A.Y. McDonald Mfg. Co. | P.O. Box 508 | Dubuque, IA 52004-0508 | TOLL FREE 800-292-2737 | TOLL FREE FAX 800-832-9296
pumps@aymcdonald.com | aymcdonald.com
CONTROLLING PROVISIONS: These terms and conditions supersede all previous terms
and conditions and shall control any sale by A.Y. McDonald Mfg. Co. (“Seller”). No alteration
or waiver of these terms and conditions shall be valid unless specically accepted in writing
by an authorized representative of Seller.
PRICES: Billing prices are those in effect at the time the order is shipped. All prices are
subject to change without notice. Possession of a price sheet shall not be construed as an
offer to sell. Seller reserves the right to reject any order.
TERMS: 2% 10th Prox., Net 25th (A 2% cash discount can be taken on the 10th of the
month following the shipment. The month is dened as the 26th through the 25th. For
example, a February 25th invoice is due 2% on March 10th, a February 26th invoice is due
2% April 10th, and all invoices are due net the 11th and considered past due on the 26th of
the month). Without open credit terms, payment may be required prior to shipping. A 2%
monthly service charge (or the maximum amount permitted by law) may be applied to the
balance of any past-due invoice. Buyer shall pay any necessary collection fees, including
reasonable attorney fees.
TAXES: Any sales tax, use tax, manufacturer tax, duty, or other cost imposed by any
government entity shall, at Seller’s option, be added to the purchase price and payable by
buyer. Buyer must certify any tax exemption and agree to indemnify Seller against any tax
imposed contrary to such certication.
FREIGHT: All prices are F.O.B. Seller’s factory, with full freight allowed within the contiguous
United States and Canada on the orders that qualify pursuant to the Freight Program
schedule. Seller reserves the right to select the carrier and route of shipment and to ship
at the most economical rate. All extra charges for special handling or delivery services will
be paid for by the buyer. Terms for shipment outside the contiguous United States and
Canada shall be established on a case-by-case basis.
"LIMITED WARRANTY Subject to the limitations stated herein, A.Y. McDonald Mfg. Co.
("Seller") warrants that pumps and pump accessories manufactured by Seller shall be free
from defects in material and workmanship and shall perform the services for which they
are intended when properly installed, under normal use, and under ordinary conditions,
for a period of two (2) years from the date of manufacture or one (1) year from the date of
installation, whichever is earliest. Other warranty periods may apply to certain products
noted below. This Limited Warranty does not cover or apply to water service products,
plumbing products, or high pressure gas products manufactured by Seller. Buyer must
notify Seller in writing of a potentially defective product as soon as possible, which notice
must provide the serial and model numbers of the product and a description of the potential
defect. Upon receipt of such notice, Seller shall, at its option and at its expense, examine
such product at Seller's factory or such other location as Seller shall determine. Should
Seller agree to a return of the product, buyer shall follow in every respect the packaging
and transportation instructions provided by Seller. In no case shall a product be returned
without rst obtaining the permission of Seller. If a product is proven to the satisfaction of
Seller to be defective, then Seller shall, at its option and at its expense, repair or replace
such product or reimburse buyer for the price paid by buyer for such product, and credit
will be issued to buyer to offset the expense of the return shipment to Seller for shipments
within the continental United States. The cost of shipping to buyer a repaired or replaced
product shall be paid by Seller on the same shipping terms as the original shipment of
such product to buyer. Except as stated herein, buyer shall assume all responsibility and
expense for any dismantling, removal, reinstallation, and shipping in connection with this
Limited Warranty, and no claims will be allowed for labor, shipping, materials, or other costs
incident to the repair, replacement, or return of a product.
THIS LIMITED WARRANTY IS THE ONLY WARRANTY PROVIDED BY SELLER AND
IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
SELLER'S LIABILITY IS LIMITED TO REPAIR, REPLACEMENT, OR REIMBURSEMENT
AS PROVIDED ABOVE, AND IN NO EVENT SHALL SELLER'S LIABILITY EXCEED THE
PURCHASE PRICE OF THE PRODUCT(S) INVOLVED. THIS LIMITED WARRANTY
PROVIDES THE EXCLUSIVE REMEDY AGAINST SELLER FOR CLAIMS RELATING
TO PRODUCTS, WHETHER IN CONTRACT, IN TORT (INCLUDING NEGLIGENCE),
OR UNDER ANY OTHER LEGAL THEORY, AND WHETHER ARISING OUT OF
WARRANTIES, REPRESENTATIONS, INSTRUCTIONS, OR DEFECTS FROM ANY
CAUSE. IN NO EVENT SHALL SELLER BE LIABLE FOR OR OBLIGATED TO PAY
ANY CONSEQUENTIAL, INCIDENTAL, SPECIAL, INDIRECT, OR PUNITIVE DAMAGES
OF ANY KIND.
THIS LIMITED WARRANTY EXTENDS ONLY TO BUYERS WHO PURCHASE
SELLER'S PRODUCT(S) DIRECTLY FROM SELLER ("ORIGINAL PURCHASERS"),
INCLUDING DISTRIBUTORS, WHOLESALERS, UTILITIES, AND CONTRACTORS.
THIS LIMITED WARRANTY IS NOT ASSIGNABLE OR OTHERWISE TRANSFERRABLE
BY THE ORIGINAL PURCHASER TO ANY OTHER PARTY. SELLER EXTENDS
NO WARRANTY, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, TO "CONSUMERS," AS THAT TERM IS DEFINED IN THE MAGNUSON-
MOSS WARRANTY ACT (15 U.S.C. SECTIONS 2301 ET SEQ.) AND THE REGULATIONS
PROMULGATED THEREUNDER. IN NO EVENT SHALL THE DURATION OF ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE BE LONGER THAN THE PERIOD PRESCRIBED HEREIN.
This Limited Warranty shall not apply to product failure or defect: caused by sand or
abrasive materials in water, corrosion due to aggressive waters, storm, re, wind, accident,
or similar casualty, or improper electrical supply; due to a defect in the design, engineering,
or installation of any water or other system; where the product has been modied without
the prior written authority of Seller; caused by the failure to install or use the product in
conformity with any instructions or specications provided by Seller; caused by the improper
installation, use, application, maintenance, repair, transportation, handling, or storage of
the product; caused by the fault or negligence of anyone other than Seller or any other act
or event beyond the control of Seller. Seller makes no warranties as to any products or
product parts or components that are not manufactured by Seller, and such items (including
the motors, tanks, air volume controls, and pressure switches that may be a part of the
pump system) may be warranted only to the extent of the original manufacturer's warranty,
if any. The limitations of liability contained in this Limited Warranty shall be effective without
regard to Seller's performance or failure or delay of performance under any other term or
condition of any trade customs, warranty, or other agreement. No employee, representative,
or agent of Seller, nor any other person, has authority to assume or incur on behalf of Seller
any liability, obligation, or responsibility in place of or in addition to this Limited Warranty."
The following warranty periods apply to the products noted below and are the only variations
to the above standard Limited Warranty:
Two (2) years from date of installation applies to model# 5000PVSPBU Battery Backup
Sump Pump
Three (3) years from date of installation applies to model(s)# 17035R020PC1,
17052R020PC1, 17070R020PC1, 17040C035PC2, 17062C035PC2, 17078C035PC2
Booster Pumps; 5020PUUP, 5025PTSP, 5025PVSP, 5033PVSP, 5033PVPD Sump Pumps;
5033CUEF, 5033CTEF25, 5050CUEF, 5050CTEF, 5050CTEF25, 5050CVSJ, 5050CTSJ25,
5050CTSJ, 5050CVEF, 5050CUSJ, 5050CUEF25, 5050CUSJ15, 5050CTSJ15,
5050CVSJ15, 5040CUEFH25, 5040CTEFH25, 5050CUEFH25, 5050CTEFH25
Effluent/Sewage Pumps; and 5050CTSJPAC, 5050CTSJPACSL, 5025PTSPCWB,
5050CTSSJPAC24, 5050CTSJPACSDA Package Systems.
Five (5) years from date of installation applies to model(s)# 5030CVSP, 5030CUSP,
5030CUSP25, 5030CTSP, 5033CVSP, 5033CUSP, 5033CUSP25, 5050CVSP,
5050CUSP25, 5033CVSPEZ, 5050CVPD Sump Pumps; 5030CVSPK, 5030CVSPCSK
Package Systems; 5030CVSPBUSS, 5033CVSPBUSS Side x Side Sumps; 16002-V3MPX,
16005-V3MPX Potable Water Pressure Tanks; and 16002-V3M, 16005-V3M, 16007-V3M,
16014-H4M, 16020MV4F, 16020-H4M, 16032MV4F, 16036MV4F, 16052MV5F, 16086MV5F,
16096MV5F, 16119MV5F Well Tanks.
CLAIMS: Inspect all shipments immediately upon receipt, examining products for damage
and verifying quantity. Any claim of damage, shortage, or non-conformance must be made
in writing within 5 business days of receipt of goods (any claim of damage or shortage must
be noted on the Freight Carrier’s signed delivery receipt).
ORDERS: Seller is not responsible for and shall not be held liable for damages resulting
from delays or failures in shipment, nor shall Seller be liable for any delay or failure to provide
goods where occasioned by any force majeure event, including without limitation: strikes
and other labor disputes; res; acts of God; oods, snowstorms, tornados, and other storms;
unusually severe inclement weather conditions; fuel, energy, carrier, or material shortages
or embargoes; war; terrorism; civil disturbances; acts of civil or military authority; court order
or decree; partial or complete destruction of factory or other facility; acts of buyer; inability
to obtain or retain fuel, energy, carriers, materials, facilities, or labor without litigation or the
payment of penalties or unreasonable prices or the acceptance of unreasonable terms and
conditions; and any other cause beyond Seller’s control.
RETURNS: Goods cannot be returned without the prior written approval of Seller. Return
freight must be prepaid by buyer. After inspecting the returned goods, Seller may impose
upon buyer: (1) a handling and restocking charge equal to a minimum of 25% of the invoiced
cost of the returned goods; and, in addition thereto, (2) any costs required to put the goods
in like-new condition. All credit memos are subject to cash discount terms as dened in
our standard terms.
CANCELLATION: The contract resulting from Seller’s acceptance of Buyer’s order cannot
be cancelled, terminated, or modied by Buyer, in whole or in part, except upon Seller’s
prior written approval.
INVOICING: Minimum invoice charge of $50.00 (does not apply to Plumbing Products).
NON-STOCK PRODUCTS: Non-stock products (i.e., customized or non-standard products)
may require a minimum order and buyer should make prior inquiry to Seller. Once production
has begun, orders for non-stock products cannot be cancelled without the prior written
approval of Seller. Seller will not accept the return of non-stock products.
CONSTRUCTION: All sales, contracts, and offers to buy or sell, all rights, remedies and
duties of all persons, and the construction and effect of all provisions hereof, shall be governed
by and construed according to the laws of the State of Iowa.
A.Y. McDonald Mfg. Co.
Pumps and Accessories
Price List Effective December 11, 2016
Supersedes December 31, 2015
WARNING: It is unlawful in CALIFORNIA & VERMONT (effective 1/1/2010); MARYLAND (effective 1/1/2012); LOUISIANA (effective 1/1/2013) and the UNITED STATES
OF AMERICA (effective 1/4/2014) to use any product in the installation or repair of any public water system or any plumbing in a facility or system that provides water for
human consumption if the wetted surface area of the product has a weighted average lead content greater than 0.25%. This prohibition does not extend to service saddles used
in California, Louisiana or under USA Public Law 111-380.
12-11-16
Trade Customs
2A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
I. PRODUCT GROUP QUALIFICATION LEVELS
Freight will be prepaid and allowed by Seller on orders that meet or exceed the following net prices or unit qualiers (net prices reect
list prices less applicable discounts):
1. High Pressure Gas (may be combined with Plumbing Valves) ..............................................................................$2,500 Net
2. Water Service Products (may be combined with Curb Boxes, Pumps, Pump Accessories, Plumbing Valves,
Frames & Covers, HPG, and Yoke Boxes) ............................................................................................................. $6,000 Net
3. Pumps ..................................................................................................................................................................... 12+ units
4. Plumbing Products (may be combined with Pump Accessories) ........................................................................... $1,300 Net
5. Tanks.......................................................................24+ units (may be 24 units in combination with Jets and Submersibles)
6. Pit Setters . . . 15” diameter – 144 units
18” diameter – 96 units
21” diameter – 72 units
24” diameter – 48 units
30” and 36” diameter – 24 units
II. ADDITIONS
Once an order qualies for freight in any product group, other products on your order ride free (excluding Tanks and Pit Setters). However,
additions to freight allowed orders will NOT be allowed once the original order is on board or a partial shipment has been made against
the original order.
Freight qualiers are subject to change without notice.
Freight Program
3
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
CUSTOMS & FREIGHT .................................... 1-2
Trade Customs .......................................................1
Return Goods ........................................................1
Limited Warranty ...................................................1
No-Lead Warning ...................................................1
Freight Program .....................................................2
1 4" SUBMERSIBLE PUMPS............................ 4-16
21000 Series - Silicon Bronze ........................... 4-6
23000 Series - Stainless Steel .......................... 7-8
22000 Series - Thermoplastic ...............................9
24000 Series - 5 - 80 GPM ..........................10-13
26000 Series - 4" Stainless Steel Pump Ends ... 14
Cistern Pump ..................................................... 14
Control Boxes & Drives ....................................... 15
Motors & Contactors for three phase motors ...... 16
2 6", 8", 10" PUMP ENDS ..................................17-20
6", 8", & 10" Stainless Steel Pump Ends ...... 17-18
6" Submersible Motors ...................................... 19
Control Boxes ..................................................... 19
Hitachi Submersible Motors ............................... 20
Control Panels & Submonitors ........................... 20
3 TANKS ............................................................ 21
DuraMACTM Pump Tanks ...................................... 21
DuraMACTM Expansion & Potable Tanks ............... 21
4 JET PUMPS ................................................ 21-23
Shallow Well, Multi-Stage ..............................21-22
Ejectors Packages & Casing Adapters
& Flanges ......................................................22-23
5 DURAMACTM BOOSTER PUMPS .................... 24-26
DuraMACTM Variable Speed Boosters ..............24-25
DuraMACTM Booster Pump ................................... 26
6 CENTRIFUGAL PUMPS................................ 26-27
27000 Series - Super Booster .......................26-27
1500XSW Series - Multi-stage ........................... 27
8600SW Pumps ................................................. 27
88000 & 84000 Series ...................................... 27
87000 Series - Rainmaker ................................. 27
92000/93000 Series - Workhorse ..................... 27
7 UTILITY & SUMP PUMPS ................................. 28
DuraMACTM Sump Pumps & Utility ....................... 28
8 SEWAGE, EFFLUENT, GRINDER, & GUARDIAN
PUMPS ..................................................... 29-31
DuraMACTM Efuent & Sewage Pumps ................. 29
Guardian ............................................................ 29
High Head Efuent Pumps .................................. 30
Efuent Pumps ................................................... 31
Sewage Ejectors ................................................. 31
Grinder Pumps & Packages ................................ 31
9 DEWATERING PUMPS ................................. 32-33
Mini Mac Transfer Pump ..................................... 32
Submersible Dewatering Pumps ......................... 32
Handymac .......................................................... 32
Sludgemaster ..................................................... 32
Electric Trash Pumps .......................................... 32
General Purpose Pumps ..................................... 32
High Pressure ..................................................... 32
Trash Pumps ....................................................... 33
Dredging Pumps ................................................. 33
Diaphragm Pumps .............................................. 33
Fire Pumps ......................................................... 33
10 PUMP ACCESSORIES ................................. 34-37
Electric Instruments............................................ 34
Silicon Bronze Foot Valves .................................. 34
Silicon Bronze Check Valves ............................... 34
No-Lead Brass Relief Valves ............................... 34
No-Lead Brass Tank Tees .................................... 34
Sanitary Well Seals ............................................ 35
Plastic Sanitary Well Seals ................................. 35
Pressure Switches .............................................. 35
Air Volume Controls ............................................ 35
Pressure Gauges ................................................ 35
Pipe Holder ........................................................ 36
Float / Float Valves ............................................ 36
Mechanical Pump Float Switches ....................... 36
Control Switches ................................................ 36
Liquid Level Alarm Systems ................................ 37
Grinder Accessories ............................................ 37
Poly Basins, Covers & Kits .................................. 37
11 PUMP REPAIR PARTS ................................. 38-49
Motor Control Components ................................ 38
303022SP Repair Parts ..................................... 39
8100/8200 Series ............................................. 40
8500/8600 Series ............................................. 41
1000/1500 Series ........................................42-43
92000/93000 Series ........................................ 44
27000 Superbooster Motors .............................. 44
87000 Series ..................................................... 45
84000 Series ..................................................... 46
88000 Series ..................................................... 47
Guardian Repair Parts ........................................ 48
DuraMACTM Booster Repair Parts ......................... 49
PAGESECTION SECTION PAGE
Table of Contents
4A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
21 050 K 3 A
Pump Model
Model 21 - Bronze
Model 22 - Plastic
Model 23 - Stainless Steel
Model 24 - Stainless Steel
Horsepower
030 - 1/3 HP
050 - 1/2 HP
075 - 3/4 HP
100 - 1 HP
150 - 1 1/2 HP
200 - 2 HP
300 - 3 HP
500 - 5 HP
Series
J Series - 5 GPM
V Series - 7 GPM
K Series - 10 GPM
L Series - 15 GPM
P Series - 20 GPM
M Series - 25 GPM
Wires
Two wire or
Three wire
Other
A - 115V Single Phase
Y - 460V Three Phase
Z - 230V Three Phase
F - 220V 50HZ Three Phase
C - 200V Three Phase
Q - 380V Three Phase
M - 575V Three Phase
H - 380V 50HZ Three Phase
N - 415V 50HZ Three Phase
NOTES
- Standard is 230V, Single Phase
- Three-wire single phase models include pump, motor, 48" leads (1/2 through 2 HP) OR 100" leads (3 HP and larger), control box (1/2 thru 3 HP Standard
control box, 5 HP Deluxe control box), and check valve.
- Two-wire single phase models include pump, motor, 48" leads, and check valve.
- Three-wire three phase models include pump, motor, 48" leads (1/2 through 2 HP) OR 100" leads (3 HP and larger), contactor, and check valve.
- All submersible pumps include grounded leads.
M
c
D
O
N
A
L
D
M
c
D
O
N
A
L
D
5 GPM - J Series
Two Wire
21030J2A - 1/3 HP - 115V ............... $ 1,164.00 1 28
21030J2 - 1/3 HP - 230V ................. $ 1,164.00 1 28
21050J2A - 1/2 HP - 115V ............... $ 1,164.00 1 32
21050J2 - 1/2 HP - 230V ................. $ 1,164.00 1 30
21075J2 - 3/4 HP - 230V ................. $ 1,480.00 1 35
21100J2 - 1 HP - 230V .....................$ 1,711.00 1 40
21150J2 - 1 1/2 HP - 230V ...............$ 2,112.00 1 51
Three Wire
21030J3A - 1/3 HP - 115V ............... $ 1,204.00 1 32
21030J3 - 1/3 HP - 230V ................. $ 1,204.00 1 31
21050J3A - 1/2 HP - 115V ............... $ 1,204.00 1 35
21050J3 - 1/2 HP - 230V ................. $ 1,204.00 1 35
21075J3 - 3/4 HP - 230V ................. $ 1,497.00 1 38
21100J3 - 1 HP - 230V .................... $ 1,702.00 1 43
21150J3 - 1 1/2 HP - 230V ................ $ 2,116.00 1 50
21150J3Z - 1 1/2 HP - 230V - 3 Ph ....$ 2,663.00 1 48
7 GPM - V Series
Two Wire
21030V2A - 1/3 HP - 115V ................. $ 980.00 1 27
21030V2 - 1/3 HP - 230V ................... $ 980.00 1 28
21050V2A - 1/2 HP - 115V ................. $ 980.00 1 29
21050V2 - 1/2 HP - 230V .................. $ 980.00 1 27
21075V2 - 3/4 HP - 230V ................ $ 1,360.00 1 33
21100V2 - 1 HP - 230V .................... $ 1,557.00 1 36
21150V2 - 1 1/2 HP - 230V .............. $ 1,965.00 1 49
Three Wire
21030V3A - 1/3 HP - 115V .............. $ 1,049.00 1 28
21030V3 - 1/3 HP - 230V ................ $ 1,049.00 1 30
21050V3A - 1/2 HP - 115V .............. $ 1,049.00 1 31
21050V3 - 1/2 HP - 230V ................ $ 1,049.00 1 31
21075V3 - 3/4 HP - 230V ................ $ 1,372.00 1 37
21100V3 - 1 HP - 230V .................... $ 1,549.00 1 40
21150V3 - 1 1/2 HP - 230V .............. $ 1,956.00 1 50
21200V3 - 2 HP - 230V ................... $ 2,804.00 1 54
10 GPM - K Series
Two Wire
21030K2A - 1/3 HP - 115V ................. $ 943.00 1 25
21030K2 - 1/3 HP - 230V ................... $ 943.00 1 20
21050K2A - 1/2 HP - 115V ................. $ 943.00 1 26
21050K2 - 1/2 HP - 230V .................. $ 943.00 1 25
21075K2 - 3/4 HP - 230V ................ $ 1,181.00 1 29
21100K2 - 1 HP - 230V .................... $ 1,277.00 1 33
21150K2 - 1 1/2 HP - 230V .............. $ 1,865.00 1 45
Three Wire
21030K3A - 1/3 HP - 115V ................. $ 982.00 1 29
21030K3 - 1/3 HP - 230V ................... $ 982.00 1 22
21050K3A - 1/2 HP - 115V ................. $ 982.00 1 30
21050K3 - 1/2 HP - 230V ................... $ 982.00 1 28
21075K3 - 3/4 HP - 230V ................ $ 1,196.00 1 32
21100K3 - 1 HP - 230V .................... $ 1,269.00 1 36
21150K3 - 1 1/2 HP - 230V .............. $ 1,872.00 1 48
21150K3Z - 1 1/2 HP - 230V- 3 Ph .. $ 2,370.00 1 44
21200K3 - 2 HP - 230V ................... $ 2,635.00 1 50
21200K3Z - 2 HP - 230V- 3 Ph ........ $ 2,744.00 1 52
21300K3 - 3 HP - 230V ................... $ 3,733.00 1 62
21300K3Z - 3 HP - 230V- 3 Ph ........ $ 3,489.00 1 58
21500K3 - 5 HP - 230V ................... $ 4,962.00 1 97
15 GPM - L Series
Two Wire
21030L2A - 1/3 HP - 115V ............... $ 1,189.00 1 26
21030L2 - 1/3 HP - 230V ................. $ 1,189.00 1 26
21050L2A - 1/2 HP - 115V ............... $ 1,189.00 1 27
21050L2 - 1/2 HP - 230V ................. $ 1,189.00 1 26
21075L2 - 3/4 HP - 230V ................. $ 1,367.00 1 30
21100L2 - 1 HP - 230V .................... $ 1,462.00 1 33
21150L2 - 1 1/2 HP - 230V .............. $ 1,783.00 1 43
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Multiplier ___________________________
1 - 21000 Series - Silicon Bronze Submersible Pumps 4"
5
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
- All single phase pumps can be ordered less control box by
 addingsuxLB to model number.
- All three phase pumps can be ordered less starter by adding
 suxLS to model number.
- Deduct list price of control box or starter to determine list price.
M
c
D
O
N
A
L
D
15 GPM - L Series
Three Wire
21030L3A - 1/3 HP - 115V ............... $ 1,230.00 1 29
21030L3 - 1/3 HP - 230V ................. $ 1,230.00 1 29
21050L3A - 1/2 HP - 115V ............... $ 1,230.00 1 29
21050L3 - 1/2 HP - 230V ................. $ 1,230.00 1 30
21075L3 - 3/4 HP - 230V ................. $ 1,384.00 1 33
21100L3 - 1 HP - 230V .................... $ 1,454.00 1 37
21150L3 - 1 1/2 HP - 230V .............. $ 1,788.00 1 46
21200L3 - 2 HP - 230V .................... $ 2,158.00 1 51
21200L3Z - 2 HP - 230V 3 Ph ......... $ 2,333.00 1 47
21300L3 - 3 HP - 230V .....................$ 3,116.00 1 66
21300L3Z - 3 HP - 230V 3 Ph .............. $ 2,931.00 1 60
21500L3 - 5 HP - 230V .................... $ 4,923.00 1 100
21500L3Z - 5 HP - 230V 3 Ph .............. $ 4,612.00 1 81
20 GPM - P Series
Two Wire
21050P2A - 1/2 HP - 115V .............. $ 1,169.00 1 26
21050P2 - 1/2 HP - 230V ............... $ 1,169.00 1 26
21075P2 - 3/4 HP - 230V ................ $ 1,332.00 1 29
21100P2 - 1 HP - 230V .................... $ 1,405.00 1 34
21150P2 - 1 1/2 HP - 230V .............. $ 1 , 6 9 8 . 0 0 1 4 4
Three Wire
21050P3A - 1/2 HP - 115V .............. $ 1,208.00 1 29
21050P3 - 1/2 HP - 230V ................ $ 1,208.00 1 29
21075P3 - 3/4 HP - 230V ................ $ 1,347.00 1 32
21100P3 - 1 HP - 230V .................... $ 1,398.00 1 37
21150P3 - 1 1/2 HP - 230V .............. $ 1,706.00 1 46
21150P3Z - 1 1/2 HP - 230V - 3 Ph ............$ 2,163.00 1 48
21200P3 - 2 HP - 230V ................... $ 2,465.00 1 50
21200P3Z - 2 HP - 230V - 3 Ph ..........$ 2,573.00 1 47
21300P3 - 3 HP - 230V ................... $ 3,452.00 1 65
21300P3Z - 3 HP - 230V - 3 Ph ....... $ 3,210.00 1 55
21500P3 - 5 HP - 230V ................... $ 4,600.00 1 101
21500P3Z - 5 HP - 230V - 3 Ph ....... $ 4,270.00 1 81
25 GPM - M Series
Two Wire
21050M2A - 1/2 HP - 115V .............. $ 1,045.00 1 26
21050M2 - 1/2 HP - 230V ................ $ 1,045.00 1 24
21075M2 - 3/4 HP - 230V ................ $ 1,260.00 1 30
21100M2 - 1 HP - 230V ................... $ 1,319.00 1 32
21150M2 - 1 1/2 HP - 230V ............. $ 1 , 8 4 2 . 0 0 1 4 1
Three Wire
21050M3A - 1/2 HP - 115V ................$ 1,086.00 1 29
21050M3 - 1/2 HP - 230V ..................$ 1,086.00 1 29
21075M3 - 3/4 HP - 230V ..................$ 1,273.00 1 31
21100M3 - 1 HP - 230V .....................$ 1,308.00 1 35
21150M3 - 1 1/2 HP - 230V ...............$ 1,849.00 1 44
21150M3Z - 1 1/2 HP - 230V 3 Ph .....$ 2,227.00 1 42
21200M3 - 2 HP - 230V .....................$ 2,358.00 1 49
21200M3Z - 2 HP - 230V 3 Ph ..........$ 2,467.00 1 46
21300M3 - 3 HP - 230V .....................$ 3,372.00 1 63
21300M3Z - 3 HP - 230V 3 Ph ..........$ 3,381.00 1 53
21500M3 - 5 HP - 230V .....................$ 4,549.00 1 96
21500M3Z - 5 HP - 230V 3 Ph ..........$ 4 , 1 3 2 . 0 0 1 7 5
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
21000 Series - Silicon Bronze Submersible Pumps 4" - 1
6A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
1 - 21000 Series - Silicon Bronze Submersible Pumps 4"
M
c
D
O
N
A
L
D
- All single phase pumps can be ordered less control box by
 addingsuxLB to model number.
- All three phase pumps can be ordered less starter by adding
 suxLS to model number.
- Deduct list price of control box or starter to determine list price.
M
c
D
O
N
A
L
D
E-Z PAC Constant Pressure Package
Nema 3R
21075VCP1EZ - 7 GPM ................ $ 3,365.00 1 65
21100VCP1EZ - 7 GPM .................. $ 3,641.00 1 65
21150VCP1EZ - 7 GPM .................. $ 6,036.00 1 78
21075KCP1EZ - 10 GPM ................ $ 3,198.00 1 58
21100KCP1EZ - 10 GPM ................ $ 3,377.00 1 66
21150KCP1EZ - 10 GPM ................ $ 5,903.00 1 72
21075LCP1EZ - 15 GPM................. $ 3,349.00 1 58
21100LCP1EZ - 15 GPM ................. $ 3,537.00 1 66
21150LCP1EZ - 15 GPM ................. $ 5,673.00 1 69
21075PCP1EZ - 20 GPM ................ $ 3,371.00 1 59
21100PCP1EZ - 20 GPM ................ $ 3,522.00 1 68
21150PCP1EZ - 20 GPM ................ $ 5,695.00 1 76
21075MCP1EZ - 25 GPM................ $ 3,286.00 1 56
21100MCP1EZ - 25 GPM ................ $ 3,417.00 1 65
21150MCP1EZ - 25 GPM ................ $ 5,760.00 1 75
Nema 4
21075VCP4EZ - 7 GPM .................. $ 3,792.00 1 63
21100VCP4EZ - 7 GPM .................. $ 4,267.00 1 81
21150VCP4EZ - 7 GPM .................. $ 6,505.00 1 95
21075KCP4EZ - 10 GPM ................ $ 3,625.00 1 68
21100KCP4EZ - 10 GPM ................ $ 4,000.00 1 76
21150KCP4EZ - 10 GPM ................ $ 6,372.00 1 85
21075LCP4EZ - 15 GPM................. $ 3,774.00 1 69
21100LCP4EZ - 15 GPM ................. $ 4,161.00 1 78
21150LCP4EZ - 15 GPM ................. $ 6,142.00 1 84
21075PCP4EZ - 20 GPM ................ $ 3,797.00 1 67
21100PCP4EZ - 20 GPM ................ $ 4,146.00 1 78
21150PCP4EZ - 20 GPM ................ $ 6,165.00 1 87
21075MCP4EZ - 25 GPM.................$ 3,711.00 1 70
21100MCP4EZ - 25 GPM ................ $ 4,042.00 1 76
21150MCP4EZ - 25 GPM ................ $ 6,229.00 1 86
CP300 Constant Pressure System
21300K3CP - 10 GPM, 3 HP-230V
.$ 11,054.00 1 109
21300L3CP - 15 GPM, 3 HP-230V .
$ 10,496.00 1 111
21300P3CP - 20 GPM, 3 HP-230V
. $ 10,774.00 1 112
21300M3CP - 25 GPM, 3 HP-230V
. $ 10,697.00 1 106
5 GPM - J Series
21030J - 1/3 HP .................................. $ 547.00 1 10
21050J - 1/2 HP .................................. $ 547.00 1 11
21075J - 3/4 HP .................................. $ 733.00 1 13
21100J - 1 HP .................................. $ 1,037.00 1 15
21150J - 1 1/2 HP ............................ $ 1 , 2 2 3 . 0 0 1 1 8
7 GPM - V Series
21030V - 1/3 HP ................................. $ 383.00 1 9
21050V - 1/2 HP ................................. $ 383.00 1 10
21075V - 3/4 HP ................................. $ 609.00 1 13
21100V - 1 HP .................................... $ 755.00 1 11
21150V - 1 1/2 HP ........................... $ 1,064.00 1 16
21200V - 2 HP ................................. $ 1 , 4 0 6 . 0 0 1 1 8
10 GPM - K Series
21030K - 1/3 HP ................................. $ 327.00 1 7
21050K - 1/2 HP ................................. $ 327.00 1 8
21075K - 3/4 HP ................................. $ 441.00 1 9
21100K - 1 HP .................................... $ 488.00 1 10
21150K - 1 1/2 HP .............................. $ 932.00 1 13
21200K - 2 HP ................................. $ 1,238.00 1 15
21300K - 3 HP ................................. $ 1,623.00 1 17
21500K - 5 HP ................................. $ 2,026.00 1 19
15 GPM - L Series
21030L - 1/3 HP.................................. $ 549.00 1 8
21050L - 1/2 HP.................................. $ 549.00 1 9
21075L - 3/4 HP.................................. $ 591.00 1 10
21100L - 1 HP ..................................... $ 650.00 1 11
21150L - 1 1/2 HP ............................... $ 702.00 1 11
21200L - 2 HP..................................... $ 828.00 1 13
21300L - 3 HP.................................. $ 1,064.00 1 17
21500L - 5 HP.................................. $ 1,986.00 1 24
20 GPM - P Series
21050P - 1/2 HP ................................. $ 530.00 1 7
21075P - 3/4 HP ................................. $ 6 1 4 . 0 0 1 8
21100P - 1 HP .................................... $ 634.00 1 9
21150P - 1 1/2 HP .............................. $ 724.00 1 11
21200P - 2 HP ................................. $ 1,067.00 1 12
21300P - 3 HP ................................. $ 1,342.00 1 16
21500P - 5 HP ................................. $ 1,647.00 1 24
25 GPM - M Series
21050M - 1/2 HP ................................ $ 450.00 1 9
21075M - 3/4 HP ................................ $ 529.00 1 9
21100M - 1 HP .................................... $ 5 3 0 . 0 0 1 1 0
21150M - 1 1/2 HP .............................. $ 7 8 9 . 0 0 1 1 1
21200M - 2 HP ................................... $ 9 6 2 . 0 0 1 1 1
21300M - 3 HP ................................ $ 1,265.00 1 14
21500M - 5 HP ................................ $ 1 , 5 0 8 . 0 0 1 1 9
4" Silicon Bronze Pump Ends
7
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
M
c
D
O
N
A
L
D
5 GPM - J Series
Two Wire
23030J2A - 1/3 HP - 115V ............... $ 1,164.00 1 26
23030J2 - 1/3 HP - 230V ................ $ 1,164.00 1 27
23050J2A - 1/2 HP - 115V ............... $ 1,164.00 1 28
23050J2 - 1/2 HP - 230V ................. $ 1,164.00 1 28
23075J2 - 3/4 HP - 230V ................. $ 1,480.00 1 33
23100J2 - 1 HP - 230V .....................$ 1,711.00 1 37
23150J2 - 1 1/2 HP - 230V ...............$ 2 , 1 1 2 . 0 0 1 4 9
Three Wire
23030J3A - 1/3 HP - 115V ............... $ 1,204.00 1 28
23030J3 - 1/3 HP - 230V ................. $ 1,204.00 1 27
23050J3A - 1/2 HP - 115V ............. $ 1,204.00 1 32
23050J3 - 1/2 HP - 230V ................. $ 1,204.00 1 31
23075J3 - 3/4 HP - 230V ................. $ 1,497.00 1 35
23100J3 - 1 HP - 230V .................... $ 1,702.00 1 41
23150J3 - 1 1/2 HP - 230V ...............$ 2 , 1 1 6 . 0 0 1 3 1
23150J3Z - 1 1/2 HP - 230V 3 Ph ... $ 2,663.00 1 42
7 GPM - V Series
Two Wire
23030V2A - 1/3 HP - 115V ................. $ 980.00 1 26
23030V2 - 1/3 HP - 230V ................... $ 980.00 1 27
23050V2A - 1/2 HP - 115V ................. $ 980.00 1 26
23050V2 - 1/2 HP - 230V .................. $ 980.00 1 27
23075V2 - 3/4 HP - 230V ................ $ 1,360.00 1 30
23100V2 - 1 HP - 230V ................... $ 1,557.00 1 34
23150V2 - 1 1/2 HP - 230V ............. $ 1,965.00 1 45
Three Wire
23030V3A - 1/3 HP - 115V ............. $ 1,049.00 1 27
23030V3 - 1/3 HP - 230V ................ $ 1,049.00 1 28
23050V3A - 1/2 HP - 115V .............. $ 1,049.00 1 24
23050V3 - 1/2 HP - 230V ................ $ 1,049.00 1 29
23075V3 - 3/4 HP - 230V ................ $ 1,372.00 1 33
23100V3 - 1 HP - 230V ................... $ 1,549.00 1 37
23150V3 - 1 1/2 HP - 230V ............. $ 1,956.00 1 48
23200V3 - 2 HP - 230V ................... $ 2 , 8 0 4 . 0 0 1 5 0
10 GPM - K Series
Two Wire
23030K2A - 1/3 HP - 115V ................. $ 943.00 1 24
23030K2 - 1/3 HP - 230V ................... $ 943.00 1 24
23050K2A - 1/2 HP - 115V ................. $ 943.00 1 25
23050K2 - 1/2 HP - 230V ................... $ 9 4 3 . 0 0 1 2 5
23075K2 - 3/4 HP - 230V ................ $ 1,181.00 1 28
23100K2 - 1 HP - 230V ................... $ 1,277.00 1 32
23150K2 - 1 1/2 HP - 230V ............. $ 1 , 8 6 5 . 0 0 1 4 3
Three Wire
23030K3A - 1/3 HP - 115V ................. $ 9 8 2 . 0 0 1 2 1
23030K3 - 1/3 HP - 230V ................... $ 9 8 2 . 0 0 1 2 1
23050K3A - 1/2 HP - 115V ................. $ 982.00 1 28
23050K3 - 1/2 HP - 230V ................... $ 982.00 1 28
23075K3 - 3/4 HP - 230V ................ $ 1,196.00 1 31
23100K3 - 1 HP - 230V ................... $ 1,269.00 1 35
23150K3 - 1 1/2 HP - 230V ............. $ 1,872.00 1 44
23150K3Z - 1 1/2 HP - 230V - 3 Ph . $ 2,370.00 1 42
23200K3 - 2 HP - 230V ................... $ 2,635.00 1 52
23200K3Z - 2 HP - 230V - 3 Ph ....... $ 2,744.00 1 50
23300K3 - 3 HP - 230V ................... $ 3,733.00 1 64
23300K3Z - 3 HP - 230V - 3 Ph ....... $ 3,489.00 1 58
23500K3 - 5 HP - 230V - ................ $ 4,962.00 1 95
23500K3Z - 5 HP - 230V - 3 Ph ...... $ 4,651.00 1 77
15 GPM - L Series
Two Wire
23030L2A - 1/3 HP - 115V ............... $ 1,189.00 1 24
23030L2 - 1/3 HP - 230V ................. $ 1,189.00 1 24
23050L2A - 1/2 HP - 115V ............... $ 1,189.00 1 25
23050L2 - 1/2 HP - 230V ................. $ 1,189.00 1 24
23075L2 - 3/4 HP - 230V ................. $ 1,367.00 1 28
23100L2 - 1 HP - 230V .................... $ 1,462.00 1 32
23150L2 - 1 1/2 HP - 230V .............. $ 1,783.00 1 41
Three Wire
23030L3A - 1/3 HP - 115V ............... $ 1,230.00 1 27
23030L3 - 1/3 HP - 230V ................. $ 1,230.00 1 27
23050L3A - 1/2 HP - 115V ............... $ 1,230.00 1 27
23050L3 - 1/2 HP - 230V ................. $ 1,230.00 1 28
23075L3 - 3/4 HP - 230V ................. $ 1,384.00 1 31
23100L3 - 1 HP - 230V .................... $ 1,454.00 1 35
23150L3 - 1 1/2 HP - 230V .............. $ 1,788.00 1 44
23200L3 - 2 HP - 230V .................... $ 2,158.00 1 50
23200L3Z - 2 HP - 230V - 3 Ph ....... $ 2,333.00 1 48
23300L3 - 3 HP - 230V .....................$ 3,116.00 1 64
23300L3Z - 3 HP - 230V - 3 Ph ....... $ 2,931.00 1 57
23500L3 - 5 HP - 230V .................... $ 4,923.00 1 100
23500L3Z - 5 HP - 230V - 3 Ph ....... $ 4,612.00 1 81
20 GPM - P Series
Two Wire
23050P2A - 1/2 HP - 230V .............. $ 1,169.00 1 25
23050P2 - 1/2 HP - 230V ................ $ 1,169.00 1 24
23075P2 - 3/4 HP - 230V ................ $ 1,332.00 1 28
23100P2 - 1 HP - 230V ................... $ 1,405.00 1 32
23150P2 - 1 1/2 HP - 230V ............. $ 1,698.00 1 41
Three Wire
23050P3A - 1/2 HP - 230V ............. $ 1,208.00 1 27
23050P3 - 1/2 HP - 230V ............... $ 1,208.00 1 27
23075P3 - 3/4 HP - 230V ............... $ 1,347.00 1 30
23100P3 - 1 HP - 230V .................. $ 1,398.00 1 34
23150P3 - 1 1/2 HP - 230V ............. $ 1,706.00 1 43
23150P3Z - 1 1/2 HP - 230V - 3 Ph
.
$ 2,163.00 1 41
23200P3 - 2 HP - 230V ................... $ 2,465.00 1 49
23200P3Z - 2 HP - 230V - 3 Ph ....... $ 2,573.00 1 45
23300P3 - 3 HP - 230V ................. $ 3,452.00 1 63
23300P3Z - 3 HP - 230V - 3 Ph ....... $ 3,210.00 1 53
23500P3 - 5 HP - 230V ................... $ 4,600.00 1 99
23500P3Z - 5 HP - 230V - 3 Ph ....... $ 4 , 2 7 0 . 0 0 1 7 8
25 GPM - M Series
Two Wire
23050M2A - 1/2 HP - 115V .............. $ 1 , 0 4 5 . 0 0 1 2 4
23050M2 - 1/2 HP - 230V ................ $ 1,045.00 1 24
23075M2 - 3/4 HP - 230V ................ $ 1 , 2 6 0 . 0 0 1 27
23100M2 - 1 HP - 230V ................... $ 1 , 3 1 9 . 0 0 1 31
23150M2 - 1 1/2 HP - 230V
.............
$ 1 , 8 4 2 . 0 0 1 4 0
Three Wire
23050M3A - 1/2 HP 115V ................ $ 1 , 0 8 6 . 0 0 1 2 7
23050M3 - 1/2 HP 230V .................. $ 1 , 0 8 6 . 0 0 1 27
23075M3 - 3/4 HP 230V .................. $ 1,273.00 1 30
23100M3 - 1 HP - 230V ................... $ 1,308.00 1 33
23150M3 - 1 1/2 HP - 230V ............. $ 1,849.00 1 42
23150M3Z - 1 1/2 HP - 230V - 3 Ph
. $ 2,227.00 1 40
23150M3Y - 1 1/2 HP - 460V - 3 Ph
. $ 2,227.00 1 38
23200M3 - 2 HP - 230V ................... $ 2,358.00 1 48
23200M3Z - 2 HP - 230V - 3 Ph ...... $ 2,467.00 1 44
23200M3Y - 2 HP - 460V - 3 Ph ...... $ 2,467.00 1 44
23300M3 - 3 HP - 230V ................... $ 3,372.00 1 60
23300M3Z - 3 HP - 230V - 3 Ph ...... $ 3,381.00 1 50
23300M3Y - 3 HP - 460V - 3 Ph ...... $ 3,381.00 1 51
23500M3 - 5 HP - 230V ................... $ 4,549.00 1 95
23500M3Z - 5 HP - 230V - 3 Ph ...... $ 4,132.00 1 75
23500M3Y - 5 HP - 460V - 3 Ph ...... $ 4,132.00 1 73
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
23000 Series - Stainless Steel Submersible Pumps 4" - 1
8A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
1 - 23000 Series - Stainless Steel Submersible Pumps 4"
M
c
D
O
N
A
L
D
E-Z PAC Constant Pressure Package
Nema 3R
23075VCP1EZ - 7 GPM, ................. $ 3,365.00 1 59
23100VCP1EZ - 7 GPM .................. $ 3,641.00 1 68
23150VCP1EZ - 7 GPM .................. $ 6,036.00 1 75
23075KCP1EZ - 10 GPM ................ $ 3,198.00 1 57
23100KCP1EZ - 10 GPM ................ $ 3,377.00 1 64
23150KCP1EZ - 10 GPM ................ $ 5,903.00 1 70
23075LCP1EZ - 15 GPM................. $ 3,349.00 1 56
23100LCP1EZ - 15 GPM................. $ 3,537.00 1 63
23150LCP1EZ - 15 GPM................. $ 5,673.00 1 72
23075PCP1EZ - 20 GPM ................ $ 3,371.00 1 55
23100PCP1EZ - 20 GPM ................ $ 3,522.00 1 64
23150PCP1EZ - 20 GPM ................ $ 5,695.00 1 72
23075MCP1EZ - 25 GPM................ $ 3,286.00 1 57
23100MCP1EZ - 25 GPM................ $ 3,417.00 1 62
23150MCP1EZ - 25 GPM................ $ 5,760.00 1 70
Nema 4
23075VCP4EZ - 7 GPM .................. $ 3,792.00 1 61
23100VCP4EZ - 7 GPM .................. $ 4,267.00 1 80
23150VCP4EZ - 7 GPM .................. $ 6,505.00 1 91
23075KCP4EZ - 10 GPM ................ $ 3,625.00 1 67
23100KCP4EZ - 10 GPM ................ $ 4,000.00 1 73
23150KCP4EZ - 10 GPM ................ $ 6,372.00 1 83
23075LCP4EZ - 15 GPM................. $ 3,774.00 1 67
23100LCP4EZ - 15 GPM................. $ 4,161.00 1 75
23150LCP4EZ - 15 GPM................. $ 6,142.00 1 82
23075PCP4EZ - 20 GPM ................ $ 3,797.00 1 64
23100PCP4EZ - 20 GPM ................ $ 4,146.00 1 75
23150PCP4EZ - 20 GPM ................ $ 6,165.00 1 84
23075MCP4EZ - 25 GPM.................$ 3,711.00 1 59
23100MCP4EZ - 25 GPM................ $ 4,042.00 1 75
23150MCP4EZ - 25 GPM................ $ 6,229.00 1 80
CP300 Constant Pressure System
23300K3CP - 10 GPM, 3 HP-230V .... $ 11,054.00 1 109
23300L3CP - 15 GPM, 3 HP-230V ....$ 10,496.00 1 108
23300P3CP - 20 GPM, 3 HP-230V .... $ 10,774.00 1 108
23300M3CP - 25 GPM, 3 HP-230V ...$ 10,697.00 1 102
5 GPM - J Series
23030J - 1/3 HP ..............................$ 547.00 1 9
23050J - 1/2 HP ..............................$ 547.00 1 10
23075J - 3/4 HP ..............................$ 733.00 1 12
23100J - 1 HP ..............................$ 1,037.00 1 13
23150J - 1 1/2 HP ........................$ 1,223.00 1 18
7 GPM - V Series
23030V - 1/3 HP ............................. $ 383.00 1 8
23050V - 1/2 HP ............................. $ 383.00 1 9
23075V - 3/4 HP ............................. $ 609.00 1 10
23100V - 1 HP ................................ $ 755.00 1 11
23150V - 1 1/2 HP ....................... $ 1,064.00 1 12
23200V - 2 HP ............................. $ 1,406.00 1 16
10 GPM - K Series
23030K-1/3 HP ............................... $ 327.00 1 7
23050K-1/2 HP ............................... $ 327.00 1 7
23075K-3/4 HP ............................... $ 441.00 1 8
23100K-1 HP ................................. $ 488.00 1 9
23150K-1 1/2 HP ............................ $ 932.00 1 11
23200K-2 HP ............................... $ 1,238.00 1 14
23300K-3 HP ............................... $ 1,623.00 1 16
23500K-5 HP ............................... $ 2,026.00 1 18
15 GPM - L Series
23030L - 1/3 HP..............................$ 549.00 1 7
23050L - 1/2 HP..............................$ 549.00 1 7
23075L - 3/4 HP..............................$ 591.00 1 8
23100L - 1 HP ................................$ 650.00 1 9
23150L - 1 1/2 HP...........................$ 702.00 1 10
23200L - 2 HP.................................$ 828.00 1 12
23300L - 3 HP..............................$ 1,064.00 1 15
23500L - 5 HP..............................$ 1,986.00 1 22
20 GPM - P Series
23050P - 1/2 HP ............................. $ 530.00 1 6
23075P - 3/4 HP ............................. $ 614.00 1 8
23100P - 1 HP ................................ $ 634.00 1 9
23150P - 1 1/2 HP .......................... $ 724.00 1 10
23200P - 2 HP ............................. $ 1,067.00 1 11
23300P - 3 HP ............................. $ 1,342.00 1 14
23500P - 5 HP ............................. $ 1 , 6 4 7 . 0 0 1 2 2
25 GPM - M Series
23050M - 1/2 HP ............................$ 450.00 1 7
23075M - 3/4 HP ............................$ 529.00 1 7
23100M - 1 HP ...............................$ 530.00 1 8
23150M - 1 1/2 HP .........................$ 789.00 1 9
23200M - 2 HP ...............................$ 962.00 1 10
23300M - 3 HP ............................$ 1,265.00 1 11
23500M - 5 HP ............................$ 1 , 5 0 8 . 0 0 1 1 8
4" Stainless Steel Pump Ends
9
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
M
c
D
O
N
A
L
D
5 GPM - J Series
Plastic - Two Wire
22050J2 - 1/2 HP - 230V .......... $ 1,025.00 1 25
22075J2 - 3/4 HP - 230V .......... $ 1,248.00 1 30
22100J2 - 1 HP - 230V ............. $ 1,398.00 1 35
Plastic - Three Wire
22050J3 - 1/2 HP - 230V .......... $ 1,065.00 1 29
22075J3 - 3/4 HP - 230V .......... $ 1,262.00 1 33
22100J3 - 1 HP - 230V ............. $ 1,391.00 1 38
7 GPM - V Series
Plastic - Two Wire
22050V2 - 1/2 HP, 230V ........... $ 1,010.00 1 24
22050V2A - 1/2 HP, 115V ......... $ 1,010.00 1 25
22075V2 - 3/4 HP, 230V ........... $ 1,235.00 1 28
22100V2 - 1 HP, 230V .............. $ 1,377.00 1 31
22150V2 - 1 1/2 HP, 230V ........ $ 1,857.00 1 43
Plastic - Three Wire
22050V3 - 1/2 HP, 230V ........... $ 1,051.00 1 26
22050V3A - 1/2 HP, 115V ......... $ 1,051.00 1 28
22075V3 - 3/4 HP, 230V ........... $ 1,252.00 1 30
22100V3 - 1 HP, 230V .............. $ 1,369.00 1 34
22150V3 - 1 1/2 HP, 230V ........ $ 1,861.00 1 47
10 GPM - K Series
Plastic - Two Wire
22050K2A - 1/2 HP - 115V .......... $ 870.00 1 22
22050K2 - 1/2 HP - 230V ............ $ 870.00 1 23
22075K2 - 3/4 HP - 230V ......... $ 1,093.00 1 27
22100K2 - 1 HP - 230V ............ $ 1,233.00 1 30
22150K2 - 1 1/2 HP - 230V ...... $ 1,723.00 1 41
Plastic - Three Wire
22050K3A - 1/2 HP - 115V .......... $ 910.00 1 27
22050K3 - 1/2 HP - 230V ............ $ 910.00 1 26
22075K3 - 3/4 HP - 230V ......... $ 1,108.00 1 30
22100K3 - 1 HP - 230V ............ $ 1,225.00 1 33
22150K3 - 1 1/2 HP - 230V ...... $ 1,730.00 1 44
15 GPM - L Series
Plastic - Two Wire
22050L2A - 1/2 HP - 115V ........ $ 1,024.00 1 23
22050L2 - 1/2 HP - 230V .......... $ 1,024.00 1 23
22075L2 - 3/4 HP - 230V .......... $ 1,203.00 1 26
22100L2 - 1 HP - 230V ............. $ 1,352.00 1 30
22150L2 - 1 1/2 HP - 230V ....... $ 1,637.00 1 42
Plastic - Three Wire
22050L3A - 1/2 HP - 115V ........ $ 1,065.00 1 27
22050L3 - 1/2 HP - 230V .......... $ 1,065.00 1 26
22075L3 - 3/4 HP - 230V .......... $ 1,217.00 1 30
22100L3 - 1 HP - 230V ............. $ 1,352.00 1 33
22150L3 - 1 1/2 HP - 230V ....... $ 1,634.00 1 42
20 GPM - P Series
Plastic - Two Wire
22050P2A - 1/2 HP - 115V ....... $ 1,040.00 1 23
22050P2 - 1/2 HP - 230V ......... $ 1,040.00 1 23
22075P2 - 3/4 HP - 230V ......... $ 1,099.00 1 27
22100P2 - 1 HP - 230V ............ $ 1,187.00 1 29
22150P2 - 1 1/2 HP - 230V ...... $ 1,525.00 1 39
20 GPM - P Series
Plastic - Three Wire
22050P3A - 1/2 HP - 115V .......... $ 991.00 1 26
22050P3 - 1/2 HP - 230V ............ $ 991.00 1 26
22075P3 - 3/4 HP - 230V ..........$ 1,115.00 1 29
22100P3 - 1 HP - 230V ............ $ 1,179.00 1 32
22150P3 - 1 1/2 HP - 230V ...... $ 1,532.00 1 42
25 GPM - M Series
Plastic - Two Wire
22050M2A - 1/2 HP - 230V ........$ 1,011.00 1 23
22050M2 - 1/2 HP - 230V ..........$ 1,011.00 1 22
22075M2 - 3/4 HP - 230V ......... $ 1,136.00 1 26
22100M2 - 1 HP - 230V ............ $ 1,226.00 1 29
22150M2 - 1 1/2 HP - 230V ...... $ 1,535.00 1 38
Plastic - Three Wire
22050M3A - 1/2 HP - 230V ....... $ 1,061.00 1 26
22050M3 - 1/2 HP - 230V ......... $ 1,061.00 1 25
22075M3 - 3/4 HP - 230V ......... $ 1,151.00 1 29
22100M3 - 1 HP - 230V ............ $ 1,238.00 1 32
22150M3 - 1 1/2 HP - 230V ...... $ 1,626.00 1 42
5 GPM - J Series
22050J - 1/2 HP ........................... $ 365.00 1 7
22075J - 3/4 HP .......................... $ 449.00 1 11
22100J - 1 HP .............................. $ 543.00 1 13
7 GPM - V Series
22050V - 1/2 HP .......................... $ 349.00 1 6
22075V - 3/4 HP .......................... $ 439.00 1 9
22100V - 1 HP ............................. $ 521.00 1 9
22150V - 1 1/2 HP ....................... $ 740.00 1 13
10 GPM - K Series
22050K - 1/2 HP .......................... $ 210.00 1 6
22075K - 3/4 HP .......................... $ 296.00 1 6
22100K - 1 HP ............................. $ 378.00 1 7
22150K - 1 1/2 HP ........................$ 611.00 1 10
15 GPM - L Series
22050L - 1/2 HP........................... $ 378.00 1 6
22075L - 3/4 HP........................... $ 419.00 1 6
22100L - 1 HP.............................. $ 525.00 1 8
22150L - 1 1/2 HP........................ $ 587.00 1 9
20 GPM - P Series
22050P - 1/2 HP .......................... $ 291.00 1 5
22075P - 3/4 HP .......................... $ 302.00 1 6
22100P - 1 HP ............................ $ 384.00 1 7
22150P - 1 1/2 HP ....................... $ 411.00 1 8
25 GPM - M Series
22050M - 1/2 HP ......................... $ 365.00 1 5
22075M - 3/4 HP ......................... $ 404.00 1 5
22100M - 1 HP ........................... $ 447.00 1 6
22150M - 1 1/2 HP ..................... $ 510.00 1 7
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
4" Thermoplastic Pump Ends
22000 Series - Thermoplastic Submersible Pumps 4" - 1
10 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
1 - 24000 Series - Stainless Steel Submersible Pumps 4"
5 GPM - J Series
Two Wire
24050J2 - 1/2 HP, 230V ..................... $ 1,057.00 1 26
24050J2A - 1/2 HP, 115V ................... $ 1,057.00 1 26
24075J2 - 3/4 HP, 230V ..................... $ 1,327.00 1 30
24100J2 - 1 HP, 230V ........................ $ 1,597.00 1 35
24150J2 - 1 1/2 HP, 230V .................. $ 1,995.00 1 48
Three Wire
24050J3 - 1/2 HP, 230V ..................... $ 1,096.00 1 30
24050J3A - 1/2 HP, 115V ................... $ 1,096.00 1 30
24075J3 - 3/4 HP, 230V ..................... $ 1,340.00 1 34
24100J3 - 1 HP , 230V, ..................... $ 1,587.00 1 38
24150J3 - 1 1/2 HP, 230V .................. $ 1,963.00 1 44
24150J3Z - 1 1/2 HP, 230V, 3 PH ..... $ 2,302.00 1 42
7 GPM - V Series
Two Wire
24050V2 - 1/2 HP, 230V ........................$ 943.00 1 26
24050V2A - 1/2 HP, 115V ......................$ 943.00 1 26
24075V2 - 3/4 HP, 230V .................... $ 1,238.00 1 30
24100V2 - 1 HP, 230V ....................... $ 1,399.00 1 34
24150V2 - 1 1/2 HP, 230V ................. $ 1,884.00 1 45
Three Wire
24050V3 - 1/2 HP, 230V ........................$ 982.00 1 30
24050V3A - 1/2 HP, 115V ......................$ 982.00 1 30
24075V3 - 3/4 HP, 230V .................... $ 1,254.00 1 33
24100V3 - 1 HP, 230V ....................... $ 1,390.00 1 37
24150V3 - 1 1/2 HP, 230V ................. $ 1,852.00 1 43
24200V3 - 2 HP, 230V ....................... $ 2,392.00 1 51
24200V3Z - 2 HP, 230V, 3 PH ........... $ 2,453.00 1 49
10 GPM - K Series
Two Wire
24050K2 - 1/2 HP, 230V ........................$ 903.00 1 25
24050K2A - 1/2 HP, 115V ......................$ 903.00 1 25
24075K2 - 3/4 HP, 230V .................... $ 1,121.00 1 29
24100K2 - 1 HP, 230V ........................$ 1,211.00 1 32
24150K2 - 1 1/2 HP, 230V ................. $ 1,790.00 1 41
Three Wire
24050K3 - 1/2 HP, 230V ........................$ 943.00 1 29
24050K3A - 1/2 HP, 115V ......................$ 943.00 1 29
24075K3 - 3/4 HP, 230V .................... $ 1,135.00 1 32
24100K3 - 1 HP, 230V ....................... $ 1,201.00 1 35
24150K3 - 1 1/2 HP, 230V ................. $ 1,758.00 1 41
24150K3Z - 1 1/2 HP, 230V, 3PH ..... $ 2,079.00 1 39
24200K3 - 2 HP, 230V ....................... $ 2,274.00 1 47
24200K3Z - 2 HP, 230V, 3 PH ........... $ 2,382.00 1 44
24300K3 - 3 HP, 230V ....................... $ 3,224.00 1 58
24300K3Z - 3 HP, 230V, 3 PH ........... $ 3,012.00 1 54
24500K3 - 5 HP, 230V ....................... $ 4,436.00 1 93
24500K3Z - 5 HP, 230V, 3 PH ........... $ 4,057.00 1 80
15 GPM - L Series
Two Wire
24050L2 - 1/2 HP, 230V ..................... $ 1,059.00 1 24
24050L2A - 1/2 HP, 115V ................... $ 1,059.00 1 24
24075L2 - 3/4 HP, 230V ..................... $ 1,226.00 1 28
24100L2 - 1 HP, 230V ........................ $ 1,325.00 1 32
24150L2 - 1 1/2 HP, 230V.................. $ 1,628.00 1 39
15 GPM - P Series - continued
Three Wire
24050L3 - 1/2 HP, 230V ..................... $ 1,098.00 1 28
24050L3A - 1/2 HP, 115V ................... $ 1,098.00 1 28
24075L3 - 3/4 HP, 230V ..................... $ 1,239.00 1 31
24100L3 - 1 HP, 230V ........................ $ 1,315.00 1 35
24150L3 - 1 1/2 HP, 230V.................. $ 1,596.00 1 39
24200L3 - 2 HP, 230V ........................ $ 1,984.00 1 39
24200L3Z - 2 HP, 230V, 3 PH ........... $ 2,091.00 1 43
24300L3 - 3 HP, 230V ........................ $ 2,832.00 1 56
24300L3Z - 3 HP, 230V, 3 PH ........... $ 2,619.00 1 52
24500L3 - 5 HP, 230V ........................ $ 4,410.00 1 91
24500L3Z - 5 HP, 230V, 3 PH ........... $ 4,031.00 1 78
20 GPM - P Series
Two Wire
24050P2 - 1/2 HP, 230V .................... $ 1,045.00 1 25
24050P2A - 1/2 HP, 115V .................. $ 1,045.00 1 24
24075P2 - 3/4 HP, 230V .................... $ 1,241.00 1 28
24100P2 - 1 HP, 230V ....................... $ 1,314.00 1 31
24150P2 - 1 1/2 HP, 230V ................. $ 1,644.00 1 39
Three Wire
24050P3 - 1/2 HP, 230V .................... $ 1,085.00 1 28
24050P3A - 1/2 HP,115V ................... $ 1,085.00 1 28
24075P3 - 3/4 HP, 230V .................... $ 1,257.00 1 31
24100P3 - 1 HP, 230V ....................... $ 1,304.00 1 34
24150P3 - 1 1/2 HP, 230V ................. $ 1,612.00 1 42
24150P3Z - 1 1/2 HP, 230V, 3 PH .... $ 1,951.00 1 37
24200P3 - 2 HP, 230V ....................... $ 2,152.00 1 46
24200P3Z - 2 HP, 230V, 3 PH ........... $ 2,259.00 1 42
24300P3 - 3 HP, 230V ....................... $ 3,028.00 1 55
24300P3Z - 3 HP, 230V, 3 PH ........... $ 2,816.00 1 51
24500P3 - 5 HP, 230V ....................... $ 4,085.00 1 90
24500P3Z - 5 HP, 230V, 3 PH ........... $ 3,791.00 1 77
25 GPM - M Series
Two Wire
24100M2 - 1 HP, 230V ....................... $ 1,239.00 1 31
24150M2 - 1 1/2 HP, 230V ................ $ 1,689.00 1 39
Three Wire
24100M3 - 1 HP, 230V ....................... $ 1,230.00 1 34
24150M3 - 1 1/2 HP, 230V ................ $ 1,658.00 1 39
24150M3Z - 1 1/2 HP, 230V, 3 PH .... $ 1,997.00 1 37
24200M3 - 2 HP, 230V ....................... $ 2,080.00 1 45
24200M3Z - 2 HP, 230V, 3 PH .......... $ 2,187.00 1 42
24300M3 - 3 HP, 230V ....................... $ 2,973.00 1 55
24300M3Z - 3 HP, 230V, 3 PH .......... $ 2,761.00 1 51
24500M3 - 5 HP, 230V ....................... $ 3,986.00 1 90
24500M3Z - 5 HP, 230V, 3 PH .......... $ 3,693.00 1 77
11
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
24000 Series - Stainless Steel Submersible Pumps 4" - 1
E-Z PAC Constant Pressure Package
Nema 3R
24075VCP1EZ - 7 GPM, ................. $ 3,029.00 1 59
24100VCP1EZ - 7 GPM .................. $ 3,278.00 1 68
24150VCP1EZ - 7 GPM .................. $ 5,432.00 1 75
24075KCP1EZ - 10 GPM ................ $ 2,879.00 1 57
24100KCP1EZ - 10 GPM ................ $ 3,039.00 1 64
24150KCP1EZ - 10 GPM ................ $ 5,313.00 1 70
24075LCP1EZ - 15 GPM................. $ 3,014.00 1 56
24100LCP1EZ - 15 GPM................. $ 3,184.00 1 63
24150LCP1EZ - 15 GPM................. $ 5,107.00 1 72
24075PCP1EZ - 20 GPM ................ $ 3,035.00 1 55
24100PCP1EZ - 20 GPM ................ $ 3,170.00 1 64
24150PCP1EZ - 20 GPM ................ $ 5,126.00 1 72
24100MCP1EZ - 25 GPM................ $ 3,075.00 1 57
24150MCP1EZ - 25 GPM................ $ 5,184.00 1 70
24100RCP1EZ - 35 GPM ................ $ 3,747.00 1 61
24150RCP1EZ - 35 GPM ................ $ 5,857.00 1 72
24150GCP1EZ - 40 GPM ................ $ 6,037.00 1 70
24150SCP1EZ - 55 GPM ................ $ 6,162.00 1 72
24150QCP1EZ - 60 GPM ................ $ 5,957.00 1 71
Nema 4
24075VCP4EZ - 7 GPM .................. $ 3,414.00 1 61
24100VCP4EZ - 7 GPM .................. $ 3,840.00 1 80
24150VCP4EZ - 7 GPM .................. $ 5,855.00 1 91
24075KCP4EZ - 10 GPM ................ $ 3,263.00 1 67
24100KCP4EZ - 10 GPM ................ $ 3,600.00 1 73
24150KCP4EZ - 10 GPM ................ $ 5,735.00 1 83
24075LCP4EZ - 15 GPM................. $ 3,397.00 1 67
24100LCP4EZ - 15 GPM................. $ 3,745.00 1 75
24150LCP4EZ - 15 GPM................. $ 5,528.00 1 82
24075PCP4EZ - 20 GPM ................ $ 3,417.00 1 64
24100PCP4EZ - 20 GPM ................ $ 3,732.00 1 75
24150PCP4EZ - 20 GPM ................ $ 5,548.00 1 84
24100MCP4EZ - 25 GPM................ $ 3,637.00 1 75
24150MCP4EZ - 25 GPM................ $ 5,607.00 1 80
24100RCP4EZ - 35 GPM ................ $ 4,373.00 1 78
24150RCP4EZ - 35 GPM ................ $ 6,325.00 1 81
24150GCP4EZ - 40 GPM ................ $ 6,506.00 1 79
24150SCP4EZ - 55 GPM ................ $ 6,631.00 1 82
24150QCP4EZ - 60 GPM ................ $ 6,425.00 1 81
CP300 Constant Pressure System
24300R3CP - 35 GPM, 3 HP-230V ....$ 10,766.00 1 101
24300G3CP - 40 GPM, 3 HP-230V ....$ 10,951.00 1 97
24300S3CP - 55 GPM, 3 HP-230V .... $ 10,930.00 1 102
24300Q3CP - 60 GPM, 3 HP-230V ....$ 10,830.00 1 100
24300T3CP - 80 GPM, 3 HP-230V ....$ 10,766.00 1 102
4" Stainless Steel Pump Ends
5 GPM - J Series
24050J - 1/2 HP ............................. $ 406.00 1 8
24075J - 3/4 HP .............................. $ 543.00 1 9
24100J - 1 HP ................................. $ 769.00 1 11
24150J - 1 1/2 HP ........................... $ 906.00 1 13
7 GPM - V Series
24050V - 1/2 HP ............................$ 285.00 1 8
24075V - 3/4 HP .............................$ 451.00 1 9
24100V - 1 HP ................................$ 560.00 1 10
24150V - 1 1/2 HP ..........................$ 789.00 1 12
24200V - 2 HP .............................$ 1,043.00 1 15
10 GPM - K Series
24050K - 1/2 HP ............................$ 242.00 1 7
24075K - 3/4 HP .............................$ 327.00 1 8
24100K - 1 HP ................................$ 362.00 1 8
24150K - 1 1/2 HP ..........................$ 690.00 1 10
24200K - 2 HP ................................$ 918.00 1 11
24300K - 3 HP .............................$ 1,202.00 1 14
24500K - 5 HP .............................$ 1,501.00 1 26
15 GPM - L Series
24050L - 1/2 HP .............................$ 407.00 1 6
24075L - 3/4 HP..............................$ 438.00 1 7
24100L - 1 HP.................................$ 482.00 1 8
24150L - 1 1/2 HP...........................$ 519.00 1 9
24200L - 2 HP.................................$ 615.00 1 10
24300L - 3 HP.................................$ 789.00 1 12
24500L - 5 HP..............................$ 1,472.00 1 17
20 GPM - P Series
24050P - 1/2 HP ............................$ 393.00 1 6
24075P - 3/4 HP .............................$ 454.00 1 7
24100P - 1 HP ................................$ 470.00 1 8
24150P - 1 1/2 HP ..........................$ 536.00 1 9
24200P - 2 HP ................................$ 791.00 1 9
24300P - 3 HP ................................$ 995.00 1 13
24500P - 5 HP .............................$ 1,221.00 1 16
25 GPM - M Series
24100M - 1 HP ...............................$ 393.00 1 7
24150M - 1 1/2 HP .........................$ 585.00 1 9
24200M - 2 HP ...............................$ 713.00 1 10
24300M - 3 HP ...............................$ 938.00 1 12
24500M - 5 HP ............................$ 1,118.00 1 16
12 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
NOTES
- Standard is 230V, Single Phase
- Three-wire single phase models include pump, motor, 48" leads (1/2 through 2 HP) OR 100" leads (3 HP and larger),
control box (1/2 thru 3 HP Standard control box, 5 HP Deluxe control box) and check valve.
- Two-wire single phase models include pump, motor, 48" leads, and check valve.
- Three-wire three phase models include pump, motor, 48" leads (1/2 through 2 HP) OR 100" leads (3 HP and larger), contactor, and check valve.
- All submersible pumps include grounded leads.
Order by Model Number. Example: 24200R3
24 200 R 3
Pump Model
4" Submersible
Stainless Steel
Pumps are Model 24
Horsepower
100 - 1 HP
150 - 1 1/2 HP
200 - 2 HP
300 - 3 HP
500 - 5 HP
750 - 7 1/2 HP
1000 - 10 HP
Series
R Series - 35 GPM
G Series - 40 GPM
S Series - 55 GPM
Q Series - 60 GPM
T Series - 80 GPM
Wires
Two wire or
Three wire
(Leave blank
for pump
end only)
Other
Leave blank for 230V
60 HZ, Single Phase (Standard)
A - 115V Single Phase
C - 200V Three Phase
Z - 230V Three Phase
Q - 380V Three Phase
Y - 460V Three Phase
Other Options - Contact Factory
M - 575V Three Phase
E - 220V 50HZ Single Phase
F - 220V 50HZ Three Phase
H - 380V 50HZ Three Phase
N - 415V 50HZ Three Phase
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
35 GPM - R Series
Two Wire
24100R2 - 1 HP 230V ................... $ 1,723.00 1 38
24150R2 - 1 1/2 HP 230V ............. $ 2,013.00 1 40
Three Wire
24100R3 - 1 HP 230V ................... $ 1,715.00
1 38
24150R3 - 1 1/2 HP 230V ............. $ 1,807.00 1 48
24150R3Z - 1 1/2 HP 230V - 3 Ph . $ 2,324.00 1 42
24150R3Y - 1 1/2 HP 460V - 3 Ph $ 2,324.00 1 37
24200R3 - 2 HP 230V ................... $ 2,454.00 1 52
24200R3Z - 2 HP 230V - 3 Ph ....... $ 2,562.00 1 62
24200R3Y - 2 HP 460V - 3 Ph ...... $ 2,562.00 1 48
24300R3 - 3 HP 230V ................... $ 3,414.00 1 75
24300R3Z - 3 HP 230V - 3 Ph ....... $ 3,199.00 1 60
24300R3Y - 3 HP 460V - 3 Ph ...... $ 3,199.00 1 54
24500R3 - 5 HP 230V ................... $ 4,780.00 1 103
24500R3Z - 5 HP 230V - 3 Ph ....... $ 4,402.00 1 79
24500R3Y - 5 HP 460V - 3 Ph ...... $ 4,402.00 1 74
24750R3Z - 7 1/2 HP 230V - 3 Ph . $ 5,287.00 1 98
24750R3Y - 7 1/2 HP 460V - 3 Ph $ 5,287.00 1 97
241000R3Y - 10 HP 460V - 3 Ph .. $ 8,230.00 1 159
1 - 24000 Series - High Flow Stainless Steel Submersible Pumps 4"
40 GPM - G Series
Two Wire
24150G2 - 1 1/2 HP 230V ............ $ 2,193.00 1 37
Three Wire
24150G3 - 1 1/2 HP 230V ............ $ 2,164.00 1 48
24150G3Z - 1 1/2 HP 230V - 3 Ph $ 2,505.00 1 47
24150G3Y - 1 1/2 HP 460V - 3 Ph $ 2,505.00 1 40
24200G3 - 2 HP 230V .................. $ 2,594.00 1 51
24200G3Z - 2 HP 230V - 3 Ph ..... $ 2,701.00 1 47
24200G3Y - 2 HP 460V - 3 Ph ..... $ 2,701.00 1 46
24300G3 - 3 HP 230V .................. $ 3,596.00 1 73
24300G3Z - 3 HP 230V - 3 Ph ..... $ 3,386.00 1 60
24300G3Y - 3 HP 460V - 3 Ph ..... $ 3,386.00 1 51
24500G3 - 5 HP 230V .................. $ 5,053.00 1 99
24500G3Z - 5 HP 230V - 3 Ph ..... $ 4,676.00 1 75
24500G3Y - 5 HP 460V - 3 Ph ..... $ 4,676.00 1 71
24750G3Z - 7 1/2 HP 230V - 3 Ph $ 5,624.00 1 93
24750G3Y - 7 1/2 HP 460V - 3 Ph $ 5,624.00 1 93
13
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
24000 Series - High Flow Stainless Steel Submersible Pumps 4" - 1
55 GPM - S Series
Two Wire
24150S2 - 1 1/2 HP 230V ............. $ 2,318.00 1 40
Three Wire
24150S3 - 1 1/2 HP 230V ............. $ 2,288.00 1 44
24150S3Z - 1 1/2 HP 230V - 3 Ph
. $ 2,631.00 1 38
24150S3Y - 1 1/2 HP 460V - 3 Ph ..
$ 2,631.00 1 39
24200S3 - 2 HP 230V ....................$ 2,811.00 1 49
24200S3Z - 2 HP 230V - 3 Ph ...... $ 2,920.00 1 44
24200S3Y - 2 HP 460V - 3 Ph ...... $ 2,920.00 1 44
24300S3 - 3 HP 230V ................... $ 3,574.00 1 61
24300S3Z - 3 HP 230V - 3 Ph ...... $ 3,362.00 1 51
24300S3Y - 3 HP 460V - 3 Ph ...... $ 3,362.00 1 51
24500S3 - 5 HP 230V ................... $ 4,931.00 1 96
24500S3Z - 5 HP 230V - 3 Ph ...... $ 4,555.00 1 74
24500S3Y - 5 HP 460V - 3 Ph ...... $ 4,555.00 1 73
24750S3Z - 7 1/2 HP 230V - 3 Ph
..$ 5,411.00 1 97
24750S3Y - 7 1/2 HP 460V - 3 Ph
..$ 5,411.00 1 95
241000S3Y - 10 HP 460V - 3 Ph .. $ 7,879.00 1 107
60 GPM - Q Series
Two Wire
24150Q2 - 1 1/2 HP 230V .............$ 2,114.00 1 40
Three Wire
24150Q3 - 1 1/2 HP 230V ............ $ 2,084.00 1 43
24150Q3Z - 1 1/2 HP 230V - 3 Ph
. $ 2,426.00 1 38
24150Q3Y - 1 1/2 HP 460V - 3 Ph
. $ 2,426.00 1 39
24200Q3 - 2 HP 230V .................. $ 2,461.00 1 49
24200Q3Z - 2 HP 230V - 3 Ph ..... $ 2,569.00 1 44
24200Q3Y - 2 HP 460V - 3 Ph ..... $ 2,569.00 1 44
24300Q3 - 3 HP 230V .................. $ 3,475.00 1 61
24300Q3Z - 3 HP 230V - 3 Ph ..... $ 3,265.00 1 51
24300Q3Y - 3 HP 460V - 3 Ph ..... $ 3,265.00 1 51
24500Q3 - 5 HP 230V .................. $ 4,785.00 1 96
24500Q3Z - 5 HP 230V - 3 Ph ..... $ 4,407.00 1 74
24500Q3Y - 5 HP 460V - 3 Ph ..... $ 4,407.00 1 73
24750Q3Z - 7 1/2 HP 230V - 3 Ph
. $ 5,151.00 1 97
24750Q3Y - 7 1/2 HP 460V - 3 Ph .
$ 5,151.00 1 95
80 GPM - T Series
Three Wire
24300T3 - 3 HP 230V ....................$ 3,411.00 1 59
24300T3Z - 3 HP 230V - 3 Ph ...... $ 3,199.00 1 49
24300T3Y - 3 HP 460V - 3 Ph ...... $ 3,199.00 1 49
24500T3 - 5 HP 230V ................... $ 4,744.00 1 92
24500T3Z - 5 HP 230V - 3 Ph ...... $ 4,367.00 1 71
24500T3Y - 5 HP 460V - 3 Ph ...... $ 4,367.00 1 70
24750T3Z - 7 1/2 HP-230V - 3 Ph
. $ 5,497.00 1 94
24750T3Y - 7 1/2 HP 460V - 3 Ph
. $ 5,497.00 1 92
High Flow Stainless Steel Pump Ends
35 GPM - R Series
24100R - 1 HP .................... $ 8 6 1 . 0 0 1 8
24150R - 1 1/2 HP ............... $ 885.00 1 9
24200R - 2 HP .................. $ 1,058.00 1 11
24300R - 3 HP .................. $ 1,334.00 1 13
24500R - 5 HP .................. $ 1,780.00 1 18
24750R - 7
1/2
HP ............ $ 2,145.00 1 26
241000R - 10 HP .............. $ 3 , 0 9 6 . 0 0 1 3 1
40 GPM - G Series
24150G - 1 1/2 HP ............ $ 1,065.00 1 7
24200G - 2 HP .................. $ 1,196.00 1 8
24300G - 3 HP .................. $ 1,521.00 1 9
24500G - 5 HP .................. $ 2,052.00 1 13
24750G - 7 1/2 HP ............ $ 2,480.00 1 18
55 GPM - S Series
24150S - 1 1/2 HP ............ $ 1,191.00 1 10
24200S - 2 HP .................. $ 1,415.00 1 12
24300S - 3 HP ................. $ 1,499.00 1 14
24500S - 5 HP .................. $ 1,929.00 1 20
24750S - 7 1/2 HP ............ $ 2,269.00 1 28
241000S - 10 HP .............. $ 2,744.00 1 35
60 GPM - Q Series
24150Q - 1 1/2 HP ............... $ 985.00 1 9
24200Q - 2 HP .................. $ 1,063.00 1 10
24300Q - 3 HP .................. $ 1,399.00 1 12
24500Q - 5 HP .................. $ 1,782.00 1 16
24750Q - 7 1/2 HP ............ $ 2,009.00 1 23
80 GPM - T Series
24300T - 3 HP .................. $ 1,334.00 1 10
24500T - 5 HP ................. $ 1,745.00 1 16
24750T - 7 1/2 HP ............ $ 2,354.00 1 22
14 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
5 GPM - J Series
26050J - 1/2 HP ................................... $ 685.00 1 9
26075J - 3/4 HP ................................... $ 865.00 1 11
26100J - 1 HP ................................. $ 1,114.00 1 13
26150J - 1 1/2 HP .............................$ 1,293.00 1 14
26200J - 2 HP .................................$ 1,944.00 1 16
10 GPM - K Series
26050K - 1/2 HP .................................. $ 446.00 1 7
26075K - 3/4 HP .................................. $ 644.00 1 8
26100K - 1 HP .................................... $ 803.00 1 10
26150K - 1 1/2 HP ............................ $ 1,061.00 1 13
26200K - 2 HP ................................. $ 1,136.00 1 16
26300K - 3 HP ................................. $ 1,793.00 1 25
18 GPM - P Series
26050P - 1/2 HP .................................. $ 477.00 1 6
26075P - 3/4 HP .................................. $ 637.00 1 6
26100P - 1 HP .................................... $ 704.00 1 7
26150P - 1 1/2 HP ............................... $ 749.00 1 9
26200P - 2 HP ................................. $ 1,017.00 1 11
26300P - 3 HP ................................. $ 1,195.00 1 13
26500P - 5 HP ................................. $ 1,911.00 1 26
22050L2AB - 1/2 HP ........................... $ 635.00 1 19
22075L2AB - 3/4 HP ........................... $ 673.00 1 23
25 GPM - M Series
26050M - 1/2 HP ................................. $ 574.00 1 6
26075M - 3/4 HP ................................. $ 669.00 1 6
26100M - 1 HP .................................... $ 767.00 1 6
26150M - 1 1/2 HP .............................. $ 864.00 1 7
26200M - 2 HP .................................$ 1,008.00 1 9
26300M - 3 HP .................................$ 1,158.00 1 10
26500M - 5 HP .................................$ 1,687.00 1 16
26750M - 7 1/2 HP ...........................$ 3,388.00 1 28
40 GPM - G Series
26100G - 1 HP .................................... $ 878.00 1 9
26150G - 1 1/2 HP .............................. $ 974.00 1 10
26200G - 2 HP .................................$ 1,076.00 1 12
26300G - 3 HP .................................$ 1,345.00 1 14
26500G - 5 HP .................................$ 2,180.00 1 17
26750G - 7 1/2 HP ...........................$ 4,008.00 1 27
261000G - 10 HP .............................$ 5,790.00 1 37
70 GPM - H Series
26200H - 2 HP .................................$ 1,106.00 1 9
26300H - 3 HP .................................$ 1,347.00 1 11
26500H - 5 HP .................................$ 2,384.00 1 14
26750H - 7 1/2 HP ............................$ 2,822.00 1 24
261000H - 10 HP ..............................$ 4,135.00 1 29
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
1 - 26000 Series - Stainless Steel Submersible Pumps 4"
1 - Cistern Pumps
15
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
6618-116 - 1/3 HP, 115V ............. $ 129.00 1 3
6618-117 - 1/3 HP, 230V ............ $ 129.00 1 3
6618-118 - 1/2 HP, 115V ............. $ 129.00 1 3
6618-119 - 1/2 HP, 230V ............. $ 129.00 1 3
6617-110 - 3/4 HP, 230V ............ $ 134.00 1 3
6617-111 - 1 HP, 230V ................ $ 138.00 1 3
6617-428 - 1 1/2 HP, 230V .......... $ 206.00 1 6
6617-113 - 2 HP, 230V ................ $ 323.00 1 7
6617-114 - 3 HP, 230V ................ $ 408.00 1 7
6617-133 - 5 HP, 230V ................ $ 594.00 1 8
6617-141 - 2 HP-Deluxe - (w/ Starter)-230V
..................................................... $ 458.00 1 8
6617-142 - 3 HP-Deluxe - (w/ Starter)-230V
..................................................... $ 531.00 1 8
6617-134 - 5 HP-Deluxe - (w/ Starter)-230V
..................................................... $ 677.00 1 12
6617-116 - 1/2 HP, 230V ............ $ 193.00 1 4
6617-117 - 3/4 HP, 230V ............ $ 195.00 1 4
6617-118 - 1 HP, 230V ................ $ 1 9 9 . 0 0 1 4
Pump-Tec w/ Remote
6617-425 Use w/ 1/3 -1 1/2 HP - Two & Three Wire -
115/230V ................................. $ 3 8 5 . 0 0 1 3
Pump-Tec Plus
6617-143 Use w/ 1/2 - 5 HP, 230V Motors
..................................................... $ 7 9 7 . 0 0 1 7
QD Pump-Tec
6617-145 Use w/ 1/3 - 1 HP,230V Motors
..................................................... $ 3 0 8 . 0 0 1 1
6617-430 - Duplex ..................... $1,246.00 1 4
SubDrive 15
6617-433 - Nema 3R Programmable .. $ 1,816.00 1 26
SubDrive 20
6617-435 - Nema 3R Programmable .. $ 1,877.00 1 26
SubDrive 30
6617-436 - Nema 3R Programmable .. $ 3,534.00 1 26
SubDrive 75
6617-156 - Nema 4............................... $ 2,226.00 1 29
SubDrive 100
6617-158 - Nema 4............................... $ 2,479.00 1 33
SubDrive 150
6617-155 - Nema 4............................... $ 3,985.00 1 33
SubDrive 300
6617-153 - Nema 4. ............................... $ 7 , 0 9 2 . 0 0 1 4 2
SubDrive 2W
6617-164 - Nema 3R ............................ $ 1,858.00 1 21
6617-432 use with 1/2, 3/4, or 1 HP single
phase pumps/motors Nema 3R
.............................................................. $ 1,922.00 1 20
6617-159 use with 1/2, 3/4, or 1 HP single
phase pumps/motors Nema 4
.............................................................. $ 2,349.00 1 29
6617-434 - MonoDriveXT use with 1 1/2 & 2 HP
single phase pumps/motors - Nema 3R
.............................................................. $ 1,957.00 1 26
6617-160 - MonoDriveXT use with 1 1/2 & 2 HP
single phase pumps/motors - Nema 4
.............................................................. $ 2,782.00 1 33
Monodrive Fan Kits
Fans & pressure sensor kit (use accessories discount)
6617-161 - Fan Kit - CP75 & Monodrive - Nema 4
................................................................. $ 140.00 1 3
6617-162 - Fan Kit CP100, 150, & Monodrive XT -
Nema 4 .................................................... $ 150.00 1 3
6617-163 - Fan Kit CP75 & Monodrive -
Pre08L45 - Nema 1 ................................. $ 144.00 1 2
6627-088 - Pressure Sensor Kit for CP75,100, 150
................................................................. $ 110.00 1 1
6617-431 - Pressure Sensor Kit for CP300
................................................................. $ 282.00 1 1
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
QD Control Boxes - Single Phase Nema 3R Programmable - SubDrive
Nema 4 - SubDrive
MonoDrive Controller
Deluxe Control Boxes - Single Phase
CRC Control Box
Pump-Tec
Alternator
Control Boxes & Motors - Submersible Pumps 4" - 1
Motor Adapter
6180-326 4" Pump End x 6" Motor .....$ 391.00
(Use accessories discount)
16 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Franklin Electric
Two-Wire (Single Phase) w/ lead assembly
3129-731 1/3 HP, 115V ................ $ 692.00 1 16
3129-732 1/3 HP, 230V ............... $ 692.00 1 16
3129-736 1/2 HP, 115V ................ $ 673.00 1 19
3129-733 1/2 HP, 230V ............... $ 673.00 1 18
3129-734 3/4 HP, 230V ................$ 811.00 1 21
3129-735 1 HP, 230V .................. $ 869.00 1 23
3129-755 1 1/2 HP, 230V ......... $ 1 , 1 3 5 . 0 0 1 3 1
Three-Wire(Single Phase) w/ lead assembly
3129-364 1/3 HP, 115V ................ $ 631.00 1 17
3129-365 1/3 HP, 230V ............... $ 631.00 1 17
3129-366 1/2 HP, 115V ................ $ 580.00 1 18
3129-367 1/2 HP, 230V .............. $ 580.00 1 19
3129-359 3/4 HP, 230V ............... $ 687.00 1 21
3129-360 1 HP, 230V .................. $ 715.00 1 24
3129-361 1 1/2 HP, 230V ............ $ 889.00 1 29
3129-396 2 HP, 230V .............. $ 1,066.00 1 33
3129-363 3 HP, 230V ............... $ 1,628.00 1 43
3129-880 3 HP, 230V 1500# thrust .$ 1,804.00 1 49
3129-717 5 HP, 230V ............... $ 2 , 2 6 4 . 0 0 1 6 6
Three-Wire (Three Phase) w/ lead assembly
3129-788 1/2 HP, 230V .............. $ 692.00 1 18
3129-789 1/2 HP, 460V ............... $ 692.00 1 18
3129-853 3/4 HP, 200V ............... $ 792.00 1 21
3129-790 3/4 HP, 230V .............. $ 792.00 1 21
3129-791 3/4 HP, 460V .............. $ 792.00 1 21
3129-856 1 HP, 200V ................. $ 848.00 1 24
3129-792 1 HP, 230V .................. $ 848.00 1 24
3129-793 1 HP, 460V .................. $ 8 4 8 . 0 0 1 2 4
3129-839 1 1/2 HP, 200V ............ $ 871.00 1 24
3129-794 1 1/2 HP, 230V ............ $ 871.00 1 24
3129-795 1 1/2 HP, 460V ............ $ 871.00 1 24
3129-869 1 1/2 HP, 575V ............ $ 871.00 1 24
3129-798 2 HP, 200V .................. $ 937.00 1 29
3129-796 2 HP, 230V .................. $ 937.00 1 29
3129-797 2 HP, 460V .................. $ 937.00 1 29
3129-855 2 HP, 575V .................. $ 937.00 1 29
3129-846 3 HP, 200V ............... $ 1,273.00 1 35
3129-709 3 HP, 230V ............... $ 1,273.00 1 34
3129-807 3 HP, 460V ............... $ 1,273.00 1 35
3129-868 3 HP, 575V .............. $ 1,273.00 1 35
3129-847 5 HP, 200V .............. $ 2,020.00 1 53
3129-718 5 HP, 230V ............... $ 2,020.00 1 52
3129-808 5 HP, 460V .............. $ 2,020.00 1 52
3129-835 5 HP, 575V ............... $ 2,020.00 1 52
3129-848 7 1/2 HP, 200V ......... $ 2,532.00 1 66
3129-783 7 1/2 HP, 230V ......... $ 2,532.00 1 68
3129-784 7 1/2 HP, 460V ......... $ 2,532.00 1 66
3129-866 7 1/2 HP, 575V ......... $ 2,532.00 1 66
3129-785 10 HP, 460V ............. $ 4 , 4 9 4 . 0 0 1 7 8
3129-883 10 HP, 575V ............. $ 4 , 4 9 4 . 0 0 1 7 7
Contactors w/ 200V Coil
3131-290 1/2 HP, 200V ............... $ 552.00 1 6
3131-291 3/4 HP, 200V ............... $ 552.00 1 6
3131-292 1 HP, 200V .................. $ 552.00 1 6
3131-293 1 1/2 HP, 200V ............ $ 552.00 1 6
3131-294 2 HP, 200V .................. $ 552.00 1 6
3131-295 3 HP, 200V .................. $ 552.00 1 6
3131-296 5 HP, 200V .................. $ 5 5 2 . 0 0 1 6
3131-297 7 1/2 HP, 200V ............ $ 5 5 2 . 0 0 1 6
3131-298 10 HP, 200V ............. $ 1 , 1 7 2 . 0 0 1 9
3131-299 15 HP, 200V ............. $ 1 , 1 7 2 . 0 0 1 9
3131-300 20 HP, 200V ............. $ 1 , 7 9 9 . 0 0 1 2 0
3131-301 25 HP, 200V ............. $ 1 , 7 9 9 . 0 0 1 2 0
3131-302 30 HP, 200V ............. $ 1 , 7 9 9 . 0 0 1 2 0
Contactors w/ 230V Coil
3131-303 1/2 HP, 230V ............... $ 552.00 1 6
3131-304 3/4 HP, 230V ............... $ 552.00 1 6
3131-305 1 HP, 230V .................. $ 552.00 1 6
3131-306 1 1/2 HP, 230V ............ $ 552.00 1 6
3131-307 2 HP, 230V .................. $ 552.00 1 6
3131-308 3 HP, 230V .................. $ 552.00 1 6
3131-309 5 HP, 230V .................. $ 5 5 2 . 0 0 1 6
3131-310 7 1/2 HP, 230V ............ $ 5 5 2 . 0 0 1 6
3131-311 10 HP, 230V .............. $ 1 , 1 7 2 . 0 0 1 9
3131-312 15 HP, 230V ............. $ 1 , 1 7 2 . 0 0 1 9
3131-313 20 HP, 230V ............. $ 1 , 7 9 9 . 0 0 1 2 0
3131-314 25 HP, 230V ............. $ 1 , 7 9 9 . 0 0 1 2 0
3131-315 30 HP, 230V ............. $ 1 , 7 9 9 . 0 0 1 2 0
Contactors w/ 460V Coil
3131-316 1/2 HP, 460V ............... $ 552.00 1 6
3131-317 3/4 HP, 460V ............... $ 552.00 1 6
3131-318 1 HP, 460V .................. $ 552.00 1 6
3131-319 1 1/2 HP, 460V ............ $ 552.00 1 6
3131-320 2 HP, 460V .................. $ 552.00 1 6
3131-321 3 HP, 460V .................. $ 552.00 1 6
3131-322 5 HP, 460V .................. $ 5 5 2 . 0 0 1 6
3131-323 7 1/2 HP, 460V ............ $ 5 5 2 . 0 0 1 6
3131-324 10 HP, 460V ................ $ 5 5 2 . 0 0 1 6
3131-325 15 HP, 460V ................ $ 5 5 2 . 0 0 1 6
3131-326 20 HP, 460V ............. $ 1 , 1 7 2 . 0 0 1 9
3131-327 25 HP, 460V ............. $ 1 , 1 7 2 . 0 0 1 9
3131-328 30 HP, 460V ............. $ 1 , 1 7 2 . 0 0 1 9
3131-329 40 HP, 460V ............. $ 1 , 2 8 3 . 0 0 1 9
3131-330 50 HP, 460V ............. $ 1 , 8 1 0 . 0 0 1 2 0
3131-331 60 HP, 460V ............. $ 1 , 8 1 0 . 0 0 1 2 0
3131-332 75 HP, 460V ............. $ 1 , 8 1 0 . 0 0 1 2 0
IEC Contactors for three phase motors. Each kit includes Nema 1
enclosure, contactor, and overload assembled with the correct voltage
coil needed.
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
60 Hz - 4" Submersible Motors Contactors
1 - Motors - Submersible Pumps 4"
17
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Order by Model Number. Example: 90S3HP64
90S 3HP 6 4
Horsepower Pump Size
6"
8"
10"
Motor Bracket
4"
6"
8"
10"
3 HP
5 HP
7 1/2 HP
10 HP
15 HP
20 HP
25 HP
30 HP
40 HP
50 HP
60 HP
75 HP
85 HP
100 HP
125 HP
150 HP
175 HP
230 HP
Pump Model-GPM
90S - 90 GPM
150S - 150 GPM
230S - 230 GPM
300S - 300 GPM
400S - 400 GPM
500S - 500 GPM
650S - 650 GPM
800S - 800 GPM
1100S - 1100 GPM
NOTE: Motors, contactors/control panels, and check valves must be added for a complete set.
- For 6" pumps up to 10 HP with 4" motor adapters, call factory for pricing.
- The 4" motor adapter adds about 2" to the overall length of the pump.
6", 8", 10" Submersible Pumps - 2
90 GPM
90S3HP64 - 3 HP ............................ $ 1,315.00
1 16
90S5HP64 - 5 HP ............................ $ 1,653.00 1 21
90S7.5HP66 - 7 1/2 HP ................... $ 2,470.00 1 31
90S10HP66 - 10 HP ........................ $ 3,034.00 1 40
90S15HP66 - 15 HP ........................ $ 4,057.00 1 52
90S20HP66 - 20 HP ........................ $ 5,247.00 1 66
90S25HP66 - 25 HP .........................$ 6,112.00 1 78
90S30HP66 - 30 HP ........................ $ 7,278.00 1 91
90S40HP66 - 40 HP ........................ $ 7,883.00 1 104
150 GPM
150S5HP64 - 5 HP .......................... $ 1,709.00 1 22
150S7.5HP66 - 7 1/2 HP ................. $ 2,389.00 1 30
150S10HP66 - 10 HP ...................... $ 2,514.00 1 35
150S15HP66 - 15 HP ...................... $ 3,602.00 1 48
150S20HP66 - 20 HP ...................... $ 4,430.00 1 52
150S25HP66 - 25 HP ...................... $ 5,514.00 1 67
150S30HP66 - 30 HP ...................... $ 6,582.00 1 75
150S40HP66 - 40 HP .......................$ 9,114.00 1 97
150S50HP66 - 50 HP .................... $ 10,839.00 1 116
230 GPM
230S5HP64 - 5 HP .......................... $ 1,584.00 1 20
230S7.5HP66 - 7 1/2 HP ................. $ 1,751.00 1 25
230S10HP66 - 10 HP ...................... $ 2,241.00 1 35
230S15HP66 - 15 HP ...................... $ 2,727.00 1 40
230S20HP66 - 20 HP ...................... $ 3,397.00 1 50
230S25HP66 - 25 HP ...................... $ 4,249.00 1 50
230S30HP66 - 30 HP ...................... $ 4,857.00 1 81
230S40HP66 - 40 HP ...................... $ 6,949.00 1 76
230S50HP66 - 50 HP ...................... $ 8,940.00 1 99
230S60HP66 - 60 HP .................... $ 10,096.00 1 110
300 GPM
300S5HP64 - 5 HP .......................... $ 1,817.00 1 15
300S7.5HP66 - 7 1/2 HP ................. $ 2,355.00 1 21
300S10HP66 - 10 HP ...................... $ 2,603.00 1 21
300S15HP66 - 15 HP ...................... $ 2,937.00 1 35
300S20HP66 - 20 HP ...................... $ 3,253.00 1 46
300S25HP66 - 25 HP ...................... $ 3,832.00 1 52
300S30HP66 - 30 HP ...................... $ 4,950.00 1 63
300S40HP66 - 40 HP ...................... $ 5,614.00 1 66
300S50HP66 - 50 HP ...................... $ 6,797.00 1 108
300S60HP66 - 60 HP ...................... $ 7,928.00 1 96
400 GPM
400S5HP86 - 5 HP .......................... $ 3,308.00 1 56
400S7.5HP86 - 7 1/2 HP ................. $ 3,407.00 1 56
400S10HP86 - 10 HP ...................... $ 3,688.00 1 64
400S15HP86 - 15 HP ...................... $ 3,688.00 1 64
400S20HP86 - 20 HP ...................... $ 4,313.00 1 72
400S25HP86 - 25 HP ...................... $ 4,651.00 1 98
400S30HP86 - 30 HP ...................... $ 5,325.00 1 106
400S40HP86 - 40 HP ...................... $ 6,091.00 1 95
400S50HP86 - 50 HP ...................... $ 6,729.00 1 103
400S60HP86 - 60 HP ...................... $ 8,304.00 1 114
400S75HP88 - 75 HP .................... $ 10,325.00 1 130
400S100HP88 - 100 HP ................ $ 13,389.00 1 154
CTN
SIZE LIST QTY WT CTN
SIZE LIST QTY WT
6" Stainless Steel Pump Ends
8" Stainless Steel Pump Ends
18 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
500 GPM
500S5HP86 - 5 HP .......................... $ 3,562.00 1 56
500S7.5HP86 - 7 1/2 HP ................. $ 3,667.00 1 56
500S10HP86 - 10 HP ...................... $ 3,667.00 1 69
500S15HP86 - 15 HP ...................... $ 3,973.00 1 78
500S20HP86 - 20 HP ...................... $ 4,052.00 1 84
500S25HP86 - 25 HP ...................... $ 4,638.00 1 88
500S30HP86 - 30 HP ...................... $ 5,046.00 1 98
500S40HP86 - 40 HP ...................... $ 5,853.00 1 108
500S50HP86 - 50 HP ...................... $ 6,585.00 1 95
500S60HP86 - 60 HP ...................... $ 7,045.00 1 106
500S75HP88 - 75 HP ...................... $ 8,528.00 1 114
500S100HP88 - 100 HP .................$ 11,402.00 1 138
500S125HP88 - 125 HP ................ $ 13,755.00 1 154
650 GPM
Min. Well Size 9” ID
650S15HP106 - 15 HP ............................ $ 4,238.00 1 65
650S25HP106 - 25 HP ............................ $ 4,238.00
1 65
650S30HP106 - 30 HP ............................ $ 5,572.00 1 79
650S40HP106 - 40 HP ............................ $ 5,572.00 1 79
650S40HP106H - 40 HP ......................... $ 5,572.00 1 79
650S50HP106 - 50 HP ............................ $ 7,234.00 1 93
650S60HP106 - 60 HP ............................ $ 7,233.00 1 94
650S75HP108H - 75 HP ......................... $ 7,804.00 1 115
650S100HP108 - 100 HP ........................ $ 7 , 8 0 4 . 0 0 1 1 1 5
650S100HP108H - 100 HP ..................... $ 8,484.00
1 126
650S100HP108SH - 100 HP ................. $ 11,748.00
1 137
650S125HP108H - 125 HP ................... $ 11,748.00
1 137
650S125HP108SH - 125 HP ................. $ 13,783.00
1 148
800 GPM
Min. Well Size 10-12” ID
800S20HP106 - 20 HP ............................ $ 4,464.00 1 67
800S30HP106 - 30 HP ............................ $ 4,464.00
1 67
800S40HP106 - 40 HP ............................ $ 5,956.00 1 81
800S50HP106 - 50 HP ............................ $ 5,956.00 1 81
800S50HP106H - 50 HP ......................... $ 5,956.00
1 81
800S60HP106 - 60 HP ............................ $ 7 , 1 8 3 . 0 0 1 9 8
800S75HP108H - 75 HP ......................... $ 7,183.00 1 99
800S100HP108 - 100 HP ........................ $ 7,951.00
1 112
800S100HP108H - 100 HP ..................... $ 7,951.00
1 113
800S125HP108 - 125 HP ........................ $ 9,178.00 1 127
800S125HP108HH - 125 HP ................... $ 9,178.00
1 127
1100 GPM
1100S30HP106 - 30 HP .......................... $ 5,370.00 1 102
1100S40HP106 - 40 HP .......................... $ 5,370.00 1 102
1100S60HP106 - 60 HP .......................... $ 6,179.00
1 123
1100S75HP108 - 75 HP .......................... $ 6,179.00 1 123
1100S100HP108 - 100 HP ...................... $ 6,179.00 1 123
1100S100HP108H - 100 HP .................... $ 7,108.00
1 145
1100S125HP108 - 125 HP ...................... $ 7,108.00 1 145
1100S150HP108 - 150 HP ...................... $ 8,422.00 1 166
1100S150HP108HH - 150 HP ................. $ 8,422.00
1 166
1100S175HP1010 - 175 HP .................... $ 9,649.00
1 200
1100S200HP1010 - 200 HP .................... $ 9,649.00
1 200
1100S250HP1010 - 250 HP .................. $ 11,317.00
1 223
1100S250HP1010HH - 250 HP ............. $ 11,317.00
1 223
Adapters
6180-114 - 500SDA 5X6 Discharge Adaptor .. $ 255.00 1 7
(Use accessories discount)
Motor Adapter
6180-326 4" Pump End x 6" Motor ............ $ 391.00 1 6
(Use accessories discount)
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
2 - Submersible Pumps 6", 8", 10"
10" Stainless Steel Pump Ends
19
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
- Six-inch single-phase motors require control boxes.
- Six and eight-inch motors are equipped with Subtrol
transmitters as standard equipment.
Water Well - Single Phase
6201-101 - 5 HP, 230V ............. $ 3 , 9 1 6 . 0 0 1 11 5
6201-102 - 7 1/2 HP, 230V ....... $ 4,056.00 1 124
6201-103 - 10 HP, 230V ........... $ 4,227.00 1 145
6201-104 - 15 HP, 230V ........... $ 5 , 4 8 3 . 0 0 1 1 5 5
Water Well - Three Phase
6201-221 - 5 HP, 230V ............. $ 3,024.00 1 100
6201-222 - 5 HP, 460V ............ $ 3,024.00 1 100
6201-254 - 7 1/2 HP, 200V ....... $ 3,517.00 1 108
6201-223 - 7 1/2 HP, 230V ....... $ 3,517.00 1 108
6201-224 - 7 1/2 HP, 460V ....... $ 3,517.00 1 105
6201-180 - 7 1/2 HP, 575V ...... $ 3,517.00 1 108
6201-225 - 10 HP, 200V ........... $ 3 , 9 3 2 . 0 0 1 11 5
6201-226 - 10 HP, 230V ......... $ 3,932.00 1 115
6201-227 - 10 HP, 460V .......... $ 3,932.00 1 114
6201-249 - 10 HP, 575V ........... $ 3,932.00 1 116
6201-220 - 15 HP, 200V ........... $ 4 , 5 1 8 . 0 0 1 1 2 9
6201-228 - 15 HP, 230V ........... $ 4,518.00 1 128
6201-229 - 15 HP, 460V ........... $ 4,518.00 1 127
6201-252 - 15 HP, 575V ........... $ 4,518.00 1 129
6201-230 - 20 HP, 200V .......... $ 5 , 5 4 1 . 0 0 1 1 4 5
6201-231 - 20 HP, 230V ........... $ 5 , 5 4 1 . 0 0 1 1 4 5
6201-232 - 20 HP, 460V ........... $ 5 , 5 4 1 . 0 0 1 1 4 1
6201-253 - 20 HP, 575V ........... $ 5,541.00 1 145
6201-240 - 25 HP, 200V ........... $ 6,427.00 1 155
6201-233 - 25 HP, 230V ........... $ 6 , 4 2 7 . 0 0 1 1 6 0
6201-234 - 25 HP, 460V ........... $ 6 , 4 2 7 . 0 0 1 1 5 6
6201-244 - 30 HP, 200V ........... $ 7 , 4 4 9 . 0 0 1 1 7 4
6201-235 - 30 HP, 230V ........... $ 7 , 4 4 9 . 0 0 1 1 7 2
6201-236 - 30 HP, 460V ........... $ 7 , 4 4 9 . 0 0 1 1 6 8
6201-237 - 40 HP, 460V ........... $ 8 , 8 6 3 . 0 0 1 2 0 5
6201-250 - 40 HP, 575V ........... $ 8,863.00 1 202
6201-238 - 50 HP, 460V ..........$ 1 1 , 7 1 3 . 0 0 1 2 9 6
6201-242 - 50 HP, 575V ..........$ 11,713.00 1 300
6201-239 - 60 HP, 460V ......... $ 1 3 , 8 7 5 . 0 0 1 3 4 0
6201-245 - 60 HP, 575V ......... $ 1 3 , 8 7 5 . 0 0 1 3 8 0
Water Well - Three Phase
6201-140 - 40 HP, 460V ........ $ 1 3 , 9 8 8 . 0 0 1 3 6 6
6201-141 - 50 HP, 460V ......... $ 1 5 , 5 8 4 . 0 0 1 3 4 8
6201-142 - 60 HP, 460V ........ $ 2 0 , 4 9 0 . 0 0 1 4 3 6
6201-143 - 75 HP, 460V ......... $ 2 4 , 0 8 4 . 0 0 1 4 4 6
6201-144 - 100 HP, 460V ....... $ 2 8 , 2 6 5 . 0 0 1 5 2 2
6201-241 - 100 HP, 575V ....... $ 2 8 , 2 6 5 . 0 0 1 5 3 0
6201-248 - 125 HP, 460V ....... $ 37,070.00 1 700
6201-243 - 150 HP, 575V ....... $ 4 3 , 4 3 4 . 0 0 1 8 4 0
Water Well
Less Subtrol -
Three Phase
6201-050 - 5 HP, 230V ............. $ 3 , 0 9 0 . 0 0 1 1 0 0
6201-051 - 5 HP, 460V ............ $ 3 , 0 9 0 . 0 0 1 1 0 1
6201-052 - 7 1/2 HP, 230V ....... $ 3 , 6 0 0 . 0 0 1 1 0 5
6201-053 - 7 1/2 HP, 460V ....... $ 3 , 6 0 0 . 0 0 1 1 0 5
6201-054 - 7 1/2 HP, 575V ....... $ 3 , 6 0 0 . 0 0 1 1 0 5
6201-055 - 10 HP, 200V ........... $ 4 , 0 2 9 . 0 0 1 1 1 5
6201-056 - 10 HP, 230V ........... $ 4 , 0 2 9 . 0 0 1 1 1 5
6201-057 - 10 HP, 460V ........... $ 4 , 0 2 9 . 0 0 1 1 1 5
6201-058 - 10 HP, 575V ........... $ 4 , 0 2 9 . 0 0 1 1 1 5
6201-059 - 15 HP, 200V ........... $ 4 , 6 3 3 . 0 0 1 1 3 0
6201-060 - 15 HP, 230V ........... $ 4 , 6 3 3 . 0 0 1 1 3 0
6201-061 - 15 HP, 460V ........... $ 4 , 6 3 3 . 0 0 1 1 3 0
6201-062 - 15 HP, 575V ........... $ 4 , 6 3 3 . 0 0 1 1 3 0
6201-063 - 20 HP, 200V ........... $ 5 , 6 8 5 . 0 0 1 1 4 5
6201-064 - 20 HP, 230V ........... $ 5 , 6 8 5 . 0 0 1 1 4 5
6201-065 - 20 HP, 460V ........... $ 5 , 6 8 5 . 0 0 1 1 4 5
6201-066 - 20 HP, 575V ........... $ 5 , 6 8 5 . 0 0 1 1 4 5
6201-067 - 25 HP, 230V ........... $ 6 , 6 0 7 . 0 0 1 1 5 8
6201-068 - 25 HP, 460V ........... $ 6 , 6 0 7 . 0 0 1 1 5 8
6201-069 - 25 HP, 575V ........... $ 6 , 6 0 7 . 0 0 1 1 5 8
6201-070 - 30 HP, 230V ........... $ 7 , 6 6 0 . 0 0 1 1 7 2
6201-071 - 30 HP, 460V ........... $ 7 , 6 6 0 . 0 0 1 1 7 2
6201-072 - 30 HP, 575V ........... $ 7,660.00 1 172
- See page 15 for 3 & 5 HP control boxes for 4"
and 6" single phase motors.
- See page 34 for check valves.
No separate magnetic starter required.
6201-151 7 1/2 HP, 230V - Deluxe
.................................... $ 1,044.00 1 13
6201-152 10 HP, 230V - Deluxe
.................................... $ 1,530.00 1 15
6201-153 15 HP, 230V - Deluxe
.................................... $ 2,746.00 1 18
6201-154 7 1/2 HP, 230V - STD
....................................... $ 816.00 1 12
6201-155 10 HP, 230V - STD
.................................... $ 1,122.00 1 14
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
6" Franklin Electric Submersible Motors 6" Franklin Electric Submersible Motors
Control Boxes - Single Phase
8" Franklin Electric Submersible Motors
6", 8", 10" Motors & Controls - 2
20 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Three Phase - 60 HZ includes:
- Fusible Disconnect - H.O.A. & Start Button
- Solid state overload - Nema 3R enclosure
- 230 or 460 Volt coil
Does not include fuses.
Heaters not required.
With sub-
monitor
Without sub-
monitor
with
"ESP 200"
- Two-Pole 60 HZ Motors
- Field replaceable 200-inch leads included
- Three-year limited warranty (from date of installation)
- Control boxes or panels must be ordered separately
Single Phase
6202-100 - 5 HP, 230V ............. $ 3,146.00 1 154
6202-101 - 7 1/2 HP, 230V ....... $ 3,916.00 1 176
6202-102 - 10 HP, 230V ........... $ 4,193.00 1 176
6202-103 - 15 HP, 230V ........... $ 5,427.00 1 198
Three Phase
6202-104 - 5 HP, 230V ............. $ 2,993.00 1 110
6202-105 - 7 1/2 HP, 230V ....... $ 3,686.00 1 141
6202-106 - 10 HP, 230V ........... $ 3,814.00 1 137
6202-107 - 15 HP, 230V ........... $ 4,512.00 1 179
6202-108 - 20 HP, 230V ........... $ 5,556.00 1 198
6202-109 - 25 HP, 230V ........... $ 6,396.00 1 220
6202-110 - 30 HP, 230V ........... $ 7,546.00 1 243
6202-111 - 40 HP, 460V ............ $ 9,018.00 1 276
Contact factory for other sizes and prices.
Three Phase - Voltage Plug
6202-130 - 460V Voltage Plug....... $ 84.00 1 1
To change 230V to 460V on three phase motors
Control panels with Submonitor assembled to Furnas
pump control panel. Use with Franklin 6" and 8" three
phase motors
6201-197 - 5 HP, 230V ............. $ 6,397.00 1 34
6201-198 - 7 1/2 HP, 230V ....... $ 6,397.00 1 34
6201-199 - 10 HP, 230V ........... $ 6,397.00 1 42
6201-200 - 15 HP, 230V ........... $ 7,066.00 1 42
6201-201 - 20 HP, 230V ........... $ 7,889.00 1 80
6201-202 - 25 HP, 230V ........... $ 8,623.00 1 80
6201-203 - 30 HP, 230V ........... $ 9,109.00 1 80
6201-204 - 5 HP, 460V ............. $ 6,471.00 1 55
6201-205 - 7 1/2 HP, 460V ....... $ 6,471.00 1 55
6201-206 - 10 HP, 460V ........... $ 6,471.00 1 55
6201-207 - 15 HP, 460V ........... $ 6,799.00 1 34
6201-208 - 20 HP, 460V ........... $ 7,181.00 1 42
6201-209 - 25 HP, 460V ........... $ 7,181.00 1 42
6201-210 - 30 HP, 460V ........... $ 7,970.00 1 62
6201-211 - 40 HP, 460V ........... $ 8,843.00 1 62
6201-212 - 50 HP, 460V ........... $ 8,843.00 1 62
6201-213 - 60 HP, 460V ..........$ 11,757.00 1 80
6201-214 - 75 HP, 460V ..........$ 11,757.00 1 130
6201-215 - 100 HP, 460V ....... $ 12,276.00 1 130
6201-216 - 125 HP, 460V ........ $20,937.00 1 150
6201-217 - 150 HP, 460V ........ $20,937.00 1 150
All items above include Premium Submonitor kit.
Submonitor Kits
6201-218 - Up to 200, 190-600V - Premium
.................................... $ 2,187.00 1 3.5
6201-219 - Up to 200, 190-600V - Standard
.................................... $ 1,584.00 1 3.5
Includes magnetic starter and “ESP 200” - Class 10 Overload
6617-000 - 2 HP Max. 230V .... $ 1,803.00 1 55
6617-001 - 3 HP Max. 230V ..... $ 1,803.00 1 55
6617-002 - 7 1/2 HP Max. 230V $ 1,803.00 1 55
6617-003 - 10 HP Max. 230V ... $ 2,142.00 1 55
6617-004 - 15 HP Max. 230V ... $ 2,421.00 1 55
6617-005 - 20 HP Max. 230V ... $ 3,197.00 1 90
6617-006 - 30 HP Max. 230V ... $ 3,446.00 1 90
6617-007 - 5 HP Max. 460V ..... $ 1,828.00 1 55
6617-008 - 10 HP Max. 460V ... $ 1,828.00 1 55
6617-009 - 15 HP Max. 460V ... $ 2,142.00 1 55
6617-010 - 25 HP Max. 460V ... $ 2,462.00 1 55
6617-011 - 30 HP Max. 460V ... $ 3,285.00 1 90
6617-012 - 50 HP Max. 460V ... $ 4,446.00 1 90
6617-013 - 75 HP Max. 460V ... $ 5,978.00 1 90
6617-014 - 100 HP Max. 460V $ 6,466.00 1 170
6617-015 - 200 HP Max. 460V $14,056.00 1 350
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
6" Hitachi Submersible Motors Furnas Control Panel w/Submonitor
Furnas Control Panel without Submonitor
2 - Motors & Controls 6", 8", 10"
21
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Jet Pumps - 4
Class# Gallons Base Position Connection Male or Expanion Expanion Option
2, 5, 7, 20, M = Metal V = Vertical Size Female Tanks Only for Tanks Only
32, 36, 52, - = No base H = Horizontal 3 = 3/4” M = Male P = Potable X = 5 Year
86, 96, 119 4 = 1” F = Female H = Hydronic Limited Warranty
5 = 1 1/4”
16 002 - V 3 M P X
Contact Factory for pricing on tanks with plastic bases, galvanized tanks, and glass lined tanks.
Diaphragm Tanks
16002-V3M ............................$ 1 5 9 . 0 0 1 6
16005-V3M ............................$ 2 1 7 . 0 0 1 9
16007-V3M ............................$ 3 5 1 . 0 0 1 1 1
16014-H4M ............................ $ 5 0 6 . 0 0 1 2 3
16020MV4F ...........................$ 3 7 8 . 0 0 1 3 1
16020-H4M ............................ $ 5 4 4 . 0 0 1 2 9
16032MV4F ...........................$ 5 6 3 . 0 0 1 4 1
16036MV4F ...........................$ 6 0 1 . 0 0 1 4 5
16052MV5F ...........................$ 8 7 0 . 0 0 1 7 4
16086MV5F ........................$ 1 , 1 5 8 . 0 0 1 1 0 5
16096MV5F ........................ $ 1 , 5 1 1 . 0 0 1 1 1 1
16119MV5F ........................$ 1,596.00 1 165
Universal Mounting Bracket
16000BRKT .............................$ 28.00 1 2
(Use accessories discount)
Potable Water Expansion Tanks
16002-V3MPX .........................$ 8 5 . 0 0 1 6
16005-V3MPX .......................$ 1 2 4 . 0 0 1 1 0
16005-V3MP - 2.1 gallon ......... $ 6 7 . 0 0 1 6
16012-V3MP - 4.4 gallon ......... $ 8 4 . 0 0 1 1 0
Hydronic Expansion Tanks
16002-V2MH ...........................$ 6 1 . 0 0 1 6
16005-V2MH ...........................$ 8 4 . 0 0 1 1 0
No "X" on Expansion have
1 Year Limited Warranty
BASE PRICE & QUANTITY DISCOUNT
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
8100 Series
Shallow Well Jet Pumps - High Capacity
8150 - 1/2 HP, 115/230V,
Noryl impeller ..................$ 7 0 6 . 0 0 1 4 6
8151 - 1/2 HP, 115/230V,
Brass impeller ..................$ 7 7 3 . 0 0 1 4 7
8170 - 3/4 HP, 115/230V,
Noryl impeller ..................$ 7 8 1 . 0 0 1 4 9
8171 - 3/4 HP, 115/230V,
Brass impeller ..................$ 9 0 8 . 0 0 1 4 9
8110 - 1 HP, 115/230V,
Noryl impeller ................. $ 8 3 7 . 0 0 1 5 2
8111 - 1 HP, 115/230V,
Brass impeller ..................$ 959.00 1 53
8100HP Series
Shallow Well Jet Pumps - High Pressure
8150HP - 1/2 HP, 115/230V,
Noryl impeller .................$ 7 0 6 . 0 0 1 4 6
8151HP - 1/2 HP, 115/230V,
Brass impeller ..................$ 7 7 3 . 0 0 1 4 7
8170HP - 3/4 HP, 115/230V,
Noryl impeller ..................$ 7 8 1 . 0 0 1 4 9
8171HP - 3/4 HP, 115/230V,
Brass impeller ..................$ 9 0 8 . 0 0 1 4 9
8110HP - 1 HP, 115/230V,
Noryl impeller ..................$ 8 3 8 . 0 0 1 5 2
8111HP - 1 HP, 115/230V,
Brass impeller ..................$ 959.00 1 53
DuraMAC
TM
Pump Tanks - 3
Non-Potable
Use Only
8500 Series
Shallow Well Jet Pumps
Square Flange - High Capacity
8530 - 1/3 HP, 115V,
Noryl impeller .............. $ 603.00 1 41
8531 - 1/3 HP, 115V,
Brass impeller ............. $ 662.00 1 42
8550 - 1/2 HP, 115/230V,
Noryl impeller .............. $ 619.00 1 41
8551 - 1/2 HP, 115/230V,
Brass impeller ............. $ 719.00 1 42
8570 - 3/4 HP, 115/230V,
Noryl impeller .............. $ 6 7 6 . 0 0 1 4 4
8571 - 3/4 HP, 115/230V,
Brass impeller ............. $ 7 9 1 . 0 0 1 4 4
8510 - 1 HP, 115/230V,
Noryl impeller ............. $ 7 4 1 . 0 0 1 4 5
8511 - 1 HP, 115/230V,
Brass impeller ............ $ 870.00 1 47
8500HP Series
Shallow Well Jet Pumps
Square Flange - High Pressure
8530HP - 1/3 HP, 115V -
Noryl impeller .............. $ 6 0 3 . 0 0 1 4 1
8531HP - 1/3 HP, 115V,
Brass impeller ............. $ 6 6 3 . 0 0 1 4 2
8550HP-1/2 HP, 115/230V,
Noryl impeller .............. $ 6 1 9 . 0 0 1 4 1
8551HP-1/2 HP, 115/230V,
Brass impeller ............. $ 7 1 9 . 0 0 1 4 2
8570HP-3/4 HP, 115/230V,
Noryl impeller .............. $ 6 7 6 . 0 0 1 4 4
8571HP-3/4 HP, 115/230V,
Brass impeller ............. $ 7 9 1 . 0 0 1 4 4
8510HP- 1 HP, 115/230V,
Noryl impeller .............. $ 7 4 1 . 0 0 1 4 5
8511HP- 1 HP, 115/230V,
Brass impeller ............. $ 870.00 1 47
22 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
8200 Series
Convertible Jet Pumps
8250 - 1/2 HP, 115/230V,
Plastic impeller ........... $ 693.00 1 42
8251 - 1/2 HP, 115/230V,
Brass impeller ............ $ 7 5 1 . 0 0 1 4 4
8270 - 3/4 HP, 115/230V,
Plastic impeller ........... $ 7 6 7 . 0 0 1 4 5
8271 - 3/4 HP, 115/230V,
Brass impeller ............ $ 897.00 1 45
8210 - 1 HP, 115/230V,
Plastic impeller ............ $ 8 2 1 . 0 0 1 4 8
8211 - 1 HP, 115/230V,
Brass impeller ............. $ 925.00 1 49
8600 Series
Convertible Jet Pumps - Square Flange
8630 - 1/3 HP, 115V,
Plastic impeller ............ $ 600.00 1 35
8631 - 1/3 HP, 115V,
Brass impeller ............. $ 658.00 1 37
8650 - 1/2 HP, 115/230V,
Plastic impeller ............ $ 600.00 1 39
8651 - 1/2 HP, 115/230V,
Brass impeller ............. $ 694.00 1 40
8670 - 3/4 HP, 115/230V,
Plastic impeller ............ $ 6 7 4 . 0 0 1 4 0
8671 - 3/4 HP, 115/230V,
Brass impeller ............. $ 7 8 9 . 0 0 1 4 1
8610 - 1 HP, 115/230V,
Plastic impeller ........... $ 7 4 1 . 0 0 1 4 2
8611 - 1 HP, 115/230V,
Brass impeller ............ $ 870.00 1 44
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Multi-Stage Jet Pumps
4 - Jet Pumps
1500 Series
1575 - 3/4 HP, 115/230V,
Brass impeller .......... $ 1,705.00 1 64
1575P - 3/4 HP, 115/230V,
Plastic impeller ....... $ 1,487.00 1 62
1510 - 1 HP, 115/230V,
Brass impeller ......... $ 1,887.00 1 67
1510P - 1 HP, 115/230V,
Plastic impeller ......... $ 1,580.00 1 65
1500SW Series (SW = No regulating valve)
1575SW - 3/4 HP, 115/230V,
Brass impeller .......... $ 1,616.00 1 62
1575SWP - 3/4 HP, 115/230V,
Plastic impeller ........ $ 1,395.00 1 60
1510SW - 1 HP, 115/230V,
Brass impeller .......... $ 1,703.00 1 65
1510SWP - 1 HP, 115/230V,
Plastic impeller ......... $ 1,481.00 1 64
1515SW - 1 1/2 HP, 115/230V,
Brass impeller .......... $ 1,766.00 1 69
1515SWP - 1 1/2 HP, 115/230V,
Plastic impeller ........ $ 1,544.00 1 66
1000 Series
1075 - 3/4 HP, 115/230V,
Brass impeller ......... $ 1,766.00 1 65
1075P - 3/4 HP, 115/230V,
Plastic impeller ........ $ 1,544.00 1 60
1010 - 1 HP, 115/230V,
Brass impeller ......... $ 1,859.00 1 69
1010P - 1 HP, 115/230V,
Plastic impeller ........ $ 1 , 6 3 3 . 0 0 1 6 6
1000SW Series
1075SW - 3/4 HP, 115/230V,
Brass impeller ......... $ 1,717.00 1 66
1075SWP - 3/4 HP, 115/230V,
Plastic impeller ......... $ 1,498.00 1 60
1010SW - 1 HP, 115/230V,
Brass impeller .......... $ 1,824.00 1 68
1010SWP - 1 HP, 115/230V,
Plastic impeller ......... $ 1,604.00 1 66
1015SW - 1 1/2 HP, 115/230V,
Brass impeller .......... $ 1,913.00 1 68
1015SWP - 1 1/2 HP, 115/230V,
Plastic impeller ......... $ 1,694.00 1 63
23
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Shallow Well
Multi-Stage
659JP For 1575 .............................$ 11 4 . 0 0 1 5
658JP For 1510 .............................$ 11 4 . 0 0 1 5
652JP For 1515 .............................$ 114 . 0 0 1 5
Deep Well
Multi-Stage
4" Two Pipe
7109MP For 1075 & 1575, 30/70’
.....$ 220.00 1 4
7110MP For 1075 & 1575, 60/110’
....$ 220.00 1 4
7111MP For 1075 & 1575, 90/150’
....$ 220.00 1 4
7112MP For 1010 & 1510, 30/80’
......$ 220.00 1 3
7113MP For 1010 & 1510, 60/120’
... $ 220.00 1 3
7114MP For 1010 & 1510, 100/160’
..$ 220.00 1 3
To order less foot valve, add L to model number.
2" Single Pipe
7125MP For 1075 & 1575, 30/70’
...$ 262.00 1 3
7126MP For 1075 & 1575, 60/110’
.. $ 262.00 1 3
7127MP For 1075 & 1575, 90/150’
.$ 262.00 1 3
7128MP For 1010 & 1510, 30/80’ .....
$ 262.00 1 3
7129MP For 1010 & 1510, 60/120’
.$ 262.00 1 3
7130MP For 1010 & 1510, 100/150
’ ..
$ 262.00 1 3
To order less foot valve, add L to model number.
Shallow Well
Single Stage Jet Pumps - High Capacity
650JP - 1/3 HP ....................... $ 114.00 1 5
651JP - 1/2 HP ....................... $ 114.00 1 5
652JP - 3/4 HP ....................... $ 114.00 1 5
653JP - 1 HP .......................... $ 114.00 1 5
High Pressure
654JP - 1/3 HP ....................... $ 114.00 1 5
655JP - 1/2 HP ....................... $ 114.00 1 5
656JP - 3/4 HP ....................... $ 114.00 1 5
657JP - 1 HP .......................... $ 114.00 1 5
Deep Well
Single Stage Jet Pumps - 4" Two Pipe
7502JP - 1/3 HP - 30/50’ ........ $ 166.00 1 6
7503JP - 1/3 HP - 40/70’ ........ $ 166.00 1 4
7508JP - 1/2 HP - 30/50’ ........ $ 166.00 1 4
7509JP - 1/2 HP - 40/80’ ........ $ 166.00 1 4
7901JP - 3/4 & 1 HP - 30/50’ .. $ 166.00 1 4
7902JP - 1 HP - 50/80’ ........... $ 166.00 1 4
7903JP - 1 HP - 80/110’ .......... $ 166.00 1 4
7906JP - 3/4 HP - 50/80’ ........ $ 166.00 1 4
7907JP - 3/4 HP - 80/100’ ...... $ 166.00 1 4
To order less foot valve, add L to model number.
2" Single Pipe
7733JP - 1/3 HP - 30/50’ ........ $ 214.00 1 3
7734JP - 1/3 HP - 40/70’ ........ $ 214.00 1 3
7735JP - 1/2 HP - 30/50’ ........ $ 214.00 1 3
7736JP - 1/2 HP - 40/70’ ........ $ 214.00 1 3
7808JP - 3/4 & 1 HP - 30/50’ .. $ 214.00 1 3
7809JP - 1 HP - 50/80’ ........... $ 214.00 1 3
7810JP - 1 HP - 80/110’ .......... $ 214.00 1 4
7812JP - 3/4 HP - 50/80’ ........ $ 214.00 1 3
7813JP - 3/4 HP - 80/100’ ...... $ 214.00 1 4
To order less foot valve, add L to model number.
Ejector Packages - 4
All tapped for 1 1/4" suction pipe.
Gaskets, bolts and washers included.
100-4 - Casing Adapter Plate
6316-114..........................$ 162.00 1 2
1 0 1 - 2 " F o r a l l 8 2 0 0 / 8 6 0 0 & 1 5 0 0 s e r i e s
6450-103 .........................$ 150.00 1 9
106 - 2" For all 1000,8200,8600,1500 series
6450-110 .........................$ 275.00 1 9
108 - 4" For all 1000 series
6421-124 .........................$ 125.00 1 3
Casing, Adapters, and Flanges
8200/8600 Ejector Packages 1000/1500 Ejector Packages
24 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
5 - DuraMAC
TM
Booster Pumps
DuraMACTM
Vertical Multistage Variable Speed
Simplex Booster System
Features
- Easy set-up installation
- Variable speed control
- Stainless Steel pump
- Energy Efcient NEMA TEFC motors
- Liquid lled gauges
- Wafer check valves with soft seat
- Stainless Steel base
- 2” Brass No-Lead isolation valves
- NEMA 1 Enclosure
- Suction and discharge transducers
- Fused disconnect
- 2” Suction and discharge
MODELS AVAILABLE
Model Description Pump Boost Voltage HP List Price
17062V080Y-1 62 PSI 230V VFD Booster 62 PSI 230 Single Phase 3
17062V080Y-3 62 PSI 230V VFD Booster 62 PSI 230 Three Phase 3
17084V080Y-1 84 PSI 230V VFD Booster 84 PSI 230 Single Phase 5
17084V080Y-3 84 PSI 230V VFD Booster 84 PSI 230 Three Phase 5
17104V080Y-1 104 PSI 230V VFD Booster 104 PSI 230 Single Phase 5
17104V080Y-3 104 PSI 230V VFD Booster 104 PSI 230 Three Phase 5
17150V080Y-3 150 PSI 230V VFD Booster 150 PSI 230 Three Phase 7 1/2 CONTACT
17142V120Y-3 142 PSI 230V VFD Booster 142 PSI 230 Three Phase 10 FACTORY
17056V120Y-1 56 PSI 230V VFD Booster 56 PSI 230 Single Phase 5
17060V140Y-3 60 PSI 230V VFD Booster 60 PSI 230 Three Phase 5
17088V140Y-3 88 PSI 230V VFD Booster 88 PSI 230 Three Phase 7 1/2
17062V080Y-34 62 PSI 460V VFD Booster 62 PSI 460 Three Phase 3
17084V080Y-34 84 PSI 460V VFD Booster 84 PSI 460 Three Phase 5
17104V080Y-34 104 PSI 460V VFD Booster 104 PSI 460 Three Phase 5
17150V080Y-34 150 PSI 460V VFD Booster 150 PSI 460 Three Phase 7 1/2
17142V120Y-34 142 PSI 460V VFD Booster 142 PSI 460 Three Phase 10
17060V140Y-34 60 PSI 460V VFD Booster 60 PSI 460 Three Phase 5
17088V140Y-34 88 PSI 460V VFD Booster 88 PSI 460 Three Phase 7 1/2
25
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps shown on this page do not include pressure switches.
DuraMAC
TM
Booster Pumps - 5
DuraMACTM
Vertical Multistage Variable Speed
Duplex Booster System
MODELS AVAILABLE
Model Description Pump Boost Voltage HP List Price
17062V160Y-1 62 PSI 230V VFD Booster 62 PSI 230 Single Phase 3
17062V160Y-3 62 PSI 230V VFD Booster 62 PSI 230 Three Phase 3
17084V160Y-1 84 PSI 230V VFD Booster 84 PSI 230 Single Phase 5
17084V160Y-3 84 PSI 230V VFD Booster 84 PSI 230 Three Phase 5
17104V160Y-1 104 PSI 230V VFD Booster 104 PSI 230 Single Phase 5
17104V160Y-3 104 PSI 230V VFD Booster 104 PSI 230 Three Phase 5
17150V160Y-3 150 PSI 230V VFD Booster 150 PSI 230 Three Phase 7 1/2
17142V240Y-3 142 PSI 230V VFD Booster 142 PSI 230 Three Phase 10 CONTACT
17056V240Y-1 56 PSI 230V VFD Booster 56 PSI 230 Single Phase 5 FACTORY
17060V280Y-3 60 PSI 230V VFD Booster 60 PSI 230 Three Phase 5
17088V280Y-3 88 PSI 230V VFD Booster 88 PSI 230 Three Phase 7 1/2
17084V160Y-34 84 PSI 460V VFD Booster 84 PSI 460 Three Phase 5
17104V160Y-34 104 PSI 460V VFD Booster 104 PSI 460 Three Phase 5
17150V160Y-34 150 PSI 460V VFD Booster 150 PSI 460 Three Phase 7 1/2
17142V240Y-34 142 PSI 460V VFD Booster 142 PSI 460 Three Phase 10
17060V280Y-34 60 PSI 460V VFD Booster 60 PSI 460 Three Phase 5
17088V280Y-34 88 PSI 460V VFD Booster 88 PSI 460 Three Phase 7 1/2
Features
- Easy set-up installation
- Variable speed control
- Stainless Steel pump
- Energy Efcient NEMA TEFC motors
- Liquid lled gauges
- Wafer check valves with soft seat
- Stainless Steel base
- 2” Brass No-Lead isolation valves
- NEMA 1 Enclosure
- Suction and discharge transducers
- Fused disconnect
- 3” Flanged Stainless Steel Manifolds
26 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
DuraMACTM
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
- Easy Set-up and Installation
- Digital Control
- Dry-Run Protection
- Durable Stainless Steel and
No-Lead Brass Connections
The World’s Most Versatile Booster System
Residential Boosters
17035R020PC1 - 35 PSI 120V System ...$ 1,511.00 1 33
17052R020PC1 - 52 PSI 120V System ...$ 1,697.00 1 37
17070R020PC2 - 70 PSI 230V System ...$ 2,022.00 1 40
Light Commercial Boosters
17040C035PC2 - 40 PSI 230V System ...$ 1,963.00 1 38
17062C035PC2 - 62 PSI 230V System ...$ 2,070.00 1 41
17078C035PC2 - 78 PSI 230V System ...$ 2,183.00 1 35
Dual-Mode Modular
17044C070PC2-M - 44 PSI 230V System .... $ 3,007.00 1 56
17060C070PC2-M - 60 PSI 230V System .... $ 3,196.00 1 56
Dual-Mode Simplex
17044C070PC2-S - 44 PSI 230V System ..... $ 5,198.00 1 168
17060C070PC2-S - 60 PSI 230V System ..... $ 6,053.00 1 168
Dual-Mode Duplex
17044C120PC2-D - 44 PSI 230V System ... $ 10,860.00 1 252
17060C120PC2-D - 60 PSI 230V System ... $ 12,239.00 1 252
See Pumps & Accessories Price List for Limited Warranty details.
Light CommercialResidential
Dual-Mode Dual-Mode Dual-Mode
Modular Simplex Duplex
Commercial Boosters
5 - DuraMAC
TM
Booster Pumps
6 - Centrifugal Pumps - 27000 Super Booster
Water Pressure Booster System
CTN
LIST QTY WT
CTN
LIST QTY WT
5 GPM - J Series
27050JHB - 1/2 HP ........................... $ 1,223.00 1 38
27075JHB - 3/4 HP ........................... $ 1,359.00 1 45
27100JHB - 1 HP .............................. $ 1,551.00 1 46
7 GPM - V Series
27050VHB - 1/2 HP ..........................$ 1,086.00 1 36
27075VHB - 3/4 HP ..........................$ 1,166.00 1 43
27100VHB - 1 HP .............................$ 1,347.00 1 44
10 GPM - K Series
27050KHB - 1/2 HP .............................$ 984.00 1 36
27075KHB - 3/4 HP ..........................$ 1,068.00 1 38
27100KHB - 1 HP .............................$ 1,191.00 1 42
27150KHB - 1 1/2 HP .......................$ 1,391.00 1 53
27200KHB - 2 HP .............................$ 1,740.00 1 54
15 GPM - L Series
27050LHB - 1/2 HP ..........................$ 1,168.00 1 35
27075LHB - 3/4 HP ..........................$ 1,224.00 1 36
27100LHB - 1 HP .............................$ 1,333.00 1 41
27150LHB - 1 1/2 HP .......................$ 1,611.00 1 52
27200LHB - 2 HP .............................$ 1,752.00 1 47
20 GPM - P Series
27075PHB - 3/4 HP ..........................$ 1,193.00 1 40
27100PHB - 1 HP .............................$ 1,293.00 1 37
27150PHB - 1 1/2 HP .......................$ 1,512.00 1 52
27200PHB - 2 HP .............................$ 1,840.00 1 47
25 GPM - M Series
27100MHB - 1 HP ............................$ 1,191.00 1 37
27150MHB - 1 1/2 HP ......................$ 1,390.00 1 49
27200MHB - 2 HP ............................$ 1,840.00 1 52
27
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
8600SW Series - Plastic Impeller
8650SW - 1/2 HP, 115/230V .............. $ 5 6 4 . 0 0 1 3 7
8670SW - 3/4 HP, 115/230V ............... $ 6 1 3 . 0 0 1 3 9
8610SW - 1 HP, 115/230V ................. $ 672.00 1 41
84000 Series - Self-Priming
84300 - 3 HP 230V ......................... $ 2 , 6 7 6 . 0 0 1 1 3 6
84500 - 5 HP 230V .......................... $ 2 , 8 0 4 . 0 0 1 1 4 6
Cast Iron Impeller
87000 Series - Rainmaker
Self-Priming
87070 3/4 HP ...................................... $ 8 3 7 . 0 0 1 4 5
87100 1 HP ........................................ $ 9 0 4 . 0 0 1 4 8
87150 1 1/2 HP ................................... $ 9 7 2 . 0 0 1 5 1
87200 2 HP ..................................... $ 1,071.00 1 51
88000 Series - Self-Priming
88075 - 3/4 HP 115/230V .................. $ 9 3 5 . 0 0 1 6 0
88100 - 1 HP 115/230V ................... $ 1 , 0 0 3 . 0 0 1 6 5
88150 - 1 1/2 HP 115/230V ............. $ 1 , 0 4 0 . 0 0 1 7 0
88200 - 2 HP 230V .......................... $ 1,366.00 1 73
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Pumps shown on this page do not include pressure switches.
27000 Series Pump Ends Only
Centrifugal Pumps - 6
90000 Series - Workhorse
Single Phase
92030 - 1/3 HP, 115/230V-Plastic ....... $ 5 8 4 . 0 0 1 3 6
92031 - 1/3 HP, 115/230V-Brass ........ $ 6 8 3 . 0 0 1 3 2
92050 - 1/2 HP, 115/230V-Plastic ....... $ 6 1 7 . 0 0 1 3 6
92051 - 1/2 HP, 115/230V-Brass ........ $ 7 1 4 . 0 0 1 3 4
92070 - 3/4 HP, 230/115V-Plastic ....... $ 6 7 3 . 0 0 1 3 6
92100 - 1 HP, 230/115V-Plastic .......... $ 7 3 9 . 0 0 1 3 8
92150 - 1 1/2 HP, 230/115V-Plastic .... $ 8 1 7 . 0 0 1 4 2
92200 - 2 HP, 230V-Plastic .............. $ 1 , 0 5 6 . 0 0 1 4 3
92250 - 2 1/2 HP, 230V-Plastic ........ $ 1 , 2 7 3 . 0 0 1 4 3
92300 - 3 HP, 230V-Plastic .............. $ 1 , 5 2 1 . 0 0 1 5 4
Three Phase
93050 - 1/2 HP, 230/460V-Plastic ....... $ 6 3 8 . 0 0 1 3 2
93051 - 1/2 HP, 230/460V-Brass ........ $ 7 3 9 . 0 0 1 3 3
93070 - 3/4 HP, 230/460V-Plastic ....... $ 6 9 7 . 0 0 1 3 4
93100 - 1 HP, 230/460V-Plastic .......... $ 7 4 0 . 0 0 1 3 7
93150 - 1 1/2 HP, 230/460V-Plastic .... $ 8 8 9 . 0 0 1 4 1
93200 - 2 HP, 230/460V-Plastic ....... $ 1 , 2 1 7 . 0 0 1 4 8
93300 - 3 HP, 230/460V-Plastic ....... $ 1,630.00 1 58
1500XSW Series - Multi-Stage
1575XSW - 3/4 HP, 115/230V-1 Phase-
Brass ............................ $ 1 , 5 1 0 . 0 0 1 6 4
1575XSWP - 3/4 HP, 115/230V-1 Phase-
Plastic ........................... $ 1 , 2 9 8 . 0 0 1 5 9
1510XSW - 1 HP, 115/230V-1 Phase-
Brass ............................ $ 1 , 5 9 9 . 0 0 1 6 4
1510XSWP - 1 HP, 115/230V-1 Phase-
Plastic ........................... $ 1 , 4 0 0 . 0 0 1 6 1
1515XSW - 1 1/2 HP, 115/230V-1 Phase-
Brass ............................ $ 1 , 6 6 5 . 0 0 1 6 6
1515XSWP - 1 1/2 HP, 115/230V-1 Phase-
Plastic ........................... $ 1,568.00 1 64
5 GPM - J Series
27050JHBPE - 1/2 HP ......................... $ 741.00 1 18
27075JHBPE - 3/4 HP ......................... $ 825.00 1 21
27100JHBPE - 1 HP ............................ $ 931.00 1 19
7 GPM - V Series
27050VHBPE - 1/2 HP ........................$ 659.00 1 13
27075VHBPE - 3/4 HP ........................$ 712.00 1 17
27100VHBPE - 1 HP ...........................$ 809.00 1 19
10 GPM - K Series
27050KHBPE - 1/2 HP ........................$ 589.00 1 14
27075KHBPE - 3/4 HP ........................$ 641.00 1 15
27100KHBPE - 1 HP ...........................$ 714.00 1 16
27150KHBPE - 1 1/2 HP .....................$ 835.00 1 18
27200KHBPE - 2 HP ........................$ 1,045.00 1 17
15 GPM - L Series
27050LHBPE - 1/2 HP ......................... $ 805.00 1 12
27075LHBPE - 3/4 HP ......................... $ 816.00 1 15
27100LHBPE - 1 HP ............................ $ 853.00 1 17
27150LHBPE - 1 1/2 HP ......................$ 965.00 1 18
27200LHBPE - 2 HP ......................... $ 1,000.00 1 16
20 GPM - P Series
27075PHBPE - 3/4 HP ........................$ 717.00 1 12
27100PHBPE - 1 HP ...........................$ 782.00 1 15
27150PHBPE - 1 1/2 HP .....................$ 907.00 1 16
27200PHBPE - 2 HP ........................$ 1,106.00 1 20
25 GPM - M Series
27100MHBPE - 1 HP ........................... $ 835.00 1 12
27150MHBPE - 1 1/2 HP .....................$ 835.00 1 12
27200MHBPE - 2 HP ........................ $ 1,026.00 1 15
28 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
5025PTSP - 1/4 HP, 120V - Plastic .............. $ 176.00 1 9
5025PVSP - 1/4 HP, 120V - Plastic .............. $ 187.00 1 9
5033PVSP - 1/3 HP, 120V - Plastic .............. $ 225.00 1 10
5030CTSP - 3/10 HP, 120V - Cast Iron ........ $ 239.00 1 19
5030CVSP - 3/10 HP, 120V - Cast Iron ........ $ 263.00 1 20
5030CUSP - 3/10 HP, 120V - Cast Iron ....... $ 248.00 1 18
5030CUSP25 - 3/10 HP,
120V
- Cast Iron, 25
' $ 288.00 1 19
5033CVSP - 1/3 HP, 120V - Cast Iron .......... $ 298.00 1 25
5033CUSP - 1/3 HP, 120V - Cast Iron .......... $ 289.00 1 24
5033CUSP25 - 1/3 HP,
120V
- Cast Iron, 25' .
$ 361.00 1 25
5050CVSP - 1/2 HP, 120V - Cast Iron .......... $ 344.00 1 25
5050CUSP25 - 1/2 HP,
120V
- Cast Iron, 25' .
$ 395.00 1 27
5020PUUP -
1/5 HP, 115V ...................... $ 149.00 1 8
5025PTSP 5025PVSP 5033PVSP 5030CVSP 5033CVSP 5050CVSP
5030CVSPK - 3/10 HP, 115V -
Cast Iron ........................... $ 502.00 1 30
5033CVSPEZ - 1/3 HP, 115V -
Cast Iron ........................... $ 341.00 1 28
5000PVSPBU - Battery Back-Up
Sump Pump .................. $ 526.00 1 14
5025PTSPCWB - Clear Water Sump Pump
1 1/2" Check Valve, Discharge Pipe &
18x24 Basin
Basin Package .......$ 442.00 1 29
5030CVSPCSK - Crawl Space Sump Pump
System .................. $ 644.00 1 34
5033PVPD - Pedestal Pump
1/3 HP Sump Pump ...$ 223.00 1 16
5050CVPD - Pedestal Pump
1/2 HP Sump Pump ..$ 344.00 1 28
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
DuraMACTM Sump Pumps
DuraMACTM Pedestal Pumps
Sink / Drain System
EZ Sump Kit
Battery Back-Up
Utility Pump
Pump Basin Package
Crawl Space
7 - Utility & Sump Pumps
Non-Potable
Use Only
29
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Utility Pump
Pump Basin Package
Crawl Space
5000BLK Mounting Block ....................$ 40.00 1 1
5000LSKIT - Lake Screen Kit ..............$ 53.00 1 1
5000LSBAG - Lake Screen Bag ..........$ 20.00 1 .1
5000LS - Lake Screen Filter ................$ 46.00 1 2
(use accessories discount)
5050CTSJPACSL - Split Lid Sewage Simplex
System with 18 x 30 Basin
................................$ 866.00 1 58
5033CTEF25 - 1/3 HP, 120V - Cast Iron, 25' ..$ 399.00 1 27
5033CUEF - 1/3 HP, 120V - Cast Iron .............$ 360.00 1 24
5050CTEF - 1/2 HP, 120V - Cast Iron .............$ 403.00 1 25
5050CUEF - 1/2 HP, 120V - Cast Iron .............$ 403.00 1 24
5050CVEF - 1/2 HP - Cast Iron ....................... $ 458.00 1 25
High Head
5050CUEFH25 -1/2 HP, 120V - Cast Iron / SS ..... $ 746.00 1 26
5050CTEFH25 -1/2 HP, 120V - Cast Iron / SS ..... $ 803.00 1 26
5033CUEF 5050CTEF 5050CVEF
5050CTSJ - 1/2 HP, 120V - Cast Iron ..............$ 474.00 1 27
5050CTSJ25 - 1/2 HP, 120V - Cast Iron, 25' ... $ 512.00 1 28
5050CVSJ - 1/2 HP, 120V - Cast Iron .............$ 528.00 1 26
5050CUSJ - 1/2 HP, 120V - Cast Iron .............$ 444.00 1 25
5050CTSJPAC - 1/2 HP, 120V - Cast Iron ...... $ 763.00 1 54
(with alarm, order alarm # 6190-025, see page 33)
5050CTSJPACSDA - 1/2 HP, 120V - Cast Iron
..$ 1,427.00 1 62
5050CTSJPAC24 - 1/2 HP, 120V - Cast Iron ..
$ 1,306.00 1 62
5050CTSJ15 - 1/2 HP, 120V - Cast Iron / SS ..$ 684.00 1 25
5050CVSJ15 - 1/2 HP, 120V - Cast Iron / SS ..$ 729.00 1 25
5050CTSJ 5050CVSJ 5050CTSJPAC 5050CTSJPACSDA 5050CTSJPAC24
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
DuraMACTM Sewage / High Volume Pumps
DuraMACTM Efuent Pumps / High Head
Split Lid Sewage Accessories
Sewage, Efuent, and Grinder Pumps - 8
747H20 .............................................$ 599.00 1 11
747H20-0001 with RPZ .....................$ 741.00 1 16
747H20RR Radon Ready .................$ 599.00 1 10
747H20A w/Tank Alert Alarm .............$ 700.00
747H20RRA Radon Ready w/Alarm
.............................................$ 700.00
Guardian Sump Pumps
Non-Potable
Use Only
GUARDIAN PRICED ON QUANTITY
30 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Flowrate, A.Y. Model # HP List
gal/min
10 22050KAJ 1/2 $ 305.00
10 22075KJ 3/4 $ 317.00
10 22100KJ 1 $ 407.00
10 22150KJ 1 1/2 $ 651.00
20 22050PAJ 1/2 $ 305.00
20 22075PJ 3/4 $ 325.00
20 22100PJ 1 $ 355.00
20 22150PJ 1 1/2 $ 439.00
30 22050EJ 1 $ 423.00
30 22075EJ 1 1/2 $ 478.00
30 22100EJ 1 $ 534.00
30 22150EJ 1 1/2 $ 580.00
Pump Ends
Part # # Wire Length List
6635-234 2 10 $ 63.00
6635-235 2 50 $ 212.00
6635-236 2 100 $ 316.00
6635-237 2 25 $ 167.00
Leads (use accessories discount)
High Head Efuent Pumps
8 - Sewage, Efuent, and Grinder Pumps
Non-Potable
Use Only
10" Lead 10' Lead 25' Lead 50' Lead 100' Lead
AY Model # Flow HP Voltage X996 X993 X995 X994
22050K2AJ 10 1/2 115 $1,084.00 $1,084.00 $1,246.00 $1,296.00 $1,428.00
22050K2J 10 1/2 230 $1,084.00 $1,084.00 $1,246.00 $1,296.00 $1,428.00
22075K2J 10 3/4 230 $1,239.00 $1,239.00 $1,405.00 $1,449.00 $1,552.00
22100K2J 10 1 230 $1,384.00 $1,384.00 $1,547.00 $1,596.00 $1,697.00
22150K2J 10 1 1/2 230 $1,945.00 $1,945.00 $2,111.00 $2,155.00 $2,258.00
22050P2AJ 20 1/2 115 $1,099.00 $1,099.00 $1,261.00 $1,310.00 $1,442.00
22050P2J 20 1/2 230 $1,099.00 $1,099.00 $1,261.00 $1,310.00 $1,442.00
22075P2J 20 3/4 230 $1,237.00 $1,237.00 $1,391.00 $1,447.00 $1,550.00
22100P2J 20 1 230 $1,325.00 $1,325.00 $1,404.00 $1,537.00 $1,638.00
22150P2J 20 1 1/2 230 $1,822.00 $1,822.00 $1,987.00 $2,006.00 $2,135.00
22050E2AJ 30 1/2 115 $1,134.00 $1,134.00 $1,300.00 $1,344.00 $1,447.00
22050E2J 30 1/2 230 $1,134.00 $1,134.00 $1,300.00 $1,344.00 $1,447.00
22075E2J 30 3/4 230 $1,288.00 $1,288.00 $1,453.00 $1,498.00 $1,601.00
22100E2J 30 1 230 $1,438.00 $1,438.00 $1,585.00 $1,652.00 $1,768.00
22150E2J 30 1 1/2 230 $2,024.00 $2,024.00 $2,190.00 $2,212.00 $2,337.00
less Check valve, cable guard, cable guard screws, with hole
drilled into center of discharge
31
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Includes 15' cable & 2" NPT discharge.
Cast Iron Construction
404011EF - 4/10 HP, 115V .............$ 608.00 1 29
404011EFA - 4/10 HP, 115V with piggyback oat
..........................................$ 683.00 1 32
405011EF - 1/2 HP, 115V ............$ 1,116.00 1 36
405011EFA - 1/2 HP, 115V with piggyback oat
.......................................$ 1,192.00 1 38
405012EF - 1/2 HP, 208/230V ..... $ 1,116.00 1 36
405012EFA - 1/2 HP, 208/230V with piggyback oat
.......................................$ 1,192.00 1 38
405011EFH - 1/2 HP, 115V High Head
.......................................$ 1,942.00 1 71
405012EFH - 1/2 HP, 208/230V High Head
.......................................$ 1,942.00 1 72
410012EF - 1 HP, 208/230V ........$ 2,726.00 1 75
410032EF - 1 HP, 208/230V, 3 Ph
.......................................$ 2,599.00 1 57
410034EF - 1 HP, 460V, 3 Ph ......$ 2,599.00 1 57
410012EFH - 1 HP, 208/230V High Head
.......................................$ 2,726.00 1 77
Includes 15' cable & 2" NPT vertical discharge.
Cast Iron Construction
404011SJ - 4/10 HP, 115V ..............$ 639.00 1 34
404011SJA - 4/10 HP, 115V with piggyback oat
..........................................$ 714.00 1 35
405011SJ - 1/2 HP, 115V .............$ 1,152.00 1 36
405011SJA - 1/2 HP, 115V with piggyback oat
.......................................$ 1,224.00 1 37
405012SJ - 1/2 HP, 208/230V .....$ 1,152.00 1 35
405012SJA - 1/2 HP, 208/230V with piggyback oat
.......................................$ 1,224.00 1 38
405032SJ - 1/2 HP, 208/230V, 3 Ph
.......................................$ 2,151.00 1 78
405034SJ - 1/2 HP, 460V, 3 Ph ...$ 2,151.00 1 78
407511SJ - 3/4 HP, 115V .............$ 2,505.00 1 85
407512SJ - 3/4 HP, 208/230V .....$ 2,505.00 1 40
407532SJ - 3/4HP, 208/230V, 3 Ph
.......................................$ 2,249.00 1 80
407534SJ - 3/4 HP, 460V, 3 Ph ...$ 2,249.00 1 80
410012SJ - 1 HP, 208/230V ........$ 2,726.00 1 89
410032SJ - 1 HP, 208/230V, 3 Ph
.......................................$ 2,599.00 1 80
410034SJ - 1 HP, 460V, 3 Ph ......$ 2,599.00 1 80
415012SJ - 1 1/2 HP, 208/230V ..$ 3,181.00 1 90
415032SJ - 1 1/2 HP, 208/230V, 3 Ph
.......................................$ 3,112.00 1 84
415034SJ -
1 1/2 HP, 460V, 3 Ph .
$ 3,112.00 1 84
420012SJ - 2 HP, 208/230V ........$ 3,821.00 1 90
420032SJ -
2 HP, 208/230V, 3 Ph .
$ 3,821.00 1 84
420034SJ - 2 HP, 460V, 3 Ph ......$ 3,821.00 1 84
-For pumps larger than 2 HP, contact factory.
See page 36 & 37 (Accessories)
For Control Panels, Basins Covers, & Float Switches.
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Efuent Pumps Sewage Ejectors
Sewage, Efuent, and Grinder Pumps - 8
Non-Potable
Use Only
120212GRP
Residential / Light Duty Grinder Pumps
120912GRP -2 HP, 230V-single phase .
$ 3,260.00 1 53
Heavy Duty Grinder Pumps
120212GRP - 2 HP, 230V-single phase .. $ 3,992.00 1 76
120232GRP - 2 HP, 230V-3 phase ... $ 3,992.00 1 70
120234GRP - 2 HP, 460V-3 phase ... $ 3,992.00 1 70
Grinder Pumps
32 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Engine Driven Dewatering Pumps
Cast Iron Construction
02G3AC - 3 1/2 HP - B&S Cast Iron
..................................... $ 1,487.00 1 70
02G5HC - 5 HP - Honda Cast Iron
...................................... $2,001.00 1 76
Thermoplastic Construction
02G5AT - 4 HP - B&S INTEK Plastic
...................................... $1,423.00 1 52
02G5HT - 5 HP Honda Plastic - 2"
..................................... $ 1,665.00 1 41
Die-Cast Aluminum - Engine Driven
02P5XAR - 6 1/2 HP - B&S CP650
..................................... $ 2,295.00 1 90
02P5XHR - 5 1/2 HP - Honda
..................................... $ 2,990.00 1 80
02P5XZR - 4.7 HP - Hatz
..................................... $ 8,471.00 1 107
02S5HK - High Pressure Hose Kit
..................................... $ 1,104.00 1 38
*Optional Wheel Kit
03G8WK10 -10" Semi-Pneumatic
6195-314 ......................... $ 335.00 1 26
Hose Kit (Items use accessories discount)
02S5HK -2"
6195-141 ...................... $ 1,104.00
Seal & Gasket Repair Kit
(Repair Parts Multipler)
2SX/3SX - All Models
EPDM .............Contact Factory
2SX/3SX - All Models
Viton® .............Contact Factory
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Mini Mac Transfer Pumps
300611TPK - 115V ............................ $ 235.00 1 6
300622RK - Impeller Repair Kit ........... $ 29.00 1 1
(Use repair parts discount)
Submersible Dewatering Pumps
01.5G.3V - 1/3 HP - 115V .................. $ 999.00 1 30
02G.5V - 1/2 HP - 115V .................. $ 1,187.00 1 31
02G1V - 1 HP - 115V ...................... $ 2,037.00 1 51
DC Dewatering Pumps - Handymac
303022SP Dewatering Pump-
DC 1/3 HP .........................$ 2,798.00 1 36
(Item below use Accessories discount)
303022B Carry Box for
above pump ....................................... $ 482.00 1 16
Air Powered Pump - Sludgemaster
325070SL Sludgemaster ................ $ 6,528.00 1 70
Cast Iron Sewage & Trash Pumps
Electric Motor Driven
02S3VZ - 3 HP - TEFC - 3 Ph ........ $ 2,941.00 1 87
02S3V - 3 HP - TEFC - 1 Ph .......... $ 2,888.00 1 91
02S5VZ - 5 HP - TEFC - 3 Ph... ..... $ 4,093.00 1 146
02S5V - 5 HP - TEFC - 1 Ph .......... $ 5,205.00 1 170
03S7.5VZ - 7 1/2 HP - TEFC - 3 Ph $ 5,107.00 1 200
03S7.5V - 7 1/2 HP - TEFC - 1 Ph ... $ 6,033.00 1 215
03S10VZ - 10 HP - TEFC - 3 Ph ..... $ 5,770.00 1 215
03S10V - 10 HP - TEFC - 1 Ph ...... $ 6,952.00 1 285
04S15VZ - 15 HP - TEFC - 3 Ph ...... $ 6,938.00 1 287
General Purpose Pumps●
High Pressure Pumps - P Series*●
Accessories/Repair Parts
9 - Dewatering Pump
Non-Potable
Use Only
33
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Die-Cast Aluminum - Engine Driven
Briggs & Stratton
02S5XAR - 6 1/2 HP - Alum ........$ 2,337.00 1 100
03S5XAR - 6 1/2 HP - Alum ........$ 2,569.00 1 96
Honda
02S5XHR - 5 1/2 HP - Alum .......$ 3,037.00 1 91
03S5XHR - 5 1/2 HP -Alum ......... $ 3,272.00 1 100
Hatz Diesel
02S5XZR - 4.7 HP - Alum .............$8,497.00 1 112
03S5XZR - 4.7 HP - Alum .............$8,728.00 1 121
Cast Aluminum - Engine Driven
03S8IR - 8 HP - B&S 1350
...............$ 4,883.00 1 143
03S9HR - 8 HP - Honda .............. $ 5,836.00 1 136
04S13HPV - 13 HP - Honda ......$ 12,165.00 1 299
(13 HP includes transport dolly/wheel kit)
Cast Aluminum - Engine Driven
03S8HR - 8 HP - Honda .............. $ 8,664.00 1 136
04S13HR - 13 HP - Honda ........ $ 14,151.00 1 262
06S24HSV 24 HP - Honda ........ $ 29,193.00 1 725
06S24HTV 24 HP - Honda ........$ 29,632.00 1 1000
06S24YSV 24 HP - Yanmar.......$ 50,022.00 1 975
06S24YTV 24 HP - Yanmar .......$ 50,460.00 1 1250
Skid Mounted - S
Trailer Mounted - T
Cast Iron - Engine Driven
02J5HCR - 5 1/2 HP - Honda ...... $ 3,673.00 1 85
Cast Aluminum Construction
03D1.5V - 1 1/2 HP - Elec Motor
.......
$ 6,339.00 1 186
03D5A - 5 1/2 HP - B&S Intek .....$ 6,023.00 1 181
03D5H - 5 1/2 HP - Honda ..........$ 6,952.00 1 183
03D5Z - 4.7 HP - Hatz Diesel .... $ 12,999.00 1 203
Aluminum Construction - Engine Driven
02.5FP13HR - 13 HP Honda ............$ 7,306.00 1 200
02.5FP13AR - 13 HP B&S ................$ 7,718.00 1 225
02.5FP23AR - 23 HP B&S .............. $ 11,834.00 1 255
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Trash Pumps - S Series*●6" Trash Pumps●
Dredging Pumps*●
Self-Priming Diaphragm Pump●
Fire Pump●
Trash Pumps*●
Heavy Duty Trash Pumps ●
Dewatering Pump - 9
Non-Potable
Use Only
●HP Class: Indicates classication for marketing purposes and does not indicate actual engine horsepower.
Contact engine manufacturer for actual HP specications.
34 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
No-Lead, double tapped
540SB - FNPT x FNPT, tapped 1/8" and 1/4"
6814-327 3/4" ....................................$ 62.00 1 1
6814-010 1" .......................................$ 70.00 1 2
6814-011 1 1/4" .................................$ 82.00 1 2
6814-012 1 1/2" .................................$ 95.00 1 2
6814-013 2" .....................................$ 139.00 1 4
No-Lead
500MS - FNPT x MNPT, no tappings
6814-192 1" x 1 1/4" ..........................$ 49.00 1 2
6814-193 1 1/4" x 1 1/4" ....................$ 54.00 1 2
6814-194 2" x 2" ..............................$ 139.00 1 4
500MSS - Stainless FNPT x MNPT, no tapping
6814-195 1" x 1 1/4" ..........................$ 53.00 1 2
6814-196 1 1/4" .................................$ 68.00 1 2
No-Lead Brass Check Valves - Spring Loaded
FNPT x MNPT Threads
6200-188 - 6" x 6"
(Ductile Iron) ...................... $ 1,115.00 1 40
* (Includes 6" long nipple)
500D Ductile Iron Check Valves - FNPT x FNPT
with Breakoff Plug
3 (6814-314) ......................................$ 429.00 1 10
4 (6814-315) ......................................$ 599.00 1 10
6814-316 Breakoff Plug Only ..............$ 74.00 1 .2
Factory set at 30, 75, or 100 PSI. Composition disc on
brass seat. 180ºF max. temp.
Field adjusting not recommended.
6214 Brass Relief Valves
1/2" 30# ..............................$ 90.00 6 4
1/2" 75# ..............................$ 90.00 6 5
3/4" 30# ............................$ 101.00 6 7
3/4" 75# ............................$ 101.00 6 8
3/4" 100# ..........................$ 101.00
1" 30# ............................$ 135.00 4 7
1" 75# ............................ $ 135.00 4 7
1" 100# .......................... $ 135.00
1 1/4" 30# ............................ $ 207.00 6 17
1 1/4" 65# ............................$ 207.00 6 18
1 1/4" 100# ..........................$ 207.00
1 1/2" 30# ............................$ 394.00 1 4
1 1/2" 65# ............................$ 394.00 1 6
2" 30# ............................$ 403.00 1 6
2" 65# ............................ $ 403.00 1 6
704SB-Silicon Bronze body - copper leg
13" long 1 1/4" MNPT three ends x 1" FNPT
two ends w/2, 3/4" taps on top surface.
........................................$ 100.00 1 3
740SB - 2 Taps - 3/4" x 1"
11" x 10" x 1" - Length x Height x Connection
........................................$ 100.00 9 27
741SB - 2 Taps - 1" x 1 1/4"
11" x 10" x 1 1/4" - Length x Height x Connection
........................................$ 164.00 6 29
For additional No-Lead Brass Tank Tees, see
A.Y. McDonald Plumbing Products.
Snifter Valve
7891 - 1/8" No-Lead Brass ..................$ 12.00 1 1
7892 - 1/4" No-Lead Brass ..................$ 15.00 1 1
Torque Arrest
877H - 4" to 8" - Two piece rubber ......$ 35.00 1 2
For Submersible Installations
6635-229 Motor Leads 48", 4" Jam Nut, (2) w/ground,
1 1/2 HP & below ....................$ 44.00 1 1
6635-230 Motor Leads 48", 4" Jam Nut, (3) w/ground,
2 HP & below ..........................$ 48.00 1 1
6635-232 Motor Leads 100", Jam Nut Style
(3) w/ground, 3 HP & above ...$ 59.00 1 1
6635-245 4" 48" High Thrust - Clamp Style Motor Leads
three wire ................................$ 48.00 1 1
6635-242 Motor Leads 100" High Thrust - Clamp Style
(3) w/ground, 3 HP & above ...$ 65.00 1 2
6635-243 Motor Leads 6" 13ft. Brass Jam Nut
.............................................$ 216.00 1 7
6617-255 Sta-Kons (#12 & #10) ............$ 1.80 1 1
6617-336 Sta-Kons (#8 & #6) ................$ 4.49 20 1
6617-115 Set (3) Mech. Connectors ....$ 16.00 1 1
6610-224 Lightning Arrestor ................$ 86.00 1 1
6610-260 Three-phase Lightning
Arrestor .................................$ 324.00 1 1
6617-135 Heat Shrink Splice Kit
Three-wire (10/12/4 gauge) ....$ 10.30 1 .0
6617-136 Heat Shrink Splice Kit
Two-wire (12 gauge) .................$ 9.03 1 .0
No-Lead Perforated stainless steel strainer. Spring loaded.
400 PSI working pressure.
400SB - FNPT
6814-000 - 3/4" ....................................$ 44.00 1 1
6814-001 - 1" .......................................$ 45.00 1 1
6814-002 - 1 1/4" .................................$ 54.00 1 1
6814-003 - 1 1/2" .................................$ 75.00 1 2
6814-004 - 2" .....................................$ 122.00 1 4
No-Lead Spring loaded. 400 PSI working pressure.
500SB - Bronze nish, no tappings. FNPT x FNPT
6814-031 - 1/2" ....................................$ 47.00 1 1
6814-005 - 3/4" ....................................$ 51.00 1 1
6814-006 - 1" .......................................$ 54.00 1 2
6814-007 - 1 1/4" .................................$ 70.00 1 2
6814-008 - 1 1/2" .................................$ 85.00 1 2
6814-009 - 2" .....................................$ 131.00 1 4
6814-197 - 2 1/2" ...............................$ 588.00 1 10
Ductile Iron 670SB
6200-200 3" .......................................$ 410
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Electrical Instruments & Accessories
No-Lead Silicon Bronze Foot Valves
Silicon Bronze Check Valves
Silicon Bronze Check Valves - continued
No-Lead Brass Relief Valves
Tank Tees
10 - Pump Accessories
35
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
6155-356 - Straight 1/4" plas x 1/4" MNPT ........ $ 3.96 1 .0
6155-355 - 90° 1/4" plastic x 1/8" MNPT ........... $ 4.56 1 .0
6610-169 - Plastic tubing 1/4" x 5' ..................... $ 4.49 1 1
6610-168 - Plastic tubing 1/4" x 100' ............... $ 65.00 1 8
6155-355 - Elbo Conn 1/4" Tube x 1/4" NPT ..... $ 4.56
6155-356 -
Conn-Fast&Tite-1/4" Tube x 1/8" NPT
$ 3.96
*Use with switches in right column
Diaphragm type
3129-378 - 1/4"-30 AV ........................ $ 59.00 1 1
3129-388 - 1/4"-42 AV ........................ $ 82.00 1 2
3129-379 - 1/4"-80 AV ...................... $ 105.00 1 2
3129-380 - 3/8"-120 AV .....................$ 118.00 1 3
3129-389 - 1/4"-45 AV ........................ $ 47.00 1 1
3129-386 - 3/8"-100 AV ...................... $ 54.00 1 1
Float type
3129-383 Deep well-894 .................... $ 53.00 1 1
3129-421 - 1/4" - 20-40
(9013FSG2J20) ................................. $ 4 8 . 0 0 1 1
3129-423 - 1/4" - 30-50
(9013FSG2J21) ................................. $ 4 8 . 0 0 1 1
3129-432 - 1/4" - 40-60
(9013FSG2J24) ................................. $ 4 8 . 0 0 1 1
3129-449 - 1/4" - 60-80
(9013FHG2J99) ................................. $ 4 8 . 0 0 1 2
3129-442 - 1/4" - 20-40 (9013FSG2J20C20)
20 pack - Price per each switch
............. $ 41.00 20 17
3129-443 - 1/4" - 30-50 (9013FSG2J21C20)
20 pack - Price per each switch
........... $ 41.00 20 16
3129-448 - 1/4" - 40-60 (9013FSG2J24C20)
20 pack - Price per each switch.
........... $ 41.00 20 15
3129-414 - 1/4" - 20-40
(9013FSG2J20P) ............................... $ 51.00 1 1
3129-436 - 1/4" - 30-50
(9013FSG2J21P) ............................... $ 51.00 1 2
3129-420 - 1/4" - 20-40
(9013FSG2J20M4) ............................ $ 57.00 1 2
3129-433 - 1/4" - 30-50
(9013FSG2J21M4) ............................ $ 57.00 1 1
3129-438 - 1/4" - 40-60
(9013FSG2J24M4) ............................ $ 57.00 1 1
3129-439 - 1/4" - 30-50
(9013FSG2J21M1) ............................ $ 59.00 1 1
3129-430 - 1/4" - 20-40
(9013GSG2J20) .............................. $ 130.00 1 3
3129-435 - 1/4" - 30-50
(9013GSG2J21) .............................. $ 130.00 1 2
3129-434 - 1/4" - 40-60
(9013GSG2J24) .............................. $ 130.00 1 3
3129-461 -1/4" 60-80 (9013GSG2J25) . $ 130.00 1 2
3129-462 -1/4" 50-70 (9013GSG2J33) . $ 130.00 1 2
3129-453 - 1/4" - 50/70
(9013FYG2J33M4) ............................ $ 70.00 1 1
3129-457 - 1/4" - 20-40 ...................... $ 24.00 1 1
3129-458 - 1/4" - 30-50 ...................... $ 24.00 1 1
3129-459 - 1/4" - 40-60 ...................... $ 24.00 1 1
3129-460 - 1/4" 10-5 Reverse Acting . $ 75.00 1 1
5999-897 Steel Case, Vertical ......................... $ 18.00 1 .2
1-100 lbs., 2" dial, 1/4” MNPT
6012-567 - 200PSI Liquid Filled ...................... $ 25.00
Two piece, cast iron. Rubber comp. seal
459S-One pipe
4" x 1" ................................................. $ 5 3 . 0 0 1 4
4" x 1 1/4" ........................................... $ 5 3 . 0 0 1 4
4 1/2" x 1 1/4" ..................................... $ 7 0 . 0 0 1 4
5" x 1" ................................................ $ 6 8 . 0 0 1 6
5" x 1 1/4" ........................................... $ 7 3 . 0 0 1 6
5 5/8 x 1" ............................................ $ 7 0 . 0 0 1 8
5 5/8 x 1 1/4" ...................................... $ 70.00 1 7
6" x 1" ................................................. $ 8 1 . 0 0 1 8
6" x 1 1/4" ........................................... $ 8 1 . 0 0 1 8
6" x 1 1/2" ........................................... $ 7 9 . 0 0 1 8
6" x 2" ............................................... $ 152.00 1 8
460S-Two pipe
4" x 1 1/4" x 1" .................................... $ 6 8 . 0 0 1 3
5" x 1 1/4" x 1" .................................... $ 7 1 . 0 0 1 6
5 5/8" x 1 1/4" x 1" .............................. $ 71.00 1 7
6" x 1 1/4" x 1" .................................... $ 7 9 . 0 0 1 8
6" x 1 1/2" x 1 1/4" .............................. $ 79.00 1 8
401S 4" x 1" ........................................ $ 4 5 . 0 0 1 2
402S 4" x 1 1/4" .................................. $ 4 5 . 0 0 1 2
451S 4 1/2" x 1" .................................. $ 4 6 . 0 0 1 2
452S 4 1/2" x 1 1/4" ............................ $ 4 6 . 0 0 1 2
453S 4 1/2" x 1 1/2" ............................ $ 4 6 . 0 0 1 2
501S 5" x 1" ........................................ $ 4 7 . 0 0 1 2
502S 5" x 1 1/4" .................................. $ 4 7 . 0 0 1 2
601S 6" x 1" ........................................ $ 6 0 . 0 0 1 3
602S 6" x 1 1/4" .................................. $ 6 0 . 0 0 1 3
359S 6" x 2" ........................................ $ 5 5 . 0 0 6 4 5
359SWS 4" x 1" .................................. $ 73.00 1 2
359SWS 4" x 1 1/4" ............................ $ 73.00 1 2
359SWS 5" x 1" .................................. $ 9 0 . 0 0 1 3
359SWS 5" x 1 1/4" ............................ $ 9 0 . 0 0 1 3
359SWS 5" x 2" .................................. $ 9 0 . 0 0 1 3
359SWS 6" x 1" ................................ $ 2 0 2 . 0 0 1 4
359SWS 6" x 1 1/4" .......................... $ 2 0 2 . 0 0 1 4
359SWS 6" x 2" ................................ $ 2 0 2 . 0 0 1 4
359SWS 8" x 2" ................................ $ 2 0 2 . 0 0 1 8
359SWS 8" x 3" ................................ $ 2 0 8 . 0 0 1 8
359SWS 10" x 2" .............................. $ 214.00 1 17
105 Automatic regulating valve-1" .... $ 1 7 4 . 0 0 1 0 3 3
6411-225 Turned couplings 1 1/4" ...... $ 25.00 1 1
6127-300 Reducing nipple-
1 1/4" x 1" x 8" .................................... $ 26.00 1 1
6814-177 Spray paint-(not pictured)
dark green-13 oz. ............................... $ 2 6 . 0 0 1 1
3126-676 - Galvanized Face Bushing
1 1/4" x 1 ............................................ $ 26.00 1 1
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Sanitary Well Seals Air Volume Controls
Pressure Switches
Pressure Gauges
Plastic Sanitary Well Seals
Stainless Steel Sanitary Well Seals
Miscellaneous
Tubing and Fittings
Pump Accessories - 10
36 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Wide Angle, Piggyback - Open
For pumps up to 1/2 HP 115V or 1 HP 230V
13 max running amps. Normally open, pump down.
6190-012 - 115V-10’ cord .................. $ 91.00 1 2
6190-013 - 115V 15’ cord .................. $ 98.00 1 2
6190-014 - 230V 15’ cord ................ $ 102.00 1 2
6190-011 - 115V 20’ cord ................. $ 102.00 1 3
6190-015 - 230V 20’ cord ................ $ 107.00 1 3
Wide Angle, Piggyback - Closed
For pumps up to 1/2 HP 115V or 1 HP 230V
13 max running amps. Normally closed, pump up.
6190-027 - 115V-15’ cord .................. $ 98.00 1 2
Piggyback mechanical oat switches allow manually operated
pumps to be operated automatically. Individually boxed.
Mounting strap and molded plug included (230V plugs
are style.)
Heavy Duty, Wide Angle, Piggyback
For pumps up to 3/4 HP 115V or 2 HP 230V
15 max running amps. Normally open, pump down.
6190-016 - 115V-15’ cord ................ $ 138.00 1 3
6190-017 - 230V 15’ cord ................ $ 147.00 1 3
6190-018 - 115V 20’ cord ................ $ 147.00 1 3
6190-019 - 230V 20’ cord ................ $ 160.00 1 3
Double Float Switch
6190-142 - 115V - 15' Cord Pump down w/plug
........................................... $ 178.00 1 4
6190-143 - 230V - 15' Cord Pump down w/plug
........................................... $ 187.00 1 4
6190-173 230V, 30' Cord, Pump down w/plug
........................................... $ 208.00 1 5
Vertical - Piggyback
For pumps up to 1/2 HP 115V or 1 HP 230V
13 max running amps. Pumping range from .75” to 6.5”
6190-020 - 115V-15’ cord ................ $ 106.00 1 2
6190-021 - 115V/230V 30’ cord ........$ 118.00 1 3
6190-022 - 115V 20’ cord .................$ 111.00 1 3
6190-023 - 230V 20’ cord ................ $ 126.00 1 3
Mechanically Activated
15 Amp - Piggyback Switch Less Plug - 10' Cable
6190-008 - Normally closed..............$ 111.00 1 2
6190-130 - Normally open ................$ 111.00 1 2
DuraMACTM Floats
5000-T--10 - Tethered 10' .................. $ 75.00 1 1
5000-T--25 - Tethered 25' .................. $ 91.00 1 1
5000-V--10 - Vertical 10' .................. $ 102.00 1 2
5000-V--25 - Vertical 25' .................. $ 126.00 1 1
6190-044 SignalMaster®, 20' cable, external
weight, NC, Mech ................. $ 86.00 1 4
6190-045 SignalMaster®, 15' cable, pipe
clamp, No, Mech .................. $ 86.00 1 2
6190-046 SignalMaster®, 20' cable, NC
............................................. $ 82.00 1 2
6190-144 Sensor Float, 15' cable, NC
............................................. $ 86.00 1 2
6190-035 PS Patrol System
w/o switch ........................... $ 525.00 1 13
8871 For 1", 1 1/4", 1 1/2", or 2" pipe
6814-110 ......................................... $ 266.00 1 25
Max. Recommended load = 2000 pounds.
PIPE HOLDER REPAIR PARTS
1. 3117-612 Set screw 1/2-13 X 3/4 ................. $ 2.53 1 0
2. 6814-236 Adjusting slide ............................ $ 17.00 1 3
3. 3117-611 Adjusting screw ........................... $ 17.00 1 1
4. 6814-235 Pipe holder dog .......................... $ 70.00 1 5
5. 6814-234 Body Casting (Holder) .............. $ 144.00 1 14
6. 6814-237 Pin .............................................. $ 16.00 1 1
7. 6814-238 Wood Base ................................. $ 65.00 1 4
3122-104 Cotter Pin ..................................... $ 0.18 1 0
8713 - 18" long
6814-102 3/4 ..................................... $ 57.00 1 2
6814-104 1 ........................................ $ 57.00 1 2
Float Valve Repair Parts
6814-326 Replacement ball .............................. $ 4.43 1 0
6814-204 Screw-3/4 .......................................... $ 2.67 1 0
6814-207 Lever arm ........................................ $ 25.00 1 1
6814-312 Float Body 3/4 ................................. $ 40.00 1 1
6814-313 Float Body 1 .................................... $ 40.00 1 1
Floats for Float Valve
6813-199 8715 3" X 12" diameter oat ......... $ 47.00 12 25
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Vertical Float
6
Pipe Holder
Float Valves
Control Switches
Mechanical Pump Float Switches
10 - Pump Accessories
37
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
6190-137 Tank Alert AB-indoor 115V-Nema I panel with
mechanical switch ........................... $ 198.00 1 3
6190-025 Tank Alert XT-indoor/Outdoor
with mechanical switch ................ $ 307.00 1 4
6190-176 Tank Alert AB w/Auxiliary Contacts
........................................... $ 252.00 1 3
6190-121-2" Check Valve-Plastic ...... $ 68.00 1 3
6190-122-2" Check Valve-Brass...... $ 334.00 1 5
6190-123-3" Check Valve-Brass...... $ 679.00 1 5
6190-006 - Repair Check Valve for
sump pumps-1/4, 1/3, 1/2 HP ........ $ 86.00 1 1
6190-129 - Repair Float Switch for Old Style
Sump Pump 1/4, 1/3, 1/2 HP ........ $ 147.00 1 1
6190-141 - Repair Float Switch for New Style
Sump Pump 1/4, 1/3, 1/2 HP .......... $ 57.00 1 1
Control Panels & Start Kit
6194-110-DUPLEX-three phase, For use
with 120232GRP ............. $ 4,724.00 1 20
6194-015 Start Kit............................ $ 578.00 1 2
Pedestal Base
6194-109-For Heavy Duty
Grinder Pumps ................... $ 273.00 1 10
Guide Rails
6194-119-Standard-Grinder
Pumps ............................. $ 1,027.00 1 57
6194-120 Ball Check Guide Rail for
120212GRP ........................ $ 893.00 1 10
6194-121 Ball Check Guide Rail for
120912GRP ........................ $ 831.00 1 1
Simplex
6192-010 18"x30” Poly Basin w/4" adapt-a-ex .... $ 256.00 1 13
6192-011 18" Structural foam cover, 2 x 2
with gaskets (ind. boxed) ............................. $ 94.00 1 6
6192-012 18" steel cover, 2 x 2, (ind. boxed) .......... $ 94.00 1 8
6192-013 18" x 30" Simplex Basin kit
with structural foam cover ......................... $ 291.00 1 21
6192-014 18" x 30" Simplex Basin kit
with steel cover .......................................... $ 291.00 1 27
Simplex basins include 18" x 30" basin, cover, 4" schedule 40 adapt-a-
ex inlet, lid gasket, discharge and vent gasket, and cord grommet.
Duplex
6192-015 36"x30" Poly Basin-no inlet ................... $ 845.00 1 45
6192-016 36" Duplex cover, 10 ga. steel ............ $ 1,098.00 1 20
6192-017 36" Duplex cover, 1/4" steel ............... $ 1,481.00 1 30
Basin Accessories
6192-018 4" schedule 40 adapt-a-ex inlet ............. $ 52.00 1 1
6192-019 4" caulking hub inlet ................................ $ 99.00 1 2
Submersible Motor Adapters
6180-326 4" Pump End x 6" Motor .................................. $ 391.00
Adapters
6180-114 - 500SDA 5X6 Discharge Adaptor ......................... $ 255.00 1 7
(Use accessories discount)
CTN
SIZE LIST QTY WT
CTN
SIZE LIST QTY WT
Liquid Level Alarm Systems Poly Basins, Covers, & Kits
Miscellaneous
Heavy Duty Grinder Pump Accessories
Pump Accessories - 10
Non-Potable
Use Only
Non-Potable
Use Only
Non-Potable
Use Only
38 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Starting Capacitor Cap & OL Assembly QD Relay Kit Overload Kit
HP Volts Part # List Part # List Part # List Part # List
1/3 115 6617-378 $ 66.00 6617-260 $ 52.00 6617-404 $ 119.00
1/3 230 6617-379 $ 78.00 6617-261 $ 52.00 6617-400 $ 132.00
1/2 115 6617-380 $ 89.00 6617-262 $ 56.00 6617-405 $ 110.00
1/2 230 6617-381 $ 71.00 6617-263 $ 52.00 6617-401 $ 151.00 6617-409 $ 85.00
3/4 230 6617-382 $ 73.00 6617-264 $ 53.00 6617-402 $ 135.00 6617-410 $ 85.00
1 230 6617-266 $ 56.00 6617-265 $ 52.00 6617-403 $ 151.00 6617-411 $ 134.00
Starting Cap. Run Cap. Start O.L. Main O.L. Relay Contactor
HP Volts Part # List Part # List Part # List Part # List Part # List Part # List
1 1/2 OLD 230 6617-266 $ 56.00 6617-282 $ 53.00 6617-277 $ 42.00 N/A 6617-269 $ 105.00 N/A
2 230 6617-266 $ 56.00 6617-283 $ 53.00 6617-290 $ 25.00 6617-280 $ 46.00 6617-269 $ 105.00 N/A
2 DLX 230 6617-266 $ 56.00 6617-283 $ 53.00 6617-290 $ 25.00 6617-280 $ 46.00 6617-269 $ 105.00
3 230 6617-226 $ 103.00 6617-288 $ 86.00 6617-291 $ 26.00 6617-281 $ 40.00 6617-269 $ 105.00 N/A
3 DLX 230 6617-226 $ 103.00 6617-288 $ 86.00 6617-291 $ 26.00 6617-281 $ 40.00 6617-269 $ 105.00
5 230 6617-284 $ 156.00 6617-289 $ 69.00 6617-292 $ 26.00 6617-340 $ 110.00 6617-424 $ 173.00 N/A
5 DLX 230 6617-284 $ 156.00 6617-289 $ 69.00 6617-292 $ 26.00 6617-340 $ 110.00 6617-424 $ 173.00 6617-297 $ 268.00
7 1/2 230 6617-284 $ 156.00 6617-288 $ 86.00 6617-339 $ 54.00 6617-293 $ 52.00 6617-424 $ 173.00 N/A
6617-341 $ 192.00
7 1/2 DLX 230 6617-284 $ 156.00 6617-288 $ 86.00 6617-339 $ 54.00 6617-294 $ 56.00 6617-424 $ 173.00 6617-298 $ 584.00
6617-341 $ 192.00
6617-285 $ 83.00
10 230 6617-341 $ 192.00 6617-287 $ 78.00 6617-295 $ 56.00 N/A 6617-424 $ 173.00 N/A
6617-284 $ 156.00
6617-285 $ 83.00
10 DLX 230 6617-341 $ 192.00 6617-287 $ 78.00 6617-295 $ 56.00 N/A 6617-424 $ 173.00 6617-298 $ 584.00
6617-284 $ 156.00
15 DLX 230 6617-286 $ 91.00 6617-288 $ 86.00 6617-295 $ 56.00 N/A 6617-424 $ 173.00 6617-299
$ 1,045.00
6617-284 $ 156.00
Motor Control Components
Control Box Components
11 - Pump Repair Parts
39
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Part # Plate # Vender Part# Description List Price
6195-258 303022STSC 710-004-330 Self-tapping screw $ 3.82
6195-259 303022MTCV 258-017-157 Motor cover $ 122.00
6195-260 303022HNUT 545-005-330 Hex nut $ 3.98
6195-261 303022HNDL 405-009-000 Handle $ 33.00
6195-262 303022GLNT 543-001-162 Gland nut $ 9.48
6195-263 303022GLSP 770-007-162 Gland spacer $ 5.99
6195-264 303022SLRG 675-016-360 Sealing ring $ 5.91
6195-265 303022HXNT 545-004-330 Hex nut $ 3.98
6195-266 303022LKWS 900-004-330 Lock washer $ 3.98
6195-267 303022STUD 807-011-330 Stud $ 17.00
6195-268 303022CRBK 270-001-000 Circuit breaker $ 33.00
6195-269 303022HHCS 170-028-330 Hex head capscrew $ 3.98
6195-270 303022LWSR 900-001-330 Lock washer $ 3.98
6195-271 303022CSGS 360-001-440 Casing gasket $ 5.84
6195-272 303022HCSR 170-003-115 Hex head capscrew $ 4.14
6195-176 303022MPLR 444-001-010 Impeller $ 241.00
6195-179 303022SHIM 740-001-115 Shim $ 9.48
Part # Plate # Vender Part# Description List Price
6195-179 303022SHIM 740-001-115 Shim $ 9.48
6195-274 303022STRN 612-001-156 Base Plate $ 175.00
6195-273 303022SCTC 258-001-157 Suction cover $ 199.00
6195-177 303022SCRN 700-001-330 Strainer screen $ 35.00
6195-275 303022CSVL 181-001-155 Casing volute 1 1/2 NPT $ 579.00
6195-276 303022RING 560-022-360 O-ring $ 3.68
6195-178 303022SEAL 720-005-000 Seal $ 172.00
6195-277 303022MTR 525-005-000 Motor $ 2,081.00
6195-278 303022CBCL 200-003-000 Cable clamp $ 6.45
6195-279 303022MCSC 706-007-330 Machine screw $ 5.23
6195-280 303022PWRC 150-036-000 Power cable assembly $ 401.00
6195-281 303022LCKW 900-002-330 Lock washer $ 3.02
6195-282 303022CMPL 510-003-000 Compression lug $ 16.00
6195-283 303022SSKT 475-132-000 Shell & stud kit $ 313.00
6195-180 303022EYE 321-001-330 Eye bolt $ 293.00
6195-182 303022HK 475-238-000 Handle update kit $ 42.00
6195-154 303022SCR 706-006-330 Handle screw $ 15.00
15
13
19
20
18
14
16
17
23
12
13
10
427 29 26
5
6
7
8
9
3
2
22
10
28
25
24
1
11
30
31
22
21
118
19
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
20
21
22
23
25
26
27
28
29
30
303022SP Repair Parts
Pump Repair Parts - 11
Non-Potable
Use Only
40 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Part # Description List Price
6155-373 Adapter $ 110.00
6422-100 Rotary Seal $ 21.00
6155-224 Housing Gasket D09 or Older $ 1.32
3138-995 O-ring E09 or Newer $ 0.91
3134-133 Pump Body O-ring D09 or Newer $ 0.25
6155-238 Reg. Valve assembly $ 4.78
6155-236 8100 Pump Body assembly $ 181.00
6155-237 8200 Pump Body assembly $ 192.00
Part # Description List Price
6127-248 Pump Foot $ 6.09
3100-530 Foot Capscrews $ 0.27
3100-528 Adapter Capscrews $ 0.45
5999-903 Diffuser Screws $ 0.32
3110-951 Set Screw $ 1.14
6450-217 Ejector Gasket $ 6.78
5999-958 Bolt-on Jet Body $ 69.00
HP Models Part# List
1/3 8130-8131, 650JP, 8530, 8531 6155-203 $ 9.73
1/2 8150-8151, 651JP, 8550, 8551 6155-204 $ 9.73
3/4 8170-8171, 652JP, 8570, 8571 6155-212 $ 9.73
1 8110-8111, 653JP, 8510, 8511 6155-213 $ 9.73
1/3 8130HP, 8131HP, 654JP, 8530HP, 8531HP 6155-202 $ 9.73
1/2 8150HP, 8151HP, 655JP, 8550HP, 8551HP 6155-205 $ 9.73
3/4 8170HP, 8171HP, 656JP, 8570HP, 8571HP 6155-211 $ 9.73
1 8110HP, 8111HP, 657JP, 8510HP, 8511HP 6155-214 $ 15.00
Nozzle/venturi o-ring for assemblies 3134-120 $ 0.18
Models Part# List Part# List
7502JP, 7733JP 6413-203 $ 17.00 6128-201 $ 4.34
7503JP, 7734JP 6413-204 $ 17.00 6128-201 $ 4.34
7508JP, 7735JP 6414-207 $ 17.00 6128-201 $ 4.34
7509JP, 7736JP 6414-208 $ 20.00 6128-201 $ 4.34
7901JP, 7808JP 6413-250 $ 23.00 6413-246 $ 6.09
7902JP, 7809JP 6413-249 $ 23.00 6413-246 $ 6.09
7903JP, 7810JP 6413-248 $ 23.00 6413-246 $ 6.09
7906JP, 7812JP 6413-253 $ 23.00 6413-246 $ 6.09
7907JP, 7813JP 6413-254 $ 23.00 6413-246 $ 6.09
Venturi Nozzle
Model Part # List Part # List Part # List Part # List
8130, 8130HP 8230 6155-240 $ 388.00 6127-324 $ 68.00 6155-359 $ 29.00 6130-201 $ 15.00
8131, 8131HP, 8231 6155-240 $ 388.00 6127-325 $ 188.00 6155-331 $ 151.00 6130-201 $ 15.00
8150, 8150HP, 8250 6155-240 $ 388.00 6127-326 $ 68.00 6155-358 $ 29.00 6130-201 $ 15.00
8151, 8151HP, 8251 6155-240 $ 388.00 6127-327 $ 188.00 6155-330 $ 155.00 6130-201 $ 15.00
8170, 8170HP, 8270 6155-241 $ 448.00 6127-328 $ 71.00 6155-370 $ 32.00 6155-223 $ 17.00
8171, 8171HP, 8271 6155-241 $ 448.00 6127-329 $ 234.00 6155-334 $ 188.00 6155-223 $ 17.00
8110, 8110HP, 8210 6155-242 $ 508.00 6127-330 $ 71.00 6155-369 $ 32.00 6155-223 $ 17.00
8111, 8111HP, 8211 6155-242 $ 508.00 6127-331 $ 234.00 6155-333 $ 188.00 6155-223 $ 17.00
Motor Impeller/Diffuser Kit* Impeller Diffuser
8100 SHALLOW WELL SERIES 8200 CONVERTIBLE SERIES
1
2
3
4
5
81
2
4
5
8
3
67
Ejector Gasket
6450-217
2
3
4
4
5
1
6
7
8
8
*Kit includes impeller, diffuser, rotary seal & housing gasket with instructions
8100 / 8200 Repair Parts
Shallow Well Venturi - Nozzle - O-ring Assemblies
Deep Well Kits - Jet Package
11 - Pump Repair Parts
41
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Part # Description List Price
6155-284 Seal Plate $ 40.00
6422-100 Rotary Seal $ 21.00
3138-995 O-Ring E03 & Newer $ 0.91
6155-224 Housing gasket D03 & Older $ 1.32
6164-212 8500 Pump Body assembly $ 204.00
3134-133 Pump Body O-ring $0.25
6164-213 8600 Pump Body assembly $ 214.00
6155-238 Reg. Valve assembly $ 4.78
6127-248 Pump Foot $ 6.09
3100-530 Foot Capscrews $ 0.27
3100-565 Body Capscrews $ 0.53
5999-903 Brass diffuser screws $ 0.32
3110-951 Set screw $ 1.14
6450-217 Ejector Gasket $ 6.78
Part # Description List Price
3119-112 101-2 Casing Adapter Washers $ 0.61
3100-527 1/2-13x1” Capscrew $ 0.80
3100-303 3/8-16 x 13⁄4 Sq Hd. Bolt $ 0.99
6450-214 2” Rubber Packing $ 9.48
6450-215 2” Gland $ 35.00
6450-261 Casing Adapter Gasket $ 4.36
Model Part # List Part # List Part # List Part # List Part # List Part # List Part # List
8530, 8530HP, 6164-203 $261.00 6127-324 $68.00 6164-211 $7900 6155-359 $29.00 6130-201 $15.00 6155-360 $ 31.00 6130-201 $15.00
8630
8531, 8531HP, 6164-203 $261.00 6127-325 $188.00 6155-331 $151.00 6130-201 $15.00 6130-201 $15.00
8631
8550, 8550HP, 6164-200 $261.00 6127-326 $68.00 6164-205 $68.00 6155-358 $29.00 6130-201 $15.00 6155-361 $ 31.00 6130-201 $15.00
8650
8551, 8551HP, 6164-200 $261.00 6127-327 $188.00 6155-330 $155.00 6130-201 $15.00 6130-201 $15.00
8651
8570, 8570HP, 6164-201 $310.00 6127-328 $71.00 6164-207 $68.00 6155-370 $32.00 6155-223 $17.00 6155-365 $29.00 6155-223 $17.00
8670
8571, 8571HP, 6164-201 $310.00 6127-329 $234.00 6155-334 $188.00 6155-223 $17.00 6155-223 $17.00
8671
8510, 8510HP, 6164-202 $348.00 6127-330 $71.00 6164-209 $68.00 6155-369 $32.00 6155-223 $17.00 6155-366 $ 29.00 6155-223 $17.00
8610
8511, 8511HP, 6164-202 $348.00 6127-331 $234.00 6155-333 $188.00 6155-223 $17.00 6155-223 $17.00
8611
Impeller /
Motor Impeller / Diffuser Kit Impeller Diffuser Impeller Diffuser
Diffuser Kit* D99 & Older
D99 & OlderCurrent Model
8
7
Ejector Gasket
6450-217
1
2
8
3
4
5a or 5b
6Pump body
O-ring 3134-133
8600 Pump 8500
Pump
*Body/Housing Seal
1
2
3
4
4
8
6
7
5a
5b
*Kit includes impeller, diffuser, rotary seal, housing gasket, & O-ring with instructions.
8
Miscellaneous Parts
8500 / 8600 Repair Parts
Pump Repair Parts - 11
42 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Description Part # List Part # List Part # List Part # List Part # List Part # List
Motor 6127-154 $ 340.00 6127-154 $ 340.00 6127-160 $ 395.00 6127-154 $ 340.00 6127-160 $ 395.00 6127-156 $ 440.00
Brass Impeller 6316-210 $ 207.00 6316-209 $ 206.00 6316-208 $ 196.00 6316-210 $ 207.00 6316-209 $ 206.00 6316-208 $ 196.00
Plastic Impeller 6316-252 $ 35.00 6316-251 $ 33.00 6316-250 $ 37.00 6316-252 $ 35.00 6316-251 $ 33.00 6316-250 $ 37.00
1/2 HP 3/4HP 1 HP 3/4HP 1 HP 1 1/2 HP
1050 & 1550 1075 & 1575 1010 & 1510 1075SW & 1575SW 1010SW & 1510SW 1015SW & 1515SW
Part # Description List Price
3129-394 1000 Series motor cover (Magnetek) $ 53.00
6127-334 Shaft assembly $ 127.00
6316-241 Adapter $ 219.00
6152-207 Body Gasket $ 2.16
3100-529 Capscrews $ 0.36
6422-103 Shaft Seal $ 44.00
6316-216 1st Diffuser $ 107.00
3121-509 Drive pin (supplied w/1 duffuser) $ 3.47
6316-217 2nd diffuser $ 89.00
6127-335 Diffuser cover assembly * $ 157.00
6421-124 Flange assembly+ $ 125.00
3100-545 Diffuser capscrews $ 0.61
Part # Description List Price
6127-336 Impeller spacer kit* $ 25.00
3104-131 Impeller locknut $ 1.13
6316-228 Impeller Key $ 6.09
6316-213 Cover gasket $ 4.34
6316-234 1000 Series body assembly $ 384.00
6316-235 1500 Series body assembly $ 395.00
6127-248 1500 Series pump foot $ 6.09
3100-530 Pump foot capscrew $ 0.27
5999-902 Series vent cock (1000 Series) $ 8.13
3126-103 1/8” plug $ 1.01
6316-227 Diffuser Cover $ 147.00
5999-842 Impeller spacer 1500/1000 Series $ 30.00
Models Part# List Part# List
7109MP & 7125MP 6414-207 $ 17.00 5999-911 $ 52.00
7110MP & 7126MP 6413-203 $ 17.00 6128-201 $ 4.34
7111MP & 7127MP 6421-217 $ 17.00 5999-911 $ 51.00
7112MP & 7128MP 6421-219 $ 17.00 5999-913 $ 52.00
7113MP & 7129MP 6414-208 $ 20.00 5999-912 $ 52.00
7114MP & 7130MP 6414-208 $ 20.00 5999-911 $ 52.00
2003 & Newer Venturi Nozzle
Models HP Part# List
659 JP 3/4 HP 6155-314 $ 20.00
658JP 1 HP 6155-316 $ 6.68
652JP 1 1/2 HP 6155-212 $ 9.73
Venturi Assembly
1
9
9
2
3
4
5
6 7
8
10
11
12
15
16
18
19
20
21
22
23
24
25
26
26
Model Part # Description List Price
-- 5999-863 Body assembly $ 75.00
-- 6152-213 Adjustment screw $ 17.00
-- 6453-204 Diaphragm for reg. valve $ 9.48
-- 6453-224 Regulator spring $ 6.09
17
Reference page 43 for diagrams of 1000 & 1500 Series pumps.
*Includes body gasket (5) and cover gasket (21).
+For 1000 series, sold separately.
1000 / 1500 Repair Parts
Shallow Well Jet Packages Deep Well Jet Package
Miscellaneous - Pressure Regulator
11 - Pump Repair Parts
43
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
SERIES 1000 - VERTICAL
1
2
SERIES 1500 - HORIZONTAL
1
3
4
5
6
7
8
9
10
11
9
12
15
17
18
19
20
21
23
24
26
9
26
26
16
25
Regulating
Valve
22
1000 / 1500 Repair Parts
Pump Repair Parts - 11
44 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Pump Model Model # Part # List Model # Part # List Model # Part # List
92030 92050RM 6712-258 $ 440.00 92050RK 6712-046 $ 103.00 92100RV 6712-262 $ 359.00
92031 92050RM 6712-258 $ 440.00 92051RK 6712-047 $ 156.00 92100RV 6712-262 $ 359.00
92050 92050RM 6712-258 $ 440.00 92050RK 6712-046 $ 103.00 92100RV 6712-262 $ 359.00
92051 92050RM 6712-258 $ 440.00 92051RK 6712-047 $ 156.00 92100RV 6712-262 $ 359.00
92070 92070RM 6712-257 $ 499.00 92070RK 6712-045 $ 108.00 92100RV 6712-262 $ 359.00
92100 92100RM 6712-256 $ 580.00 92100RK 6712-044 $ 111.00 92100RV 6712-262 $ 359.00
92150 92150RM 6712-255 $ 678.00 92150RK 6712-043 $ 117.00 92100RV 6712-262 $ 359.00
92200 92200RM 6712-254 $ 893.00 92200RK 6712-042 $ 128.00 92200RV 6712-261 $ 407.00
92250 92250RM 6712-253 $ 949.00 92250RK 6712-041 $ 133.00 92300RV 6712-260 $ 435.00
92300 92300RM 6712-252 $ 1,082.00 92300RK 6712-040 $143.00 92300RV 6712-260 $ 435.00
Repair Motor Impeller/Seal Kit Volute Assembly
Model Part # Description List Price
92000SP 6712-250 Seal Plate $ 111.00
92000RS 6712-268 Rotary seal $ 35.00
92000RO 6712-267 O-ring for seal plate $ 4.35
92000MB 6712-251 Mounting base $ 31.00
--- 3100-565 Hex cap screws $ 0.53
Catalog
Number HP Volts List
6903-280 1/2 115/230 $ 309.00
6903-281 3/4 230/115 $ 333.00
6903-282 1 230/115 $ 390.00
6903-283 1 1/2 230/115 $ 451.00
6903-284 2 230 $ 506.00
Catalog Model
Number Number List
6903-041 27000KIT $ 22.00
Repair gauge kit (use for alignment when
assembling motor and pump end back together).
See page 21 for pump ends.
Pipe plugs & pet
cock (drain) are
included with
volute assemblies.
123
4
5
6
7
8
NEMA C (Keyed shaft) Motor
Single Phase, Open Drip Proof (ODP)
Capacitor Start
92000 / 93000 Series Repair Parts
Superbooster Motors
11 - Pump Repair Parts
45
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Model Part # Description List Price
87000RB 6180-270 Pump body w/plugs $ 366.00
87000RA 6180-271 Motor Adapter $ 276.00
87000DO 6180-272 Diffuser O-ring $ 15.00
87000AO 6180-273 Adapter/Body O-ring $ 17.00
87000PS 6180-275 Diffuser/Body O-ring $ 10.30
87000CS 6180-276 Hex Cap screws $ 8.12
87000DV 6180-277 Drain Valve $ 10.30
87000RS Rotary Shaft Seal Contact
Factory
Description Model # Part # List Model # Part # List Model # Part # List Model # Part # List
Repair motor -- -- -- -- -- -- -- 6180-231 $ 563.00 - 6180-278 $ 588.00
Impeller/
87070RK 6180-008 $ 107.00 87100RK 6180-009 $ 110.00 87150RK 6180-010 $ 111.00 87200RK 6180-011 $ 111.00
diffuser kit
87070 87100 87150 87200
1
* Includes impeller, diffuser, diffuser o-ring, diffuser
plate, adapter/body o-ring, and rotary shaft seal
Motor Shaft
(Repair N/A)
*
1
*2
3
4
6
7
5
87000 Series Repair Parts
Pump Repair Parts - 11
46 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Hardware Items
15 - 1/4" NPT Pipe Plug
17 - 3/8-16 x 1" Hex Head Bolt
18 -3/8-16 x 3/4" Hex Head Bolt
20 - 3/8-16 x 1 1/2" Hex Head Bolt
21 - Hex Nut
24 - 3/8-16 x 7/8" Hex Head Bolt
84300 and 84500
(1998 and After)
84300 84500
3 HP 5 HP
REF# Model# Description Part# List $ Part# List $
#1 Body Houseing
#2 84000D Diuser - - - -
#3 84075RK Overhaul Kit* - - - -
#3 84100RK Overhaul Kit* - - - -
#3 84150RK Overhaul Kit* - - - -
#3 84200RK Overhaul Kit* - - - -
#3 84300IMP Impeller - - - -
#3 84500IMP Impeller - - - -
#5 84000VCV Valve Body - - - -
#5 84500VB Valve Body - - - -
#6 84000VG Flapper Valve - - - -
#7 84000TW Top Weight - - - -
#8 84000BW Bottom Weight - - - -
#10 84100SL Slinger kit - - - -
#10 84000SLG Slinger Kit - - - -
#11 84000SL Shaft Seal Kit - - - -
#12 84000DR DiuerRing - - - -
#16 84000GSKT Gasket - - - -
#19 Motor - - - -
#22 84000SS Shaft Sleeve - - - -
#23 84000SL Spring Holder - - - -
#28 Base - - - -
#31 84300WSH Impeller Washer - - - -
#31 84500WSH Impeller Washer - - - -
REF# Description No longer available
4 Seal Plate X
9 Mach Screw - Hex Head Bolt X
29 Hex Bolt X
30 Key X
* MUST PURCHASE IN KIT
Each overhaul kit includes: #3 impeller, #10 slinger, #16 gasket, and
hardware items 84000SL includes #11 & #23
84000 Series Repair Parts
(1984 & After)
11 - Pump Repair Parts
Contact factory for
repair part pricing.
47
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
REF # Description
1 Casing
2 Adapter
3 Diuser
4 Impeller 3/4 HP
4 Impeller 1 HP
4 Impeller 1 1/2 HP
4 Impeller 2 HP
5 Plug, 1/4” NPT
6 Pllug, 3/4” NPT
7 Gasket
8 O-Ring
9 Motor, 3/4 HP, 1 phase, 115/230,
9 Motor, 1 HP, 1 phase 115/230, square
9 Motor 1 1/2 HP, 1 phase, 115/230, square
9 1 Motor 2 HP, 1 phase, 230V, square
10 Bolt, 3/8” UNC x 1”
11 Bolt, 7/16” UNC x 1 1/4”
12 Screw, #10-24 UNC x 1”
13 Seal, 5/8” diameter 3/4, 1, 1 1/2 HP
13 Seal, 3/4” diameter 2 HP
x Slinger 1.25x .59x.09
KIT REF #
88000RK Overhaul Kit includes: 3, 4, 7, 8, 10, 11, 12, 13, x
88000CSG Casing Kit includes: 1, 5, 6, 7, 11
88000FS Fastener Kit includes: 10, 11, 12, x
88000AD Adapter Kit includes: 2, 7, 10, 11, 12
88000GS Gasket Kit includes: 7, 8
3/4 HP 1 HP 1 1/2 HP 2 HP
88075 88100 88150 88200
Model# Description Part# List $ Part# List $ Part# List $ Part# List $
Motor 6180-292 $923.00 6180-293
$1,065.00
6180-294
$1,259.00
6180-295 $1,356.00
88075RK Overhaul Kit* 6180-298 $134.00 - - - - - -
88100RK Overhaul Kit* - - 6180-299 $135.00 - - - -
88150RK Overhaul Kit* - - - - 6180-300 $137.00 - -
88200RK Overhaul Kit* - - - - - - 6180-301 $252.00
88000CSG Casing Kit* 6180-302 $169.00 6180-302 $169.00 6180-302 $169.00 6180-302 $169.00
88000FS Fastener Kit* 6180-303 $46.00 6180-303 $46.00 6180-303 $46.00 6180-303 $46.00
88000AD Adapter Kit* 6180-304 $184.00 6180-304 $184.00 6180-304 $184.00 6180-304 $184.00
88000GS Gasket Kit* 6180-305 $24.00 6180-305 $24.00 6180-305 $24.00 6180-305 $24.00
Repair parts sold in kits only.
88000 Series Repair Parts
Lawn & Turf Sprinkler Pumps (3/4 HP - 2 HP Models, Square Flange)
Pump Repair Parts - 11
48 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
11 - Pump Repair Parts
Non-Potable
Use Only
Model Part # Description List Price
747H20FL 6225-002 Float Package (Old Style - Pre Oct. 2014) $ 32.00
747H20FL2 6225-017 Float Package (New Style) $ 32.00
- Float, Float Rod, four rubber grommet
 stoppers,stando,andhoseclamp
747H20MT 6225-004 Mounting Package $ 26.00
- Galvanized Nipple 1/4" x 5
- Mounting Bracket 1/4" FNPT Zinc Flange
- Elbow 1/4" 90º Galvanized Iron
- Split Ring Hanger 1 1/4" OD-Zinc
747H20SC 6225-003 Suction Kit $ 23.00
- Suction Tube - 1" PVC
- Inlet Strainer
- Adaptor PVC x FNPT 1" SCH 40
- Hose Clamp
747H20SV 6225-001
Switch Valve Replacement (Old Style - Pre Oct. 2014)
$ 309.00
747H20SV2 6225-016 Switch Valve Replacement (New Style) $ 309.00
- To replace the mechanically activated
 diaphragmvalvewithattachedoatmechanism
*Repair parts/pieces are not sold separately for this valve.
5040-007 Basic Guardian Single Check $ 38.00
6225-525 Jet Package Kit $ 67.00
- Jet Body and Venturi Nozzle Assembly
6155-316 Venturi/Nozzle Assembly $ 6.49
1
5
3
4
2
City
Water Nozzle
Creates a
Vacuum
Here’s How
It Works...
Vacuum
pulls
water from
sump pit
Emergency Back Up Sump Pump
The Guardian consists of all
components outlined
Guardian Repair Parts
4
3
5
2
1
49
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
DuraMACTM Booster Repair Parts
Pump Repair Parts - 11
Non-Potable
Use Only
17035R020PC1 List
6010-003 - 17035R020P-1 Pump 120V
Pump +35 | 20 GPM | 1/2 HP | 120V $ 719.00
6010-001 - Repair Control | 120V with Tee $ 789.00
6010-009 - Repair Control | 120V (Black box) $ 504.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6127-337 - Two gallon diaphragm tank $ 159.00
6010-027 - Check Valve | 1” MNPT x 1” MNPT $ 52.00
6010-554 - Seal kit $ 39.00
6010-028 - Pressure Gauge | 0 - 100 | 2” Dry $ 18.00
17052R020PC1 List
6010-004 - 17052R020P-1 Pump 120V
Pump +52 | 20 GPM | 3/4 HP | 120V $ 772.00
6010-001 - Repair Control | 120V with Tee $ 789.00
6010-009 - Repair Control | 120V (Black box) $ 504.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6127-337 - Two gallon diaphragm tank $ 159.00
6010-027 - Check Valve | 1” MNPT x 1” MNPT $ 52.00
6010-554 - Seal kit $ 39.00
6010-028 - Pressure Gauge | 0 - 100 | 2” Dry $ 18.00
17070R020PC2 List
6010-005 - 17070R020P-2 Pump 230V
Pump +70 | 20 GPM | 1 HP | 230V $ 847.00
6010-002 - Repair Control | 230V with Tee $ 1,100.00
6010-010 - Repair Control | 230V (Black box) $ 729.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6127-337 - Two gallon diaphragm tank $ 159.00
6010-027 - Check Valve | 1” MNPT x 1” MNPT $ 52.00
6010-554 - Seal kit $ 39.00
6010-028 - Pressure Gauge | 0 - 100 | 2” Dry $ 18.00
Residential Light Commercial
17044C070PC2-M | 17044C070PC2-S | 17044C120PC2-D
List
6010-017
- 17044C070P-2 Pump 230V
Pump +44 | 70 GPM | 230V $ 1,331.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6011-009 - Dual-Mode Control | Repair (Black box) $ 567.00
6011-012 - Paddle Switch $ 462.00
6127-341 - 16020MV4F - Pressure Tank $ 378.00
6011-011 - Pressure Gauge | 0 - 100 | 2 1/2” Liquid lled $ 46.00
6010-555 - Seal kit $ 49.00
5424-401 - Ball Valve | 1/4” MNPT x 1/4” FNPT (Test Cock) $ 6.01
17060C070PC2-M | 17060C070PC2-S | 17060C120PC2-D
List
6010-018
- 17060C070P-2 Pump 230V
Pump +60 | 70 GPM | 230V $ 1,339.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6011-009 - Dual-Mode Control | Repair (Black box) $ 567.00
6011-012 - Paddle Switch $ 462.00
6127-341 - 16020MV4F - Pressure Tank $ 378.00
6011-011 - Pressure Gauge | 0 - 100 | 2 1/2” Liquid lled $ 46.00
6010-555 - Seal kit $ 49.00
5424-401 - Ball Valve | 1/4” MNPT x 1/4” FNPT (Test Cock) $ 6.01
17040C035PC2 List
6010-011
- 17040C035P-2 Pump 230V
Pump +40 | 35 GPM | 1 HP | 230V $ 789.00
6010-002 - Repair Control | 230V with Tee $ 1,100.00
6010-010 - Repair Control | 230V (Black box) $ 729.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6127-337 - Two gallon diaphragm tank $ 159.00
6010-029 - Check Valve | 1 1/4” MNPT x 1 1/4” FNPT $ 57.00
6010-554 - Seal kit $ 39.00
6010-028 - Pressure Gauge | 0 - 100 | 2” Dry $ 18.00
17062C035PC2 List
6010-012
- 17062C035P-2 Pump 230V
Pump +62 | 35 GPM | 1 HP | 230V $ 850.00
6010-002 - Repair Control | 230V with Tee $ 1,100.00
6010-010 - Repair Control | 230V (Black box) $ 729.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6127-337 - Two gallon diaphragm tank $ 159.00
6010-029 - Check Valve | 1 1/4” MNPT x 1 1/4” FNPT $ 57.00
6010-554 - Seal kit $ 39.00
6010-028 - Pressure Gauge | 0 - 100 | 2” Dry $ 18.00
17078C035PC2 List
6010-013
- 17078C035P-2 Pump 230V
Pump +78 | 35 GPM | 1 1/2 HP | 230V $ 973.00
6010-002 - Repair Control | 230V with Tee $ 1,100.00
6010-010 - Repair Control | 230V (Black box) $ 729.00
6010-026 - Transducer | TDL32K | 150PSI | 5V $ 167.00
6127-337 - Two gallon diaphragm tank $ 159.00
6010-029 - Check Valve | 1 1/4” MNPT x 1 1/4” FNPT $ 57.00
6010-554 - Seal kit $ 39.00
6010-028 - Pressure Gauge | 0 - 100 | 2” Dry $ 18.00
Dual Mode - Modular,
Simplex, & Duplex
10
20
30
40 50 60
70
80
90
100
PSI
Dual-Mode
Simplex
50 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
Notes
51
Pumps and Accessories-Effective 12-11-16
A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Notes
52 A.Y. McDONALD MFG. CO. | P.O. BOX 508 | DUBUQUE, IA 52004-0508 | 800-292-2737 | FAX 800-832-9296
pumps@aymcdonald.com • aymcdonald.com
Pumps and Accessories-Effective 12-11-16
A.Y. McDonald Mfg. Co. is a leading manufacturer of Waterworks Brass,
Plumbing Valves, Pumps and Water Systems, and High Pressure Gas Valves
and Meter Bars. The Company has distinguished itself with a proud tradition
of quality and reliability since its founding in 1856.
The mission of A.Y. McDonald Mfg. Co., in the words of our founder, is “to
make good products and sell them honestly.” We, the stockholders and
employees, accomplish this by extending the McDonald family culture
through excellent customer service and by focusing on our customers’ needs.
800.292.2737 | FAX 800.832.9296 | pumps@aymcdonald.com | aymcdonald.com
More than a brand. We’re a family.
Locations: Albia, IA | Dubuque, IA | Elizabethton, TN | Sparks, NV
12-16

Navigation menu
