Seal bearing assembly
file no: 10.14
date: february 2014
supersedes: 10.14
date: december 2013
solution outline
more choice
more value
For Servicing three-piece circulators, your
choice of replacement parts can make a
big dierence for you and your customers.
The Armstrong Seal Bearing Assembly and
Replacement Pump Shaft Bearing module
now give you more options and helps you
make the most of your service opportunities.
More value to build your sales
with optional maintenance-
free ball bearing design
Faster service calls – the
re-designed 5 Series sba
makes on-site service easier
tm
building a successful service
business is huge challenge.
Focusing on service excellence,
creating value for customers and at
the same time controlling your costs
can make every-day operating
decisions seem impossible.
leading
maintenance
solutions
With the right replacement parts solu-
tion for three-piece circulators, you
can add more customer value by
migrating installations to the Armstrong sba
platform. You can also reduce on-site service
time to make your service calls more profit-
able. Lastly, with the Armstrong sba, you
can minimize your inventory costs by stock-
ing parts that are compatible with multiple
pump designs and sizes.
Now, with the new maintenance-free ball bearing op-
tion, the Armstrong Seal Bearing Assembly gives you
more choice and even more flexibility for serving your
customers.
For replacement parts to help you service three-piece
circulators in the field, you can't beat the Armstrong
Universal Seal Bearing Assembly. When you install the
time-tested Armstrong sba, your customers get great
value and numerous benefits.
key benefits
Safer solutions for facility
and service personnel
The reliability of a durable
long-term solution
A choice of models to suit
your customers installation/
operation
Certainty of long service life
without maintenance
Faster on-site service/
replacement
An easily serviceable unit using
a universal module
A choice between the long-
standing sleeve bearing design
or the maintenance-free ball
bearing design
Compatibility with Bell &
Gossett three-piece circulators
as well as Armstrong s25 – s57,
h32 – h 54 and 1050 circulators
A new, improved design for #5
model oering easier access
to the coupler, while provid-
ing osha compliant protection
from rotating elements.
A premium quality silicon
carbide seal is standard
the Armstrong Universal Seal
Bearing Assembly design oers
features you won't see on any
other circulator repair solution. With the
Armstrong sba you’re getting:
key features
maintenance
FREE
maintenance
FREE
now available
The new
universal
module is
compatible
with the
installed
base of
Armstrong
SBAs
bangalore
+91 (0) 80 4906 3555
manchester
+44 (0) 8444 145 145
buffalo
+1 716 693 8813
toronto
+1 416 755 2291
shanghai
+86 21 3756 6696
birmingham
+44 (0) 8444 145 145
tm
For more information, contact your
Armstrong representative or visit
us at:
ArmstrongFluidTechnology.com/
ContactUs
armstrongfluidtechnology.com
armstrong fluid technology
established 1934
sba cross reference information
File no: 10.xxx
Date: xxxx xx, 2013
Supersedes: new
Date: new
S&H SERIES
|
SEAL BE ARING ASSEMBLY
|
C R O S S REFERENCE CHAR T
pump model numbers seal bearing assembly part number armstrong module/ kit (+)
armstrongbell &
gosset
armstrong
sleeve bearing
sba
b&g sleeve
bearing sba
armstrong
maintenance
free sba
b&g
maintenance
free sba
sleeve
design
maintenance
free design
S-25 O #100 O810119-001 118844LF/
189134LF 810119MF-001 n/a
816999-041 816999MF-041
S-25 1 #100 1810119-001 118844LF/
189134LF 810119MF-001 n/a
S-25 1N #100 1N 810119-001 118844LF/
189134LF 810119MF-001 n/a
S-25 1K #100 1K 810119-001 118844LF/
189134LF 810119MF-001 n/a
S-35 12"
816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
816999-041 816999MF-041
816023-001(*) 189120-29/
189131816023MF-001(*) n/a
H-32 1HV 1816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
H-32 1N HV 1N 816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
H-32 1K HV 1K 816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
S-45 2K 2K 816027-002189105LF 816027MF-002 n/a
816999-041 816999MF-041
S-45 3LD3 816027-002189105LF 816027MF-002 n/a
S-46 HD3 816027-002189105LF 816027MF-002 n/a
H-41 1 PR 816027-002189105LF 816027MF-002 n/a
S-55 PD-35 816032-000186863/
186863LF 816032MF-000 n/a
816999-041 816999MF-041
S-57 PD-37 816032-000186863/
186863LF 816032MF-000 n/a
H-51 601 816032-000186863/
186864816032MF-000 185332LF
H-52 602 816032-000186863/
186864816032MF-000 185332LF
H-53 603 816032-000186863/
186864816032MF-000 185332LF
H-54 615 816032-000186863/
186864816032MF-000 185332LF
ar m s tr o ng flu i dt ec h no lo g y.com
ar m s tr ong flu i d t ec h no lo g y
established 1934
notes:
(+) Armstrong module/kit are not interchangable to b&g Pump or sba.
(*) Replacement for b&g 2-3 series only.
Disclaimer: This cross reference is a guide only. Use individual technical data sheet for correct
comparison.
File no: 10.xxx
Date: xxxx xx, 2013
Supersedes: new
Date: new
S&H SERIES
|
SEAL BE ARING ASSEMBLY
|
C R O S S REFERENCE CHAR T
pump model numbers seal bearing assembly part number armstrong module/ kit (+)
armstrongbell &
gosset
armstrong
sleeve bearing
sba
b&g sleeve
bearing sba
armstrong
maintenance
free sba
b&g
maintenance
free sba
sleeve
design
maintenance
free design
S-25 O #100 O810119-001 118844LF/
189134LF 810119MF-001 n/a
816999-041 816999MF-041
S-25 1 #100 1810119-001 118844LF/
189134LF 810119MF-001 n/a
S-25 1N #100 1N 810119-001 118844LF/
189134LF 810119MF-001 n/a
S-25 1K #100 1K 810119-001 118844LF/
189134LF 810119MF-001 n/a
S-35 12"
816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
816999-041 816999MF-041
816023-001(*) 189120-29/
189131816023MF-001(*) n/a
H-32 1HV 1816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
H-32 1N HV 1N 816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
H-32 1K HV 1K 816549-091/
810119-003
189165LF/
189166LF
816549MF-091/
810119MF-003 n/a
S-45 2K 2K 816027-002189105LF 816027MF-002 n/a
816999-041 816999MF-041
S-45 3LD3 816027-002189105LF 816027MF-002 n/a
S-46 HD3 816027-002189105LF 816027MF-002 n/a
H-41 1 PR 816027-002189105LF 816027MF-002 n/a
S-55 PD-35 816032-000186863/
186863LF 816032MF-000 n/a
816999-041 816999MF-041
S-57 PD-37 816032-000186863/
186863LF 816032MF-000 n/a
H-51 601 816032-000186863/
186864816032MF-000 185332LF
H-52 602 816032-000186863/
186864816032MF-000 185332LF
H-53 603 816032-000186863/
186864816032MF-000 185332LF
H-54 615 816032-000186863/
186864816032MF-000 185332LF
ar m s tr o ng flu i dt ec h no lo g y.com
ar m s tr ong flu i d t ec h no lo g y
established 1934
notes:
(+) Armstrong module/kit are not interchangable to b&g Pump or sba.
(*) Replacement for b&g 2-3 series only.
Disclaimer: This cross reference is a guide only. Use individual technical data sheet for correct
comparison.
