Mercury to Mechanical Float Switch Conversion Chart
Mercury Pump Switches (wide angle) Mechanical Pump Switches (wide angle)
Mercury Model Start Amps Pumping Mechanical Model Alternative Start Amps Pumping
Run Amps Range Run Amps Range
Junior Super Single®40/13 120V 6.5 to 19 inches
20/8 230V
Super Single®55/15 120V 6.5 to 13.5 inches
35/12 230V
Double Float®55/15 120V 1.75 to 48 inches
35/12 230V wider ranges available
SJE MicroMaster®PLUS WS 78/13 125V 8 to 36 inches
78/13 250V
SJE PumpMaster®85/13 120V 7 to 36 inches
85/13 230V
SJE PumpMaster®PLUS 85/15 120V 7 to 36 inches
85/15 230V
Double Float®Master
78/13 120V 10 to 56 inches
78/13 240V wider ranges available
OR
Mercury Control Switches (narrow angle) Mechanical Control Switches (narrow angle)
Mercury Model Electrical Control Mechanical Model Alternative Electrical Control
Rating Differential Rating Differential
Sensor Float®5 amps .5 inches above or
120/230V below horizontal
Sensor Float®Mini 5 amps .5 inches above or
120/230V below horizontal
SJE SignalMaster®5 amps 1.5 inches above or
125/250V below horizontal
SJE MilliAmpMaster™
Low current, non-arching
1.5 or 4 inches above
down to 0.160 mA 125V
or below horizontal
SJE SignalMaster®5 amps 1.5 inches above or
125/250V below horizontal
SJE MilliAmpMaster™
Low current, non-arching
1.5 or 4 inches above
down to 0.160 mA 125V
or below horizontal
OR
OR
22650 County Highway 6 , Detroit Lakes, MN 56501
1-888-DIAL-SJE (1-888-342-5753)
Phone: 218-847-1317
Fax: 218-847-4617
©SJE-Rhombus Printed in USA 03/08 www.sjerhombus.com
NOTE: Double Float®Master Run Amps
are different than the Double Float®.
