600 Series
Features
The "Sewage-Waste" series of submersible pumps is designed for use in
commercial dewatering and wastewater applications and can be used to transfer
wastewater or unscreened raw sewage. The semi-open reversing impeller
design reduces the risk of clogging and allows each pump to pass a 2½ (63
mm) spherical solid. These durable cast iron pumps include a powder coated
epoxy finish to prevent corrosion, and are designed to provide great heat
dissipation from the motor, ensuring a long service life. As with every Zoeller
pump, each one is 100% pressure-tested, submerged and run to ensure quality
and reliability for years of trouble-free performance! This attention to detail is an
inherent feture in every pump of this series, making it one of the most reliable in
the industry.
Variable level control systems and containers of various sizes are available for
longer cycles.
Double seal models improve bearing lubrication and aid in the prevention of
leaks and damage to seals or bearings during dry run conditions.
Includes a stainless steel handle for easy installation and removal.
All models are hermetically sealed to be watertight, dust-tight, and completely
submersible.
Reserve Powered Design: For unusual conditions, a reserve safety factor is
engineered into the design of every pump.
Specifications
Motor Characteristics
Horse Power 1 - 7.5 HP
Voltage 200 - 575 V
Phase 1 or 3 Ph
Hertz 60 Hz
RPM 1750 RPM
Type Capacitor start capacitor run or 3 phase
Insulation Class F
Amps 1.6 - 28.0 Amps
Pump Characteristics
Operation Nonautomatic
Discharge Size 3" NPT (optional 3" or 4" flange available)
Solids Handling 2-1/2" (63 mm) spherical solids
Cord Length 25' (8 m) standard
Cord Type UL listed
Max Head 65' (19.8 m)
Max Flow Rate 533 GPM (2018 LPM)
Max Operating Temp 104° F (40° C)
Cooling Oil filled
Motor Protection Auto reset thermal overload (1 Ph)
Materials Characteristics
Cap Cast iron
Motor Housing Cast iron
Pump Housing Cast iron
Base Cast iron
Upper Bearing Ball bearing
Lower Bearing Ball bearing
Mechanical Seals Tandem carbon and ceramic
Impeller Type Semi-open
Impeller Ductile iron
Hardware Stainless steel
Motor Shaft Stainless steel
Gasket Buna N O-Ring
FM1591_Ea
Model
Model Number Seal Mode Volts Phase Amps HP Hz Lbs Kg
E611 Double Non 230 1 6.9 1 60 245 111
J611 Double Non 200 3 4.3 1 60 245 111
F611 Double Non 230 3 3.7 1 60 245 111
G611 Double Non 460 3 1.9 1 60 245 111
BA611 Double Non 575 3 1.6 1 60 245 111
E621 Double Non 230 1 8.9 1-1/2 60 245 111
J621 Double Non 200 3 5.9 1-1/2 60 245 111
F621 Double Non 230 3 5.1 1-1/2 60 245 111
G621 Double Non 460 3 2.6 1-1/2 60 245 111
BA621 Double Non 575 3 2.0 1-1/2 60 245 111
E631 Double Non 230 1 14.5 2 60 245 111
J631 Double Non 200 3 7.8 2 60 245 111
F631 Double Non 230 3 6.8 2 60 245 111
G631 Double Non 460 3 3.4 2 60 245 111
BA631 Double Non 575 3 2.7 2 60 245 111
E641 Double Non 230 1 17.0 3 60 245 111
J641 Double Non 200 3 11.0 3 60 245 111
F641 Double Non 230 3 9.6 3 60 245 111
G641 Double Non 460 3 4.8 3 60 245 111
BA641 Double Non 575 3 3.9 3 60 245 111
E651 Double Non 230 1 28.0 5 60 245 111
J651 Double Non 200 3 17.5 5 60 245 111
F651 Double Non 230 3 15.2 5 60 245 111
G651 Double Non 460 3 7.6 5 60 245 111
BA651 Double Non 575 3 6.1 5 60 245 111
J661 Double Non 200 3 25.3 7-1/2 60 245 111
F661 Double Non 230 3 22.0 7-1/2 60 245 111
G661 Double Non 460 3 11.0 7-1/2 60 245 111
BA661 Double Non 575 3 9.0 7-1/2 60 245 111
Additional cord lengths are available in 35' (11 m) and 50' (15 m). 75' (22 m) cords are available for 3 Ph units only.
