REMOTE MONITORING

Scan ‘N View Yes

Dual Stream D1 @ 15PS, CIF @ 30FPS

Simultaneous Users 128 (bandwidth permitting)

QC918

DVR Technology

AnalogHD / BNC

Channels 8

Recording Resolution 1080p/720p/960H/D1/CIF

Live Viewing Resolution 1080p/720p/1280x1024/1024x768

800x600

Live Display FPS 30 FPS

Hard Drive Supports 1 HDD up to 4TB

Remote Monitoring 128 Simultaneous Users

Compatibility Mac and PC

Connects With Local Cameras

Monitor Connections HDMI, VGA

COMMUNICATION PORTS

Network RJ45 10/100 Mbps

USB 2 USB 2.0

eSATA None

VIDEO, AUDIO & ALARM PORTS

Video in 8 BNC

Video Out HDMI, VGA

Alarm In None

Alarm Out None

Audio In None

Audio Out None

RECORDING RESOLUTION OPTIONS

1080P Recording Option 1920 x 1080 pixels

720P Recording Option 1280 x 720 pixels

960H Recording Option 960 x 480 pixels

D1 Recording Option 704 x 480 pixels

RECORDING MODES

Recording Modes Manual, Time Schedule, Motion Detection

Backup Methods PC, Flash, USB Hard Drive

Playback Speed 1080 at 15 FPS per channel 120 FPS total

720P at 30 FPS per channel 240 FPS total

960H at 30 FPS per channel 240 FPS total

D1 at 30 FPS per channel 240 FPS total

Number Channels 8 Simultaneous Local Playback

PLAYBACK ON DVR

DVR

Video Compression H.264

Live Display Resolution 1080p, 720p, 1280x1024, 1024x768, 800x600

Live Display FPS 30 FPS

Display Modes 1, 4, 8, Auto Sequence

Languages English, French, Spanish

ACCESSORIES

Control USB Mouse

Connectors / Cables HDMI Cable

Mounting Hardware Screws for Hard Drives

Other Quick Start Guide

COMPATIBILITY

Application Support QC View

Browser Support IE, Firefox & Chrome (with IE

plugin)

Mobile Support iPhone, iPad, Android,

Computer Support WinXP, Vista, Win7/8,

Mac OS 10.7/10.8/10.9/10.10

(QC918 cont’d…)

POWER

Power Supply 12v 2A

Power Consumption 10w (w/o HD)

PHYSICAL

Weight 1 lb

Dimensions 8”W X 8”D X 1.5”H

Operating Temperature 14°– 131°F

HARD DRIVES

Maximum Size 4TB

Number Supported 1

PTZ

PTZ Support None

Supported Protocols Pelco D, Pelco P, HD-SD
