REMOTE MONITORING
Scan ‘N View Yes
Dual Stream D1, CIF
Simultaneous Users 128 (bandwidth permitting)
QC8916
NVR Technology IP
Channels 16
Recording Resolution 4K / 12MP / 8MP / 6MP / 5MP / 4MP /
3MP / 1080p / 720p
Live Viewing Resolution 4K, 1080p, 720p, 1280x1024,
1024x768
Live Display FPS 30 FPS per Channel
Hard Drive Supports 2 HDD up to 6TB each
Remote Monitoring 128 Simultaneous Users
Compatibility Mac and PC
Connects With IP Cameras
COMMUNICATION PORTS
Network RJ45 10/100/1000 Mbps
USB 1 USB 3.0, 1 USB 2.0
eSATA No
COMPATIBILITY
Mobile Support iPhone, iPad, Android,
Computer Support WinXP, Vista, Win7/8,
Mac OS 10.7/10.8/10.9/10.10
VIDEO, AUDIO & ALARM PORTS
Video In 16 RJ45 POE - ONVIF 2.4
Video Out HDMI, VGA
Alarm In 4
Alarm Out 2
Audio In 1 RCA, 16 thru CAT5 cable
Audio Out 1 RCA
ACCESSORIES
Control USB Mouse, Remote Control
Connectors / Cables HDMI Cable,
Mounting Hardware Screws for Hard Drives
Other Quick Start Guide
RECORDING
Recording Modes Manual, Time Schedule, Motion Detection, Alarm
Backup Methods PC, Flash, USB Hard Drive, eSATA
NVR
Video Compression H.265 / H.264 (depending on camera)
Live Display Resolution 4K, 1080p, 720p, 1280x1024, 1024x768
Live Display FPS 30 FPS
Display Modes 1, 4, 8, 9, 16, Auto Sequence
Languages English, French, Spanish,
RECORDING RESOLUTION OPTIONS
4K 3840 x 2160 pixels
4MP 2560 x 1440 pixels
3MP 2048 x 1536 pixels
1080P 1920 x 1080 pixels
720P 1280 x 720 pixels
Playback Speed 4K at 7FPS per channel 112 FPS Total
4MP at 20 FPS per channel 320 FPS Total
3MP at 20 FPS per channel 320 FPS Total
1080P at 30 FPS per channel 480 FPS Total
720P at 30 FPS per channel 480 FPS Total
Number Channels 4 (full resolution) / 16 (low resolution)
PLAYBACK ON NVR
(QC8916 cont’d…)
PHYSICAL
Weight 10.25 lbs
Dimensions 17.5”W X 16.25”D X 2.75”H
Operating Temperature 14°– 131°F 10-90% Humidity
HARD DRIVES
Maximum Size 6TB
Number Supported 2
PTZ
PTZ Support Through CAT5e cable
Supported Protocols DH-SD, Pelco D/P (Settings through camera)
POWER
Power Supply AC 100-240V
Power Consumption 26.5W (w/o HD)
POE Max 25.5W /port
