REMOTE MONITORING
Scan ‘N View Yes
Dual Stream D1, CIF
Simultaneous Users 128 (bandwidth permitting)
QC858
NVR Technology IP
Channels 8
Recording Resolution 5MP / 3MP / 1080p / 720p / D1
Live Viewing Resolution 1920x1080, 1280x1024, 1280x720,
1024x768
Live Display FPS 30 FPS per Channel
Hard Drive Supports 1 HDD up to 4TB
Remote Monitoring 128 Simultaneous Users
Compatibility Mac and PC
Connects With IP Cameras
Monitor Connections
HDMI, VGA,
COMMUNICATION PORTS
Network RJ45 10/100 Mbps
USB 2 USB 2.0
eSATA None
COMPATIBILITY
Mobile Support iPhone, iPad, Android,
Computer Support WinXP, Vista, Win7/8,
Mac OS 10.7/10.8/10.9/10.10
VIDEO, AUDIO & ALARM PORTS
Video in 8 RJ45 POE
Video Out HDMI, VGA,
Alarm In None
Alarm Out None
Audio In 1 RCA
Audio Out 1 RCA
ACCESSORIES
Control USB Mouse,
Connectors / Cables HDMI Cable,
Mounting Hardware Screws for Hard Drives
Other Quick Start Guide
RECORDING
Recording Modes Manual, Time Schedule, Motion Detection
Backup Methods PC, Flash, USB Hard Drive
DVR
Video Compression H.264
Live Display Resolution 1920x1080, 1280x1024, 1280x720, 1024x768
Live Display FPS 30 FPS
Display Modes 1, 4, 8, Auto Sequence
Languages English, French, Spanish,
RECORDING RESOLUTION OPTIONS
5MP 2560 x 1920 pixels
3MP 2048 x 1536 pixels
1080P 1920 x 1080 pixels
720P 1280 x 720 pixels
D1 704 x 480 pixels
Playback Speed 5MP at 8 FPS per channel 64 FPS Total
3MP at 20 FPS per channel 160 FPS Total
1080P at 30 FPS per channel 240 FPS Total
720P at 30 FPS per channel 240 FPS Total
D1 at 30 FPS per channel 240 FPS Total
Number Channels 8 Simultaneous
PLAYBACK ON NVR
(QT858 cont’d…)
POWER
Power Supply 48v 2a
Power Consumption 12w (w/o HD)
PHYSICAL
Weight 1.5 lbs
Dimensions 10.75”W X 8”D X 1.75”H
Operating Temperature 14°– 131°F 10-90% Humidity
HARD DRIVES
Maximum Size 4TB
Number Supported 1
PTZ
PTZ Support Through CAT5e cable
Supported Protocols DH-SD, Pelco D/P (Settings through camera)
