REMOTE MONITORING
Scan ‘N View Yes
Dual Stream CIF @ 30FPS D1 @ 7FPS
Simultaneous Users 128
QC9032
DVR Technology BNC HD
Channels 32
Recording Resolution 1080p / 720p / 960H / D1 / CIF
Live Viewing Resolution 1080p / 720p / 1280x1024 / 1024x768
Live Display FPS 30 FPS per Channel
Hard Drive Supports 4 HDD up to 24TB
Remote Monitoring 128 Simultaneous Users
Compatibility Mac and PC
Connects With Local Cameras
Monitor Connections HDMI, VGA
COMMUNICATION PORTS
Network RJ45 10/100/1000 Mbps
USB 3 USB 2.0
eSATA 1 port
COMPATIBILITY
Software Support QC View
Mobile Support iPhone, iPad, Android
Computer Support WinXP, Vista, Win7/8/10
Mac OS 10.7/10.8/10.9/10.10
VIDEO, AUDIO & ALARM PORTS
Video in 32 BNC
Video Out HDMI (2), VGA, BNC
Alarm In 16
Alarm Out 5
Audio In 4 RCA
Audio Out 1 RCA
Mic 1 BNC in, 1 BNC out (2way talk)
RECORDING RESOLUTION OPTIONS
1080p Resolution 1920 x 1080 pixels
720P Resolution 1280 x 720 pixels
960H Resolution 960 x 480 pixels
D1 Resolution 704 x 480 pixels
CIF Resolution 352 x 240 pixels
RECORDING MODES
Recording Modes Manual, Time Schedule, Motion Detection, Alarm
Backup Methods PC, Flash, USB Hard Drive
Playback Speed 1080p at 15 FPS per channel 480 FPS total
720P at 30 FPS per channel 960 FPS total
960H at 30 FPS per channel 960 FPS total
D1 at 30 FPS per channel 960 FPS total
Number Channels 16 Simultaneous Local Playback
PLAYBACK ON DVR
DVR
Video Compression H.264
Live Display Resolution 1080p, 720p, 1280x1024, 1024x768
Live Display FPS 30 FPS
Display Modes 1, 4, 8, 9, 16, Auto Sequence
Languages English, French, Spanish
Control USB Mouse, Remote Control
Connectors / Cables HDMI Cable, BNC/RCA Adapter
Mounting Hardware Screws for Hard Drives, Rack
mount brackets
Other Quick Start Guide
ACCESSORIES
(QC9032 cont’d…)
POWER
Power Supply AC 110-240 V, 50/60 Hz
Power Consumption 40W (w/o HD)
PHYSICAL
Weight 10.25 lbs
Dimensions 17.5”W X 16.25”D X 2.75”H
Operating Temperature 14°– 131°F
HARD DRIVES
Maximum Size 6TB
Number Supported 4
PTZ
PTZ Support RS485 (Analog), RG59 cable (Analog HD)
Supported Protocols Pelco D, Pelco D, HD-SD
