QCN8090B

Camera Type

Camera Technology

Video Compression

Image Sensor Size

Image Sensor Type

Image Resolution

Effective Pixels

Lens Size

Angle of View

IR Cut Filter

Bullet

IP

H.265/H.264

1/2.5”

4K Progressive scan CMOS

4K (8MP)

3840 x 2160

4 mm

88º Diagonal and 48º Horizontal

Yes

Storage Micro SD Card Max. 128GB

NIGHT VISION PTZ

IR LEDS Two high-power LED

Infrared Wavelength 850nM

Min Lux Illumination 0.07Lux/F2.0 (color), 0Lux/F2.0(IR on)

Night Vision Range Up to 98 Ft.

ADDITIONAL IMAGE FEATURES

Horizontal Rotation Not applicable

Vertical Tilt Not applicable

Preset and Cruise Patterns Not applicable

Intelligent Video Analysis (IVA)

Auto Iris No

On Screen Display No

Backlight CompensationBLC/HLC/DWDR

Electronic Shutter 1/3(4)~1/10000s

Gain Control Auto/Manual

Wide Dynamic Range DWDR

Noise Reduction 3D

REMOTE MONITORING

Use as Standalone Yes

Compatible Software QC View

Compatible Mobile Devices iPhone, iPad, Android

Compatible Systems QC-NVRs

IVA Functions Tripwire, Intrusion, Abadon

Missing Object

CONNECTIVITY

Connector Types RJ45 (10/100Base-T)

Other Connections 2.1mm power

Wireless No

ONVIF 2.3 PSIA,CGI

POWER

Power Supply DC 12V or POE

Power Consumption < 6.7 W

RESOLUTION AND FRAME RATE

PHYSICAL ATTRIBUTES

4K (3840 x 2160) 15FPS

3MP (2048 x 1536) 25FPS

1080p (1920 x 1080) 30FPS

30FPS

Weatherproof Yes

IP Rating IP67

Body Construction Metal

Mounting Hardware Screws

Weight 14.32 oz

Dimensions 7.09” x 2.75” x 2.75”

Operating Temperature -22° to 140°F

720p (1280 x 720)

D1 (704 x 576) 30FPS

www.q-see.com DIGITAL PERIPHERAL SOLUTIONS, INC. | 8015 E. CRYSTAL DR., ANAHEIM, CA 92807 USA
