Model QT5682

Type Analog

Video Format NTSC/PAL

Live Display Resolution(s) 720x480, 720P, 1080P

Video Compression H264

Live Display FPS 30

Languages

English, Chinese (Simplified & Traditional), Czech, French,

Portuguese, Spanish, Turkish, Bulgarian, Greek, Italian, German,

Russian, Polish, Japanese, Indonesian, Thai, Hungarian,

Lithuanian, Vietnamese, Dutch, Swedish, Norwegian, Persian,

Arabic, Romanian

CIF

CIF Recording Display

Resolutions

352x240

CIF Recording FPS 30

2CIF

2CIF Recording Display

Resolutions

Not Applicable

2CIF Recording FPS Not Applicable

D1

D1 Recording Display

Resolutions

702x480

D1 Recording FPS 30

960H

960H Recording Display

Resolutions

960x480

960H Recording FPS 15

720p

720p Recording Display

Resolutions

Not Applicable

720p Recording FPS Not Applicable

1080p

1080p Recording Display

Resolutions

Not Applicable

1080p Recording FPS Not Applicable

Hard Drives

Maximum Size 3TB

Number Supported 1

Recording

Recording Modes Manual, Time Schedule, Motion Detection

Display Modes 1, 4, 8, Auto Sequence

Backup Methods USB Flash Drive, USB Hard Drive, Network

Playback

Playback Speed 30FPS

Number Channels

Simultaneous Local Playback

8

Video, Audio & Alarm Ports

Video In 8 BNC

Video Out HDMI, VGA, BNC (main or spot out)

Alarm In None

Alarm Out None

Audio In 2

Audio Out 1

PTZ

PTZ Support RS485

Supported Protocols

Null, Pelco D, Pelco D, Lilin, Minking, Neon, Star, VIDO, DSCP,

VISCA, Samsung, RM110, HY

Communication Ports

Network RJ45 10/100 mbps

USB 2 USB 2.0

eSATA None

Compatibility

Software Support QT View

Mobile Support iPhone, iPad, Android

Computer Support WinXP, Vista, Win7/8, Mac OS 10.7/10.8/10.9

Remote Monitoring

Scan N’ View Support Yes

Dual Stream CIF

Simultaneous Users 10

Power

Power Supply 12V 2A

Power Consumption 13W w/o hard drive

Physical

Weight 3.3 lbs

Dimensions (WxDxH) 10 x 8.25 x 1.75 in

Operating Temperature Range 50°F to 104° F

Accessories

Control Remote, Mouse

Connectors/Cables HDMI, RCA to BNC Adapter

Power 12V 2A

Mounting Hardware Hard Drive Screws

Other CD with manuals & software, quick start guide
