iX SERIES

Commercial/Residential

Portable Generators

iX2000

Models 5793-0, 5793-1, 5793-2 UPC: 696471057935

(EPA/49-State/cETL)

Features

49-State Control Panel

®

iX2000

• Inverter technology creates quiet, clean power.

• Lightweight, compact design with built in handle for

easy portability.

• Low-oil level shutdown automatically safeguards

engine from damage.

• FlexPower™ Mode saves fuel and reduces noise.

• Durable, fully enclosed case for added durability and

strength.

• Circuit breakers provide electronic overload protection.

• LED lights indicate status.

AC Rated Output Running Watts 2000

AC Maximum Output Starting Watts 2200

(1) 120V 20A 5-15R Duplex Outlet

FlexPower™ Switch

Ground

(1) 12V DC Outlet

Status LEDs

Length in (mm) 22 (559)

Width in (mm) 12 (305)

Height in (mm) 18 (457)

Carton Length in (mm) 25 (635)

Carton Width in (mm) 13.75 (350)

Carton Height in (mm) 20.75 (525)

Unit Weight lbs (kg) 52 (23.5)

Shipping Weight lbs (kg) 63 (28.4)

Product Series iX2000

Model (Configuration) 5793-0, 5793-1, 5793-2

(EPA/49-State/cETL)

AC Rated Output Running Watts 2000

AC Maximum Output Starting Watts 2200

Rated AC Voltage 120 VAC

Rated AC Frequency 60 Hz

Rated 120 VAC Amperage 16.7

Max 120 VAC Amperage 18.3

Engine Displacement 127cc

Engine Type OHV

Engine RPM Variable

Recommended Oil 10W-30 / SAE 30

Lubrication Method Splash

Choke Location On Side of Unit

Fuel Shut Off On Side of Unit

Idle Control FlexPower™

Starting Method Recoil Pull Start

Low Oil Shutdown Low Level

Neutral Bonded to Ground No

Start Switch Type On/Off

Switch Location On Side of Unit

Fuel Tank Capacity Gal (Ltrs) 0.85 (3.23)

Run Time at 25% (Hours) 5.3

Maintenance Kit Sold Separately

Warranty- Residential 2 Year

Warranty- Commercial 6 Months

Dimensions and Weights

2 of 2

iX2000

GeneracPowerSystems,Inc.•P.O.Box8,Waukesha,WI53187•generac.com

©2012 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin0196550SBY-A/PrintedinU.S.A.09/17/12

iX2000

®

Specifications

Length

Width

Height
