Model QT5716
Type Analog
Video Format NTSC/PAL
Live Display Resolution(s) 1080P, 720P, 1280x1024, 1024x768, 704x480
Video Compression H264
Live Display FPS 30
Languages
English, Chinese (Simplified & Traditional), Czech, French,
Portuguese, Spanish, Turkish, Bulgarian, Greek, Italian, German,
Russian, Polish, Japanese, Indonesian, Thai, Hungarian,
Lithuanian, Vietnamese, Dutch, Swedish, Norwegian, Persian,
Arabic, Romanian
CIF
CIF Recording Display
Resolutions
352x240
CIF Recording FPS 30
2CIF
2CIF Recording Display
Resolutions
Not Applicable
2CIF Recording FPS Not Applicable
D1
D1 Recording Display
Resolutions
702x480
D1 Recording FPS 30
960H
960H Recording Display
Resolutions
960x480
960H Recording FPS 15
720p
720p Recording Display
Resolutions
Not Applicable
720p Recording FPS Not Applicable
1080p
1080p Recording Display
Resolutions
Not Applicable
1080p Recording FPS Not Applicable
Hard Drives
Maximum Size 3TB
Number Supported 1
Recording
Recording Modes Manual, Time Schedule, Motion Detection
Display Modes 1, 4, 8, 16, Auto Sequence
Backup Methods USB Flash Drive, USB Hard Drive, Network
Playback
Playback Speed 30FPS
Number Channels
Simultaneous Local Playback
16
Video, Audio & Alarm Ports
Video In 16 BNC
Video Out HDMI, VGA, BNC
Alarm In None
Alarm Out None
Audio In 2 (2 way available on 1st port)
Audio Out 1
PTZ
PTZ Support RS485
Supported Protocols
Null, Pelco D, Pelco D, Lilin, Minking, Neon, Star, VIDO, DSCP,
VISCA, Samsung, RM110, HY
Communication Ports
Network RJ45 10/100 mbps,
USB 2 USB 2.0
eSATA None
Compatibility
Software Support QT View
Mobile Support iPhone, iPad, Android
Computer Support WinXP, Vista, Win7/8, Mac OS 10.7/10.8/10.9
Remote Monitoring
Scan N’ View Support Yes
Dual Stream CIF
Simultaneous Users 10
Power
Power Supply 12V 2A
Power Consumption 13W w/o hard drive
Physical
Weight 3.3 lbs
Dimensions (WxDxH) 11.75 x 10.75 x 2 in
Operating Temperature Range 50°F to 104° F
Accessories
Control Remote, Mouse
Connectors/Cables HDMI, RCA to BNC Adapter
Power 12V 2A
Mounting Hardware Hard Drive Screws
Other Quick start guide
