RedLionProducts.com | Hotline: 1.888.956.0000
Engine Drive Multi-Purpose EFFLUENT/SEWAGE Sump Lawn & Irrigation Clean Water
SNAP-ACTION CAST IRON SUMP/EFFLUENT PUMPS
3
THREE YEAR
APPLICATIONS
Ideal for average- to high-volume water and effluent removal in residential
spaces such as basements, laundry facilities, and crawl spaces.
FEATURES & BENEFITS
• Automatic submersible cast iron sump/effluent pump
• 1-1/2" FNPT discharge
• Integrated snap-action float switch suitable for use in narrow
basins (11" or greater)
• Solid float will never become waterlogged
• Built-in rod protection prevents float from contacting basin
• Clog-resistant design (1/2" diameter semi-solids handling)
• 10' cord
Model Item
Number UPC HP Volts Amps Discharge Cord
Length
Gallons Per Hour at Height Shut-
Off On/Off
Levels Basin
Diameter
5' 10' 15' 20' 30'
RL-33SC 14942652 0 10121 14579 5 1/3 115 5 1-1/2" FNPT 10' 3200 3000 2500 2200 - 28' On: 8 - 11"
Off: 2 - 5"
11" or
more
RL-50SC 14942653 0 10121 14580 1 1/2 115 6.5 1-1/2" FNPT 10' 4000 3420 3090 2800 1680 36' On: 8 - 11"
Off: 2 - 5"
11" or
more
Model Length Width Height Weight
(lbs)
Carton
Cubes
(cu ft)
Pallet
Quantity
Qty. per
Layer Layers
per Pallet
RL-33SC 9.75" 11" 12.75" 27.75 0.79 48 16 3
RL-50SC 10.25" 11.50" 13.75" 28.46 0.94 36 12 3
Carton Specifications
0 500 1000 1500 2000 2500 3000 3500 4000 4500
0
5
10
15
20
25
30
35
40
Capacity - US gph
Total Dynamic Head (ft)
Snap-Action Sump/Effluent Pumps
RL-33SC
RL-50SC
996508_Red_Lion_Product_Catalog_02-16.indd 37 2/11/16 7:39 AM
