S-5959
REMOTE MONITORING
Scan ‘N View Yes
Dual Stream CIF
Simultaneous Users 10
QT5816
DVR Technology Analog
Channels 16
Recording Resolution 960H / D1 / CIF
Live Viewing Resolution 1080P/720P/1280x1024/1024x768/
720x480
Live Display FPS 30 FPS per Channel
Hard Drive Supports 1 HDD up to 3TB
Remote Monitoring 10 Simultaneous Users
Compatibility Mac and PC
Connects With Local Cameras
Monitor Connections HDMI, VGA, BNC
COMMUNICATION PORTS
Network RJ45 10/100 Mbps
USB 2 USB 2.0
eSATA None
COMPATIBILITY
Software Support QT View
Mobile Support iPhone, iPad, Android
Computer Support WinXP, Vista, Win7/8,
Mac OS 10.7/10.8/10.9/10.10
VIDEO, AUDIO & ALARM PORTS
Video in 16 BNC
Video Out HDMI, VGA, BNC
Alarm In None
Alarm Out None
Audio In 1 RCA
Audio Out 1 RCA
ACCESSORIES
Control USB Mouse, Remote Control
Connectors / Cables HDMI Cable, BNC/RCA
Adapter, Ethernet Cable
Mounting Hardware Screws for Hard Drives
Other Quick Start Guide
DVR
Video Compression H.264
Live Display Resolution 1080p, 720p, 1280x1024, 1024x768, 720x480
Live Display FPS 30 FPS
Display Modes 1, 4, 8, 16 Auto Sequence
Languages English, Chinese (Simplified & Traditional),
Czech, French, Portuguese, Spanish, Turkish,
Bulgarian, Greek, Italian, German, Russian,
Polish, Japanese, Indonesian, Thai, Hungarian,
Lithuanian, Vietnamese, Dutch, Swedish,
Norwegian, Persian, Arabic, Romanian
RECORDING RESOLUTION OPTIONS
960H Resolution 960 x 480
D1 Resolution 704 x 408
CIF Resolution 352 x 240
RECORDING
Recording Modes Manual, Time Schedule, Motion Detection
Backup Methods PC, Flash, USB Hard Drive
Playback Speed 960H at 15 FPS per channel 240 FPS Total
D1 at 30 FPS per channel 480 FPS Total
CIF at 30 FPS per channel 480 FPS Total
Number Channels 16 Simultaneous
PLAYBACK ON DVR
(QT5816 cont’d…)
POWER
Power Supply 12v 2a
Power Consumption 10w (w/o HD)
PHYSICAL
Weight 3.3 lbs
Dimensions 11.75”W X 10.75”D X 2”H
Operating Temperature 50°– 104°F
HARD DRIVES
Maximum Size 3TB
Number Supported 1
PTZ
PTZ Support RS485
Supported Protocols Null, Pelco D, Pelco P, Lilin, Minking, Neon, Star, VIDO,
DSCP, VISCA, Samsung, RM110, HY
