Models 6342, 6343, 6344 Models 6345, 6346, 6347 Models 6336, 6339, 6337,
6340, 6338, 6341
1 of 2
Commercial/Residential
For Portable Generators
Power Inlet Boxes
Features
Power Inlet Boxes
•Safelyconnectsyourportablegeneratortoyourtransferswitch.
PowerInletBox
2 of 2
Power Inlet Boxes
GeneracPowerSystems,Inc.•P.O.Box8,Waukesha,WI53187•generac.com
©2012GeneracPowerSystems,Inc.Allrightsreserved.Allspecificationsaresubjecttochangewithoutnotice.Bulletin0196860SBY-A/PrintedinU.S.A.09/04/12
®
Specifications
Model 6344 6338 6341 6347
UPC 696471063448 696471063387 696471063417 696471063479
NEMAConfiguration CS6365 CS6365 CS6365withspringloadedfliplid
Amperage 50
VoltageRating 125/250VAC
MaximumGeneratorSize(Watts) 12500
EnclosureMaterial
Corrosion-resistantaluminumprovideslong
life,andcanbepainted.
Retainsraintightratingwhileinuse.
Non-metallicresinenclosureincludes6knockoutsforultimatewiringflexibility.
Madefromdurable,high-impact,glass-fillednylon.Retainsraintightratingwhileinuse.
Corrosion-resistantaluminumprovideslong
life,andcanbepainted.
FlipLidcoverstheinlettokeepoutnesting
insects,dirt,moisture,andmore.
RaintightEnclosure • • •
CompatibleGeneracGenerators GP15000E,GP17500E,XG10000E,XP10000E
CompatibleTransferSwitches
(Model#'s) 6380,6381,6335
Warranty 2Year
Model 6342 6336 6339 6345 6343 6337 6340 6346
UPC 696471063424 696471063363 696471063394 696471063455 696471063431 696471063370 696471063400 696471063462
NEMAConfiguration L14-20 L14-20 L14-20withspringloadedfliplid L14-30 L14-30 L14-30withspringloadedfliplid
Amperage 20 30
VoltageRating 125/250VAC 125/250VAC
MaximumGenerator
Size(Watts) 5000 7500
EnclosureMaterial
Corrosion-resistant
aluminumprovides
longlife,andcanbe
painted.
Retainsraintightrating
whileinuse.
Non-metallicresinenclosureincludes6
knockoutsforultimatewiringflexibility.
Madefromdurable,high-impact,glass-filled
nylon.Retainsraintightratingwhileinuse.
Corrosion-resistant
aluminumprovides
longlife,andcanbe
painted.
FlipLidcoverstheinlet
tokeepoutnesting
insects,dirt,moisture,
andmore.
Corrosion-resistant
aluminumprovides
longlife,andcanbe
painted.
Retainsraintightrating
whileinuse.
Non-metallicresinenclosureincludes6
knockoutsforultimatewiringflexibility.
Madefromdurable,high-impact,glass-filled
nylon.Retainsraintightratingwhileinuse.
Corrosion-resistant
aluminumprovides
longlife,andcanbe
painted.
FlipLidcoverstheinlet
tokeepoutnesting
insects,dirt,moisture,
andmore.
RaintightEnclosure • • • • • •
CompatibleGenerac
Generators GP3250,LP3250,XG4000,XP4000 GP3250,LP3250,XG4000,XP4000,GP5500,GP6500E,GP7500E,XG6500,XG7000E,XG8000E,
XP6500E,XP8000E
CompatibleTransfer
Switches(Model#'s) 6376,6377,6378,6379 6376,6378,6377,6379,6382
Warranty 2Year
Spring Loaded Flip Lid- Model 6393
Accessory
CompatiblewithanyGeneracGenTranPowerInletBoxmodels6342,6343,6344,6336,6337,&6338
Mustbemountedpriortoinstallation
ULListed
Model 6342 6336 6339 6345 6343 6337 6340 6346 6344 6338 6341 6347 6393
Product
LxWxH
in(mm)
6x5x5
(152x127x127)
5x5x7
(127x127x178)
6x5x5
(152x127x127)
5x5x7
(127x127x178)
6x5x5
(152x127x127)
5x5x7
(127x127x178)
6x8
(152x203)
ProductWeight
lb(kg) 3(1.25) 2(1) 3(1.25) 3(1.25) 3(1.25) 2(1) 3(1.25) 3(1.25) 3(1.25) 2(1) 3(1.25) 3(1.25) 0.5(0.2)
MasterCarton
Quantity 3333333333335
MasterCarton
UPC 20696471063428 20696471063367 20696471063398 20696471063459 20696471063435 20696471063374 20696471063404 20696471063466 20696471063442 20696471063381 20696471063411 20696471063473 20696471063930
MasterCarton
LxWxH
in(mm)
16.5x6.5x6(419x165x152) 16.5x5x7
(419x127x178) 16.5x6.5x6(419x165x152) 16.5x5x7
(419x127x178) 16.5x6.5x6(419x165x152) 16.5x5x7
(419x127x178)
9x6x5
(229x152x127)
MasterCarton
Weightlb(kg) 9(4) 6(3) 9(4) 9(4) 9(4) 6(3) 9(4) 9(4) 9(4) 6(3) 9(4) 9(4) 3(1.25)
Dimensions and Weights
Power Inlet Boxes
