" Dia. cover assembly A8SF18
(includes bolts, seal tape, cord grommet and
(1) 3" and (2) 2" grommets)
OR
• Steel 18" Dia. cover with epoxy coating A8ST18
(includes bolts, seal tape, cord grommet and
(2) 2" grommets)
NOTE: 3" vent not available on standard steel cover
• Swing style check valve (2 choices)
• 2" Compression type A9-2P
• 2" Full ow rubber sleeve style A9-2PH
• Sch 40 PVC discharge pipe 2"D x 30"L ADP2030
• Roll top basin 18" torque stop insert ATS18
• Inlet grommet for 18" x 30" roll top basin A8-4U
• Vent and discharge grommets
*(to purchase separately from cover assembly)
• 2" (pipe) x 4" (cover hole) grommet *A8-24U
• 3" (pipe) x 4" (cover hole) grommet *A8-3U
