brands you trust.
PROFESSIONAL PLUMBING SEV412 SERIES
Outstanding Performance
• Maximum fl ow rate to 72gpm at 11’ of head
• Maximum shutoff head of 25’
• Vortex impeller provides 2” solids handling capability
• Permanent split capacitor motor for reliable,
high performance, longer motor life, greater
starting torque, and lower amp draw
• 1/2hp 3450rpm single phase motor includes
overload protection
• Heavy duty upper and lower ball bearings are oil
lubricated for superior cooling and maximum life
Heavy Duty Materials of Construction
• Cast iron motor housing
• Cast iron pump body
• Cast iron multi-vane vortex impeller
• Stainless steel pump shaft
• Stainless steel hardware
• Buna-N O-rings
Level Control Options
• Manual operation, no control provided
• Wide angle mechanical fl oat mounted on
discharge pipe or pump body
• Snap action vertical fl oat switch mounted on
discharge pipe or pump body
• All switches utilize “piggy back” switches which
eliminates the need to pull pump to check for
switch failure.
Barnes SEV pumps combine high quality, high
performance and low cost in a rugged, heavy duty
design. Capable of handling up to 2 inch spherical
solids, the pump utilizes a vortex impeller and
a combination of cast iron and stainless steel
components to stand up to the toughest residential
sewage ejector applications.
412
EHV
412
SEV
SUBMERSIBLE NON-CLOG PUMP
Professional Plumbing
2012 Crane Pumps & Systems, Inc.
A Crane Co. Company
Printed in U.S.A.
BPPSEV - Rev. D (4/12)
Crane Pumps & Systems Canada
83 West Drive
Brampton, Ont. Canada L6T 2J6
(905) 457-6223
Fax (905) 457-2650
Crane Pumps & Systems
420 Third Street
Piqua, Ohio 45356
(937) 778-8947
Fax (937) 773-7157
www.cranepumps.com
A Crane Co. Company
brands you trust.
SEV Series
TOTAL HEAD
mft
10
20
30
40
50
2
4
6
8
10
12
14
12 3 4 5 6 7
12010080604020
U.S. gpm
L/s
3450RPM
60Hz
Design Features
1. 2” NPT outlet connection
2. Proven cord entry design prevents leakage
3. Heavy duty industrial Type 21 silicon carbide seal
4. 1/2hp motor for effi cient and reliable
effl uent pumping
5. Motor capacitor provides high start torque
6. Corrosion-resistant cast iron construction
7. Vortex impeller and generous casing volute easily
pass up to 2” solids.
8. Oil-lubricated ball bearings provide
maximum life
9. Stainless steel lifting handle with rubber grip
10. Standard 20’ cord length
®
C US
1
2
3
4
5
6
7
8
8
9
10
Available Models
• SEV412
manual unit, no control provided
• SEV412A
furnished with mechanical fl oat for pipe mount
• SEV412VF
furnished with vertical fl oat for pipe mount
• SEV412AT
furnished with mechanical fl oat tethered to pump
• SEV412VFT
furnished with vertical fl oat mounted to pump
