548347 1 SJE Rhombus 115 Control Panel Specifications
549050 1 Sje Rhombus 115 Control Panel Specifications 549050_1_SJE Rhombus 115 Control Panel Specifications
548367 2 Sje Rhombus 115 Control Panel Specifications 548367_2_SJE Rhombus 115 Control Panel Specifications
: Pump 548347 1 Sje Rhombus 115 Control Panel Specifications 548347_1_SJE Rhombus 115 Control Panel Specifications pdf
Open the PDF directly: View PDF
.
Page Count: 2
Single phase, simplex pump switch control.
The Model 115 control panel provides customers with a reliable means of controlling one 120, 208, or 240 VAC single phase pump
in water and wastewater installations. A pump oat switch turns the pump on and off. If an alarm condition occurs, an additional
alarm switch activates the audio/visual alarm system. Common applications include pump chambers, sump pump basins, irrigation
systems, and lift stations.
MODEL 115 Control Panel
1. Enclosure measures 8 x 6 x 4 inches (20.32 X 15.24 X 10.16 cm).
Choice of NEMA 1 (steel for indoor use), or NEMA 4X (ultraviolet stabilized
thermoplastic with removable mounting feet for outdoor or indoor use).
2. HOA Switch for manual pump control.
3. Green Pump Run Indicator Light
4. Pump Circuit Terminal Block
5. Alarm Circuit Terminal Block (mounted on circuit board).
6. Alarm Fuse (mounted on circuit board).
7. Alarm Power Indicator (mounted on circuit board).
8. Ground Lug
STANDARD ALARM PACKAGE
9. Red Alarm Beacon provides 360° visual check of alarm condition
Note: NEMA 1 style utilizes a door mounted indicator in lieu of a beacon.
10. Alarm Horn provides audio warning of alarm condition (83 to 85 decibel
rating) Note: NEMA 1 style utilizes an internally mounted buzzer in lieu of a
horn.
11. Exterior Alarm Test/Normal/Silence Switch allows horn and light to be
tested and horn to be silenced in an alarm condition. Alarm automatically
resets once alarm condition is cleared.
12. Horn Silence Relay (mounted on circuit board).
NOTE: other options available.
FEATURES
Entire control system (panel and switches) is UL Listed to meet
and/or exceed industry safety standards
Dual safety certication for the United States and Canada
Standard package includes oat switches
Complete, step-by-step installation instructions
Five-year limited warranty
PANEL COMPONENTS
PO Box 1708, Detroit Lakes, MN 56502
1-888-DIAL-SJE • 1-218-847-1317
1-218-847-4617 Fax
email: customer.service@sjerhombus.com
www.sjerhombus.com
SEE BACKSIDE FOR COMPLETE LISTING OF AVAILABLE OPTIONS.
SEE PRICE BOOK FOR LIST PRICE.
Model Shown 1151W600X
11
2
7
12 6
4
35
10
1
9
B.37
8
OPTIONAL FEATURE
34" (86.36cm) Panel Mounting Post (Factory Installed). Includes Simplex
Installation Kit (Enclosure upsized to 10" x 8" x 6" (25.4 x 20.32 x 15.24 cm).
Max. Enclosure size14" x 12" x 6" (35.56 x 30.48 x 15.24 cm)
9500064A
© SJE-Rhombus 06/16
1A Red beacon only / no audio
(must select 1E if oats included)
1C Horn only / no visual
(must select 1E if oats included)
1E Alarm oat
3A Alarm asher
3B Manual alarm reset
6A Auxiliary alarm contact, form C
8A Elapsed time meter (120V)
8B Elapsed time meter (240V)
10E Lockable latch - NEMA 4X
10E Lockable latch - NEMA 1
10P Panel Mounting Post
(Factory Installed. Includes Simplex
Install. Kit)(Encl. upsized to 10x8x6.Max 14x12x6)
11C NEMA 1 alarm panel (must select option 6A)
11D NEMA 4X alarm panel (must select option 6A)
16A 10' cord in lieu of 20' (per oat)
(Does not apply for Double Float® or Double Float® Master
pump switches)
16B 15' cord in lieu of 20' (per oat)
16C 30' cord in lieu of 20' (per oat)
16D 40' cord in lieu of 20' (per oat)
17A SJE SignalMaster® / pipe clamp l
(alarm oat only)
17E Sensor Float® Mini / pipe clamp s
(alarm oat only)
17J Sensor Float® / pipe clamp s
(alarm oat only)
19U HOA (Hand/Off Automatic) switch and pump run light through
door mounted
19X Door mounted pump run indicator
lMechanically-activated s Mercury-activated
115
MODEL
Alarm Package
Enclosure Rating
Starting Device
Pump Full Load Amps
Pump Disconnect
Float Switch Application
Options: Elapsed time meter
115 1 W 6 0 0 X 8A
CODE DESCRIPTION CODE DESCRIPTION
SAMPLE
B.38
MODEL 115
ALARM PACKAGE
0 = select options or no alarm package
1 = alarm package (includes test/normal/silence switch, fuse, red light, horn, & oat)
ENCLOSURE RATING
I = Indoor, NEMA 1 (metal)
W = Weatherproof, NEMA 4X (engineered thermoplastic)
STARTING DEVICE
2 = SJE PumpMaster® Plus pump switch (0-15 FLA)
3 = 120 VAC Double Float® pump switch (0-15 FLA)
4 = 240 VAC Double Float® pump switch (0-12 FLA)
5 = Super Single® pump switch (120V = 0-15 FLA) (208/240V = 0-12 FLA)
6 = No pump switch
7 = 120 VAC Double Float® Master pump switch (0-15 FLA)
8 = 240 VAC Double Float® Master pump switch (0-15 FLA)
PUMP FULL LOAD AMPS
0 = 0-7 FLA
1 = 7-15 FLA
PUMP DISCONNECTS
0 = no pump disconnect
4 = circuit breaker
FLOAT SWITCH APPLICATION
H or L= pump down or pump up (select 17 option)
X = no oats
OPTIONS Listed below
If additional features are required, call the factory for a quote on an Engineered Custom control panel.
